LG 98UH5F-H · Price in Qatar

Overview

The LG 98UH5F-H is a 98-inch 4K UHD standard signage display built for lobbies, corridors and meeting areas where glare is a problem. Its IPS panel is rated at 500 nit typical, and its 28% haze surface keeps text readable under bright lighting. The built-in webOS platform plays content without an external media player, which suits government offices, malls and corporate reception areas across Qatar. Request a quote.

What the 98UH5F-H is and where it fits

The LG 98UH5F-H is a 98-inch standard signage display with a 3840 x 2160 UHD panel, giving four times the pixel count of Full HD. It uses an IPS panel with a viewing angle of 178 degrees both horizontally and vertically, so people standing at the side of a room still see accurate colour and clear text. The body measures 2191.8 x 1246.8 x 83.8 mm, a large single-screen format suited to wayfinding, announcements and presentation walls.

Glare control and brightness for bright Qatari spaces

Many lobbies in Doha have large glazing and strong daylight. This model carries a 28% haze surface treatment that diffuses reflections and helps small text stay legible. Typical brightness is 500 nit, and the panel includes an auto brightness sensor. It is rated for a 120 Hz refresh rate and an 8 ms grey-to-grey response time, with a typical contrast ratio of 1,200:1.

Built-in playback and central control

webOS 4.0 runs on a built-in quad-core SoC with 8GB of internal eMMC storage, so content can play without a separate media player. Control Manager, an embedded web tool, lets an IT team monitor and control several displays in different locations in real time. Crestron Connected and Cisco certification mean the screen can join a professional AV control system or a Cisco video conferencing room.

Connectivity and inputs

Video: three HDMI inputs (HDCP 2.2/1.4), one DisplayPort input and one DisplayPort output, plus a DVI-D input
Network and control: one RJ45 LAN input, RS232C in and out, IR in, and built-in Wi-Fi and Bluetooth
Other: two USB 2.0 Type A ports, audio in and out, and two built-in 10 W speakers

Check these before ordering: HDMI out and RGB in are not provided, and the model does not accept OPS modules, so an external PC must connect through HDMI or DisplayPort.

Planning the installation

The head weighs 81.1 kg and the packed weight is 119 kg, so the delivery route, lift access and wall or stand must all be planned for that load. The VESA mount pattern is 800 x 400 mm. Power input is AC 100-240 V, 50/60 Hz with built-in power, which covers Qatar's 240 V supply. Typical draw is 420 W and the maximum is 560 W, which should be included in circuit planning. The operating range is 0 to 40 °C and 10 to 80% humidity, so any space that can run hotter, such as an unventilated corridor or a glazed area in summer, needs cooling designed in. A free site survey will confirm the wall, the access route and the environment before installation.

Qatar scenarios

A bank branch in West Bay replacing a wall of printed posters with one 98-inch screen for rates and promotions, managed centrally across branches.
A government ministry lobby in Doha showing wayfinding and service queue information in English and Arabic, with the menu set to Arabic.
A corporate meeting room in Lusail where an AV controller operates the screen through Crestron and calls connect to a Cisco room system.

Ordering and next steps

SmartRooms Qatar supplies the 98UH5F-H with delivery to all eight municipalities of Qatar, professional installation and free site surveys. Quotations are usually issued within one working day. We accept purchase orders (LPOs), government tenders, and payment by bank transfer, cheque or purchase order. The product is covered by the manufacturer's warranty. Request a quote and tell us the room, the mounting wall and the number of units you need.

Highlights

98-inch 3840 x 2160 UHD IPS panel with 178-degree viewing angles
28% haze surface to reduce reflections and keep text readable
500 nit typical brightness with 120 Hz refresh rate
webOS 4.0 with 8GB internal storage, no external media player needed
Crestron Connected and Cisco-certified compatibility for meeting rooms
Built-in Wi-Fi and Bluetooth, RJ45 LAN and RS232C control

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

135 specifications · Source: manufacturer · checked Oct 2026

ACCESSORY2

Basic: Remote Controller(include battery 2ea), Power Cord, QSG, IR/Light sensor receiver, DP Cable(1.8M), Regulation Book, Phone to RS232C Gender, EYE-BOLT
Optional: NO

POWER2

Power Supply: AC 100-240V~, 50/60Hz
Power Type: Built-in Power

SOUND1

Speaker (Built-in): YES (10W x 2)

