PH43F
Samsung PH43F 43-inch Digital Signage Display
- Screen size
- 43"
- Resolution
- 1920 x 1080 (16:9)
- Brightness
- 700nit
- Contrast
- 3000:1
The Samsung PH43F is a 43-inch Full HD professional display for digital signage, with MagicInfo Player S4 built in so content can run without an external PC. It offers 700 nit brightness, a non-glare front panel, IP5x dust resistance and a 29.9 mm slim depth. It suits corridors, reception areas and meeting-room entrances in Doha and across Qatar. Request a quote from SmartRooms Qatar.
What the Samsung PH43F is built to do
The Samsung PH43F is a 43-inch Full HD display from the PHF Series, designed for digital signage in places where information must run for long hours without a dedicated computer. MagicInfo Player S4 is embedded in the unit and runs on the TIZEN platform, so playlists, schedules and layouts play straight from the screen. For a site with several displays, that removes a separate media player box at every point and reduces the cabling and maintenance that come with it.
The 43-inch size sits between small wall-mounted menu screens and large lobby displays. Its 29.9 mm depth keeps it close to the wall, and the narrow 6.9 mm top and side bezels keep attention on the content rather than the frame.
Image and durability facts that matter for signage
The 1920 x 1080 panel delivers 3000:1 contrast and 700 nit brightness, with a 178/178 degree viewing angle so people standing beside a corridor can still read the screen. The non-glare front surface reduces reflections from ceiling lights and daylight. Samsung lists 10-bit dithering for 1.07 billion colours, a 72 percent colour gamut and an 8 ms response time. The IP5x rating means the housing is protected against dust, which matters in dusty indoor areas.
- Operating range: 0 to 40 °C, with 10 to 80 percent humidity, non-condensing.
- Power: typical 108 W, maximum 154 W, and under 0.5 W in off and sleep modes.
- Audio: two 10 W built-in speakers, plus stereo mini jack input and output.
Where it fits in Qatar
Several realistic placements suit this model:
- Corridors and waiting areas in schools and clinics: wayfinding, timetables or health messages beside classrooms or consultation rooms, with content updated from one office.
- Reception areas of ministries, banks and offices: visitor information and service announcements, placed in an air-conditioned lobby away from direct sunlight.
- Entrances of shopping centres and hotels: promotional loops and visitor directions, with scheduling handled by the embedded player and Wi-Fi module.
What to plan before ordering
The VESA pattern is 200 x 200 mm, and the set measures 959.7 x 550.1 x 29.9 mm. The foot stand is an optional accessory (STN-L3240E), and the wall mount WMN4070SD is also listed as optional. Pivot display is supported for portrait layouts, so confirm orientation before fixing the bracket. Because the panel is rated for 0 to 40 °C, the location must be air-conditioned; Qatar's summer heat outdoors is far above that limit, so outdoor or unshaded, unconditioned installations are not appropriate. The SmartRooms Qatar team offers a free site survey to check wall loading, sightlines, cable routes and power arrangements before installation.
For a school or government office buying several units, we can handle purchase orders (LPOs) and tender paperwork. Send the number of units, the mounting type and the room list, and SmartRooms Qatar will usually issue a quotation within one working day. Request a quote for the Samsung PH43F and we will confirm the configuration and next steps.
Highlights
- Embedded MagicInfo Player S4 on TIZEN, no separate PC needed
- 700 nit brightness with a non-glare front panel
- IP5x dust protection and 29.9 mm slim depth
- 1920 x 1080 resolution, 3000:1 contrast, 178/178 viewing angle
- Video wall configuration up to 15 x 15 and daisy chain of 16 units
- Built-in Wi-Fi module, two 10 W speakers, 0 to 40 °C operating range
Estimated timeline
Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.
