Philips 43BDL6017P 43-inch 4K Signage Display

Name: Philips 43BDL6017P 43-inch 4K Signage Display
Brand: Philips
SKU: philips-43bdl6017p-00
Availability: InStock

Overview

The Philips 43BDL6017P is a 43-inch 4K UHD signage display from the Signage 6000 Series, rated for 24/7 operation in landscape or portrait. Its 800 cd/m² brightness suits lobbies, corridors and canteens with daylight. A built-in OPS slot, three HDMI 2.0 inputs and RS232 control make it practical for hospitals, hotels, schools and transport hubs in Qatar that need reliable content screens.

What the Philips 43BDL6017P is built to do

The Philips 43BDL6017P is a 43-inch signage display from the P-Line of the Signage 6000 Series. Its 3840 x 2160 panel and 16:9 format suit menus, promotions, wayfinding and information content that must stay sharp at close range. The source rates it for 24/7 operation in both landscape and portrait orientation, so one model can serve a wide wall screen or a tall column. With 800 cd/m² brightness, it stays readable in reception areas and corridors where daylight reaches the glass.

Specifications that matter for planning

Several display figures help when comparing this model with other screens. The typical contrast ratio is 1200:1, the dynamic contrast ratio is 500,000:1, and the typical response time is 8 ms. The viewing angle is 178 degrees both horizontally and vertically, and the panel shows 1.07 billion colours at 3840 x 2160 and 60 Hz. The measured diagonal is 42.5 inches (108 cm).

Connections include three HDMI 2.0 inputs, one DisplayPort 1.2 input and one DVI-I input, plus HDMI 2.0 and DisplayPort 1.2 outputs for signal loop-through. Two USB 2.0 ports play BMP, JPEG and PNG images, and H.264, H.265, Motion JPEG, MPEG1/2 and WMV3 video. An OPS slot, RJ45 and RS232 control, IR input and output, and an ambient light sensor and thermal sensor complete the list.

Where it fits in Qatar

Clinics and hospitals: a waiting-area screen in Al Sadd or Doha showing queue numbers and health information, installed inside an air-conditioned waiting hall.
Hotels and serviced apartments: a portrait screen beside lift lobbies in West Bay or The Pearl, showing dining times and local directions.
Transport areas: flight and transfer information near the arrivals zone around Hamad International Airport, where strong ambient light makes 800 cd/m² useful.

What to plan before ordering

The operating range is 0 to 40 °C with 20 to 80 percent relative humidity, without condensation. Qatar summers can pass 45 °C, so the display should sit in an air-conditioned space and away from direct sun through glass. For a window-facing or semi-outdoor position, have the SmartRooms Qatar team confirm the environment before you order. The IP5X rating covers dust protection only and should not be read as weatherproof.

Plan the mounting around the physical figures: 973 mm wide, 561.2 mm high, 64.0 mm deep at the wall mount and 14.12 kg in weight. The wall-mount pattern is 200 x 200 mm with M6 fixings. A free site survey lets the installation team check wall construction and cable routes before a portrait or multi-screen install. The unit accepts 100 to 240 VAC at 50 to 60 Hz, typically draws 85 W with a 150 W maximum, and has standby consumption below 0.5 W. Three power cables are included, and the team will confirm the cable and socket arrangement for your site.

Ordering from SmartRooms Qatar

The package includes a remote control with AAA batteries, a 3 m RS232 cable, an RS232 daisy-chain cable, two Edge Alignment Kits, a USB cover and an AC switch cover. The manufacturer warranty is three years. Philips Wave remote management is available as an option. SmartRooms Qatar delivers to all eight municipalities of Qatar and offers professional installation. Schools, ministries and companies can order by purchase order (LPO) or government tender and pay by bank transfer, cheque or purchase order. Request a quote for the Philips 43BDL6017P and our team will usually reply within one working day.

Highlights

43-inch 4K UHD panel at 3840 x 2160 resolution
800 cd/m² brightness for daylit reception areas
Rated for 24/7 operation in landscape or portrait
Tiles up to 15 x 15 in a video wall
Three HDMI 2.0 inputs, DisplayPort, DVI-I and OPS slot
Three-year manufacturer warranty

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

60 specifications · Source: manufacturer · checked Oct 2026

Connectivity6

Audio input: 3.5 mm jack
External control: IR (in/out) 3.5 mm jack; RJ45; RS232C (in/out) 2.5 mm jack; Ambient Light Sensor
Video output: DisplayPort 1.2 (x 1); HDMI 2.0 (x 1)
Video input: Display Port1.2 (x 1); DVI-I (x 1); HDMI 2.0 (x 3)
Audio output: 3.5 mm jack
Other connections: USB 2.0 (x 2); OPS; Thermal sensor

