LG 75XF3P 75-inch High-Brightness Open-Frame Display

Overview

The LG 75XF3P is a 75-inch open-frame display for digital signage that stays readable in strong daylight, with 3,000 nits typical brightness and a 3840x2160 panel. It runs webOS 6.0, supports portrait and landscape use and can show content on both sides with the right bracket. It suits shopfronts, malls, banks and hotel entrances in Doha, Lusail and Al Rayyan where glare and heat make standard indoor screens unsuitable.

What the 75XF3P is built for

The LG 75XF3P is a 75-inch open-frame display for digital signage in places where ordinary indoor screens lose contrast, such as behind shop glass or on a street-facing wall. Its 3840x2160 IPS panel shows menus, product films and wayfinding at full UHD detail. As an open-frame model, it is built to sit inside a casing that your integrator designs around it, so ventilation and mounting are planned from the start.

Brightness and visibility in strong daylight

The panel is rated at 3,000 nits typical and 2,800 nits minimum, the figure that matters for a window in Doha's afternoon sun. A 1,200:1 typical contrast ratio, 10-bit colour and an anti-glare surface with 3% haze keep content legible despite reflections from glass. The data indicates content stays visible to people wearing polarised sunglasses, and the auto brightness sensor raises output in light and lowers it in darkness.

Panel: IPS with M+ technology, 60Hz, 8ms response
Viewing angle: 178 degrees horizontal and vertical
Colour gamut: NTSC 72%

Heat, dust and power planning for Qatar

Summer heat and dust storms decide whether a window-facing screen lasts. The 75XF3P is rated for 0°C to 40°C with direct sunlight and 0°C to 50°C without it, at 10% to 80% humidity. A unit on a west-facing frontage in West Bay therefore needs shade, a ventilated casing or both, and LG's installation guide for custom casings covers ventilation size and partition placement. Conformal coating protects the circuit and power boards against dust and humidity, and the built-in power supply accepts 100 to 240 V at 50/60 Hz, which covers Qatar's 240 V mains. Typical draw is 745 W and maximum 775 W, so size the circuit for the maximum.

Where it fits in Qatar

A fashion retailer in Lusail running new-season campaigns behind the shopfront, readable from the walkway in daylight.
A serviced apartment entrance in The Pearl showing building information from a street-facing lobby window, where the double-sided design serves visitors approaching from both sides.
A bank branch in Al Sadd showing rate boards and service notices through glass, updated remotely over the LAN.

Control, connections and software

Inputs include two HDMI ports with HDCP 2.2, one DisplayPort input, DVI-D, RJ45 LAN and USB 2.0 Type A, with RS-232C in and out for control. webOS 6.0 plays content on a quad-core SoC without a separate media player, backed by 8GB of internal storage. LG Control Manager allows remote status checks and adjustments in real time from a phone or PC when the unit is on a wired LAN. Listed compatible software includes SuperSign CMS, SuperSign Control+ and Connected Care; LG software is sold separately, so include it in the quotation.

Planning the installation

The head weighs 32.7 kg and the packed weight is 43 kg, with dimensions of 1675.2 x 953.6 x 114.6 mm and an 11.8 mm bezel. Plan for two people to lift it and confirm the wall, frame or glass structure can carry the load. The optional WM-B640S double-sided bracket supports landscape and portrait mounting. A free site survey from SmartRooms Qatar lets the team check the opening, power route and ventilation before the casing is fixed.

To request a quote for the LG 75XF3P, send the SmartRooms Qatar team your unit count, site locations and bracket needs. Quotations are usually issued within one working day, and we accept purchase orders (LPOs) and government tenders via Monaqasat. Products are covered by the manufacturer's warranty.

Highlights

3,000 nits typical brightness, 2,800 nits minimum
3840x2160 IPS panel with M+ technology
Operating range 0°C to 40°C with direct sunlight
Double-sided design with portrait or landscape orientation
webOS 6.0 playback with LAN-based remote monitoring
Built-in power supply, 100-240 V, 50/60 Hz

