Name: Peerless-AV DS-MBZ947L-2X1 Ceiling Mount for Two 46-48-inch Menu Boards
Brand: Peerless
SKU: peerless-ds-mbz947l-2x1
Availability: InStock

Overview

A landscape ceiling mount that holds two 46 to 48-inch menu boards side by side. It carries up to 90.72 kg, uses a 1960 x 400 mm pattern and offers tool-less adjustment with 0° to 15° tilt. Quick connect adaptor rails with auto latch speed up installation. Built for quick service restaurant menus in Doha, Lusail and West Bay food courts. Request a quote.

What this mount holds

The DS-MBZ947L-2X1 is a ceiling-mounted frame for two digital menu boards in landscape orientation. It is designed for displays between 46 and 48 inches, and its 1960 x 400 mm mounting pattern lines two panels up across the width of the frame. The frame measures 195.96 cm wide, 40 cm high and 18.97 cm deep, and weighs approximately 22.72 kg before displays are fitted. The package contains the mount frame, adaptor rails, display mounting hardware and security hardware. The displays themselves are not included.

Alignment and adjustment that matter on a menu wall

Two boards side by side only look right when they share one plane and one tilt angle. The frame offers tool-less depth adjustment at all four corners to bring every display onto the same plane, plus a tool-less 8-point adjustment for fine positioning. Tilt ranges from 0° to 15°, and the continuous and Increlok tilt options let every display on the frame sit at the same angle. Horizontal adjustment allows the installer to close the gap between the two panels so the wall reads as one surface.

Where it fits in Qatar

Quick service restaurants across Doha use this type of mount above the ordering counter, where two boards can show the main menu and promotions without taking up extra wall space. In food courts inside shopping malls in West Bay and Lusail, the mount suits menu walls that need two screens in one line. It also suits a new restaurant branch in Al Rayyan or Al Sadd, where the menu wall is fitted during the same works as the kitchen and service area.

The data lists this mount for indoor use only. If the planned site is a terrace or a semi-open area, confirm the conditions with the SmartRooms Qatar team before relying on it.

What to plan before installation

Confirm the ceiling structure can carry the mount, both displays and cabling, against a stated maximum load of 90.72 kg.
Check that the displays are 46 to 48 inches and use the 1960 x 400 mm mounting pattern.
Allow installation time, since the mount requires assembly on site.
For a fixed column, the minimum compatible length is EXT018; for an adjustable column, ADD0203 adjusts to a minimum of 31 inches.

SmartRooms Qatar offers a free site survey before ceiling work begins, which is a useful step when the ceiling is already finished.

Compliance, security and warranty

The mount is listed as TAA compliant and UL listed, is VESA compatible, and meets RoHS restrictions. The included security hardware helps deter tampering and theft in areas where customers can reach the menu. The manufacturer provides a 5-year limited warranty on the product.

To request a quote for the DS-MBZ947L-2X1, send your display model, ceiling details and quantity to the SmartRooms Qatar team. Quotations are usually issued within one working day, and we accept purchase orders for government entities and businesses across Qatar's eight municipalities.

Highlights

Holds two displays sized from 46 to 48 inches
Maximum load capacity of 90.72 kg
1960 x 400 mm mounting pattern, VESA compatible
Tool-less 8-point adjustment and 0° to 15° tilt
Quick connect adaptor rails with automatic latch
Security hardware included; 5-year limited warranty

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

43 specifications · Source: manufacturer · checked Oct 2026

General Information9

Manufacturer: Peerless Industries, Inc
Manufacturer Part Number: DS-MBZ947L-2X1
Manufacturer Website Address: http://www.peerless-av.eu.com
Brand Name: SmartMount®
Product Series: DS-MBZ947L-2X1
Product Model: DS-MBZ947L-2X1
Product Name: DS-MBZ947L-2X1 Ceiling Mount
Packaged Quantity: 1 Unit
Product Type: Ceiling Mount

Product Information13

Device Supported: Display; Menu Board
Number of Displays Supported: 2
Maximum Load Capacity: 90.72 kg
Minimum Screen Size Supported: 46" (116.84 cm)
Maximum Screen Size Supported: 48" (121.92 cm)
Features: 3-axis; Adjustable; Adjustable Column; Adjustable Depth; Adjustable Length; Flat; Horizontal Adjustment; Increlock; Quick Connect; Tilt; Tool-less Adjustment; Tool-less Micro-Adjustment
Orientation: Landscape
Mount Pattern Compatibility Type: Universal
Minimum Tilt Angle: 0°
Maximum Tilt Angle: 15°
Mount Function: Adjustable; Tilt
Mount Surface: Wall
Durability: Tamper Resistant

Physical Characteristics11

Color Family: Black
Product Color: Black
Finishing: Matte; Powder Coated
VESA Mount Compatible: Yes
Mounting Pattern: 1960 x 400
Minimum Mounting Pattern: 100 x 100
Form Factor: Ceiling Mountable
Height: 40 cm (15.75")
Width: 195.96 cm (77.15")
Depth: 18.97 cm (7.47")
Weight (Approximate): 22.72 kg

