Philips 86BDL4511D/00 86-inch 4K UHD Signage Display

Name: Philips 86BDL4511D/00 86-inch 4K UHD Signage Display
Brand: Philips
SKU: philips-86bdl4511d-00
Availability: InStock

Overview

The Philips 86BDL4511D/00 is an 86-inch Signage 4000 Series D-Line display with 3840 x 2160 UHD resolution, 500 cd/m² brightness and IPS panel technology. It runs in landscape or portrait around the clock and offers DisplayPort, HDMI, DVI-I and RS232 control for video walls and lobbies. Suited to Qatari malls, hotels and corporate lobbies needing a large, always-on screen. Request a quote from SmartRooms Qatar.

What the 86BDL4511D/00 is built for

The Philips 86BDL4511D/00 sits in the Signage 4000 Series D-Line range and is aimed at public and staff-facing screens that run for long hours. Its 85.6-inch (217.4 cm) diagonal 4K UHD panel uses IPS technology and is rated for 178 degree horizontal and vertical viewing angles, so content stays readable from the side of a busy lobby or corridor. The display can be mounted in landscape or portrait orientation, both rated for 24/7 operation, which suits menus, wayfinding and information boards.

The picture and connectivity facts that matter

The panel offers 3840 x 2160 resolution at 60 Hz, a 0.4935 mm pixel pitch and 500 cd/m² brightness. Its 1200:1 typical contrast ratio and 8 ms typical response time suit moving content, while the 1.07 billion colour rating and 25% haze figure help you judge how it will look under bright ceiling lights. On the input side you get one DisplayPort 1.2, three HDMI 2.0, one DVI-I and two USB 2.0 ports, plus an OPS connection for an optional computing module. Control is handled through RS232C, RJ45 and IR, with loop-through outputs for DisplayPort, HDMI, RS232 and IR so several screens can be linked from one source.

Where it fits across Qatar

Hotel and mall lobbies: a hotel reception in West Bay or a mall atrium in Al Sadd can run a portrait or landscape loop of event and wayfinding content, with the Smart Power and Low Bright settings helping manage energy use during long operating hours.
Ministry and corporate reception areas: a government office in Msheireb or a headquarters in Lusail can use the hidden, lockable keyboard controls and Arabic or English on-screen menus to keep settings out of public hands.
Training rooms and boardrooms: at 1929.0 mm wide, the screen suits a lecture hall or boardroom in Education City or a training centre in the Industrial Area, where a presenter needs to show detailed drawings or spreadsheets.

What to plan before ordering

Plan for weight and wall structure first. The set weighs 50.24 kg, measures 1929.0 mm wide by 1100.0 mm high and is 69.5 mm deep at the wall mount, using a 600 x 400 mm M8 mounting pattern. Confirm that the wall or stand can carry that load. SmartRooms Qatar offers a free site survey to check position, access and cable routes before installation. Plan the environment too: the display is rated for operation between 0 and 40 °C, with 20 to 80% relative humidity without condensation and altitude up to 3000 m. An air-conditioned indoor space is the practical choice in Qatar, where outdoor and sun-facing summer temperatures can exceed that range.

The mains input is rated at 100 to 240 VAC and 50 to 60 Hz, which covers Qatar's 240 V, 50 Hz supply. Typical consumption is 355 W, maximum is 560 W and standby is under 0.5 W. The energy label class is G, so include running costs in your budget when comparing units. The unit carries a 3-year manufacturer warranty and a 50,000-hour MTBF rating. Included accessories are a remote control, RS232 cables, a 1.8 m IR sensor cable, wire clampers, an AC power cord and a quick start guide.

To check fit, connectivity and delivery to your site, request a quote from SmartRooms Qatar. We supply, deliver to all eight municipalities of Qatar and arrange professional installation, and quotations usually come within one working day. Several units for a school or government body can be ordered on one LPO.

