Philips 86BDL4550D 86-inch 4K Digital Signage Display

Name: Philips 86BDL4550D 86-inch 4K Digital Signage Display
Brand: Philips
SKU: philips-86bdl4550d-00
Availability: InStock

Overview

The Philips 86BDL4550D is an 86-inch 4K UHD signage display with a 500 cd/m² panel, built-in Android 8.0 and an internal player for playing content without a permanent external player. FailOver switches to a backup input if the main source fails, which suits lobbies, waiting areas and boardrooms across Doha. It supports portrait and landscape use around the clock and comes with a 3-year warranty.

What this 86-inch D-Line display offers

The 86BDL4550D is an 86-inch display from the Philips Signage 4000 Series (D-Line), built for public-facing content rather than desktop use. Its 3840 x 2160 IPS panel delivers 4K UHD resolution in a 16:9 format, with 1.07 billion colours, a typical contrast ratio of 1,200:1 and a 500 cd/m² brightness rating. The 178-degree horizontal and vertical viewing angles let people read the screen from the side of a corridor or from an angle.

Playback without an external player

The display runs Android 8.0 on a quad-core processor with 3 GB of memory and 32 GB of internal storage. Media can be loaded onto the internal memory for instant playback, and the same memory caches streamed content. USB playback covers MPEG, H.263, H.264 and H.265 video, BMP, JPEG and PNG pictures, and AAC, HE-AAC and MPEG audio. The built-in HTML5 browser can show web-based playlists in landscape or portrait with full-HD resolution, and streamed content can appear in a picture-in-picture window.

Keeping screens live with failover and remote management

If the main input stops, the FailOver function moves the display to a backup source from a priority list you set, so a waiting area does not show a black screen. Automatic screenshots can be taken at set intervals, stored in the display's memory or on an FTP server, and sent by email. Remote management runs over a LAN or RF connection through the CMND platform, which handles software and settings updates and status monitoring.

Connections and mounting for a signage network

Video inputs: three HDMI 2.0, one DisplayPort 1.2, one DVI-I and two USB 2.0 ports.
Outputs and loop-through: DisplayPort 1.2 and HDMI 2.0 outputs, with IR, DisplayPort, HDMI and RS232 loop-through.
Control and audio: RJ45, RS232C and IR in and out, a 3.5 mm audio input and output, and two 10 W RMS speakers.
Wireless: dual-aerial Wi-Fi on 2.4 GHz and 5 GHz with 802.1x support, an OPS slot for a plug-in computing module, and mPCIe connectors for 4G/LTE antennas.

When several units share a wall, they can be tiled in a matrix up to 10 x 15, with a 15.5 mm even bezel. The set is 1929.0 mm wide, 1100 mm high and weighs 50.4 kg, and its wall mount is 600 x 400 mm with M8 fixings. Depth is 69.5 mm on the wall mount and 91.8 mm at the handle. Confirm wall construction and fixing points before ordering, and book a site survey to plan cable routing and mounting height.

Where it fits in Qatar

A government office in Msheireb with a public counter can use the panel to show service queues and bilingual notices, since the on-screen menu supports 18 languages including Arabic. A private school in Al Wakrah can place a portrait or landscape unit in a corridor for timetables and event notices. A hospital or clinic waiting area in Lusail or Al Sadd can loop health information, with a fallback slide staying on screen if the main source drops.

Heat, power and planning checks

The operating range is 0 to 40°C with 20 to 80% relative humidity, without condensation, and up to 3000 m altitude. Summer temperatures in Qatar can pass 45°C, so install the display in an air-conditioned room and confirm the cooling plan before fitting. Power input is 100 to 240 VAC at 50 to 60 Hz, with typical consumption of 410 W, a maximum of 600 W and standby draw under 0.5 W. Smart Power can lower backlight intensity to cut consumption by up to 50%. The display is covered by a 3-year manufacturer warranty.

To request a quote, send SmartRooms Qatar your room layout, mounting wall and content plan. Quotations are usually issued within one working day, and we offer free site surveys, professional installation, delivery to all eight municipalities of Qatar, and purchasing by LPO or government tender.

