65BDL6017P/00

What the Philips 65BDL6017P does

The Philips 65BDL6017P is a 65-inch display from the Signage 6000 Series, designed to run around the clock in public-facing spaces. Its 3840 x 2160 ADS panel gives 4K detail on a 16:9 screen, and the 800 cd/m² brightness keeps menus, timetables and promotions readable in well-lit reception areas where a standard screen would wash out. Viewing angles are rated at 178 degrees both horizontally and vertically, so people approaching from the side can still read the content.

The specifications that matter for a Qatar deployment

Three figures tend to decide a signage purchase: brightness, operating temperature and power draw. The 65BDL6017P lists 800 cd/m² brightness, an operating range of 0 to 40 °C with 20 to 80% relative humidity and no condensation, and an IP5X ingress rating. Power is rated at 100 to 240 VAC, 50 to 60 Hz, with a maximum draw of 210 W and a typical draw of 128 W. Standby consumption is below 0.5 W, and the energy label class is G.

Connectivity, control and playback

• Three HDMI 2.0 inputs, one DisplayPort 1.2 input and one DVI-I input
• DisplayPort 1.2 and HDMI 2.0 outputs with loop-through for passing a signal to the next display
• An OPS slot for an OPS media player, plus two USB 2.0 ports
• RJ45 and RS232 control, with IR in and out and an ambient light sensor
• Built-in speakers rated at 2 x 10 W RMS, plus 3.5 mm audio input and output

Philips Wave remote management can be added as an option for managing displays across a site. It is not part of the standard unit, so confirm it in your quotation if you need it. The USB ports can play images in BMP, JPEG and PNG and video in H.264, H.265, Motion JPEG, MPEG-1/2 and WMV3. The on-screen menus include Arabic and English among 18 languages.

Where it fits across Qatar

A hotel lobby in West Bay might use the panel in portrait orientation for a guest information wall beside the lifts, with content scheduled from a media player in the back office. In Lusail, a shopping centre could run promotions on a landscape screen near the main atrium, where the 800 cd/m² brightness helps the content hold up against daylight from glazed entrances. A university building in Education City might use several units to publish room bookings and campus notices at corridor junctions.

Planning the installation

The set weighs 27.8 kg and measures 1462.3 mm wide by 837.3 mm high. Depth is 89.9 mm at the handles and 69.0 mm at the wall mount, and the wall mount pattern is 400 x 400 mm with M8 fixings. The carrying handles help during handling, and the optional BM05922 stand is available for freestanding use. A free site survey is worth booking before wall mounting, so the wall structure and bracket can be checked against the weight and the viewing height.

Environment is the main planning point. The operating range tops out at 40 °C, while outdoor summer temperatures in Qatar regularly pass 45 °C. Install the display in an air-conditioned space, keep it away from direct sunlight and glazing where heat builds up, and confirm the location with the SmartRooms Qatar team before ordering. The IP5X rating is a dust-protection rating and does not make the unit suitable for outdoor use.

The unit accepts 100 to 240 VAC, which covers Qatar's 240 V supply. Three power cables are included; confirm the plug type matches your socket before the order is placed.

Request a quote

Quotations from SmartRooms Qatar are usually issued within one working day, and we deliver to all eight municipalities of Qatar, with professional installation available. Schools, ministries and companies can issue a purchase order (LPO), and government tenders can be submitted through Monaqasat. Tell us how many units you need, where they will hang and what content they will show, then request a quote for the Philips 65BDL6017P today.
