Newline Newline Signage Pro Media Player (NLSProMP)

Name: Newline Signage Pro Media Player NLSProMP for Digital Signage
Brand: Newline
SKU: newline-nsp-media-player
Availability: InStock

Overview

The Newline Signage Pro Media Player turns a non-Newline display, or an older Newline screen not running Android 11, into a Newline Signage Pro endpoint. It outputs 4K at 4096 x 2160 px over HDMI 2.0a, runs Android 11.0 on a quad-core RK3566 with 4GB DDR4 and 32GB flash, and connects by Ethernet or Wi-Fi 6. It suits offices, schools and malls in Qatar that want signage on screens they already own.

What this player does for an existing screen

The Newline Signage Pro Media Player is a compact Android 11 device that runs Newline Signage Pro on displays that cannot run it natively. The manufacturer positions it for non-Newline displays and for older Newline screens that are not running Android 11 or later. Connect it to any panel with an HDMI input, power it from its DC 5V/2A adaptor, and the screen joins your digital signage network without being replaced.

Specifications that shape the installation

Video: HDMI 2.0a output at 4K (4096 x 2160 px), rated for 4K at 60Hz.
Processing: RK3566 quad-core 64-bit Cortex-A55 processor, Mali-G52-2EE GPU and 4GB DDR4 memory.
Storage: 32GB flash, plus a high-speed USB 3.0 port and a USB 2.0 port for external media on FAT16, FAT32 or NTFS drives.
Networking: 10/100/1000 Ethernet over RJ-45, built-in 2.4GHz and 5GHz Wi-Fi 6 (802.11ax), and Bluetooth 5.0.
Audio: SPDIF is supported for digital audio output.

Where it fits in Qatar

A hotel lobby in West Bay with a large panel at reception can add a looping information feed covering arrival times, dining hours and airport transfer notices, without buying a new display. A private school in Al Wakrah fitting out several classrooms can place one player behind each room display, wire the Ethernet port to the school network and use Wi-Fi 6 where cabling is difficult. A clinic in Al Sadd can show queue and health-awareness content on a waiting-room screen, with the player housed in a ventilated cabinet away from windows.

What to plan before ordering

Confirm that each target display has a free HDMI input and a cable route to it; the box includes an HDMI cable. The player measures 19.5 x 14.5 x 5.6 cm and weighs 0.52 kg, so it has a small footprint for mounting behind a display. Choose a ventilated spot, since the source data does not list an operating temperature range, and ask the SmartRooms Qatar team to confirm the location, especially in direct sunlight or near dusty entrances. Check the included adaptor's input rating against Qatar's 240 V, 50 Hz supply before committing to a quantity. A free site survey can map cable runs and power points before installation.

For one player or a fleet across several sites, send your display list and room layout to SmartRooms Qatar and request a quote. Quotations usually arrive within one working day, and purchase orders and government tenders are supported.

Highlights

4K output at 4096 x 2160 px via HDMI 2.0a
Android 11.0 on RK3566 quad-core with 4GB DDR4
32GB flash storage plus USB 3.0 and USB 2.0 ports
10/100/1000 Ethernet plus built-in Wi-Fi 6 (802.11ax)
Bluetooth 5.0 and 2.4GHz wireless keyboard and mouse support
Pre-installed Newline Signage Pro, VLC, YouTube and File Manager

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

24 specifications · Source: manufacturer · checked Oct 2026

General9

Model Name: NLSProMP
OS: Android 11.0
USB Host: 1x High speed USB 3.0, 1x USB 2.0
HDD File System: FAT16/FAT32/NTFS
High Definition Video Output: 4K (4096 x 2160 px)
LAN: Ethernet:10/100/1000 standard RJ-45 / 2.4G/5G WIFI | Built in 2.4G /5G WIFI 6 (802.11ax)
Bluetooth: Bluetooth 5.0
Mouse/ Keyboard: Support 2.4GHz wireless mouse and keyboard via 2.4GHz USB dongle
SPDIF: Supported

Hardware Specifications5

Chipset: RK3566 Quad-Core 64bit Cortex-A55
GPU: Mali-G52-2EE
Flash: 32G
SDRAM: 4GB DDR4
RTC Clock: Supported

Power Supply Specifications2

Power Supply: DC 5V/2A
Power Indicator (LED): Power ON: Blue; Standby: Red

Software Specifications4

Pre-Installed Apps: Newline Signage Pro, VLC Player, YouTube, File Manager
Certification: CE, FCC, ROHS
Accessories: Power adaptor, HDMI cable, User manual, Bluetooth remote / Support mouse and keyboard via USB; Support 2.4GHz wireless mouse and
Options: keyboard via 2.4GHz USB dongle

Packaging4

Size (1 piece): 7.7 x 5.7 x 2.2 inches (19.5 x 14.5 x 5.6 cm)
Weight (1 piece): 1.2 lbs (0.52 kg)
Carton Size (20 pieces): 14.6 x 12.8 x 12.6 in (37 x 32.5 x 32 cm)
Carton Weight (20 pieces): 23.15 lbs (10.5 kg)

Downloads

1 file from the manufacturer

PDF Datasheets NSP-Media-Player.pdf 513 KB

Questions about Newline Signage Pro Media Player (NLSProMP)

Is this player suitable for a ministry reception in Msheireb?

