LG 55UH5F-H · Price in Qatar

Overview

The LG 55UH5F-H is a 55-inch UHD IPS signage display built for information points, meeting rooms and reception areas. Its 3840 x 2160 panel carries a 28% haze surface that limits reflections in bright rooms, and built-in 10W speakers, webOS 4.1 and Crestron and Cisco compatibility simplify deployment. It suits offices, schools and hotels in Doha and beyond.

A 55-inch UHD display for busy, bright spaces

The LG 55UH5F-H is a 55-inch standard signage display with a 3840 x 2160 IPS panel, designed for lobbies, corridors, meeting rooms and reception areas where content must stay readable through glare. The specification lists 24/7 operation, and the panel can be mounted in landscape or portrait orientation, which suits directory boards and vertical menus alike.

Picture and surface facts that matter in Qatar

Glass-fronted buildings and daylight-filled atriums across Doha create reflections that wash out text on ordinary screens. This model uses a 28% haze surface treatment to soften those reflections, and its 500 nit typical brightness and 1,100:1 contrast ratio keep everyday signage clear. The 1.07 billion colour depth and BT709 95% colour gamut show corporate branding and imagery accurately.

Panel: 55-inch IPS, 16:9 aspect ratio, 60Hz refresh rate
Viewing angle: 178 degrees horizontal and vertical
Speakers: built-in, 10W x 2

Connectivity and control for content and meeting rooms

The display offers three HDMI inputs with HDCP 2.2 and 1.4 support, a DisplayPort input and output, a DVI-D input, audio in and out, and one RJ45 LAN input. Control is covered by RS232C in and out, IR in, and a single USB 2.0 Type A port. Built-in Wi-Fi and Bluetooth, webOS 4.1 with 8GB internal memory, and support for SuperSign CMS, Mobile CMS and Connected Care let facilities teams manage content centrally. Crestron Connected and Cisco certification help when the screen joins a scheduled AV control system or a video conference. OPS compatibility is piggyback type, with the OPS Kit (KT-OPSF) sold as an optional accessory, and OPS power is not built in.

Planning the mount, power and environment

The head weighs 19.0 kg, or 19.6 kg with the optional ST-653T stand, and the VESA mount interface is 300 x 300 mm, so the wall bracket must be rated for the load. The bezel measures 9.9 mm on the sides and 14.4 mm at the bottom, and the tilt can reach 30 degrees for mounting above eye level. The power supply accepts AC 100-240V at 50/60Hz, drawing 105W typical and 145W maximum. The rated operating temperature is 0 °C to 40 °C with 10% to 80% humidity. Qatar summers can exceed 45 °C, so keep the display in an air-conditioned space and confirm conditions with the SmartRooms Qatar team before placing it near windows, loading bays or enclosed kiosks. The IP5X rating covers dust protection and is not a weather rating.

Where it fits in Qatar

A reception area in a West Bay office tower can show visitor and wayfinding content, with landscape orientation on the main wall and portrait mode for a corridor directory. A school in Al Wakrah fitting out new corridors can publish timetables and announcements in Arabic and English from a central content system, since the on-screen menu supports Arabic. A clinic waiting area in Al Sadd can display queue and health information at a comfortable viewing distance. In a Lusail boardroom linking Doha with teams abroad, the Cisco and Crestron compatibility reduces the time spent adjusting picture settings and changing inputs on incoming calls.

Before you request a quote, share your wall type, typical viewing distance and daily operating hours with the SmartRooms Qatar team. We offer free site surveys, and quotations are usually provided within one working day. Request a quote for the LG 55UH5F-H and we will confirm the stand, mount and installation options for your site.

Highlights

55-inch 3840 x 2160 IPS panel with 16:9 aspect ratio
28% haze surface reduces reflections in bright rooms
Built-in 10W x 2 speakers and webOS 4.1 platform
Cisco certified and Crestron Connected for meeting rooms
IP5X dust protection and 0 °C to 40 °C operating range
VESA 300 x 300 mm mount with tilt up to 30 degrees

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

135 specifications · Source: manufacturer · checked Oct 2026

SOUND1

Speaker (Built-in): YES (10W x 2)

LANGUAGE1

OSD: English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portuguese(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese(Europe), Dutch, Czech, Greek, Turkish, Arabic

ACCESSORY2

Basic: Remote Controller(include battery 2ea), Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender
Optional: Stand(ST-653T), OPS Kit(KT-OPSF)

POWER2

Power Supply: AC 100-240V~, 50/60Hz
Power Type: Built-in Power

ENVIRONMENT CONDITIONS2

Operation Humidity: 10 % to 80 %
Operation Temperature: 0 °C to 40 °C

OPS COMPATIBILITY2

OPS Power Built-in: NO
OPS Type compatible: YES (Piggyback)

