Hisense 55WF45H (Discontinued) · Replacements in Qatar

Name: Hisense 55WF45H 55-inch Window-Facing High Brightness Display (Discontinued)
Brand: Hisense
SKU: hisense-55wf45h
Availability: Discontinued

Overview

The Hisense 55WF45H is a 55-inch display designed for indoor use facing a window, rated at 4500 nits to stay readable in bright ambient light. It runs Android 9.0 with 16GB storage, can be mounted in portrait or landscape, and includes a light sensor for automatic brightness. Hisense has discontinued this model, so buyers should request a quote for a current equivalent or compatible replacement for shopfronts in Qatar.

What the 55WF45H is built to do

The Hisense 55WF45H is a 55-inch display for indoor locations where the screen faces a window and must stay readable in daylight. Its 4500 nits rating is the headline figure, and it is the reason the model is specified for shopfronts and lobbies rather than ordinary meeting rooms. The active area measures 1209.6 x 680.4 mm in a 16:9 format with Full HD resolution of 1920 x 1080. Hisense has discontinued this model, so this page also serves organisations that already run one and need to plan spares or a replacement.

Brightness, viewing angles and display behaviour

The panel lists a 1000:1 static contrast ratio, with dynamic contrast of up to 450000:1. The 178° horizontal and vertical viewing angles let people walking past from the side read the content, and a 6ms response time is listed. A light sensor adjusts brightness to the surroundings, and the panel can be mounted in portrait or landscape to suit a tall menu board or a wide window. The backlight is rated for 50,000 hours.

Processing, storage and connections

Inside, the unit uses a quad-core ARM Cortex-A53 processor at 1.5 GHz with Arm Mali-G52 graphics, 2GB of DDR memory and 16GB of eMMC storage, running Android 9.0. Media can be stored on the display for playback without external hardware, and you can choose your own content management system. Connections include two HDMI inputs, one HDMI output, two USB 2.0 ports, two RJ45 Ethernet ports, an RS232 port, an IR input and a sensor input. Wi-Fi or wired LAN is supported, 3G/4G is optional, and a built-in speaker, line-out and Bluetooth speaker support cover the audio options.

Operating and power details to check

Operating range: -10°C to 35°C in direct sunlight, and -10°C to 45°C without direct sunlight
Humidity: 10% to 80% in operation and storage; storage temperature -10°C to +60°C
Power: built-in supply listed as AC 110/220 V, 50/60 Hz, 320 W maximum
Thermal management: smart temperature, fan and backlight control, overheating protection, optional CetusMSC cloud monitoring

Where it fits in Qatar

A clothing or electronics shop on a busy street in West Bay can place the panel behind the glass to run promotions that stay visible in afternoon light, with the unit positioned away from direct sun. A bank branch in Msheireb can use a landscape unit in the lobby to show queue information and service announcements to customers near the entrance. A serviced apartment reception in Lusail can run a portrait display for guest information, mounted indoors and away from outdoor heat.

What to plan before ordering

Check the wall and bracket first. The panel weighs 24.6 kg, the overall dimensions are 1232 x 702.8 x 56.75 mm, and the mounting pattern is VESA 400 x 400. The box includes two M6 lifting rings, filler pads and spring pads, so plan for two people and a bracket rated for the load. Confirm the mains supply, because the data lists a 110/220 V input and Qatar supplies 240 V. The front panel carries an IP5X rating for dust protection, which is not a water rating. Ask about spares and cables if you are adding to an existing fleet.

Ready to plan a window-facing installation? Request a quote from SmartRooms Qatar. We will confirm the closest current replacement, delivery to your municipality and installation options with your quotation, usually within one working day. Purchase orders and government tenders are welcome.

Highlights

4500 nits brightness for indoor window-facing use
178° viewing angle with portrait or landscape orientation
Android 9.0 with 2GB DDR and 16GB eMMC storage
Wi-Fi or LAN, two HDMI inputs and two Ethernet ports
Operates from -10°C to 35°C in direct sunlight
Discontinued by Hisense; request a quote for a replacement

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

49 specifications · Source: manufacturer · checked Oct 2026

General13

Model: 55WF45H
Screen size: 55"
Screen Active Area(mm): 1209.6 x 680.4
Resolution: FHD (1920x1080)
Aspect Ratio: 16:9
Brightness(nit): 4500nits
Contrast Ratio: 1000:1
Dynamic CR: Up to 450000:1
Viewing Angle(H/V): 178°/178°
Backlight Life Cycle: 50,000 Hrs
Operation Hours: 24/7
Response Time: 6ms
Screen Orientation: Portrait or Landscape

System6

OS: Android 9.0
CPU: ARM Quad Core Cortex-A53 1.5G
GPU: Arm Mali-G52 2EE MC1
DDR: DDR 2GB
ROM: 16GB EMMC
Language: Chinese/English

Connectivity2

Input: USB2.0 x2, HDMI IN x2, Ethernet RJ45 x2, RS232 RJ45 x1, IR in x1, Sensor x1
Output: HDMI Out x1, Audio out x1

Network connection1

Wifi or LAN: Yes 3G/4G connection: Optional

Speaker3

Build in speaker: Yes
Line-out Support: Yes
BT Speaker Support: Yes

Thermal management5

Smart Backlight Control: Yes
Smart Temperature Control: Yes
Smart Fans Control: Yes
Smart Monitoring System Cloud: Optional / CetusMSC
Overheating protection: Yes

