65UH5F-H

A 65-inch UHD display for bright, busy rooms

The LG 65UH5F-H is a 65-inch standard signage display with a 3840 x 2160 IPS panel and a 16:9 aspect ratio. Its 28% haze surface softens reflections from windows and ceiling lights, so menus, timetables and wayfinding text stay readable where a glossy screen would wash out. Typical brightness is 500 nit, the contrast ratio is 1,100:1, and the panel shows 10-bit colour across 95% of the BT.709 gamut. Viewing angles are rated at 178 degrees both horizontally and vertically, so people standing to the side still see the same picture.

With a 24/7 operation rating and a minimum lifetime of 50,000 hours, the display suits lobbies, corridors and waiting areas that run all day.

Built-in software that reduces the need for a media player

The unit runs webOS 4.1 with 8GB of internal memory, so playlists can run without a separate player. Content scheduling, group management, fail-over and gapless playback are included, and tile mode supports video walls of up to 15 x 15 screens. Built-in Wi-Fi and an RJ45 LAN port support network control, and a USB port accepts plug-in sensors such as temperature sensors, GPIO and NFC/RFID readers. Internal temperature, auto-brightness and gyro sensors are also fitted. For meeting rooms, the data lists certified compatibility with Cisco video conferencing systems and Crestron Inside network-based control.

Connections, power and mounting details

• Three HDMI inputs, with HDCP 2.2 on HDMI1 and HDMI2
• One DisplayPort input, one DVI-D input and one DisplayPort output
• RS232C in and out, IR input, and RJ45 LAN for control
• Audio in and audio out, plus a built-in speaker
• OPS-compatible, with the OPS Kit (KT-OPSF) sold as an option

The built-in power supply accepts 100 to 240 V at 50 or 60 Hz, which covers Qatar's 240 V, 50 Hz mains. Typical draw is 120 W and the maximum is 165 W. The panel measures 1453.3 x 844.0 x 39.9 mm without its stand and weighs 28.2 kg, or 28.8 kg with the stand. It has a 300 x 300 VESA interface and supports up to 30 degrees of tilt. The screen detects its orientation at first start-up, so portrait installations need no manual rotation.

Where this model fits in Qatar

• Corporate reception in West Bay or Lusail: a 65-inch screen beside the lift lobby showing company news and meeting-room schedules, with the haze surface handling daylight from glass frontages.
• Private school in Al Rayyan: a corridor display for timetables and event notices, updated over the network from one office.
• Hotel lobby in Doha: welcome and wayfinding content for guests, looping continuously through the day.

Heat needs planning in Qatar. The LG 65UH5F-H is rated for 0 to 40 °C and 10 to 80% humidity, so it belongs in air-conditioned rooms away from direct sun. Confirm room conditions with the SmartRooms Qatar team before fixing a unit to a wall that faces hot glass.

What to plan before you order

Check the wall and power points first. The optional wall bracket (LSW350B), VESA adapter (AM-B330S) and stand (ST-653T) are listed accessories, and a free site survey from SmartRooms Qatar can confirm the right mounting method for a 28.8 kg panel. Professional installation is available, and delivery covers all eight municipalities of Qatar. Organisations buying several units, such as a school in Al Khor, can issue one purchase order or LPO against a single quotation.

To request a quote for the LG 65UH5F-H, tell us the room type, number of units and planned mounting method, and our team will usually reply within one working day.
