Dahua LDV65-HAI400TL-M · Price in Qatar

Name: Dahua LDV65-HAI400TL-M 65-inch Vertical Touch Digital Signage
Brand: Dahua
SKU: dahua-ldv65-hai400tl-m
Availability: InStock

Overview

The Dahua LDV65-HAI400TL-M is a 65-inch portrait touch display for floor-standing use in reception areas, wayfinding points and retail entrances. It runs Android 11 on a quad-core processor, decodes video up to 4K, and includes a 10-point capacitive touchscreen. Built for continuous operation, it suits Qatari organisations that need scheduled content and remote management across several sites.

A 65-inch portrait display built for all-day public use

The Dahua LDV65-HAI400TL-M is a floor-standing LCD that runs in portrait orientation, aimed at information points that must stay on through long opening hours. Its 65-inch IPS panel uses a 9:16 frame, so vertical content such as directories, queue numbers and menus fills the screen instead of leaving empty bands. A black metal casing and a supplied base keep setup simple.

Panel, touch and picture quality

The 2160 by 3840 pixel panel delivers 4K detail with typical brightness of 500 cd/m² and a typical contrast ratio of 1200:1. Viewing angles are 178 degrees both horizontally and vertically, so people approaching from the side can still read the content. Colour depth is 10-bit, produced as 8-bit plus frame rate control, giving about 1.07 billion colours. A 1% haze surface and an 8 ms typical response time keep text sharp and motion smooth.

The capacitive touchscreen supports 10 touch points with a response time of 8 ms or less, so more than one visitor can use it at once.

Built-in player, ports and remote management

Android 11 runs on a quad-core A55 processor clocked at 1.92 GHz, backed by 4 GB of RAM and 32 GB of storage. The player decodes H.265 and H.264 video up to 2160p and plays mp4, avi, mov, mkv and wmv files. A browser and server platform assigns programmes by time and location, produces operation reports and controls each unit remotely.

One RJ-45 Ethernet port supporting 10/100/1000 Mbps
One HDMI 2.1 input supporting 4K at 60 Hz, with no video output
One USB 2.0 and one USB 3.0 Type-A port, plus a TF card slot up to 128 GB
A 3.5 mm audio output, two built-in 5 W speakers and an IR receiver

Wi-Fi requires an optional external module, and Bluetooth is not provided.

Where it fits in Qatar

In a government office in Msheireb, the unit can stand beside the reception desk showing visitor directions, service counter numbers and appointment notices, with content switched between daytime and evening messages. In a shopping centre in Lusail or a hotel in West Bay, a portrait screen at the entrance suits store directories and event listings, updated centrally when several sites share one platform.

Clinics in Al Sadd, schools in Al Wakrah and university buildings in Education City can use the same model for queue information, campus maps and notices.

Planning the site, power and delivery

The net weight is 68 kg and the packed weight is 83.7 kg, so plan the delivery route, lift access and a firm, level floor before ordering. The unit measures 2050 mm high, 861 mm wide and 500 mm deep, so measure doors, lifts and corridors on site. The power input accepts 100 to 240 VAC at 50/60 Hz, which covers Qatar's 240 V, 50 Hz supply, and it draws no more than 140 W in operation.

The rated operating range is 0 to +40 °C, and the specification advises avoiding direct sunlight. Qatar summers can exceed 45 °C, so keep the screen indoors in air-conditioned space, away from windows and glass frontages that receive direct sun. The box includes the base, power cord and remote control, and the unit carries CE EMC, CE LVD and CE ERP certifications.

Request a quote from SmartRooms Qatar with your room size, hours of use and planned position, and we will send a quotation, usually within one working day.