Physical9

IP rating: IP5X (Front Panel)
Glass: No
Shell: Aluminum
Standard Color: Black
Bezel width(T/L/R/B): 10mm(T/B/L/R)
Dimensions (H x W x D): 1232 x 702.8 x 56.75mm
Net Weight: 24.6kg
Packing Dimensions(W × H × D): 1404 x 867 x 180mm
VESA: 400 x 400

Operation6

Working environment: Indoor window facing
Auto Brightness control: Light sensor
Operation Temperature (ambient temp.): -10oc to 35oc (Direct Sunlight) -10oc to 45oc (w/o Direct Sunlight)
Operation Humidity: 10% to 80%
Storage Temperature: -10oc to +60oc
Storage Humidity: 10% to 80%

Power3

Power Supply: AC 110 /220V,50/60Hz
Power Type: Built-In Power
Power Consumption: 320W (Max)

What’s in the box1

Accessories: Power cord \ IR receiver \ Remote Control \ AAA batteries x2 \ Wifi antenna \ Lifting ring(M6) x2\ Filler pad(M6) x2 \ Spring pad(M6) x2 \ User manual（Electronic version）

Downloads

5 files from the manufacturer

PDF Datasheets 55WF45H_Datasheet_V2.pdf 3.1 MB PDF Manuals & guides HCD_IP_Control_Guide_v1.1.pdf 1.2 MB PDF Manuals & guides HCD_RS232_Control_Guide_v2.0.pdf 6.8 MB PDF Manuals & guides HCD_WF_UserManual_v2.0.pdf 1.7 MB PDF Manuals & guides Quick Installation Guide-Ver2.2_49_55inch.pdf 4.0 MB

Questions about 55WF45H

Is the Hisense 55WF45H still sold as a new model?

Hisense has discontinued the 55WF45H and lists it under end-of-life products, so it is no longer a current model. Request a quote from SmartRooms Qatar and we will confirm the closest current equivalent or compatible replacement for your shopfront or lobby, with its specifications set out in the quotation, usually within one working day.

Why does the 4500 nits rating matter for a window display?

Brightness is the main reason this model exists. The panel is rated at 4500 nits, which helps content stay readable when daylight falls on the glass. Standard indoor screens are not built for that level of ambient light, so a screen placed in front of a window usually needs a rating like this. Check the sun exposure of your wall before choosing a model.

Can the panel be mounted in portrait as well as landscape?

Yes. The screen supports both portrait and landscape orientation. Portrait suits a narrow shopfront or a vertical menu board, while landscape suits a wide window or lobby wall. Decide the orientation before ordering, because the mounting position and cable routing depend on it, and the team can confirm the layout during a free site survey.

Will it work in a shop in West Bay where the window gets afternoon sun?

The source data lists the model for indoor window-facing use, with an operating range of -10°C to 35°C in direct sunlight and -10°C to 45°C without direct sunlight. Plan the position so the unit is not in direct sun, and check ventilation on site. SmartRooms Qatar can run a free site survey before the quotation is finalised.

Can I install it in an open courtyard or outside a mall in Doha during summer?

No. The working environment is listed as indoor window facing, so this model is not designed for an open courtyard or an outdoor position exposed to dust storms and summer heat. For outdoor sites, ask the SmartRooms Qatar team about options suited to that location, and do not rely on the direct sunlight figure for an open-air installation.

A bank branch in Msheireb wants queue and service information near the entrance. Is this model suitable?

It can be, for a lobby where the screen faces a glass wall. A landscape unit rated at 4500 nits can show queue numbers and service announcements to customers near the door, and the 178° viewing angle lets people read it from the side. Ask the team to confirm that the glazing and sun exposure match a window-facing installation.

Which ports and connections does it have?

The unit provides two HDMI inputs, one HDMI output, two USB 2.0 ports, two RJ45 Ethernet ports, one RS232 RJ45 port, an IR input and a sensor input. An audio out is included, and connectivity is Wi-Fi or LAN, with 3G/4G optional. The box includes a Wi-Fi antenna and an IR receiver for the remote control.

Can a retail chain run content without a separate media player?

Yes. The unit has a quad-core processor, 2GB DDR memory and 16GB eMMC storage, so media can be uploaded to the display for playback without external hardware. It can run offline or cloud-based content 24 hours a day, 7 days a week, and you can choose your own content management system. Optional CetusMSC cloud monitoring is available for remote oversight.

Does the system support Arabic?

The data lists the system languages as Chinese and English. Arabic is not listed, so do not assume Arabic menus or Arabic-only content will run as planned. If your signage must be in Arabic, ask the SmartRooms Qatar team to confirm language support before the quotation is issued. The display runs Android 9.0 on a quad-core processor.

What power does it need in Qatar?

The built-in power supply is listed as AC 110/220 V, 50/60 Hz, with a maximum consumption of 320 W. Qatar mains run at 240 V, 50 Hz, so the supply arrangement must be confirmed before you order. Ask the team to confirm the power arrangement with your quotation, then plan sockets and cabling for a 320 W maximum draw per unit.

Can two staff mount the 24.6 kg panel on a lobby wall in Lusail?

Plan for two people. The panel weighs 24.6 kg and measures 1232 x 702.8 x 56.75 mm, so it needs a bracket rated for that load on a VESA 400 x 400 pattern. The box includes two M6 lifting rings, filler pads and spring pads. Ask the team to check the wall construction during the site survey before anything is fixed.

Our hotel already has this model. What should we plan for?

Record the model number and serial of each unit, keep spare mounting hardware and power cords, and check wall brackets against the VESA 400 x 400 pattern. Because Hisense has discontinued the 55WF45H, any replacement should match your mounting and connections. Request a quote and the SmartRooms Qatar team will advise on a current equivalent or compatible replacement for your hotel.
