LG 86UH7Q-E 86-inch 4K UHD Digital Signage Display

Overview

The LG 86UH7Q-E is an 86-inch 4K UHD digital signage display with 3840 x 2160 resolution, 700 nit typical brightness and built-in webOS 8.0, so content can run without a separate media player. It runs 24/7, supports portrait or landscape mounting and has IP5X dust protection. It suits lobbies, retail floors and corporate reception areas in Doha and Lusail that need a bright, always-on screen.

What the LG 86UH7Q-E is designed to do

The LG 86UH7Q-E is an 86-inch commercial display built to show advertising, wayfinding, menus and information loops for long operating hours. Its 3840 x 2160 UHD panel uses an edge-lit backlight, a 16:9 aspect ratio and a 60Hz refresh rate. It can run in landscape or portrait orientation, and its typical brightness is 700 nit with a typical contrast ratio of 1,200:1 and 95% BT709 colour gamut coverage.

Specifications that matter in lobbies and shops

Brightness is the first figure to check for a space with daylight or strong store lighting. The 700 nit value is a typical figure, so test glare at the actual position before fixing the panel. The 178 degree horizontal and vertical viewing angle lets people walking past a corridor read the content from the side, and the 8ms grey-to-grey response time suits video that changes often. The panel is rated for 24/7 operation with a minimum lifetime of 50,000 hours.

Playback and network control built into the screen

webOS 8.0 runs on the display itself, so content can be stored in 16GB of internal memory and played from USB or a URL without a separate media player. Operations teams get scheduling, group management, failover, Wake on LAN, SNMP, HDMI-CEC and screen sharing, along with four-way picture-by-picture. The unit is listed for SuperSign CMS, SuperSign Control+, SuperSign Cloud and Mobile CMS, and it carries Crestron Connected and Cisco certification.

Where it fits in Qatar

A bank branch in Msheireb running a looped service guide in its lobby, with schedules pushed from head office.
A medical centre in Al Sadd using a portrait-mounted screen for directions in an air-conditioned waiting area.
A shopping mall near The Pearl showing promotions at a store entrance, with content refreshed over the network.

Planning the mount and the environment

The head weighs 53.0 kg and the packed unit weighs 66.7 kg, with a VESA pattern of 600 x 400 mm and a 13.4 mm bezel. Check the wall or stand before ordering, and consider the optional LSW640A/B normal wall mount that is listed for this model. The operating range is 0 to 40 degrees Celsius at 10 to 80 percent humidity. Outdoor temperatures in Qatar's summer can pass 45 degrees, so plan an air-conditioned location away from direct sun. Mains input is rated 100 to 240 V at 50/60 Hz, with typical consumption of 210 W and a maximum of 297 W.

To request a quote for the LG 86UH7Q-E, send the SmartRooms Qatar team your quantity, the intended location and the mounting method. Quotations are usually issued within one working day, and a free site survey can confirm the wall, power and ventilation before the order is placed.

Highlights

86-inch panel with 3840 x 2160 UHD resolution
700 nit typical brightness for well lit interiors
Built-in webOS 8.0 with 16GB internal memory
Rated for 24/7 operation in portrait or landscape
Three HDMI inputs, DisplayPort, LAN and RS232C control
IP5X dust protection and 0 to 40 degree C operating range

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

124 specifications · Source: manufacturer · checked Oct 2026

PANEL18

Screen Size (Inch): 86
Panel Technology: ADS
Back Light Type: Edge
Aspect Ratio: 16:9
Native Resolution: 3840 x 2160 (UHD)
Refresh Rate: 60Hz
Brightness: 700nit(Typ.)
Contrast Ratio: 1,200:1 (Typ.)
Dynamic CR: 1,000,000:1
Color Gamut: BT709 95%
Viewing Angle (H x V): 178º x 178º
Color Depth (Number of Colors): 1.07 Billion colors
Response Time: 8ms (G to G)
Surface Treatment (Haze): 25% (Typ.)
Life time: 50,000Hrs (Min.)
Operation Hours (Hours/Day): 24/7
Portait / Landscape: YES / YES
Transparency: NO