Yes, if the reception already has a screen with an HDMI input and you want signage without replacing it. The NLSProMP runs Newline Signage Pro on non-Newline displays, outputs 4K at 4096 x 2160 px and runs Android 11.0. The small player sits behind the screen, which keeps the reception area tidy and suits a government setting that needs calm, managed content.

Can I connect it to a display from another brand?

Yes. The manufacturer positions it for non-Newline displays as well as older Newline screens not running Android 11 or later. The link to the screen is HDMI: an HDMI cable is included and the output is HDMI 2.0a. Check that each panel has a free HDMI input and that you can select it as the source before ordering several units.

What is the maximum video output?

The player outputs 4K at 4096 x 2160 px, and its HDMI 2.0a port is rated for 4K at 60Hz. That gives sharp text and images on large panels in lobbies, boardrooms and lecture halls. Picture quality still depends on the display you connect, so confirm that the screen accepts a 4K signal at the refresh rate you plan to use.

We are fitting out a head office in Lusail with patchy cabling. Ethernet or Wi-Fi?

Use the 10/100/1000 Ethernet RJ-45 port wherever a network point is available, because a wired link is the most predictable path for scheduled content. Where cabling is hard to run, the built-in 2.4GHz and 5GHz Wi-Fi 6 (802.11ax) connection is the alternative. Bluetooth 5.0 is also built in. Ask the team to review the network layout during the free site survey.

What software and controls come with it?

Newline Signage Pro, VLC Player, YouTube and File Manager are pre-installed on Android 11.0. The accessories list a Bluetooth remote and an HDMI cable, and the device supports a 2.4GHz wireless mouse and keyboard through a 2.4GHz USB dongle, as well as mouse and keyboard connected via USB. Confirm which accessories are in your order before planning the control setup.

Can it run a safety or wayfinding display at an industrial site in Mesaieed or Ras Laffan?

The player can drive a display in an industrial setting, but the source data does not list an operating temperature range or an ingress protection rating. Treat the location as unconfirmed. Before committing to a quantity, discuss heat and dust exposure with SmartRooms Qatar and whether the unit should sit in a protected cabinet with airflow, since Qatar summer temperatures can exceed 45°C.

What power does it need and what is included?

It runs on DC 5V/2A, and the power adaptor is in the box. The LED shows blue when powered on and red in standby. The data does not state the adaptor's input range, so confirm it works with Qatar's 240 V, 50 Hz mains supply before ordering a batch. Position the adaptor socket near the display and plan a tidy cable route.

How much storage does it have and which USB drives work?

The unit has 32GB of flash storage, a high-speed USB 3.0 port and a USB 2.0 port. The USB host supports drives formatted as FAT16, FAT32 or NTFS. For playlists that must run without network access, store the media locally and keep total file sizes within the internal 32GB plus any USB drive capacity you add.

What would a hotel lobby in West Bay show on this player?

A reception panel can loop arrival times, dining hours, airport transfer notices and local events. The 4K output suits a large screen, and the 4GB DDR4 memory with the quad-core RK3566 processor forms the computing base of the unit. Confirm the panel has an HDMI input and that the installer can route the cable behind the reception desk.

A school in Al Wakrah is fitting out classrooms. Do we need one player per room?

Usually yes, one player per classroom display is the standard approach, because each unit has its own HDMI output and Ethernet port. Keep the room count on the order and check that every display has an HDMI input. A private school ordering several units would normally issue one purchase order (LPO) for the set and book a free site survey to map cable runs before delivery.

Can a clinic in Al Sadd place it near a window or a hot entrance?

Avoid direct sunlight and dust from the entrance. Summer temperatures in Doha can pass 45°C, and the product data does not give an operating temperature range for the NLSProMP. Mount the player in a shaded, ventilated spot and ask the SmartRooms Qatar team to confirm the installation environment before work starts, so the setup suits the waiting area.

How do I buy several units for a government project?

Send the number of units, the display models and the site location, and request a quote. Quotations usually come within one working day. SmartRooms Qatar supplies against purchase orders and government tenders, including Monaqasat, and accepts payment by bank transfer, cheque or purchase order. Delivery covers all 8 municipalities of Qatar, and the product is covered by the manufacturer's warranty.
