55XE3P
LG 55XE3P 55-inch High-Brightness Outdoor IP56 Display
- Screen size
- 55"
- Resolution
- 1,920 x 1,080 (FHD)
- Brightness
- 3,500 nit (Typ), 2,800 nit(Min)
- Operation
- 24/7
The LG 55XE3P is a 55-inch outdoor display rated 3,500 nits typical brightness, with IP56 sealing against dust and water and IK10 tempered, laminated glass. It runs 24/7 across -30°C to 50°C, with built-in Wi-Fi, Bluetooth and webOS 6.1. It suits shopfronts, bus stops, building entrances and campus walkways in Doha and Lusail where sunlight washes out indoor screens.
What the 55XE3P is built for
The LG 55XE3P is a 55-inch full HD display made for outdoor signage, where sunlight, dust and temperature would defeat an indoor panel. Its 1,920 x 1,080 IPS panel is rated at 3,500 nits typical and 2,800 nits minimum, and the specification lists 24/7 operation, so it can run continuous content schedules outside shopfronts, plazas and entrances.
Protection for Qatar's dust, heat and impacts
The IP56 rating covers sealing against dust and strong water jets, which matters during dust storms in Doha. The front is 5 mm tempered, laminated protection glass rated IK10 for impact resistance, and the circuit and power boards carry a conformal coating against dust, iron powder and humidity. The operating range is -30°C to 50°C, but the data narrows it to -30°C to 40°C when direct sunlight reaches the screen, so a south or west facing position in Doha needs a site check before installation.
Brightness, viewing angle and power use
The IPS panel gives a stated viewing angle of 178 degrees horizontally and vertically, so people approaching from the side still read the content. Automatic brightness raises output in daylight and lowers it at night. Four preset modes, Manual, Highlight, Basic and Nearby, each set a different brightness ceiling and floor, letting a facilities team limit power use where the screen does not need full output. The panel is rated for 50,000 hours typical lifetime, with 380 W typical and 430 W maximum power draw.
Connectivity and content management
- Two HDMI inputs with HDCP 2.2 and one DisplayPort input
- Two RJ45 inputs, one LAN and one HDBaseT, plus LAN and RS232C outputs
- Two USB 2.0 Type A ports and 16GB of internal memory
- Built-in Wi-Fi, Bluetooth and a beacon for location-based content
- Web monitoring through LG Control Manager over wired LAN, plus compatibility with SuperSign CMS, SuperSign Control+, SuperSign Cloud and Connected Care
Where it fits in Qatar
A shopping mall in West Bay could use the 55XE3P in a street-facing window to show promotions in daylight and after dark. A serviced apartment building in The Pearl could place it at a drop-off canopy or pool-side wayfinding point, where guests need directions without a staffed desk. An industrial site near Mesaieed could mount it at a yard gate to display safety notices, with the vandalism alert notifying the administrator if the unit is struck or knocked off its installation angle.
What to plan before ordering
- Check sun exposure at the chosen wall and the expected ambient temperature
- Confirm the head weight with the team, as the data does not yet list it
- Allow for a 1292.5 x 737.4 x 88.0 mm unit; the carton measures 1446 x 890 x 207 mm
- The power input accepts 100-240 V at 50/60 Hz, which covers Qatar's 240 V supply; confirm the plug arrangement when quoting
- Plan LAN cabling if you will use LG Control Manager, since it requires a wired connection
Request a quote
Request a quote from SmartRooms Qatar for the LG 55XE3P. We offer a free site survey before wall mounting, professional installation, delivery to all eight municipalities of Qatar, and quotations usually within one working day. We accept purchase orders and government tenders, and the product is covered by the manufacturer's warranty.
Highlights
- 3,500 nits typical brightness, 2,800 nits minimum
- IP56 dust and water sealing with IK10 protective glass
- Operates -30°C to 50°C; -30°C to 40°C with direct sunlight
- Built-in Wi-Fi, Bluetooth, beacon and 16GB storage
- Vandalism alert for impacts or angle changes
- Input 100-240 V, 50/60 Hz; 380 W typical power draw
Estimated timeline
Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.
