TD-43OKTF55

A portrait outdoor kiosk for daylight messaging

The TD-43OKTF55 is a 43-inch kiosk built around a 9:16 portrait full HD panel at 1920x1080. Its upright format suits entrances, pedestrian routes and narrow footpaths where a landscape screen would waste space. It is designed for content that must stay visible outdoors, whether that is promotional loops, wayfinding messages or visitor information.

The enclosure carries an IP55 rating, which indicates protection against dust that could interfere with operation and against low-pressure water jets. The structure uses 1.5 mm galvanized steel and an SPCC metal box.

Brightness, contrast and viewing angles for outdoor use

Glare is the usual reason outdoor screens disappoint. This model lists a brightness of 1500-2000 cd/m2 from an LG high-brightness backlight system, a 1200:1 contrast ratio and a 178 degree viewing angle both horizontally and vertically. These figures help text and images remain readable in bright daylight and to people approaching from the side. A 6 ms response time and 16.7 million colours suit moving video and animated graphics. Anti-reflection glass is listed as an option for screen protection and can be added to your quotation.

Cooling, temperature limits and power

Qatar summers often exceed 45 degrees Celsius, so thermal planning comes before mounting. The stated operating range is -30 to 50 degrees Celsius, with an air cooling system fitted as standard. Storage is rated -40 to 60 degrees Celsius, and working humidity is listed at 85%. For environments above 50 degrees Celsius the manufacturer recommends an air-conditioned model. Air conditioning is listed as an option for this kiosk, so request it in your quotation if your site survey shows high afternoon temperatures in direct sun.

• Input: 100-240 V at 50/60 Hz
• Maximum consumption: 360 W
• Standby draw: under 5 W

Media player, connectivity and options

The standard unit runs an integrated Android RK3288 player with 2GB memory and 8GB storage, on Android 5.1 or 7.1. Higher memory and storage are optional, and Windows-based players with Intel i3, i5 or i7 processors and 128GB SSD are offered as alternatives. A version without an internal player, using an HDMI input, is also listed. Network support is LAN, with WiFi as an option. Touch is optional, with infrared and capacitive choices. A digital signage software option with 1GB cloud storage is available for remote scheduling.

Planning a Qatar installation

Three scenarios show where this model fits. A shopping centre in West Bay could place it at a plaza entrance to show offers and directions. A transport operator in Lusail could use it near a station forecourt for timetable information. A campus in Education City could use it on a walkway for event notices. In each case the enclosure protects the electronics from dust and water while the display keeps messages visible during the day.

Before ordering, confirm the mounting position, the base footprint, the cable route to a power point and the expected temperatures at that spot. As a freestanding kiosk, the base must be stable and accessible for maintenance. SmartRooms Qatar offers a free site survey, supply to all 8 municipalities of Qatar, professional installation and quotations usually within one working day. Government buyers can proceed with a purchase order or tender reference. Request a quote and the SmartRooms Qatar team will confirm the configuration and next steps.