Highlights

85.6-inch diagonal 4K UHD IPS panel
3840 x 2160 resolution and 500 cd/m² brightness
Landscape and portrait operation, both rated 24/7
DisplayPort 1.2, three HDMI 2.0, DVI-I and OPS connection
RS232C, RJ45 and IR control with loop-through outputs
Built-in speakers rated 2 x 10 W RMS

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

57 specifications · Source: manufacturer · checked Oct 2026

Connectivity6

Audio output: 3.5 mm jack
Video output: DisplayPort 1.2 (x 1); HDMI 2.0 (x 1)
Audio input: 3.5 mm jack
External control: IR (in/out) 3.5 mm jack; RJ45; RS232C (in/out) 2.5 mm jack
Video input: Display Port1.2 (x 1); DVI-I (x 1); HDMI 2.0 (x 3); USB 2.0 (x 2)
Other connections: OPS

Convenience6

Placement: Landscape (24/7); Portrait (24/7)
Energy-saving functions: Smart Power
Screen-saving functions: Pixel Shift, Low Bright
Network controllable: RS232; RJ45
Signal loop through: DisplayPort; RS232; HDMI; IR Loop through
Keyboard control: Hidden; Lockable

Accessories1

Included Accessories: AC Switch Cover; Philips logo (x 1); RS232 daisy-chain cable; AC power cord; IR sensor cable (1.8 m) (x 1); Quick start guide (x 1); Remote control and AAA batteries; RS232 cable; USB Cover and screw x 1; Wire Clamper (x 3)

Dimensions10

Wall Mount: 600 (H) x 400 (V) mm, M8
Set Height: 1100.0 mm
Set Width (inch): 75.94 inch
Product weight: 50.24 kg
Set Depth (inch): 2.74 (D@Wall mount)/ 3.61 (D@Handle) inch
Product weight (lb): 110.67 lb
Bezel width: 15.5 mm (Even bezel)
Set Width: 1929.0 mm
Set Depth: 69.5 (D@Wall mount)/91.8 (D@Handle) mm
Set Height (inch): 43.31 inch

Sound1

Built-in speakers: 2 x 10 W RMS

Power4

Consumption (Max): 560 W
Mains power: 100 ~ 240 VAC, 50 ~ 60 Hz
Energy Label Class: G
Consumption (Typical): 355 W

Multimedia Applications3

USB Playback Picture: BMP; JPEG; PNG
USB Playback Video: H.263; H.264; H.265; MPEG
USB Playback Audio: AAC; MPEG; HEAAC

Operating conditions6

Altitude: 0 ~ 3000 m
Temperature range (storage): -20 ~ 60 °C
Humidity range (operation)[RH]: 20–80% RH (No condensation)
Temperature range (operation): 0 ~ 40 °C
Humidity range (storage) [RH]: 5–95% RH (No condensation)
MTBF: 50,000 hour(s)

Miscellaneous3

Regulatory approvals: CE; FCC, Class A; CCC; RoHS; CB; BSMI; EMF; VCCI; PSB; ETL; CECP; EAC
On-Screen Display Languages: Arabic; Dutch; Danish; English; French; Finnish; German; Italian; Japanese; Norwegian; Polish; Portuguese; Russian; Spanish; Swedish; Simplified Chinese; Turkish; Traditional Chinese
Warranty: 3 year warranty

Picture/Display15

Optimum resolution: 3840 x 2160 @60 Hz
Brightness: 500 cd/m²
Diagonal screen size (metric): 217.4 cm
Pixel pitch: 0.4935 x 0.4935 mm
Panel resolution: 3840 x 2160
Display colours: 1.07 Billion
Response time (typical): 8 ms
Panel technology: IPS
Viewing angle (horizontal): 178 degree
Aspect ratio: 16:9
Dynamic contrast ratio: 500,000:1
Contrast ratio (typical): 1200:1
Diagonal screen size (inch): 85.6 inch
Haze: 25%
Viewing angle (vertical): 178 degree

Supported Display Resolution2

Video formats: 480i, 60 Hz; 480p, 60 Hz; 576p, 50 Hz; 576i, 50 Hz; 720p, 50,60 Hz; 1080i, 50, 60 Hz; 1080p, 50, 60 Hz; 2160p, 24, 30, 60 Hz
Computer formats: 640 x 480, 60 Hz; 800 x 600, 60 Hz; 1024 x 768, 60 Hz; 1280 x 720, 60 Hz; 1280 x 1024, 60 Hz; 1440 x 900, 60 Hz; 1600 x 900, 60 Hz; 1680 x 1050, 60 Hz; 1920 x 1080, 60 Hz; 3840 x 2160, 30, 60 Hz

Downloads

3 files from the manufacturer

PDF Datasheets 86BDL4511D_00_2021-11-01_01h19m53s.pdf 552 KB PDF Drawings & CAD 86BDL4511D_Outline_Drawing_without_Stand_V1_0_20210603.pdf 893 KB PDF Certificates & compliance 86BDL4511D_Label_1054891.pdf 70 KB

Questions about 86BDL4511D/00

Which settings is this 86-inch model best suited for in Qatar?

