Peerless DS-MBZ942L-2X1 · Price in Qatar

Name: Peerless-AV DS-MBZ942L-2X1 Menu Board Ceiling Mount, 2 x 40-42 Inch
Brand: Peerless
SKU: peerless-ds-mbz942l-2x1
Availability: InStock

Overview

The Peerless-AV DS-MBZ942L-2X1 is a landscape ceiling mount for two displays measuring 40 to 42 inches. It carries up to 90.72 kg, installs on a ceiling or wall, and uses tool-less eight-point adjustment to align both screens on one plane. Tamper and theft resistant hardware comes included, suiting quick service restaurants and food courts in Doha, Lusail and the airport area. Request a quote.

What this two-display ceiling mount does

The Peerless-AV DS-MBZ942L-2X1 is a landscape ceiling mount that holds two displays between 40 and 42 inches, positioned side by side so they read as one menu board. Its maximum load is 90.72 kg, and the mount itself weighs approximately 22.27 kg before any displays are fitted. The frame has a matte black powder-coated finish and is listed for indoor use only.

Keeping both displays on one plane

Two-panel menu boards look untidy when one screen sits higher, lower or at a different angle from its neighbour. Connecting wall plates create one continuous mounting surface, and the tool-less eight-point adjustment lets the installer set every display onto the same plane. Horizontal adjustment narrows the visible gap between the panels. Tilt ranges from 0 to 15 degrees, and the continuous and Increlok tilt options hold both displays at an identical angle once set. Quick connect adaptor rails with an auto latch engage the wall plate as each display goes on, which speeds up setup.

Installation planning

Before ordering, confirm that the ceiling structure can carry the combined weight of the mount and both displays. The package includes the mount frame, adaptor rails, display mounting hardware and security hardware, and assembly is required. Key figures to plan around:

Overall size: 176.91 cm wide, 40 cm high, 18.97 cm deep
Mounting pattern: 1769 x 400 mm, with a minimum supported pattern of 100 x 100 mm
Fixed column minimum compatible length: part EXT018
Adjustable column: part ADD0203, adjusting to a minimum of 31 inches

Where it fits in Qatar

A quick service restaurant in a Doha shopping mall food court is the typical setting. Mounting the board above the ordering counter keeps the menu readable from the queue. Included tamper and theft resistant security hardware matters for public-facing units in malls and transport hubs. A fast-food outlet at Hamad International Airport or a cafe in Lusail refitting its boards can use the same frame. For open-front units, semi-outdoor terraces or locations exposed to dust and direct sun, confirm conditions with the SmartRooms Qatar team first, because the product is listed for indoor use only.

Planning a multi-outlet rollout

Restaurant groups standardising menu boards across several branches should prepare one specification per outlet, covering ceiling height, display size and column length. A site survey before ordering confirms ceiling structure and access. SmartRooms Qatar delivers to all eight municipalities of Qatar, offers professional installation, and accepts purchase orders (LPOs). Quotations are usually issued within one working day.

To request a quote for the DS-MBZ942L-2X1, send your display models, ceiling type and outlet location. We will confirm the column length and fitting details before you order.

Highlights

Holds two displays from 40 to 42 inches in landscape orientation
Maximum load capacity of 90.72 kg
Ceiling or wall installation supported
Tool-less eight-point adjustment with tilt from 0 to 15 degrees
Tamper and theft resistant security hardware included
Five-year limited manufacturer warranty

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

42 specifications · Source: manufacturer · checked Oct 2026

General Information9

Manufacturer: Peerless Industries, Inc
Manufacturer Part Number: DS-MBZ942L-2X1
Manufacturer Website Address: http://www.peerless-av.eu.com
Brand Name: SmartMount®
Product Series: DS-MBZ942L-2X1
Product Model: DS-MBZ942L-2X1
Product Name: DS-MBZ942L-2X1 Ceiling Mount
Packaged Quantity: 1 Unit
Product Type: Ceiling Mount

Product Information13

Device Supported: Display; Menu Board
Number of Displays Supported: 2
Maximum Load Capacity: 90.72 kg
Minimum Screen Size Supported: 40" (101.60 cm)
Maximum Screen Size Supported: 42" (106.68 cm)
Features: 3-axis; Adjustable Column; Adjustable Depth; Adjustable Length; Flat; Horizontal Adjustment; Increlock; Quick Connect; Tool-less Adjustment; Tool-less Micro-Adjustment
Orientation: Landscape
Mount Pattern Compatibility Type: Universal
Minimum Tilt Angle: 0°
Maximum Tilt Angle: 15°
Mount Function: Adjustable; Tilt
Mount Surface: Ceiling; Wall
Durability: Tamper Resistant; Theft Resistant