Miscellaneous9

Package Contents: DS-MBZ947L-2X1 Ceiling Mount; Mount Frame; Adaptor Rails; Display Mounting Hardware; Security Hardware
Application/Usage: Quick Serve Restaurant (QSR)
Indoor/Outdoor: Indoor
Certifications & Standards: TAA, VESA, UL
Manufacturer Product Class: Menu Board Ceiling
Assembly Required: Yes
TAA Compliant: Yes
UL Listed: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Warranty1

Limited Warranty: 5 Year

Downloads

4 files from the manufacturer

PDF Datasheets DS-MBZ947L-2X1_Product-Datasheet.pdf 311 KB PDF Manuals & guides DS-MBZ947L-2X1_Assembly-Instructions.pdf 3.3 MB DWG Drawings & CAD · Opens on manufacturer site DS-MBZ947L-2X1_CAD DRAWING.dwg URL Other documents · Opens on manufacturer site BIMobject

Questions about DS-MBZ947L-2X1

What is the DS-MBZ947L-2X1 built for?

It is a ceiling mount that holds two digital menu boards in landscape orientation, sized for screens from 46 to 48 inches. Peerless-AV designed it for quick service restaurant menu walls, where a pair of boards sits above the ordering counter. The stated maximum load is 90.72 kg, and the mounting pattern is 1960 x 400 mm.

Are the displays included with the mount?

No. The package contains the mount frame, adaptor rails, display mounting hardware and security hardware only. Your displays must be sourced separately and sit within the 46 to 48-inch range. Before ordering, send your display model to the SmartRooms Qatar team so we can confirm it matches the 1960 x 400 mm mounting pattern.

How much weight can the mount carry?

The stated maximum load capacity is 90.72 kg, and the mount itself weighs approximately 22.72 kg. Loads on a restaurant ceiling add up quickly once displays and cabling are included, so have the installer confirm the ceiling structure before fixing the frame. SmartRooms Qatar offers a free site survey that covers this check.

How does the adjustment work?

The mount offers tool-less depth adjustment at all four corners to bring every display onto the same plane, plus a tool-less 8-point adjustment for fine positioning. Horizontal adjustment lets the installer close the gap between the two panels, and tilt runs from 0° to 15°. Because adjustment needs no tools, fine alignment does not depend on extra equipment during the install.

Can both menu boards be tilted at the same angle?

Yes. The continuous and Increlok tilt options are designed so all displays on the frame tilt at the same angle, which keeps the two boards visually aligned. In a quick service restaurant fit-out in Doha or Lusail, this matters because customers read the two screens as one menu, and any mismatch in angle is visible from the queue.

Can it be installed on an outdoor terrace or in a semi-open area?

No. The data lists the mount for indoor use only, and it does not give an operating temperature range. Summer temperatures in Qatar can exceed 45°C, so a covered terrace in Al Wakrah or a semi-open food court is not a suitable location unless the conditions are confirmed first. Ask the SmartRooms Qatar team to review the exact space.

Which column accessories are compatible, and what are the minimum lengths?

The source lists EXT018 as the minimum compatible length for a fixed column, and ADD0203 as the minimum for an adjustable column, which adjusts down to 31 inches. Confirm your ceiling height against these lengths before ordering, so the menu boards sit at the correct viewing height above the counter.

Does the mount deter theft or tampering?

Yes. The mount includes security hardware and is classed as tamper resistant. This suits customer-facing menu walls in busy food courts, such as those in Msheireb or West Bay malls, where displays are within easy reach of the public. The security hardware is supplied in the package, so it does not need to be bought separately.

How long does installation take?

The mount requires assembly on site, and the quick connect adaptor rails attach to the support frame with an automatic latch to speed up the work. The data does not give an installation time, because it depends on the ceiling and the number of units. SmartRooms Qatar can estimate timing after a free site survey, and quotations are usually issued within one working day.

What warranty applies to this mount?

The manufacturer provides a 5-year limited warranty on this mount, and SmartRooms Qatar supplies it with that manufacturer warranty coverage. The warranty terms are those of Peerless-AV. If your procurement team needs written terms before awarding an order, request the warranty document together with your quotation.

Can we order several units for multiple branches or a tender?

Yes. SmartRooms Qatar supplies all eight municipalities of Qatar and accepts purchase orders (LPOs) and government tenders, including Monaqasat. Payment can be made by bank transfer, cheque or purchase order. A restaurant group opening branches in Lusail and Al Khor can request one quotation that covers every site.

Does the mount meet compliance requirements for public procurement?

The listing shows TAA compliance, UL listing, VESA compatibility and RoHS restriction compliance. A procurement team handling a ministry cafeteria or a public-sector tender can use these listings in its technical evaluation. Ask for the datasheet with your quotation so the compliance details are documented for the file.