The Philips 86BDL4511D/00 suits lobbies, reception areas and conference spaces where a large, always-on screen is needed. Its 85.6-inch 4K UHD panel at 500 cd/m² stays readable in well-lit areas, and it is rated for 24/7 operation in landscape or portrait. Typical fits include a hotel reception in West Bay showing arrival information, or a Lusail office lobby showing the day's event schedule.

Can I mount it in portrait for a digital menu or wayfinding board?

Yes. The display is rated for both landscape and portrait placement at 24/7 operation, so it works for vertical wayfinding in a mall corridor or a menu board beside a hotel lobby. Confirm the chosen orientation during a site survey so the wall mount and cable routes are planned before installation.

Can it go outside or near a sun-facing window in summer?

The panel is rated for operation between 0 and 40 °C and 20 to 80% relative humidity without condensation. Summer temperatures in Qatar can exceed 45 °C, so the practical choice is an air-conditioned indoor space. If the lobby sits behind a large glazed facade in Lusail, ask the SmartRooms Qatar team to review sun exposure, glare and cooling before you confirm the position.

How many video sources can be connected at once in a control room?

The inputs are one DisplayPort 1.2, three HDMI 2.0, one DVI-I, two USB 2.0 and an OPS connection for an optional computing module. In an operations room in the Industrial Area that shows plant data, a camera feed and a dashboard from separate computers, you can connect several sources and switch between them. Check that your source outputs match these ports before ordering.

Can it be controlled from a central system across a school campus?

Yes. It offers RS232C in and out through 2.5 mm jacks, RJ45 for network control, and IR in and out through 3.5 mm jacks. Loop-through options for DisplayPort, HDMI, RS232 and IR help link screens across several buildings. For a school in Education City with multiple buildings, plan the control cabling and network requirements with your IT team before ordering.

Which media formats can it play from a USB drive?

USB playback supports BMP, JPEG and PNG pictures, H.263, H.264, H.265 and MPEG video, and AAC, MPEG and HEAAC audio. This suits a training room or a small reception screen where staff update a playlist on a flash drive. Check your file codecs and resolution against these formats before a content campaign goes live.

Can the menus be set in Arabic for offices that work in two languages?

Yes. The on-screen display offers Arabic and English among 18 supported languages. A Doha office working in Arabic and English side by side can set the menus to suit its staff, while the hidden, lockable keyboard controls stop visitors from changing settings. Ask us to confirm the setup while the quotation is prepared.

Will it run on Qatar's mains supply and how much power does it draw?

The rated mains input is 100 to 240 VAC at 50 to 60 Hz, which includes Qatar's 240 V, 50 Hz supply. Typical consumption is 355 W, maximum is 560 W and standby is under 0.5 W. The energy label class is G. When installing several units in a hotel or mall, include this load in your electrical planning and check the circuit with a qualified electrician.

What wall space and mounting do I need?

The set measures 1929.0 mm wide, 1100.0 mm high and 69.5 mm deep on the wall mount, and weighs 50.24 kg. The wall mount uses a 600 x 400 mm pattern with M8 fixings. Because of the weight, confirm the wall or structure before fixing. SmartRooms Qatar provides free site surveys that cover position, access and cable routes.

What warranty applies, and can we buy several units on one LPO?

The unit carries a 3-year manufacturer warranty, and products supplied by SmartRooms Qatar are covered by that warranty. Ministries, schools and companies can request a quotation and raise a purchase order (LPO), and pay by bank transfer, cheque or purchase order. Quotations usually arrive within one working day, and government tenders, including Monaqasat, are supported.