Highlights

65-inch portrait IPS panel at 2160 × 3840 resolution
Rated for up to 24 hours of operation each day
Android 11 with 4 GB RAM and 32 GB storage
Decodes H.265 and H.264 video up to 2160p
10-point capacitive touchscreen with 8 ms response
10/100/1000 Mbps Ethernet, HDMI 2.1 input, built-in AC socket

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

48 specifications · Source: manufacturer · checked Oct 2026

LCD Panel11

Panel Dimensions: 65 inch
Backlight: ELED
LCD Technology: IPS
Aspect Ratio: 9: 16
Brightness: 500 cd/m² (typ.)
Contrast: IPS 1200:1(typ.)
Display Colors: 10 bit (8 bit + FRC), 1.07B colors
Resolution: 2160 (H) × 3840 (V)
Viewing Angle: 178° (H); 178° (V)
Response Time: 8 ms (typ.)
Surface Treatment: Haze 1%

Built-in System5

Operating System: Android 11.0
CPU: 4 cores A55, 1.92 GHZ
RAM: 4 GB
ROM: 32 GB
Video Decoding: H.265 HEVC MP-10@L5.1 up to 2160p@60 fps H.264 AVC HP@L5.1 up to 2160p@30 fps VP9 Profile 2 up to 2160p@60 fps H.264 MVC up to 1080p@60 fps MPEG-4 ASP@L5 up to 1080p@60 fps (ISO-13818) WMV/VC-1 SP/MP/AP up to 1080p@60 fps

Function3

Audio Compression: MPEG-3, WMA, WAV
Video Compression: MPEG-4, H.264 AVC/MVC, H.265 HEVC
Video Format: mp4, avi, mov, mkv, wmv

Device Ports8

Network Port: 1 × RJ–45 10/100/1000 Mbps self-adaptive Ethernet port
Wi-Fi: Optional (External Wi-Fi module)
Bluetooth: NO
Data Transmission Ports: 1 × USB 2.0 ports (type A) 1 × USB 3.0 ports (type A) 1 × TF card slot, up to 128 GB
Video Input: 1 × HDMI 2.1 (4K @60Hz)
Video Output: NO
Audio Port: 1 × 3.5 mm jack output
IR Receiver: Yes

Speaker1

Built-in Speaker: 2 × 5 W

Touchscreen3

Touch Technology: Capacitive
Response Time: ≤8 ms
Touch Points: 10

General General16

Power Supply: 100–240 VAC, 50/60 Hz
Power Consumption: ≤ 140 W
Standby Power Consumpton: ≤ 0.5 W
Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F) (avoid direct sunlight)
Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
Operatng Humidity: 10%–85% (RH), non-condensing
Storage Humidity: 10%–90% (RH), non-condensing
Product Material: Metal casing
Casing Color (Frame/Rear): Black
Product Dimensions: 2050 mm × 861 mm × 500 mm (80.71" × 33.91" × 19.69")
Packaging Dimensions: 2154 mm x 234 mm x 1044 mm (84.8" × 9.21" × 41.1”)
Net Weight: 68kg (149.91 lb)
Gross Weight: 83.7kg (184.50 lb)
Installation: Vertical
Display Mode: Portrait
Accessory: Base, user's manual, power cord, legal and regulatory information, remote control

Certification General1

Certifications: CE EMC, CE LVD, CE ERP

Downloads

2 files from the manufacturer

PDF Datasheets LDV65-HAI400TL-M.pdf 1.4 MB PDF Manuals & guides Digital Signage_User's Manual_V1.0.0.pdf 6.4 MB

Questions about LDV65-HAI400TL-M

Would this 65-inch portrait display suit a ministry reception in Msheireb?

Yes, provided it stands indoors in an air-conditioned space. The unit is a floor-standing portrait screen that suits ministry reception areas where visitors need directions, service counter information or appointment notices. Its IPS panel gives a 178-degree viewing angle, so people approaching from the side can read the content. The touchscreen lets visitors search directories themselves, which can ease pressure on the front desk.

Can it run around the clock in a hospital or clinic waiting area in Al Sadd?

