LG 86UH5Q-GQ 86-inch 4K UHD Digital Signage Display

Overview

The LG 86UH5Q-GQ is an 86-inch 4K UHD signage display with a 3840 x 2160 panel, 500 nit typical brightness and 24/7 operation rated by the manufacturer. It runs webOS 8.0 with 16GB internal memory, so playlists can run without a separate media player, and it manages content through SuperSign CMS. Suited to boardrooms, lobbies and retail floors across Qatar that need a large, always-on screen.

What the LG 86UH5Q-GQ is and where it fits

The LG 86UH5Q-GQ is an 86-inch digital signage display from the UH5Q series, built around an edge-lit 16:9 panel with 3840 x 2160 native resolution. It is a signage display for showing content, so buyers who need writing on the screen should compare interactive models. In a corporate lobby in West Bay, a hotel reception in The Pearl or a retail atrium in Lusail, a screen this size carries announcements, wayfinding, promotions and corporate messages to visitors who pass it all day. The panel can be mounted in landscape or portrait orientation, which suits corridor totems and queue information.

Picture and brightness figures to check against the room

The panel is rated at 500 nit typical brightness and 1,200:1 typical contrast, with a surface haze of 25 percent typical. Colour depth is listed at 1.07 billion colours (8-bit plus FRC), with BT709 95 percent and DCI-P3 80 percent gamut coverage, a typical 8 ms grey-to-grey response and a 178 by 178 degree viewing angle. For a bright lobby with windows, compare the 500 nit figure and the haze treatment against what the site survey measures. The panel is rated for 24/7 operation with a minimum lifetime of 50,000 hours.

Running content without a separate media player

webOS 8.0 runs on a built-in processor with 16GB of internal memory, so local scheduling, group management and fail-over can operate without an external media box at each screen. Content is managed through SuperSign CMS, SuperSign Control+, SuperSign WB, SuperSign Cloud and Mobile CMS, all listed as compatible. Tile mode supports up to 15 by 15 units for video walls, and PIP and PBP are available with one external input. Wake on LAN, SNMP and HDMI-CEC help facilities teams keep screens running and monitored. Two 10 W speakers are built in, and a separate audio output is provided.

Heat, dust and electrical conditions in Qatar

The rated operating range is 0 °C to 40 °C with 10 to 80 percent humidity, so the display belongs in air-conditioned interiors. Summer temperatures in Qatar can exceed 45 °C, so keep the screen out of direct sunlight, away from glass facades and clear of open loading bays. The power board has partial conformal coating, which the manufacturer describes as protection against salt, dust, iron powder and humidity. The unit is IP5X rated. Input is AC 100-240 V at 50/60 Hz with built-in power. Typical draw is 170 W and maximum is 280 W, with Smart Energy Saving listed at 120 W. Confirm the supplied power cord against the BS 1363 sockets common in Qatar during your quotation.

Planning the mount, weight and delivery

Head weight is 53.0 kg and packed weight is 66.7 kg, so plan lifting equipment and a two-person crew.
Monitor size is 1928.8 x 1099.8 x 29.7 mm without the IR sensor and handle.
The VESA mount pattern is 600 x 400 mm; the optional LSW640A/B wall mount is listed by the manufacturer.
The carton measures 2100 x 1250 x 253 mm, so check lift access, doors and lifts before delivery.

Measure the wall, the sightline and the nearest power point before ordering. SmartRooms Qatar offers a free site survey, which is particularly useful for an 86-inch panel wall-mounted in a school corridor or a government reception. Supply and delivery cover all eight municipalities of Qatar, and professional installation can be arranged. Quotations are usually issued within one working day, and purchase orders (LPOs) and government tenders are supported. The product is covered by the manufacturer's warranty.

To receive a quote for the LG 86UH5Q-GQ, send the number of units, the mounting location and the intended content to the SmartRooms Qatar team and request a quote today.

Highlights

86-inch 4K UHD panel with 3840 x 2160 native resolution
500 nit typical brightness and 1,200:1 typical contrast
24/7 operation rating with webOS 8.0 and 16GB memory
Three HDMI inputs, one DisplayPort input and RJ45 LAN
Built-in 2 x 10W speakers and IP5X rating
Operating range 0 °C to 40 °C, 10 to 80 percent humidity