Physical Characteristics11

Color Family: Black
Product Color: Black
Finishing: Matte; Powder Coated
VESA Mount Compatible: Yes
Mounting Pattern: 1769 x 400
Minimum Mounting Pattern: 100 x 100
Form Factor: Ceiling Mountable
Height: 40 cm (15.75")
Width: 176.91 cm (69.65")
Depth: 18.97 cm (7.47")
Weight (Approximate): 22.27 kg

Miscellaneous8

Package Contents: DS-MBZ942L-2X1 Ceiling Mount; Mount Frame; Adaptor Rails; Display Mounting Hardware; Security Hardware
Application/Usage: Ceiling; Quick Serve Restaurant (QSR)
Indoor/Outdoor: Indoor
Certifications & Standards: RoHS, TAA, VESA
Manufacturer Product Class: Menu Board Ceiling
Assembly Required: Yes
TAA Compliant: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Warranty1

Limited Warranty: 5 Year

Downloads

4 files from the manufacturer

PDF Datasheets DS-MBZ942L-2X1_Product-Datasheet.pdf 311 KB PDF Manuals & guides DS-MBZ942L-2X1_Assembly-Instructions.pdf 3.3 MB DWG Drawings & CAD · Opens on manufacturer site DS-MBZ942L-2X1_CAD DRAWING.dwg URL Other documents · Opens on manufacturer site BIMobject

Questions about DS-MBZ942L-2X1

What is the Peerless-AV DS-MBZ942L-2X1 used for?

It is a landscape ceiling mount for two digital menu board displays measuring 40 to 42 inches. It is listed for quick service restaurant use, which is why it is typically fitted above ordering counters in food courts and cafes. The mount holds a combined load of up to 90.72 kg and can be installed on a ceiling or a wall, so it suits restaurants that want two aligned screens in one panel.

Which screen sizes and how many displays does it support?

It supports two displays, with a minimum screen size of 40 inches and a maximum of 42 inches. The frame is configured for landscape installation, so both displays must be mounted horizontally. The overall mounting pattern is 1769 x 400 mm, so check that each display's VESA hole spacing matches the mounting holes before ordering.

What is the maximum load and how much does the mount weigh?

The maximum load capacity for the whole assembly is 90.72 kg. The mount itself weighs approximately 22.27 kg before displays are added, so the combined weight of the mount and both screens must stay within that limit. Ask your installer to confirm that the ceiling structure can take the full load before fixing the frame.

Can it be wall-mounted as well as ceiling-mounted?

Yes. The product lists both ceiling and wall as supported mount surfaces. Wall installation suits a menu board on the back wall of a cafe or food court unit where ceiling access is limited, and the connecting wall plates still form one continuous mounting surface. The installer should confirm the wall can carry 22.27 kg for the mount plus the weight of both displays.

How do I keep both displays level and at the same angle?

Connecting wall plates form one continuous mounting surface, while the tool-less eight-point adjustment sets each display onto the same plane. Horizontal adjustment narrows the gap between the two panels. Tilt ranges from 0 to 15 degrees, and the continuous and Increlok tilt options keep both displays at the same angle. These points are set on site during installation.

Is the mount suitable for outdoor or semi-outdoor locations in Qatar?

The product is listed for indoor use only. Open-front units, semi-outdoor terraces and locations exposed to dust storms or direct sun need to be reviewed first. No operating temperature range is listed for this mount, so we cannot confirm it for hot or enclosed spaces. Ask the SmartRooms Qatar team to confirm site conditions before you order.

What does the box include?

The package contains the ceiling mount, mount frame, adaptor rails, display mounting hardware and security hardware, supplied as one unit per order. Assembly is required, so allow your installer time to fit the rails and frame before the displays go on. The quick connect adaptor rails with an auto latch are designed to make this stage faster.

Which column lengths are compatible?

Two column options are listed. For a fixed column, the minimum compatible length is set by part EXT018. For an adjustable column, part ADD0203 adjusts to a minimum of 31 inches. Measure the distance from the ceiling to your intended menu board height before choosing, because column length determines where both displays sit.

Does the mount include security features for public areas?

Yes. Security hardware is included, and the mount is designed to resist tampering and theft. This matters in a food court or mall unit where a menu board is within easy reach of passing shoppers, or at a transport hub where boards are left unattended for long periods.

How long is the warranty?

The manufacturer provides a five-year limited warranty on this mount, and SmartRooms Qatar supplies it with that manufacturer's warranty in place.

How should a restaurant group order mounts for several branches?

Prepare one list per branch showing ceiling type, display size and column length, then request a single quotation covering every outlet. SmartRooms Qatar delivers to all eight municipalities of Qatar, provides professional installation and accepts purchase orders (LPOs). Quotations are usually issued within one working day, which helps procurement teams plan rollouts.

What should be checked on site before the frame is fixed?

Confirm the ceiling can carry up to 90.72 kg, choose a column length that matches the target menu board height, and check for 176.91 cm of width and 18.97 cm of depth. In a live food court, keep service routes and customer access clear while the frame is fitted, and plan the work around the 1769 x 400 mm mounting pattern.
