43BFL2214/12

A 43-inch 4K panel for corporate signage and information screens

The Philips 43BFL2214/12 is a 43-inch Ultra HD LED display from the B-Line range, intended for reception areas, corridors, meeting rooms and internal information points. The 3840 x 2160 panel offers four times the pixel count of a Full HD screen, and the set is listed with a 16/7 landscape operation rating, which fits screens that stay on through long working days.

Android TV, Chromecast and wireless sharing

The display runs Android TV 9 (Pie) with 16 GB of flash memory, so scheduled content and the signage tools built into the software run on the screen itself without a separate media player. Chromecast is built in, and 802.11ac Wi-Fi with Wi-Fi Direct lets staff share presentations from Windows, Apple and Android devices without cables. Secure Sharing and network-managed sharing options give IT teams control over how content reaches the panel.

Control, scheduling and integration with building systems

For facilities and AV teams, the B-Line supports Crestron Connected (v2), Extron, Neets and SICP over IP, along with CMND IP remote management and JEDI Android API control. Signage functions include a scheduler, banners and CMND&Create, and the home screen, location name and device name can be customised. Auto Input Selection, Auto Power ON and Auto Power OFF help the screen follow the room routine, and RJ-48 external control with IR in and out covers older control setups.

• Connectivity: three HDMI 2.0 inputs with HDCP 2.2, one on the side and two on the rear panel, with ARC on all ports.
• Storage and media: USB 3.0 on the side, USB 2.0 on the rear, and playback of JPG, PNG, MP4-class HEVC, H.264 and MKV content.
• Network: RJ-45 LAN for wired networks, plus 802.11ac Wi-Fi for wireless deployments.
• Tuner: DVB-T/T2/C reception through an IEC-75 antenna input, with a CI+ 1.3.2 slot.

Where it fits in Qatar

A corporate reception in West Bay could use one panel beside the front desk to show visitor information and company news, with the playlist updated from head office over the network.

A clinic waiting area in Al Sadd might display queue details and health messages on a schedule, with the set switched off automatically after clinic hours through its auto switch-off timer.

A training room at a logistics company in the Industrial Area could use the panel for shift notices and safety briefings, with the screen controlled by the building's existing AV system through Crestron or Extron.

What to plan before installation

At 958 mm wide, 560 mm high and 7.6 kg, the panel is a manageable size for a standard wall installation. The wall mount pattern is M6 fixings on 100 x 200 mm, so mounting hardware and wall type should be confirmed before the day of installation. The operating ambient range is 0 °C to 40 °C, which is exceeded by Qatar summer conditions above 45 °C, so install the display in air-conditioned indoor spaces rather than unshaded or poorly ventilated areas. The mains input is rated 220-240 V and 50-60 Hz, which covers Qatar's 240 V, 50 Hz supply, but the supplied power cord should be checked against the BS 1363 socket in the room. For energy planning, the set carries energy class F, an EU energy label power of 51 W and standby consumption below 0.3 W. The package includes the remote control, two AAA batteries, a power cord and an RJ48 to DB9 adapter, and the optional Setup RC 22AV9574A/12 can be added to the quotation.

To receive a fixed quotation for the Philips 43BFL2214/12, send SmartRooms Qatar the quantity, the site location and whether you need wall mounts or a site survey. Quotations are usually issued within one working day, and purchase orders and government tender submissions are accepted. Request a quote today.