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

96 specifications · Source: manufacturer · checked Oct 2026

PANEL17

Screen Size (Inch): 86"
Panel Technology: ADS
Back Light Type: Edge
Aspect Ratio: 16:9
Native Resolution: 3840 x 2160 (UHD)
Refresh Rate: 60Hz
Brightness: 500nit (Typ.)
Contrast Ratio: 1,200:1 (Typ.)
Dynamic CR: 1,000,000:1
Color Gamut: BT709 95% (DCI-P3 80%)
Viewing Angle (H x V): 178 X 178
Color Depth (Number of Colors): 1.07 Billion colors (8bits + FRC)
Response Time: 8ms (G to G) (Typ.)
Surface Treatment (Haze): 25% (Typ.)
Life time: 50,000Hrs (Min.)
Operation Hours (Hours/Day): 24/7
Portait / Landscape: Yes / Yes

CONNECTIVITY9

HDMI In: Yes(3), 3840x2160@60Hz, HDCP 2.2/1.4
DP In: Yes(1), 3840x2160@60Hz, HDCP 2.2/1.4
RS232C In: Yes(1), 4pin Phone-jack
RJ45(LAN) In: Yes(1)
IR In: Yes(1)
USB In: USB2.0 Type A(2)
Audio Out: Yes(1)
RS232C Out: Yes(1), 4pin Phone-jack
IR Out: No (Support IR daisy chain via RS232C IN/OUT)

MECHANICAL SPECIFICATION8

Bezel Color: Black
Bezel Width: 13.4mm (Even)
Weight (Head): 53.0 kg
Packed Weight: 66.7 kg
Monitor Dimensions (W x H x D): 1928.8 x 1099.8 x 29.7mm (without IR, Handle)
Carton Dimensions (W x H x D): 2100 x 1250 x 253mm
Handle: Yes
VESA Standard Mount Interface: 600 x 400

FEATURE - HARDWARE5

Internal Memory (eMMC): 16GB
Temperature Sensor: Yes
Auto Brightness Sensor: YesIR/Light sensor receiver)
Acceleration(Gyro) Sensor: Yes
Local Key Operation: Yes

FEATURE - SOFTWARE31

OS Ver. (webOS): webOS8.0
Local Contents Scheduling: Yes
Group Manager: Yes
USB Plug & Play: Yes
Fail over: Yes
Booting Logo Image: Yes
No Signal Image: Yes
RS232C Sync: Yes
Local Network Sync: Yes
PIP: Yes
PBP: Yes(4)(Support Only One External Input)
Video Tag: Yes(4)(Support Only One External Input)
Play via URL: Yes
Screen Rotation: Yes
External Input Rotation: Yes
Gapless Playback: Yes
Tile Mode Setting: Yes (Max. 15x15)
Setting Data Cloning: Yes
SNMP: Yes
ISM Method: Yes
Auto Set ID: Yes
Status Mailing: Yes
Control Manager: Yes
Smart Energy Saving: Yes
PM mode: Yes
Wake on LAN: Yes
Network Ready: Yes
HDMI-CEC: Yes
SI Server Setting: Yes
webRTC: Yes
Pro:Idiom: Yes

ENVIRONMENT CONDITIONS2

Operation Temperature: 0 °C to 40 °C
Operation Humidity: 10 % to 80 %

POWER2

Power Supply: AC 100-240V~, 50/60Hz
Power Type: Built-In Power

POWER CONSUMPTION6

Typ.: 170W
Max.: 280W
BTU (British Thermal Unit): 581 BTU/Hr(Typ.), 957 BTU/Hr(Max)
Smart Energy Saving (70%): 120W
DPM: 0.5W
Power off: 0.5W

SOUND1

Speaker (Built-in): Yes (10W X 2)

CERTIFICATION4

Safety: CB / NRTL
EMC: FCC Class "B" / CE / KC
ERP / Energy Star: N/A / Yes
ePEAT(US only): Yes

SOFTWARE COMPATIBILITY6

SuperSign CMS: Yes
SuperSign Control+: Yes
SuperSign WB: Yes
SuperSign Cloud: Yes
Mobile CMS: Yes
Connected Care: Yes

LANGUAGE1

OSD: English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portuguese(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese(Europe), Dutch, Czech, Greek, Turkish, Arabic, Polish

ACCESSORY2

Basic: Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(6ea), Cable holder
Optional: Wall Mount (LSW640A/B)

SPECIAL FEATURE2

IP Rating: IP5X
Conformal Coating (Power Board): Yes(Partial space coating)

Downloads

1 file from the manufacturer

PDF Datasheets 86-75UH5Q-G_Datasheet(low)_LG UHD Signage_260413_20260919_161057_.pdf 1.4 MB

Questions about 86UH5Q-GQ

What is the LG 86UH5Q-GQ designed to do?