CERTIFICATION4

EMC: FCC Class "A" / CE / KC
ePEAT(US only): NO
ERP / Energy Star: YES(NewErP) / YES
Safety: CB / NRTL

MECHANICAL SPECIFICATION10

Weight (Head): 19.0Kg
Bezel Color: Black
Bezel Width: T/R/L: 9.9mm, B: 14.4mm
Carton Dimensions (W x H x D): 1360.0 x 835.0 x 175.0mm
Handle: NO
Monitor Dimensions (W x H x D): 1234.4 x 720.9 x 39.9mm (with LG Logo)
Monitor Dimension with Stand (W x H x D): 1234.4 x 770.7 x 290.0mm
Packed Weight: 24.2Kg
VESA Standard Mount Interface: 300 x 300 mm
Weight (Head+Stand): 19.6Kg

POWER CONSUMPTION6

BTU (British Thermal Unit): 358 BTU/Hr(Typ.), 495 BTU/Hr(Max.)
DPM: 0.5W
Max.: 145W
Power off: 0.5W
Smart Energy Saving (70%): 84W
Typ.: 105W

PANEL19

Aspect Ratio: 16:9
Back Light Type: Edge
Brightness: 500nit (Typ.)
Color Depth (Number of Colors): 1.07 Billion colors
Color Gamut: BT709 95%
Contrast Ratio: 1,100:1
Dynamic CR: 1,000,000:1
Life time: 50,000Hrs (Min.)
Native Resolution: 3840 x 2160 (UHD)
Operation Hours (Hours/Day): 24/7
Panel Technology: IPS
Portait / Landscape: YES / YES
QWP (Quarter Wave Plate): N/A
Refresh Rate: 60Hz
Response Time: 8ms (G to G)
Screen Size (Inch): 55
Surface Treatment (Haze): Haze 28%
Transparency: N/A
Viewing Angle (H x V): 178º x 178º

CONNECTIVITY19

Audio In: YES
Audio Out: YES
Daisy Chain: NO
DP In: YES (HDCP 2.2/1.3)
DP Out: YES
DVI-D In: YES (HDCP 1.4)
External Speaker Out: NO
HDMI In: YES (3ea)
HDMI In (HDCP Ver.): 2.2/1.4
HDMI Out: NO
IR In: YES
IR Out: NO
RGB In: NO
RJ45(LAN) In: YES (1ea)
RJ45(LAN) Out: NO
RS232C In: YES
RS232C Out: YES
Touch USB: NO
USB In: USB2.0 Type A (1ea)

SPECIAL FEATURE8

Conformal Coating (Power Board): YES
Direct Sunlight: N/A
IP Rating: IP5X
Overlay Touch Compatibility: N/A
Power Protection: N/A
Smart Calibration: N/A
Tilt (Face down): Max. 30 degree
Tilt (Face up): N/A

SOFTWARE COMPATIBILITY7

Connected Care: YES
Mobile CMS: YES
Promota: YES
SuperSign Cloud: NO
SuperSign CMS: YES
SuperSign Control+: YES
SuperSign WB: YES

FEATURE - HARDWARE13

Acceleration(Gyro) Sensor: YES
Auto Brightness Sensor: YES
BLU Sensor: NO
Current Sensor: NO
FAN (Built-in): NO
Humidity Sensor: NO
Internal Memory (eMMC): 8GB
Local Key Operation: YES
Pixel Sensor: NO
Power Indicator: NO
Proximity Sensor: NO
Temperature Sensor: YES
Wi-Fi/BT (Built-in): YES

FEATURE - SOFTWARE39

Auto Set ID: YES
Backlight Sync: NO
Beacon: YES
Booting Logo Image: YES
Brightness Compensation: NO
Cisco Certification: YES
Control Manager: YES
Crestron Connected: YES
External Input Rotation: YES
Fail over: YES
Gapless Playback: YES
Group Manager: YES
HDMI-CEC: YES
ISM Method: YES
Local Contents Scheduling: YES
Local Network Sync: YES
Network Ready: YES
No Signal Image: YES
OS Ver. (webOS): webOS 4.1
PBP: YES (4PBP)
PIP: YES
Play via URL: YES
PM mode: YES
Pro:Idiom: YES
RS232C Sync: YES
Scan Inversion: NO
Screen Rotation: YES
Screen Share: YES
Setting Data Cloning: YES
SI Server Setting: YES
Smart Energy Saving: YES
SNMP: YES
Status Mailing: YES
Tile Mode Setting: YES
USB Plug & Play: YES
Video Tag: YES (4 Video Tag)
Wake on LAN: YES
webRTC: YES
W/B Setting by Grey scale: NO

Downloads

7 files from the manufacturer

PDF Manuals & guides · Opens on manufacturer site 43495565UM3F_UH5F_UM3DF_UH7F_ENG.pdf 3.4 MB PDF Manuals & guides · Opens on manufacturer site MFL71435701_04_QSG.pdf 2.1 MB PDF Manuals & guides · Opens on manufacturer site OM_ARA.pdf 3.7 MB URL Manuals & guides · Opens on manufacturer site User Guide PDF Manuals & guides · Opens on manufacturer site webOS4.1_ENG.pdf 6.8 MB URL Software & firmware · Opens on manufacturer site Software & Drivers (support page) URL Software & firmware · Opens on manufacturer site Software & Drivers (support page)

Questions about 55UH5F-H

What is the LG 55UH5F-H best used for?