LANGUAGE1

OSD: English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arabic

ENVIRONMENT CONDITIONS2

Operation Humidity: 10 % to 80 %
Operation Temperature: 0 °C to 40 °C

OPS COMPATIBILITY2

OPS Power Built-in: NO
OPS Type compatible: NO

CERTIFICATION4

EMC: FCC Class "A" / CE / KC
ePEAT(US only): NO
ERP / Energy Star: YES(Old ErP for Jordan) / NO
Safety: CB / NRTL

MECHANICAL SPECIFICATION10

Weight (Head): 81.1Kg
Bezel Color: Black
Bezel Width: Even bezel : 14.9mm
Carton Dimensions (W x H x D): 2362 x 1386 x 420mm
Handle: YES
Monitor Dimensions (W x H x D): 2191.8 x 1246.8 x 83.8mm (without Handle and LG Logo)
Monitor Dimension with Stand (W x H x D): N/A
Packed Weight: 119Kg
VESA Standard Mount Interface: 800 x 400 mm
Weight (Head+Stand): N/A

POWER CONSUMPTION6

BTU (British Thermal Unit): 1433.25 BTU/Hr(Typ.), 1911 BTU/Hr(Max.)
DPM: 0.5W
Max.: 560W
Power off: 0.5W
Smart Energy Saving (70%): 294W
Typ.: 420W

PANEL19

Aspect Ratio: 16:9
Back Light Type: Direct
Brightness: 500nit (Typ.)
Color Depth (Number of Colors): 1.07 Billion colors
Color Gamut: NTSC 72%
Contrast Ratio: 1,200:1
Dynamic CR: 1,000,000:1
Life time: 50,000Hrs (Typ.)
Native Resolution: 3840 x 2160 (UHD)
Operation Hours (Hours/Day): 24/7
Panel Technology: IPS
Portait / Landscape: YES / YES
QWP (Quarter Wave Plate): N/A
Refresh Rate: 120Hz
Response Time: 8ms (G to G)
Screen Size (Inch): 98
Surface Treatment (Haze): Haze 28%
Transparency: N/A
Viewing Angle (H x V): 178º x 178º

CONNECTIVITY19

Audio In: YES
Audio Out: YES
Daisy Chain: NO
DP In: YES (HDCP 2.2/1.3)
DP Out: YES
DVI-D In: YES (HDCP 1.4)
External Speaker Out: NO
HDMI In: YES (3ea)
HDMI In (HDCP Ver.): 2.2/1.4
HDMI Out: NO
IR In: YES
IR Out: NO
RGB In: NO
RJ45(LAN) In: YES (1ea)
RJ45(LAN) Out: NO
RS232C In: YES
RS232C Out: YES
Touch USB: NO
USB In: USB2.0 Type A (2ea)

SPECIAL FEATURE8

Conformal Coating (Power Board): YES
Direct Sunlight: N/A
IP Rating: N/A
Overlay Touch Compatibility: N/A
Power Protection: N/A
Smart Calibration: N/A
Tilt (Face down): N/A
Tilt (Face up): N/A

SOFTWARE COMPATIBILITY7

Connected Care: YES
Mobile CMS: YES
Promota: YES
SuperSign Cloud: NO
SuperSign CMS: YES
SuperSign Control+: YES
SuperSign WB: YES

FEATURE - HARDWARE13

Acceleration(Gyro) Sensor: NO
Auto Brightness Sensor: YES
BLU Sensor: NO
Current Sensor: NO
FAN (Built-in): NO
Humidity Sensor: NO
Internal Memory (eMMC): 8GB
Local Key Operation: YES
Pixel Sensor: NO
Power Indicator: NO
Proximity Sensor: NO
Temperature Sensor: YES
Wi-Fi/BT (Built-in): YES

FEATURE - SOFTWARE39

Auto Set ID: YES
Backlight Sync: NO
Beacon: YES
Booting Logo Image: YES
Brightness Compensation: NO
Cisco Certification: YES
Control Manager: YES
Crestron Connected: YES
External Input Rotation: YES
Fail over: YES
Gapless Playback: YES
Group Manager: YES
HDMI-CEC: YES
ISM Method: YES
Local Contents Scheduling: YES
Local Network Sync: YES
Network Ready: NO
No Signal Image: YES
OS Ver. (webOS): webOS 4.0
PBP: YES (4PBP)
PIP: YES
Play via URL: YES
PM mode: YES
Pro:Idiom: YES
RS232C Sync: YES
Scan Inversion: NO
Screen Rotation: YES
Screen Share: YES
Setting Data Cloning: YES
SI Server Setting: YES
Smart Energy Saving: YES
SNMP: YES
Status Mailing: YES
Tile Mode Setting: YES
USB Plug & Play: YES
Video Tag: YES (4 Video Tag)
Wake on LAN: YES
webRTC: YES
W/B Setting by Grey scale: NO