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

97 specifications · Source: manufacturer · checked Oct 2026

Info3

Product: Outdoor
Year: Y24
Month: M02

Panel18

Screen Size (Inch): 75"
Panel Technology: IPS, M+
Back Light Type: Direct
Aspect Ratio: 16:9
Native Resolution: 3840x2160 (UHD)
Refresh Rate: 60Hz
Brightness: Min: 2800cd/m2, Typ: 3000cd/m2
Contrast Ratio: 1200:1 (Typ)
Dynamic CR: 500,000:1
Color gamut: NTSC 72%
Viewing Angle (H x V): 178 x 178
Color Depth (Number of Colors): 10bit ( Dethering), 1.07 billion colors
Response Time: 8ms (G to G BW) typ.
Surface Treatment (Haze): AGLR(Haze 3%), QWP
Life time: 50,000 Hrs
Operation Hours (Hours/Day): 24Hrs
Portait / Landscape: Yes / Yes
QWP (Quarter Wave Plate): Yes

Connectivity(Jack Interface)11

HDMI IN: Yes(2), HDMI1/2 : HDCP 2.2
DP IN: Yes(1), HDCP1.3
DVI-D IN: Yes(1)
Audio IN: Yes(1)
RS232C IN: Yes(1) (4pin phone jack)
RJ45(LAN) IN: Yes(1)
IR IN: Yes(1)
USB IN: USB2.0 Type A (1)
DP Out: Yes(1)
External Speaker Out: Yes(1) (4pin phone jack)
RS232C Out: Yes(1)

Mechanical7

Bezel Color: Black
Bezel Width: 11.8 mm Even
Weight (Head): 32.7kg
Packed Weight: 43kg
Monitor Dimensions (W x H x D): 1675.2 x 953.6 x 114.6
Carton Dimensions (W x H x D): 1816 x 1106 x 285
Handle: Yes(2)

HW Feature5

Internal Memory (eMMC): 8GB
Temperature Sensor: Yes(2)
Auto Brightness sensor: Yes
Pixel sensor: TBD
Humidity Sensor: Yes

SW Feature32

OS Ver. (webOS): webOS6.0
Local Contents Scheduling: Yes
Group Manager: Yes
USB Plug & Play: Yes
Fail over: Yes
Booting Logo Image: Yes
No Signal Image: Yes
RS232C Sync: Yes
Local Network Sync: Yes
Backlight Sync: Yes
PIP: Yes
PBP: Yes
Video Tag: Yes(4)
Play via URL: Yes
Screen Rotation: Yes
External Input Rotation: Yes
Gapless Playback: Yes
Tile Mode Setting: Yes
Setting Data Cloning: Yes
SNMP: Yes
ISM Method: Yes
Auto Set ID: Yes
Status Mailing: Yes
Control Manager: Yes
Smart Energy Saving: Yes
PM mode: Yes
Wake on LAN: Yes
Network Ready: Yes
HDMI-CEC: Yes
SI Server Setting: Yes
webRTC: Yes
Pro:Idiom: Yes

Environment Conditions2

Operation Temperature: 0 °C to 40 °C (with Solar) 0 °C to 50 °C (without Solar)
Operation Humidity: 10 % to 80 %

Power2

Power Supply: AC 100-240V~, 50/60Hz
Power Type: Built-In Power

Power Consumption6

Typ.: 745W
Max.: 775W
BTU (British Thermal Unit): 2644
Smart Enegy Saving (70%): 280W
DPM: 0.5W(DP, HDMI)
Power off: 0.5W

Certification3

Safety: CB / NRTL
EMC: FCC Class "A" / CE / KC / VCCI
ErP / Energy Star: Yes / No

Software Compatibility3

SuperSign CMS: Yes
SuperSign Control+: Yes
Connected Care: Yes

Language1

OSD: English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portuguese(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese(Europe), Dutch, Czech, Greek, Arabic, Turkish, Polish

Accessory2

Basic: Remote Controller(including battery 2ea), Power Cord, HDMI Cable,Manual (EIG, IG) RS-232C Gender
Optional: Double sided Bracket (Landscape&Portrait : WM-B640S)

Special Feature2

Conformal Coating (Power Board): Yes
Direct Sunlight: Yes

Downloads

7 files from the manufacturer

PDF Datasheets 75XF3P_Datasheet(low)_LG High-brightness Open-frame Display_240806_20240806_112327_.pdf 2.6 MB PDF Manuals & guides MFL72100101_02_Q_250617.pdf 1.1 MB PDF Manuals & guides OM_ARA.pdf 1.9 MB PDF Manuals & guides OM_ENG.pdf 2.3 MB URL Manuals & guides · Opens on manufacturer site User Guide PDF Manuals & guides · Opens on manufacturer site WebOS 6.0. 6.1_ENG.pdf 4.9 MB URL Software & firmware · Opens on manufacturer site Software & Drivers (support page)

Questions about 75XF3P

Which buyers is the LG 75XF3P built for?