CONNECTIVITY19

HDMI In: YES (3ea)
HDMI In (HDCP Ver.): 2.2/1.4
DP In: YES (HDCP 2.2/1.4)
DVI-D In: NO
RGB In: NO
Audio In: NO
RS232C In: YES
RJ45(LAN) In: YES (1ea)
IR In: YES
USB In: USB2.0 Type A (2ea)
HDMI Out: NO
DP Out: NO
Audio Out: YES
Touch USB: NO
External Speaker Out: NO
RS232C Out: YES
RJ45(LAN) Out: NO
IR Out: NO
Daisy Chain: NO

MECHANICAL SPECIFICATION8

Bezel Color: Black
Bezel Width: 13.4mm(Even)
Weight (Head): 53.0Kg
Packed Weight: 66.7Kg
Monitor Dimensions (W x H x D): 1928.8 x 1099.8 x 29.7mm (without IR, Handle)
Carton Dimensions (W x H x D): 2100 x 1250 x 253mm
Handle: YES
VESA Standard Mount Interface: 600 x 400 mm

FEATURE - HARDWARE13

Internal Memory (eMMC): 16GB
Wi-Fi/BT (Built-in): YES
Temperature Sensor: YES
Auto Brightness Sensor: YES
Pixel Sensor: NO
Proximity Sensor: NO
Current Sensor: NO
BLU Sensor: NO
Humidity Sensor: NO
Acceleration(Gyro) Sensor: YES
Power Indicator: NO
Local Key Operation: YES
FAN (Built-in): NO

FEATURE - SOFTWARE39

OS Ver. (webOS): webOS 8.0
Local Contents Scheduling: YES
Group Manager: YES
USB Plug & Play: YES
Fail over: YES
Booting Logo Image: YES
No Signal Image: YES
RS232C Sync: YES
Local Network Sync: YES
Backlight Sync: NO
PIP: YES
PBP: YES (4PBP)
Screen Share: YES
Video Tag: YES (4 Video Tag)
Play via URL: YES
Screen Rotation: YES
External Input Rotation: YES
Gapless Playback: YES
Tile Mode Setting: YES
Setting Data Cloning: YES
SNMP: YES
ISM Method: YES
Auto Set ID: YES
Status Mailing: YES
Control Manager: YES
Cisco Certification: YES
Crestron Connected: YES
Smart Energy Saving: YES
PM mode: YES
Wake on LAN: YES
Network Ready: YES
Beacon: YES
HDMI-CEC: YES
SI Server Setting: YES
webRTC: YES
Pro:Idiom: YES
Brightness Compensation: NO
W/B Setting by Grey scale: NO
Scan Inversion: NO

ENVIRONMENT CONDITIONS2

Operation Temperature: 0 °C to 40 °C
Operation Humidity: 10 % to 80 %

POWER2

Power Supply: AC 100-240V~, 50/60Hz
Power Type: Built-in Power

POWER CONSUMPTION6

Typ.: 210W
Max.: 297W
BTU (British Thermal Unit): 717 BTU/Hr(Typ.), 1013 BTU/Hr(Max)
Smart Energy Saving (70%): 147W
DPM: 0.5W
Power off: 0.5W

SOUND1

Speaker (Built-in): YES (10W x 2)

CERTIFICATION4

Safety: CB / NRTL
EMC: FCC Class "B" / CE / KC
ERP / Energy Star: NA / O
ePEAT(US only): YES

SOFTWARE COMPATIBILITY7

SuperSign CMS: YES
SuperSign Control+: YES
SuperSign WB: YES
SuperSign Cloud: YES
Promota: NO
Mobile CMS: YES
Connected Care: YES

LANGUAGE1

OSD: English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portuguese(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese(Europe), Dutch, Czech, Greek, Turkish, Arabic, Polish

ACCESSORY2

Basic: Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(6ea), Cable holder
Optional: Normal Wall Mount (LSW640A/B)

SPECIAL FEATURE2

IP Rating: IP5X
Conformal Coating (Power Board): YES

Downloads

3 files from the manufacturer

PDF Manuals & guides MFL05824502_02_Q_260520.pdf 2.5 MB PDF Manuals & guides · Opens on manufacturer site 7586UH5Q_UH7Q_EN.pdf 461 KB PDF Manuals & guides · Opens on manufacturer site webOS 24(8.0)_UG_ENG.pdf 2.9 MB

Questions about 86UH7Q-E

Who is the LG 86UH7Q-E for?