Specifications
INFO3
- Product
- Outdoor
- Year
- Y24
- Month
- M10
PANEL19
- Screen Size (Inch)
- 55"
- Panel Technology
- IPS, M+
- Back Light Type
- Direct
- Aspect Ratio
- 16:9
- Native Resolution
- 1,920 x 1,080 (FHD)
- Refresh Rate
- 60Hz
- Brightness
- 3,500 nit (Typ), 2,800 nit(Min)
- Contrast Ratio
- 1,000:1
- Dynamic CR
- 500,000:1
- Color Gamut
- 72%
- Viewing Angle (H x V)
- 178 x 178
- Color Depth (Number of Colors)
- 8bit, 16.7Million colors
- Response Time
- Typ. 9ms (G to G BW)
- Surface Treatment (Haze)
- 3%
- Life time
- 50,000Hrs(Typ)
- Operation Hours (Hours/Day)
- 24/7
- Portait / Landscape
- O / O
- Transparency
- N/A
- QWP (Quarter Wave Plate)
- O
Connectivity (Jack Interface)8
- HDMI IN
- O(2), HDCP2.2
- DP IN
- O(1), HDCP2.2
- RS232C IN
- O(1) (4pin phone jack)
- RJ45(LAN) IN
- O(2) (Lan (1), HDbaseT(1))
- USB IN
- USB2.0 Type A(2)
- External Speaker Out
- O(1, L/R, 10W+10W)
- RS232C Out
- O(1)
- RJ45(LAN) Out
- O(1)
MECHANICAL6
- Bezel Color
- Black
- Bezel Width
- 38.4/26/26/38.4mm
- Weight (Head)
- TBD
- Packed Weight
- TBD
- Monitor Dimensions (W x H x D)
- 1292.5 x 737.4 x 88.0mm
- Carton Dimensions (W x H x D)
- 1446 x 890 x 207mm
PROTECTION GLASS6
- Thickness
- 5mm
- Degree of Protection
- O (IK10)
- Tempered / Chemical strengthening
- Tempered
- Anti-Reflective
- O
- Infrared - Resistance (IR)
- O
- Shatter-Proof
- O
HW FEATURE12
- Internal Memory (eMMC)
- 16GB
- Wi-Fi/BT (Built-in)
- O
- Temperature Sensor
- O
- IR Temperature Sensor
- O
- Auto Brightness sensor
- O
- Pixel sensor
- O
- Current Sensor
- O
- BLU Sensor
- O
- Humidity Sensor
- O
- Acceleration(Gyro) Sensor
- O
- Power Indicator
- O
- FAN (Built-in)
- O
SW FEATURE33
- OS Ver. (webOS)
- webOS6.1
- Local Contents Scheduling
- O
- Group Manager
- O
- USB Plug & Play
- O
- Fail over
- O
- Booting Logo Image
- O
- No Signal Image
- O
- RS232C Sync
- O
- Local Network Sync
- O
- Backlight Sync
- O
- PIP
- O
- PBP
- O(2)
- Video Tag
- O(4)
- Play via URL
- O
- Screen Rotation
- O
- External Input Rotation
- O
- Gapless Playback
- O
- Tile Mode Setting
- O (Max. 15x15)
- Setting Data Cloning
- O
- SNMP
- O
- ISM Method
- O
- Auto Set ID
- O
- Status Mailing
- O
- Control Manager
- O
- Smart Energy Saving
- O
- PM mode
- O
- Wake on LAN
- O (LAN in / HDbaseT port)
- Network Ready
- O
- Beacon
- O
- HDMI-CEC
- O
- SI Server Setting
- O
- webRTC
- O
- Pro:Idiom
- O
ENVIRONMENT CONDITIONS2
- Operation Temperature
- -30°C to 50°C
- Operation Humidity
- 5% to 100%
POWER2
- Power Supply
- AC 100-240V~, 50/60Hz
- Power Type
- Built-In Power
POWER CONSUMPTION6
- Typ.
- 380W
- Max.
- 430W
- BTU (British Thermal Unit)
- 1126 BTU/Hr(Typ.), 1365 BTU/Hr(Max)
- Smart Enegy Saving (70%)
- 180W
- DPM
- 0.5W↓
- Power off
- 0.5 W↓
CERTIFICATION3
- Safety
- CB / NRTL
- EMC
- FCC Class "A" / CE / KC / VCCI
- ErP / Energy Star
- O / X
SOFTWARE COMPATIBILITY4
- SuperSign CMS
- O
- SuperSign Control+
- O
- SuperSign Cloud
- O
- Connected Care
- O
Language1
- OSD
- English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Turkish, polski (Polska), Arab
ACCESSORY1
- Basic
- Remote Controller, Manual(EIG, IG), Regulation Book, Phone to RS232C Gender, HDMI Cable , POWER CABLE, Battery, Screws
SPECIAL FEATURE3
- IP Rating
- IP56
- Conformal Coating (Power Board)
- O
- Direct Sunlight
- O
PRODUCT DEDICATED FEATURE2
- Heat dissipation
- Heat exchange
- Noise level
- 62dB