Convenience7

Network controllable: RS232; RJ45
Tiled Matrix: Up to 15 x 15
Energy-saving functions: Smart Power
Screen-saving functions: Pixel Shift, Low Bright
Placement: Landscape (24/7); Portrait (24/7)
Ease of installation: Carrying Handles; Edge Alignment Kit; Conformal Coating
Signal loop through: DisplayPort; RS232; HDMI; IR Loop through

Accessories2

Included Accessories: AC Switch Cover; Philips logo (x 1); Power cable (x 3); Quick start guide (x 1); Remote control and AAA batteries; RS232 cable (3 m) (x 1); RS232 daisy chain cable (x 1); USB Cover (x 1); Edge Alignment Kit (x 2)
Stand: BM05922(optional)

Dimensions10

Set Depth (inch): 3.02 inch (at handle), 2.52 (at wall mount) inch
Product weight (lb): 31.13 lb
Bezel width: 13.9 mm (Even bezel)
Product weight: 14.12 kg
Set Depth: 76.80 mm (at handle), 64.0 mm (at wall mount) mm
Set Width: 973 mm
Set Width (inch): 38.31 inch
Set Height: 561.2 mm
Wall Mount: 200 x 200 mm, M6
Set Height (inch): 22.1 inch

Sound1

Built-in speakers: 2 x 10 W RMS

Power4

Consumption (Max): 150 W
Mains power: 100 ~ 240 VAC, 50 ~ 60 Hz
Consumption (Typical): 85 W
Energy Label Class: G

Multimedia Applications3

USB Playback Picture: BMP; JPEG; PNG
USB Playback Video: H.264; H.265; Motion JPEG; MPEG1/2; WMV3
USB Playback Audio: AAC; MPEG; HEAAC

Miscellaneous3

Regulatory approvals: CE; FCC, Class A; CB; BSMI; EAC; EMF; VCCI; PSB; ETL; EPA
On-Screen Display Languages: Arabic; Dutch; Danish; English; French; Finnish; German; Italian; Japanese; Norwegian; Polish; Portuguese; Russian; Spanish; Swedish; Simplified Chinese; Turkish; Traditional Chinese
Warranty: 3 year warranty

Operating conditions7

Temperature range (storage): -20 ~ 60 °C
MTBF: 50,000 hour(s)
Temperature range (operation): 0 ~ 40 °C
Humidity range (storage) [RH]: 5~95% RH (No condensation)
Humidity range (operation)[RH]: 20~80% RH (No condensation)
Ingress protection: IP5X
Altitude: 0 ~ 5000 m

Picture/Display15

Response time (typical): 8 ms
Panel technology: ADS
Pixel pitch: 0.2451 x 0.2451 mm
Panel resolution: 3840 x 2160
Viewing angle (horizontal): 178 degree
Aspect ratio: 16:9
Dynamic contrast ratio: 500,000:1
Display colours: 1.07 billion
Optimum resolution: 3840 x 2160 @ 60 Hz
Brightness: 800 cd/m²
Diagonal screen size (metric): 108 cm
Diagonal screen size (inch): 42.5 inch
Contrast ratio (typical): 1200:1
Viewing angle (vertical): 178 degree
Haze: 25%

Supported Display Resolution2

Computer formats: 1440 x 900, 60 Hz; 1024 x 768, 60, 70, 75 Hz; 1152 x 864, 75 Hz; 1152 x 870, 75 Hz; 1280 x 1024, 60 Hz; 1280 x 720, 60 Hz; 1280 x 800, 60 Hz; 1600 x 1200, 60 Hz; 1680 x 1050, 60 Hz; 1920 x 1080, 60 Hz; 640 x 480, 60, 67, 72, 75 Hz; 720 x 400, 70 Hz; 800 x 600, 56, 60, 72, 75 Hz
Video formats: 480p, 60 Hz; 576p, 50 Hz; 720p, 50, 60 Hz; 1080i, 50, 60 Hz; 1080p, 50, 60 Hz; 3840 x 2160, 30Hz; 3840 x 2160, 60 Hz

Downloads

6 files from the manufacturer

PDF Datasheets 43BDL6017P_00_en_AA_b2c_GLL.pdf 438 KB PDF Manuals & guides 43_50_55BDL6017P_Traditionalch.pdf 11.1 MB PDF Manuals & guides 43_50_55BDL6017P__eng.pdf 10.1 MB PDF Manuals & guides · Opens on manufacturer site 1756185415-43_50_55bdl6017p_arabic.pdf PDF Drawings & CAD Outline_Drawing_Philips_43BDL6017P_V0_1_20241122.pdf 544 KB PDF Certificates & compliance PCF-43BDL6017P.pdf 187 KB

Questions about 43BDL6017P/00

What is the Philips 43BDL6017P best suited for?