Highlights

3840 x 2160 IPS panel with 178-degree viewing angles
500 cd/m² brightness and 1,200:1 typical contrast ratio
Android 8.0 with 3 GB memory and 32 GB internal storage
Automatic backup-input switching and scheduled screenshots
Dual-band Wi-Fi, RJ45, RS232C and an OPS slot
Operating range 0 to 40°C with 3-year manufacturer warranty

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

67 specifications · Source: manufacturer · checked Oct 2026

Connectivity8

Video output: DisplayPort 1.2 (x 1); HDMI 2.0 (x 1)
External control: RJ45; RS232C (in/out) 2.5 mm jack; IR (in/out) 3.5 mm jack
Video input: Display Port1.2 (x 1); DVI-I (x 1); HDMI 2.0 (x 3); USB 2.0 (x 2)
Audio input: 3.5 mm jack
Other connections: OPS
4G/LTE antenna connectors: mPCIe
Wi-Fi: dual aerial 2,4Ghz and 5Ghz
Audio output: 3.5 mm jack

Convenience8

Wi-Fi protocol: a b g n, 802.1x
Energy-saving functions: Smart Power
Screen-saving functions: Pixel Shift, Low Bright
Placement: Landscape (24/7); Portrait (24/7)
Keyboard control: Hidden; Lockable
Signal loop through: IR Loop through; DisplayPort; HDMI; RS232
Tiled Matrix: Up to 10 x 15
Network controllable: RS232

Accessories2

Included Accessories: RS232 daisy-chain cable; Philips logo (x 1); AC Switch Cover; USB Cover (x 1); Screws
Included accessories: Quick start guide; RS232 cable; AC Power Cord; IR sensor cable (1.8 M); Remote Control and AAA Batteries

Dimensions10

Set Width (inch): 75.94 inch
Set Width: 1929.0 mm
Set Depth (inch): 2.74 (D@Wall mount)/ 3.61 (D@Handle) inch
Product weight (lb): 111.11 lb
Product weight: 50.4 kg
Bezel width: 15.5 mm (Even bezel)
Set Height (inch): 43.31 inch
Wall Mount: 600(H)x400(V) mm, M8
Set Height: 1100 mm
Set Depth: 69.5 (D@Wall mount)/ 91.8 (D@Handle) mm

Internal Player4

CPU: 2 x A53 + 2 x A73
Memory: 3 GB DDR
Storage: 32 GB eMMc
GPU: ARM Mali G51

Sound1

Built-in speakers: 2 x 10 W RMS

Power4

Energy Label Class: G
Mains power: 100 ~ 240 VAC, 50 ~ 60 Hz
Consumption (Typical): 410 W
Consumption (Max): 600 W

Multimedia Applications3

USB Playback Video: MPEG; H.263; H.264; H.265
USB Playback Picture: BMP; JPEG; PNG
USB Playback Audio: AAC; HEAAC; MPEG

Miscellaneous3

Regulatory approvals: CE; RoHS; BSMI; CB; CCC; CU; EMF; ETL; FCC, Class A; PSB; VCCI; J-Moss; PSE
Warranty: 3 year warranty
On-Screen Display Languages: English; French; German; Spanish; Polish; Turkish; Russian; Italian; Simplified Chinese; Traditional Chinese; Arabic; Japanese; Danish; Dutch; Finnish; Norwegian; Portuguese; Swedish

Picture/Display16

Picture enhancement: 3/2 - 2/2 motion pull down; 3D Combfilter; Motion compens. deinterlacing; 3D MA deinterlacing; Dynamic contrast enhancement; Progressive scan
Display colours: 1.07 Billion
Panel resolution: 3840 x 2160
Pixel pitch: 0.4935 x 0.4935 mm
Operating system: Android 8.0
Optimum resolution: 3840 x 2160 @120 HZ
Viewing angle (vertical): 178 degree
Contrast ratio (typical): 1200:1
Diagonal screen size (inch): 85.6 inch
Brightness: 500 cd/m²
Diagonal screen size (metric): 217.4 cm
Dynamic contrast ratio: 500,000:1
Viewing angle (horizontal): 178 degree
Aspect ratio: 16:9
Panel technology: IPS
Response time (typical): 8 ms

Operating conditions6

Temperature range (storage): -20 ~ 60 °C
Temperature range (operation): 0 ~ 40 °C
Humidity range (storage) [RH]: 5–95% RH (No condensation)
Humidity range (operation)[RH]: 20–80% RH (No condensation)
Altitude: 0 ~ 3000 m
MTBF: 50,000 hour(s)

Supported Display Resolution2

Video formats: 1080p, 50, 60 Hz; 1080i, 50, 60 Hz; 2160p, 24, 30, 60 Hz; 480i, 60 Hz; 480p, 60 Hz; 576i, 50 Hz; 576p, 50 Hz; 720p, 50,60 Hz
Computer formats: 1920 x 1080, 60 Hz; 1280 x 1024, 60 Hz; 1024 x 768, 60 Hz; 1280 x 720, 60 Hz; 1440 x 900, 60 Hz; 1600 x 900, 60 Hz; 1680 x 1050, 60 Hz; 3840 x 2160, 30, 60 Hz; 640 x 480, 60 Hz; 800 x 600, 60 Hz