It suits indoor digital signage that must stay bright and run for long hours, such as lobby information, retail promotions and corporate reception. A bank branch in Msheireb could loop a service guide in its entrance hall, with the 86-inch panel rated for 24/7 operation and 700 nit typical brightness.

Do I need a separate media player with this display?

No. webOS 8.0 runs on the display itself, with 16GB of internal eMMC memory, so playlists can be stored on the unit and played from USB or a URL. Scheduling and gapless playback are included, which removes an extra box from the back of the panel or the wall cabinet.

Can it be mounted in portrait orientation for directories or menus?

Yes. The panel supports both portrait and landscape operation, which suits vertical directories in a mall, menu boards in a hotel restaurant or wayfinding in a hospital corridor. Because the head weighs 53.0 kg, confirm that the wall or stand can take the load before the panel is ordered.

Will the screen be readable in a sunlit glass atrium in Lusail?

The typical brightness is 700 nit, which suits well lit interiors, but direct sun through a glass atrium can wash out any screen. Test the glare at the chosen position and use the 178 degree horizontal and vertical viewing angle to decide the height and angle. A free site survey from SmartRooms Qatar can check this before installation.

What is the operating temperature, and how does it apply to Qatar summers?

The source data rates operation from 0 to 40 degrees Celsius at 10 to 80 percent humidity. Outdoor temperatures in Qatar's summer can exceed 45 degrees, so install the display in an air-conditioned space away from direct sun and confirm the location with the SmartRooms Qatar team before ordering.

Is it rated for outdoor use or a dusty courtyard?

The listed protection is IP5X against dust, and the data gives no outdoor rating. The power board has conformal coating against dust, salt and humidity, but a courtyard exposed to sand and heat is not a suitable location for this model. Choose an indoor, air-conditioned position instead.

Which inputs and outputs does the LG 86UH7Q-E have?

It has three HDMI inputs with HDCP 2.2/1.4, one DisplayPort input, two USB 2.0 Type A ports, one RJ45 LAN input, RS232C in and out, an IR input and an audio output. It has no HDMI or DisplayPort output and no daisy-chain function, so each screen needs its own source feed.

Does it support Wi-Fi and wired networking?

Yes. Wi-Fi and Bluetooth are built in, and there is a single RJ45 LAN input for wired networking. For scheduled content across several screens in a school or office building, a wired connection is usually the more stable option, and Wake on LAN lets IT staff power the display on remotely.

Can it be controlled from a building or control system?

The data lists RS232C control, an IR input, SNMP, HDMI-CEC, Wake on LAN and Crestron Connected, along with Cisco certification. Confirm the exact command set and control method with your integrator before ordering, especially where several displays in a government building must share one control platform.

What mounting details should I plan for?

The VESA pattern is 600 x 400 mm, the monitor measures 1928.8 x 1099.8 x 29.7 mm without the IR and handle, and the bezel is 13.4 mm wide. An optional LSW640A/B normal wall mount is listed. Book a free site survey so the installer can check wall strength, cable routes and the position of the power point.

Would it suit a hospital waiting area in Al Sadd?

It suits a waiting area that needs clear directions or appointment information. The 86-inch panel, 700 nit typical brightness and 24/7 operation fit a busy space, provided the room stays within the 0 to 40 degree operating range. Central scheduling lets staff update instructions without visiting each screen.

How do I order, and which purchasing routes are supported?

Send SmartRooms Qatar the quantity, installation address and mounting plan, and a quotation is usually issued within one working day. Purchase orders (LPOs) and government tenders through Monaqasat are supported, and payment can be made by bank transfer, cheque or purchase order. Products are covered by the manufacturer's warranty.