The 75XF3P suits organisations that need a large screen where glare and heat rule out a standard indoor display, such as a shopfront in Lusail or a hotel forecourt on a busy road. It is a digital signage display rather than a meeting screen, so choose it when content must be read from outside or from a walkway.

How bright is it for a window facing afternoon sun in Doha?

The panel is rated at 3,000 nits typical and 2,800 nits minimum, with an anti-glare surface of 3% haze. The data indicates content stays visible to people wearing polarised sunglasses. Because glare depends on the direction a frontage faces, ask SmartRooms Qatar to review orientation during the site survey and request the LG datasheet to confirm test conditions.

What temperature range can it handle near a window?

The source rates operation at 0°C to 40°C with direct sunlight and 0°C to 50°C without direct sunlight, at 10% to 80% humidity. For a west-facing window in West Bay, that means planning shade or a ventilated casing. LG's installation guide for custom casings covers ventilation size and partition placement, so have the casing designed against it before the screen goes in.

Will dust storms damage the electronics?

Conformal coating protects the circuit board and power board against dust, iron powder and humidity, according to the manufacturer. That helps during Qatar's dust season, but the data does not give an ingress protection rating for the screen, so the enclosure must be designed to keep fine dust out of the air path. Confirm the enclosure specification with SmartRooms Qatar before ordering.

Can one unit show content to both sides of a corridor?

Yes, the 75XF3P is designed for double-sided display, which suits a mall corridor, lobby divider or serviced apartment entrance where people approach from both directions. The optional WM-B640S double-sided bracket supports landscape and portrait mounting. Confirm the bracket and mounting method with your integrator during the site survey, since the bracket is an optional accessory.

Can it be mounted in portrait?

Yes. The specification lists portrait and landscape operation, so the same panel can run a vertical menu board or a horizontal banner. Portrait use needs a bracket and casing that hold the screen in that orientation, so confirm the mounting method with your integrator before ordering. A pharmacy front in Al Rayyan, for example, could use portrait for queue messages.

How heavy is it and what does installation involve?

The head weighs 32.7 kg, and the packed weight is 43 kg. Dimensions are 1675.2 x 953.6 x 114.6 mm, with two handles. Plan for at least two people to lift and mount it, and confirm that the wall, frame or glass structure can carry the load. SmartRooms Qatar offers professional installation and free site surveys, which we recommend before fixing a unit of this size.

Does it work with Qatar's 240 V power supply?

Yes. The built-in power supply accepts 100 to 240 V at 50/60 Hz, which covers Qatar's 240 V, 50 Hz mains. Typical consumption is 745 W and maximum is 775 W, and the smart energy saving figure is 280 W. Check that the supplied power cord fits the BS 1363 socket planned for the unit, and size the circuit for the maximum draw.

What connections are available?

Inputs include two HDMI ports with HDCP 2.2, one DisplayPort input with HDCP 1.3, one DVI-D input, audio in, an RJ45 LAN port, USB 2.0 Type A and IR. RS-232C in and out supports control. There is also a DisplayPort output and an external speaker output. Check the HDCP level your source device needs for protected content.

How do I manage several screens remotely?

The embedded LG Control Manager is a web monitoring program. With a wired LAN connection, staff can check status, make adjustments and control the unit from a phone or PC, viewing both current and past data. Group Manager and Status Mailing features also help manage multiple displays. Pair the screen with SuperSign CMS, SuperSign Control+ or Connected Care, which are sold separately.

Which certifications are listed?

The listed certifications are CB/NRTL for safety, and FCC Class A, CE, KC and VCCI for EMC. ErP is listed as yes and Energy Star as no. For a government tender on Monaqasat, include these certificate lines in the technical compliance section and ask SmartRooms Qatar to confirm the documents needed for your evaluation.

How do I request a quote for several units?

Send SmartRooms Qatar the unit count, each site location and whether you need the WM-B640S bracket. Quotations are usually issued within one working day. We accept purchase orders (LPOs) and government tenders via Monaqasat, and payment is by bank transfer, cheque or purchase order. Products are covered by the manufacturer's warranty.