Downloads

6 files from the manufacturer

PDF Datasheets 86BDL4550D_00_2021-06-07_03h32m10s.pdf 795 KB PDF Manuals & guides 65_75_86BDL4550D_dfu_V1_01_eng.pdf 19.8 MB PDF Manuals & guides · Opens on manufacturer site 1726681629-65_75_86bdl4550d_dfu_v1-01_ara-pdf.pdf PDF Manuals & guides · Opens on manufacturer site 1726681838-65_75_86bdl4550d_dfu_v1-01_ara-pdf.pdf PDF Drawings & CAD 86BDL4550D_Outline_Drawing_without_Stand_V1_0_20200908.pdf 892 KB PDF Certificates & compliance 86BDL4550D_Label_423864.pdf 153 KB

Questions about 86BDL4550D/00

What is the Philips 86BDL4550D used for?

It is an 86-inch 4K signage display for showing menus, wayfinding, announcements and promotional video in public spaces. In Qatar it suits a bank hall in Doha, a ministry reception or a university atrium where content runs for long hours. Its 500 cd/m² brightness and 178-degree viewing angles keep material readable for visitors approaching from different directions.

Can it play content without a separate media player?

Yes. The display runs Android 8.0 and has 3 GB of memory and 32 GB of internal eMMC storage, so you can upload media to its internal memory for instant playback. USB playback supports MPEG, H.264 and H.265 video and JPEG or PNG images. The internal memory also caches streamed content, which helps when the network is slow.

Which video inputs and outputs does it have?

It has three HDMI 2.0 inputs, one DisplayPort 1.2 input, one DVI-I input, two USB 2.0 ports and a 3.5 mm audio input. Outputs are DisplayPort 1.2 and HDMI 2.0, so one panel can pass a signal to another. Control options are RJ45, RS232C and IR, and an RS232 daisy-chain cable is included for linking several units.

Does the on-screen menu support Arabic?

Yes. The on-screen display offers 18 languages including Arabic, alongside English, French, German and Spanish, so an office in Doha can set the menus in Arabic for local staff. Choose the default language when the unit is first switched on and commissioned. Arabic here refers to the menu language only.

Can it be mounted in portrait orientation?

Yes. The display is rated for landscape and portrait placement 24/7, and it shows content in both orientations at full HD resolution. A portrait mount suits a corridor, a retail column or a tall directory board in a mall. Confirm the orientation, wall mount position and cable routing with your installer before the panel is fixed to the wall.

Is it suitable for a lobby exposed to Qatar's summer heat?

Only in an air-conditioned space. The operating range is 0 to 40°C with 20 to 80% humidity and no condensation, while Qatar summer temperatures can exceed 45°C. Keep the panel away from direct sunlight and open doors, and check that the room cooling can hold the area within the rated range before installation.

How much does it weigh, and what wall does it need?

The set weighs 50.4 kg and measures 1929.0 mm wide and 1100 mm high. Its wall mount uses 600 x 400 mm M8 fixings, and depth is 69.5 mm on the wall mount. SmartRooms Qatar offers free site surveys, so ask for one before installation to check wall construction, fixings and load, particularly for plasterboard or glass partitions.

Can several units be tiled into a video wall?

Yes. The display supports a tiled matrix of up to 10 x 15, and its 15.5 mm even bezel keeps the gaps between panels narrow. A video wall in a bank hall or a stadium concourse could use several units. Plan the layout, source feed and controller with your integrator before ordering, so the wall is specified correctly from the start.

What happens if the main video source fails?

The FailOver function switches the display to a backup input from a list you define, so content keeps playing when the primary source goes down. This matters in waiting rooms and hotel lobbies, where a blank screen looks like a fault. Set the alternative inputs during commissioning and test the switch before handover to your team.

How does it connect to a network and how is it managed remotely?

It connects by dual-band Wi-Fi on 2.4 GHz and 5 GHz with 802.1x support, or by RJ45 cable. Through the CMND platform over a LAN or RF connection, administrators can update software and settings and monitor display status. The HTML5 browser can show online playlists, and automatic screenshots can be sent by email.

What power does it need in Qatar?

The mains input is 100 to 240 VAC at 50 to 60 Hz, which covers the 240 V supply used in Qatar. Typical consumption is 410 W and maximum is 600 W, with standby under 0.5 W. An AC power cord is included, and the SmartRooms Qatar team can confirm the plug fits your sockets when you request a quote.

What warranty applies and how can organisations buy it?

The display is covered by a 3-year manufacturer warranty. SmartRooms Qatar supplies it with delivery to all eight municipalities, and accepts purchase orders (LPOs), government tenders including Monaqasat, and payment by bank transfer, cheque or purchase order. Send the quantity and sites you need, and request a quote for your project.