The LG 55UH5F-H is a 55-inch standard signage display for lobbies, corridors, meeting rooms and reception areas. Its 3840 x 2160 IPS panel and 500 nit typical brightness suit wayfinding, service menus and corporate messaging. It fits offices, schools and hotels in Doha that need a dependable screen running content around the clock, since the specification lists 24/7 operation.

Does the 28% haze surface make the picture look soft?

The haze surface is rated at 28% and is intended to reduce reflections from windows and ceiling lights, which helps text stay readable in bright rooms. Glare depends on the room, so for a lobby facing a glass façade in West Bay, check the position against your own daylight during a free site survey before ordering several units.

Can it run in portrait orientation for a corridor directory?

Yes. The panel supports both portrait and landscape orientation and detects its orientation automatically during the initial setup, so no manual rotation is needed. A school in Al Wakrah can use portrait mode for timetables and corridor directories, then switch to landscape on a reception wall. Confirm that the chosen bracket allows the required orientation before installation.

What is the operating temperature, and can it sit near a window in summer?

The rated operating temperature is 0 °C to 40 °C, with 10% to 80% humidity. Qatar summers can exceed 45 °C, so the display should sit in an air-conditioned space with airflow around the cabinet. For positions near windows, loading bays or enclosed kiosks, confirm conditions with the SmartRooms Qatar team before installation.

Is the display protected against dust in sandy conditions?

The model carries an IP5X rating, which means it is protected against dust ingress, and the manufacturer lists this under product reliability. Dust storms are common in Qatar, so install it indoors in a closed, air-conditioned space. IP5X does not cover water, so this model is not designed for direct outdoor exposure.

Will it work with a video conferencing system for meetings with teams abroad?

Yes, it is Cisco certified and Crestron Connected, which supports integration with professional AV control and video conference systems. In a Lusail boardroom linking Doha with teams abroad, this helps reduce time spent adjusting picture settings and changing inputs on incoming calls. Ask your integrator to confirm the exact configuration, since some features depend on the control system in use.

Which connections are available for laptops, media players and control systems?

The display has three HDMI inputs, a DisplayPort input and output, a DVI-D input, audio in and out, one RJ45 LAN input, RS232C in and out, an IR input and one USB 2.0 Type A port. There is no HDMI output, so a second screen needs its own feed from the source. The box includes an HDMI cable and a remote controller with two batteries.

Do I need an external media player to run content?

Usually not. The built-in webOS 4.1 platform with 8GB internal memory plays content without a separate media player, and the display supports SuperSign CMS, Mobile CMS, Promota and Connected Care. If you need more processing power, the panel accepts piggyback-type OPS modules, with the OPS Kit (KT-OPSF) sold as an optional accessory. OPS power is not built in.

What mounting options and weight should I plan for?

The VESA mount interface is 300 x 300 mm. The head weighs 19.0 kg and 19.6 kg with the optional ST-653T stand. The screen tilts up to 30 degrees, which is useful when mounted above eye level. Bezels are 9.9 mm at the sides and 14.4 mm at the bottom. Book a site survey so the wall, bracket and cable routing are checked before installation.

How much power does it use, and does it suit Qatar's supply?

The power supply is AC 100-240V at 50/60Hz with built-in power, which covers the 240V, 50Hz mains used in Qatar. Typical consumption is 105W and maximum is 145W, falling to 84W in smart energy saving mode. When equipping a school corridor, calculate the load per unit and check the socket and circuit with your installer.

Does the on-screen menu support Arabic?

Yes. The on-screen display language list includes Arabic alongside English and many other languages. Offices and institutions working in Arabic and English can set the menus to suit their staff. Arabic content on the screen depends on the media files you publish, and the SmartRooms Qatar team can help plan bilingual layouts while preparing your quotation.

Can we order several units for a school or government tender?

Yes. SmartRooms Qatar supplies multiple units against a purchase order (LPO) or a government tender, including Monaqasat, and accepts payment by bank transfer, cheque or purchase order. Delivery covers all eight municipalities of Qatar. Send your quantity, bracket preference and site list when you request a quote, and the team will confirm lead times based on stock.