It is an 86-inch 4K UHD signage display built to show content continuously in busy public and corporate spaces. Its 3840 x 2160 panel, 500 nit typical brightness and 24/7 operation rating suit a boardroom wall in West Bay, a hotel reception in The Pearl or a mall entrance in Lusail where the screen runs all day. Buyers who need interactive annotation should compare other models before ordering.

Can it play content without an external media player?

Yes. The webOS 8.0 platform runs on a built-in processor with 16GB of internal memory, and it supports local content scheduling, fail-over and gapless playback. Playlists can be managed from SuperSign CMS, SuperSign Cloud or Mobile CMS, and USB Plug and Play lets staff load files from one of its two USB 2.0 Type A ports. This removes the need for a separate media box at each screen, which simplifies installation in schools and offices.

Can I install it near a window or outdoors in Qatar?

Not as an outdoor unit. The rated operating temperature is 0 °C to 40 °C with 10 to 80 percent humidity, so it should sit in air-conditioned interiors. Qatar summers can pass 45 °C, so keep it out of direct sun, away from glass facades and clear of loading bays. The power board has partial conformal coating against salt, dust, iron powder and humidity, but that does not extend the rated range. Confirm the room climate with the SmartRooms Qatar team before installation.

What inputs and ports does it provide?

It has three HDMI inputs and one DisplayPort input, each rated 3840 x 2160 at 60Hz with HDCP 2.2 and 1.4 support. Control and networking use one RJ45 LAN port, one RS232C input and one RS232C output with a 4-pin phone jack, plus an IR input. It also offers two USB 2.0 Type A ports and one audio output. IR out is not provided; IR daisy chaining works through the RS232C input and output.

Can several units form a video wall?

Yes, the tile mode setting supports up to 15 x 15 units. Each panel has a 13.4 mm bezel, which keeps the joins between screens narrow in a lobby or control room. Plan the mounting frame around the 600 x 400 VESA pattern and confirm the wall-mount solution for every panel. A retail atrium in Lusail or a hotel lobby with a multi-panel feature wall can be planned from a single site survey.

How big is the display and will it fit my wall?

Monitor dimensions without the IR sensor and handle are 1928.8 x 1099.8 x 29.7 mm. Head weight is 53.0 kg and packed weight is 66.7 kg. Measure the wall, check the structure and allow clearance for cables before ordering. SmartRooms Qatar offers a free site survey, which is useful for a wall in a West Bay boardroom or a school corridor where the panel must be level and secure.

Which wall mount should I use?

The panel uses a 600 x 400 VESA standard mount interface. The manufacturer lists the LSW640A/B wall mount as an optional accessory, so check that the variant fits your wall construction and the weight. For a 53.0 kg head, the mount, fixings and wall must be rated for the load. Ask for the mount to be included in your quotation, and the site survey confirms the fixing method before installation.

Does it run on Qatar's 240 V supply?

The power input is rated AC 100-240 V at 50/60 Hz with built-in power, so the supply range covers the 240 V mains at 50 Hz used in Qatar. Typical consumption is 170 W and maximum is 280 W. The supplied power cord should be checked against the BS 1363 socket outlets used in Qatar before installation, and the SmartRooms Qatar team can advise on the correct lead during the quotation.

How much power will it draw across a working day?

Typical draw is 170 W and maximum is 280 W, with Smart Energy Saving listed at 120 W. Power-off and DPM standby are each rated at 0.5 W. A facilities team running the screen 24/7 in a hospital corridor or mall should budget for the typical figure and check the room's electrical capacity during the site survey. Heat output is listed at 581 BTU/hr typical and 957 BTU/hr maximum, which matters for air conditioning.

Can it be controlled by a building system or remote management tool?

Yes. It supports RS232C control and synchronisation, an IR input, SNMP, Wake on LAN, HDMI-CEC and a Control Manager feature. Status Mailing and Auto Set ID help IT and facilities teams monitor and configure multiple screens. These functions suit a government ministry or bank that manages displays from a central network rather than visiting each screen.

Does the on-screen menu support Arabic?

Yes. The on-screen display language list includes Arabic alongside English, French and many other languages. Offices in Doha that work in Arabic and English can set the menu to the language their operators prefer. Content language is separate and depends on the material you load through SuperSign or USB.

How do I get a quote and what do I need to send?

Send the number of units, the wall or mounting location, the room use and whether you need a video wall layout. SmartRooms Qatar usually issues quotations within one working day. Payment can be made by bank transfer, cheque or purchase order, and LPO and government tender purchases, including those through Monaqasat, are supported. Products are covered by the manufacturer's warranty.