It suits public-facing screens that run for long hours in busy indoor spaces, such as clinic waiting areas, hotel lobbies, shopping mall entrances and transport hubs. Its 800 cd/m² brightness keeps content readable where daylight reaches the screen, and the 24/7 rating covers continuous playback. A queue-number screen in a clinic in Al Sadd is a typical example of its use.

Can it be mounted in portrait orientation for 24/7 use?

Yes. The source data lists both landscape and portrait placement rated for 24/7 operation. Portrait mounting works well beside a lift lobby or along a hotel corridor in West Bay, where a tall, narrow panel shows directions or dining times without using much wall width. Confirm the mounting height and wall construction during a free site survey before installation.

Is it suitable for hot or outdoor locations in Qatar?

The source data does not rate it for outdoor exposure, and the IP5X rating covers dust protection only. Its operating range is 0 to 40 °C, while Qatar summers can exceed 45 °C. Install it in an air-conditioned indoor space and keep it out of direct sun through glass. For a window-facing or semi-outdoor position, ask the SmartRooms Qatar team to confirm the environment before you request a quote.

What are the storage and humidity limits?

Operating temperature is 0 to 40 °C and operating humidity is 20 to 80 percent RH without condensation. Storage is rated -20 to 60 °C at 5 to 95 percent RH, also without condensation. The altitude range is 0 to 5,000 m and the MTBF is 50,000 hours. Keep the packed unit in a dry, cool store until installation day to avoid moisture exposure after transport.

How many screens can it form in a video wall?

The data lists tiling of up to 15 x 15 displays, and two Edge Alignment Kits are included. Its 13.9 mm even bezel keeps seams narrow across the wall. A control room in Lusail or a dispatch centre at an energy site in Ras Laffan could use a 3 x 3 arrangement for monitoring. Confirm the wall, bracket and video source needs for your matrix when you request a quote.

Which inputs and outputs does it have?

Inputs are three HDMI 2.0, one DisplayPort 1.2 and one DVI-I. Outputs are one HDMI 2.0 and one DisplayPort 1.2 for loop-through to a second display. Audio is available through a 3.5 mm input and output. There are also two USB 2.0 ports and an OPS slot. Count the ports you need before ordering, especially when several screens are chained along one corridor.

What is the OPS slot for?

OPS stands for Open Pluggable Specification, a slot that takes a compatible media player module so content can run inside the display without a separate external player. The source data lists an OPS slot but does not name supported modules, so confirm compatibility with the SmartRooms Qatar team before buying a module. A hotel lobby in Msheireb could keep its playlist inside the screen this way.

Can it be managed remotely?

Yes. The display is network controllable through RJ45 and RS232, and it has IR input and output for remote control. Philips Wave remote management can be added as an option for managing several displays from one place. A university in Education City, or a facilities team running screens across a campus, could use this to manage content and settings centrally.

Which media files can it play from USB?

USB playback supports BMP, JPEG and PNG images, H.264, H.265, Motion JPEG, MPEG1/2 and WMV3 video, and AAC, MPEG and HE-AAC audio. A school in Al Wakrah updating classroom notices could load JPEG slides and an H.264 video onto one USB drive and play them without a PC. Two USB 2.0 ports are fitted, and a USB cover is included.

Does it work with Qatar's power supply?

The mains rating is 100 to 240 VAC at 50 to 60 Hz, which covers Qatar's 240 V, 50 Hz supply. Typical consumption is 85 W and maximum is 150 W, with standby below 0.5 W. Smart Power is listed as an energy-saving function and the energy label class is G. Three power cables are included, and SmartRooms Qatar will confirm the cable and socket arrangement for your site.

Are the built-in speakers enough for a lobby?

The display has two 10 W RMS speakers, which suit short announcements or background audio in a lobby or hotel reception. For a lecture hall or a large meeting space, plan external audio through the 3.5 mm audio output. A hotel in The Pearl could use the built-in speakers for a welcome loop, while a conference room would normally rely on a dedicated sound system.

How do we order it through an LPO or government tender?

Send your requirement and quantity, and SmartRooms Qatar will usually reply with a quotation within one working day. Purchase orders (LPOs) and government tenders, including Monaqasat, are accepted, with payment by bank transfer, cheque or purchase order. The Philips 43BDL6017P carries a three-year manufacturer warranty, and professional installation and a free site survey are available across all eight municipalities.
