LG 86UP5R-E · Price in Qatar

Overview

The LG 86UP5R-E is an 86-inch UHD signage display that runs webOS 8.0 on the panel itself, so many playlists can run without an external media player. It offers 500 nit typical brightness, an anti-glare screen, 24/7 operation rating and six multi-screen layouts. It suits lobbies, reception areas and corridors in Doha and beyond where content must run all day. Request a quote for supply and installation.

What the LG 86UP5R-E does on site

The LG 86UP5R-E is an 86-inch UHD (3840 x 2160) display built for public-facing digital signage. Its webOS 8.0 platform runs playlists, schedules and layouts directly on the screen, so most installations do not need a separate media player mounted behind the panel. For facilities teams, that means fewer boxes to power, cable and maintain.

Specifications that affect everyday performance

Brightness is rated at 500 nit typical with a 1,200:1 contrast ratio and a 178 by 178 degree viewing angle, so messages stay readable from the side of a lobby or a corridor. The anti-glare surface has a 25% haze rating, which helps where large windows bring in daylight. A 120Hz refresh rate and 8 ms grey-to-grey response keep video motion clean. The panel is rated for 24/7 operation with a typical life of 50,000 hours.

Connectivity covers three HDMI inputs, one DisplayPort input, one LAN port, USB 3.0 and USB 2.0 Type A ports, RS232C in and out, IR in and audio out. Built-in Wi-Fi and Bluetooth, 32GB of internal memory and two 10 W speakers are included. Temperature, auto brightness and gyro sensors are fitted, and the display can be mounted in portrait or landscape.

Where it fits in Qatar

Government reception: a ministry or authority lobby in Msheireb showing service information in Arabic and English, with the Arabic on-screen menu available on the display.
Bank branch: a West Bay branch using a single 86-inch screen for rate and product messages, with the daylight-resistant anti-glare surface suiting a front-facing window.
University atrium: a campus entrance in Education City where a daisy-chained LAN connection lets several displays share one network link without extra routers.

What to plan before installation

The head weighs 53 kg and the packed unit weighs 66.7 kg, with monitor dimensions of 1928.8 x 1099.8 x 29.7 mm. The VESA pattern is 600 x 400 mm, and the optional LSW640B wall mount is sold separately. Plan for a two-person lift and confirm the wall structure before mounting. Typical power draw is 205 W with a maximum of 297 W, equal to 699 and 1013 BTU/hr, so include that heat load in your air-conditioning plan. The rated operating range is 0 °C to 40 °C, so confirm the room temperature and avoid direct sun exposure, which matters in Qatar's summer heat.

SmartRooms Qatar offers a free site survey before wall-mounting a heavy 86-inch panel, which helps confirm the mounting point, cable route and power position. Organisations ordering several units can raise a purchase order (LPO), and quotations are usually issued within one working day. To request a quote for the LG 86UP5R-E, contact the SmartRooms Qatar team with your room layout and the number of displays.

Highlights

86-inch UHD panel at 3840 x 2160 resolution
webOS 8.0 platform with 32GB internal memory
500 nit typical brightness with 25% haze anti-glare surface
Rated for 24/7 operation with 50,000-hour typical life
Six video tags and six multi-screen layouts
LAN daisy chain with three HDMI inputs and DisplayPort

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

102 specifications · Source: manufacturer · checked Oct 2026

PANEL17

Screen Size (Inch): 86
Panel Technology: ADS
Back Light Type: Edge
Aspect Ratio: 16:9
Native Resolution: 3840 x 2160 (UHD)
Refresh Rate: 120Hz
Brightness: 500nit (Typ.)
Contrast Ratio: 1,200:1
Dynamic CR: 1,000,000:1
Color Gamut: BT709 95%
Viewing Angle (H x V): 178º x 178º
Color Depth (Number of Colors): 1.07 Billion colors
Response Time: 8m (G to G)
Surface Treatment (Haze): 25%
Life time: 50,000Hrs (Typ.)
Operation Hours (Hours/Day): 24/7
Portait / Landscape: YES / YES

CONNECTIVITY9

HDMI In: YES (3ea)
HDMI In (HDCP Ver.): 2.2/1.4
DP In: YES (HDCP 2.2/1.3)
RS232C In: YES
RJ45(LAN) In: YES (1ea)
IR In: YES
USB In: USB3.0 Type A (1ea), USB2.0 Type A (1ea)
Audio Out: YES
RS232C Out: YES

MECHANICAL SPECIFICATION8

Bezel Color: Black
Bezel Width: 13.4mm
Weight (Head): 53kg
Packed Weight: 66.7kg
Monitor Dimensions (W x H x D): 1928.8 x 1099.8 x 29.7mm
Carton Dimensions (W x H x D): 2100 x 1250 x 253 mm
Handle: YES
VESA Standard Mount Interface: 600 x 400 mm

FEATURE - HARDWARE6

Internal Memory (eMMC): 32GB
Wi-Fi/BT (Built-in): YES
Temperature Sensor: YES
Auto Brightness Sensor: YES
Acceleration(Gyro) Sensor: YES
Local Key Operation: YES