The unit is rated for up to 24 hours of operation a day, which suits waiting areas that stay open through long hours. Its operating range is 0 to +40 °C, so place it in a well-ventilated, air-conditioned room rather than a closed corner or a sun-facing position. Make sure it does not block corridors or emergency routes, and confirm the exact spot with the SmartRooms Qatar team during a free site survey before installation.

What panel and picture specifications does the LDV65-HAI400TL-M have?

It uses an IPS LCD with ELED backlighting in a 65-inch panel with 2160 × 3840 pixel resolution and a 9:16 aspect ratio. Typical brightness is 500 cd/m² and typical contrast is 1200:1. Viewing angles are 178 degrees horizontally and vertically, and the surface has a 1% haze treatment. Colour depth is 10-bit, produced as 8-bit plus frame rate control, and typical response time is 8 ms.

Can it stand in a sunny mall entrance in Lusail?

Not as an outdoor or direct-sun installation. The specification lists an operating temperature of 0 to +40 °C and advises avoiding direct sunlight, while Qatar summers can pass 45 °C. A mall entrance with a glass frontage would need the screen placed inside, set back from the glazing, in air-conditioned space. The specification does not list an outdoor rating, so ask SmartRooms Qatar to review the exact position during a free site survey.

How does the 10-point touchscreen work, and what does one-button switching need?

The screen uses capacitive touch with 10 touch points and a response time of 8 ms or less, so several people can interact at once. One-button switching between touch channels works only if the external device connected to the unit has at least one USB touch port. If you plan to use a separate media player, check that its USB port supports touch before ordering.

Which video inputs and file formats does the built-in player support?

The single video input is an HDMI 2.1 port supporting 4K at 60 Hz, and there is no video output. The player decodes H.265 HEVC and H.264 AVC up to 2160p, VP9 up to 2160p at 60 fps, and MPEG-4, WMV and VC-1 up to 1080p. Supported file formats include mp4, avi, mov, mkv and wmv. Audio leaves through a 3.5 mm jack, and two 5 W speakers are built in.

Does it need Wi-Fi, and what network connection does it use?

The unit has one RJ-45 port for 10/100/1000 Mbps self-adaptive Ethernet, a wired option that suits school, clinic and ministry networks. Wi-Fi is available only through an optional external module, so specify it in your quotation if wireless connection is essential. Bluetooth is not provided. Local content can also be loaded from a TF card of up to 128 GB or from its USB 2.0 or USB 3.0 Type-A ports.

How would a school group in Al Wakrah manage displays across several sites?

The unit is designed to be managed through a browser and server platform. Schedules can be assigned by time and location, operation reports are generated, and each display can be controlled remotely from one place. A school group with campuses in Al Wakrah and Al Khor could let one administrator update announcements at every branch, provided each display has a working network connection. Plan an Ethernet point at each site before installation.

Can a hotel in West Bay add its own media player or mini PC?

Yes. The chassis reserves a space of 200 × 200 × 100 mm for a third-party media box or mini PC, so a hotel can fit a player with its own software or storage. Check that the chosen device fits this space before ordering, and ask for the dimensions to be confirmed in the quotation. One-button touch switching also requires the external device to have at least one USB touch port.

Will it run on Qatar's 240 V supply and how much power does it draw?

The power input accepts 100 to 240 VAC at 50/60 Hz, which covers Qatar's 240 V, 50 Hz mains supply. Maximum power consumption is 140 W, and standby draw is 0.5 W or less. The unit has a built-in AC power socket. A power cord is included, but confirm the plug type with SmartRooms Qatar at quotation stage so it matches the BS 1363 (Type G) sockets common in Qatar.

Can a school in Al Rayyan order this unit on an LPO or government tender?

Yes. Schools, ministries and other public bodies can order by local purchase order (LPO) or through government tenders, including Monaqasat. SmartRooms Qatar delivers to all eight municipalities of Qatar and accepts payment by bank transfer, cheque or purchase order. Because the unit weighs 68 kg net, include delivery and installation to the room in the quotation. Products are covered by the manufacturer's warranty.