Downloads

7 files from the manufacturer

PDF Manuals & guides MFL71454502_02_221206.pdf 5.6 MB PDF Manuals & guides OM_ENG.pdf 5.1 MB URL Manuals & guides · Opens on manufacturer site Owner's Manual URL Manuals & guides · Opens on manufacturer site User Guide PDF Manuals & guides · Opens on manufacturer site webOS4.0_UG_ENG.pdf 4.4 MB URL Software & firmware · Opens on manufacturer site Software & Drivers (support page) URL Software & firmware · Opens on manufacturer site Software & Drivers (support page)

Questions about 98UH5F-H

What is the LG 98UH5F-H best suited for?

The LG 98UH5F-H is a 98-inch standard signage display for lobbies, corridors, waiting areas and meeting rooms. Its 3840 x 2160 resolution keeps small text sharp at reading distance, and its 28% haze surface helps in rooms with large windows. It suits organisations that want one large screen for information, announcements and presentations rather than a multi-screen video wall.

Does the display need an external media player?

No. The display runs webOS 4.0 on a built-in quad-core SoC with 8GB of internal eMMC storage, so it can play content without a separate media player. It also supports play via URL and local content scheduling, so a school or hotel in Al Rayyan can run timed messages without leaving a computer connected.

How bright is the screen in a room with daylight?

The panel has a typical brightness of 500 nit and a 28% haze surface treatment that reduces reflections from windows and lighting. The model also includes an auto brightness sensor. For sites that get direct sun, we recommend a site survey before choosing the mounting position, so the window orientation and light path can be checked.

Can it connect to a Cisco video conference system?

Yes. The UH5F-H series is certified for compatibility with Cisco systems and offers integrated control for video calls. That can reduce the time spent adjusting picture settings or changing inputs when a call arrives. Confirm your Cisco codec and room setup with the SmartRooms Qatar team before ordering.

Can it be controlled through Crestron or other AV systems?

Yes. The model is listed as Crestron Connected, which supports professional AV control and automated room control. It also has RS232C in and out, an IR input and an RJ45 LAN input for network control. A government meeting room in Msheireb, for example, could operate the screen from a central control panel.

How do I manage several screens across different sites?

Control Manager is an embedded web monitoring tool that lets you check and control several displays in different locations in real time from internet-connected devices. The model also supports Wake on LAN, SNMP and status mailing. For a school group with campuses in several areas, this means content and settings can be changed without visiting each screen.

What are the power requirements?

The built-in power supply accepts AC 100-240 V at 50/60 Hz, which covers Qatar's 240 V mains supply. Typical consumption is 420 W, with a maximum of 560 W and 294 W in smart energy saving mode at 70%. Review circuit capacity with your electrician before installation, especially if several units share one supply.

How heavy is the screen and what mount does it need?

The head weighs 81.1 kg and the packed weight is 119 kg. The VESA mount interface is 800 x 400 mm. The wall or stand must be rated for this weight and match the VESA pattern. At just over 2 metres wide, the display also needs a planned route through doors and lifts, which a free site survey can check.

Is it suitable for rooms that get hot?

The operating range is 0 to 40 °C with 10 to 80% humidity. Spaces that can exceed 40 °C, such as unventilated corridors or glazed atriums, fall outside this range. Summer temperatures in Qatar can pass 45 °C, so confirm the room's cooling capacity with the SmartRooms Qatar team during the site survey.

Does it have Arabic on-screen menus?

Yes. The on-screen display language list includes Arabic alongside English and many other languages. Offices in Doha that work in Arabic and English side by side can set the menus to the language their staff use. Content language is separate and depends on the files you play.

Which ports are available for a laptop or media box?

The display has three HDMI inputs with HDCP 2.2/1.4, a DisplayPort input and output, a DVI-D input, two USB 2.0 Type A ports, audio in and out, and an RJ45 LAN input. HDMI out is not provided and there is no OPS slot, so an external computer connects through HDMI or DisplayPort.

What comes in the box?

The basic accessories include a remote controller with two batteries, a power cord, a 1.8 m DP cable, an IR/light sensor receiver, a quick start guide, a regulation book, a phone-to-RS232C gender adapter and eye-bolts. No optional accessories are listed. Procurement teams can check this list against their project before requesting additional cables.