FEATURE - SOFTWARE35

OS Ver. (webOS): webOS 8.0
Local Contents Scheduling: YES
Group Manager: YES
USB Plug & Play: YES
Fail over: YES
Booting Logo Image: YES
No Signal Image: YES
RS232C Sync: YES
Local Network Sync: YES
PIP: YES
PBP: YES (4PBP)
Screen Share: YES
Video Tag: YES (6 Video Tag)
Play via URL: YES
Screen Rotation: YES
External Input Rotation: YES
Gapless Playback: YES
Tile Mode Setting: YES
Setting Data Cloning: YES
SNMP: YES
ISM Method: YES
Auto Set ID: YES
Status Mailing: YES
Control Manager: YES
Cisco Certification: YES
Crestron Connected: YES
Smart Energy Saving: YES
PM mode: YES
Wake on LAN: YES
Network Ready: YES
Beacon: YES
HDMI-CEC: YES
SI Server Setting: YES
webRTC: YES
Pro:Idiom: YES

ENVIRONMENT CONDITIONS2

Operation Temperature: 0 °C to 40 °C
Operation Humidity: 10 % to 80 %

POWER2

Power Supply: AC 100-240V~, 50/60Hz
Power Type: Built-in Power

POWER CONSUMPTION6

Typ.: 205W
Max.: 297W
BTU (British Thermal Unit): 699 BTU/Hr(Typ.), 1013 BTU/Hr(Max)
Smart Energy Saving (70%): 144W
DPM: 0.5W
Power off: 0.5W

SOUND1

Speaker (Built-in): YES (10W x 2)

CERTIFICATION4

Safety: CB / NRTL
EMC: FCC Class "B" / CE / KC
ERP / Energy Star: YES(NewErP) / YES
ePEAT(US only): YES

SOFTWARE COMPATIBILITY7

SuperSign CMS: YES
SuperSign Control+: YES
SuperSign WB: YES
SuperSign Cloud: YES
Promota: YES (Not available for EU/CIS)
Mobile CMS: YES
Connected Care: YES

LANGUAGE1

OSD: English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portuguese(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese(Europe), Dutch, Czech, Greek, Turkish, Arabic

ACCESSORY2

Basic: Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(6EA), Cable Holder(7Pin/1EA)
Optional: Wall Mount (LSW640B)

SPECIAL FEATURE2

IP Rating: IP5X
Conformal Coating (Power Board): YES

Downloads

0 files from the manufacturer

No downloadable files are listed for this model yet. Ask us and we will send the datasheet.

Questions about 86UP5R-E

What is the LG 86UP5R-E used for?

It is an 86-inch UHD digital signage display for lobbies, reception areas, corridors and waiting zones where content runs for many hours each day. Its 500 nit typical brightness and anti-glare surface help messages remain readable in rooms with daylight, such as a bank branch or government service hall in Doha.

Do I need a separate media player to run content?

In most cases no. The display runs webOS 8.0 and stores content in 32GB of internal memory, with local scheduling and local content playback. The manufacturer states that internal deployment removes the need for external OPS players, which simplifies cabling behind the screen.

How many content zones can show at once?

The display supports up to six video tags and six multi-screen layouts, and it offers four-way picture-by-picture mode. Simultaneous playback depends on resolution and codec, and video tags need a separate system configuration. Confirm your planned layout with the SmartRooms Qatar team before ordering.

Can several displays share one network connection?

Yes. The LAN daisy chain function links multiple displays through one network connection without separate routers or extra networking equipment. This is useful at a university entrance or a hotel lobby with screens in different spaces, because content and updates can be managed from one network.

Is this display suitable for hot or outdoor areas in Qatar?

The rated operating range is 0 °C to 40 °C with 10% to 80% humidity. Qatar summers can exceed 45 °C, so it should be installed in an air-conditioned indoor space and not in direct sun. Ask SmartRooms Qatar to check the room conditions during the site survey.

Will it work with Qatar's 240 V mains supply?

The power supply is rated for AC 100-240V at 50/60Hz, which covers Qatar's 240 V, 50 Hz mains. The power cord is included, but its plug type should be confirmed in the quotation before ordering so that it matches your sockets.

What electrical load should we plan for?

Typical consumption is 205 W and maximum is 297 W, equal to 699 BTU/hr typical and 1013 BTU/hr maximum. Smart energy saving reduces consumption to 144 W at 70% in the manufacturer data, and standby draw is 0.5 W. Include these figures when planning circuits and cooling capacity.

What wall mount and space do I need?

The VESA pattern is 600 x 400 mm and the optional LSW640B wall mount is sold separately. The monitor measures 1928.8 x 1099.8 x 29.7 mm and the head weighs 53 kg. Confirm the wall structure and plan a two-person lift before mounting.

Can the display be used in portrait orientation?

Yes, the display supports both portrait and landscape orientation, and it also offers screen rotation and external input rotation settings. This suits vertical menus, directory boards or wayfinding screens in a hospital corridor or a shopping mall entrance in The Pearl.

What is included in the box and how is it managed remotely?

The box includes a remote controller with two batteries, a power cord, a quick start guide, a regulation book, cable holders and an RS232C adapter. Remote management is supported through SuperSign CMS, SuperSign Control+, SuperSign Cloud, Mobile CMS and SNMP, and the manufacturer lists Crestron Connected support.

How do I request a quote for this display?

Send SmartRooms Qatar your room layout, the number of displays and the mounting location. A free site survey can be arranged, and quotations are usually issued within one working day. Organisations can pay by bank transfer, cheque or purchase order, and the product is covered by the manufacturer warranty.