Specifications
Display14
- Diagonal Size
- 43"
- Panel Type
- 60Hz E-LED BLU
- Resolution
- 1920 x 1080 (16:9)
- Pixel Pitch (HxV, mm)
- 0.490(H) x 0.490(V)
- Contrast Ratio
- 3000:1
- Viewing Angle (H/V)
- 178/178
- Response Time
- 8 ms
- Display Color
- 10bit Dithering - 1.07Billion
- Color Gamut
- 72 %
- H-Scanning Frequency
- 30 ~ 81kHZ
- Maximum Pixel Frequency
- 148.5MHz
- V-Scanning Frequency
- 48 ~ 75HZ
- Brightness
- 700nit
- Contrast Ratio (Dynamic)
- Mega
Connectivity11
- HDMI In
- 2
- DP In
- 1
- DVI In
- 1
- USB
- 2
- RGB In
- D-Sub (DVI-I Common)
- Audio In
- Stereo Mini Jack, RGB/DVI/DP/HDMI
- Audio Out
- Stereo Mini Jack
- Video Out
- DP1.2(Loop-out)
- RS232 In
- Yes
- RS232 Out
- Yes
- RJ45 In
- Yes
Design1
- Stand Type
- Foot Stand (Optional)
Power4
- Power Supply
- 삼성전기 (SEM)
- Power Consumption (Off Mode, W)
- less than 0.5
- Power Consumption (On Mode, W)
- Max:154W / Typical:(EU)108, (US)108, (WW)108W / BTU(Max):525.14W
- Power Consumption (Sleep Mode, W)
- less than 0.5
Dimension2
- Set Dimension (WxHxD, mm)
- 959.7 x 550.1 x 29.9
- Package Dimension (WxHxD)
- 1037 x 628 x 132
Weight2
- Set Weight
- 9.4
- Package Weight
- 11.4
Operation Conditions2
- Temperature
- 0~40 ℃
- Humidity
- 10~80 (non-condensing)
Mechanical Specification3
- VESA Mount (mm)
- 200 x 200
- Bezel Width (mm)
- 6.9(Top)/6.9(Side)/8.9(Bottom)
- Media Player Option Type
- SBB, PIM Ready
General Feature2
- Special
- Non Glare Panel, Temperature Sensor, Video Wall(15x15(OSD)), Video Wall Daisy Chain(16), Pivot Display, Clock Battery(80hrs Clock Keeping), Built in Speaker(10W x 2), WiFi Module Embedded, IP5x, Center IR
- Speaker
- 10W x 2
Optional Feature3
- Mount
- WMN4070SD
- Specialty
- CML400XJ
- Stand
- STN-L3240E
Internal Player (MagicInfo)2
- Special
- Magic Clone(to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC,Plug and Play, PIP/PBP, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain(HDCP Support), Firmware Update by Network, New Home Screen, PC-less VideoWall, Multi Channel, Mobile Control, Event Schedule, Backup Player
- MagicInfo Support
- Yes
Accessory1
- Included
- Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Cover Jack
Certification and Compliance2
- EMC
- FCC (USA) Part 15, Subpart B Class A, CE (Europe) : EN55022:2006+A1:2007, EN55024:1998+A1:2001+A2:2003, VCCI (Japan) : VCCI V-3 /2010.04 Class A, KCC/EK (Korea) : Tuner : KN13 / KN20, Tunerless : KN22 / KN24, BSMI (Chinese Taiwan) : CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) / CNS14972 (Digital), C-Tick (Australia) : AS/NZS CISPR22:2009, CCC(China) : GB9254-2008, GB17625.1-2012, GOST(Russia/CIS) : GOST R 51317 Series, GOST 22505-97, EN55022:2006+A1:2007, EN55024:1998+A1:2001+A2:2003
- Safety
- CB (Europe) : IEC60950-1/EN60950-1, CCC (China) : GB4943.1-2011, PSB (Singapore ) : PSB+IEC60950-1, NOM (Mexico ) : NOM-001-SCFI-1993, IRAM (Argentina ) : IRAM+IEC60950-1, SASO (Saudi Arabia ) : SASO+IEC60950-1, BIS(India) : IEC60950-1 / IS13252, NOM(Mexico) : Tuner : NOM-001-SCFI-1993, Tunerless : NOM-019-SCFI-1998, KC(Korea) : K 60950-1, EAC(Russia) : EAC+IEC60950-1, INMETRO(Brazil) : INMETRO+IEC60950-1, BSMI(Chinese Taiwan) : BSMI+IEC60950-1, RCM(Australia) : IEC60950-1/AS/NZS 60950-1, UL(USA) : cUL60950-1, CSA (Canada) : cUL, TUV (Germany) : CE, NEMKO (Norway) : CE
