Trend TD-55DKF · Price in Qatar

Name: Trend TD-55DKF 55-inch Full HD Double-Sided Freestanding Kiosk
Brand: Trend
SKU: trend-td-55dkf
Availability: InStock

Overview

The Trend TD-55DKF is a 55-inch Full HD double-sided kiosk built for continuous indoor use. Both faces display content, and the panel runs 24/7 with 400 cd/m2 brightness, 1920x1080 resolution and a 1-year warranty. It suits malls, hotel lobbies, banks and corporate receptions in Qatar where visitors approach from two directions. Optional touch, media players and signage software can be specified with your quotation.

What the TD-55DKF is and how its two faces work

The Trend TD-55DKF is a 55-inch Full HD kiosk with a display on each face, mounted on a freestanding base. It uses a TFT panel rated for indoor application, with a 1920x1080 resolution, 400 cd/m2 brightness and a pixel pitch of 0.227mm both horizontally and vertically. Because both faces show content, one unit can serve shoppers walking in either direction along a mall corridor, or visitors entering a lobby from two sides.

The specifications that matter for continuous operation

Continuous running is the main reason to choose this model over a standard display. The source data rates it for 24/7 operation and gives an MTBF of 50,000 hours. The 89/89/89/89 viewing angle keeps the image readable from the side, which matters on a kiosk that people approach from several positions. Colour is listed at 16.7M with 95% CIE1931 coverage, and the response time is 6 ms typical, grey to grey.

Brightness: 400 cd/m2 for indoor areas with daylight from glazed entrances.
Response time: 6 ms typical (G to G).
Warranty: 1 year, covered by the manufacturer's warranty.

Choosing the media player, touch and software

The base unit includes an integrated Android media player, and the source lists 8GB storage and 2GB memory for it. Alternatives include a version with no media player that takes an HDMI input from your own PC or player, and Windows media players with i3, i5 or i7 processors, each with 4GB RAM and a 128GB SSD. Touch is optional, either infrared (IR) or capacitive. A digital signage software option with 1GB cloud storage is also listed. Memory and storage upgrades are offered, but the options differ between data sheets, so confirm the final configuration in your quotation.

Where it fits in Qatar

In a shopping mall in West Bay or Al Sadd, a double-sided kiosk can carry promotions on both sides of a walkway without doubling the number of screens. In a hotel lobby in The Pearl or Msheireb, it can show arrival information and local guidance to guests coming from the lift and from the entrance. In Education City or on a university campus, a kiosk at a junction can carry directions and event listings. Corporate receptions in Doha that welcome visitors from two sides suit the same format.

Facility managers should note the indoor rating. Lobbies with large glass fronts receive strong sunlight, and summer temperatures in Qatar regularly exceed 45°C. The source data does not state an operating temperature range for this model, so keep the unit away from direct sun and outdoor areas, and confirm the environment with the SmartRooms Qatar team before placing it.

What to plan before the unit arrives

Confirm the footprint and clearance around the freestanding base with a site survey. SmartRooms Qatar offers free site surveys.
Check the power arrangement. The source lists an input voltage range of 10V to 240V.
Decide on the touch option, media player and software before ordering, since each one changes the configuration.
Plan cable routing for the media player and any HDMI source.

Government ministries and public bodies can issue a purchase order (LPO) or take part in tenders, and SmartRooms Qatar delivers to all eight municipalities of Qatar. Request a quote for the TD-55DKF with the touch, media player and software options you need, and our team will return a quotation usually within one working day.

Highlights

Full HD 1920x1080 resolution on both faces
24/7 operation with a 50,000-hour MTBF rating
400 cd/m2 brightness for indoor visibility
89/89/89/89 viewing angle specification
Optional IR or capacitive touch screen
1-year manufacturer warranty

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

20 specifications · Source: manufacturer · checked Oct 2026

Quick Details8

Brand Name: Trend Displays
Model Number: TD-55DKF
Resolution: 1920x1080 FHD
Brightness: 400cd/m2
Application: indoor
Pixel Pitch: 0.227mm (H) x 0.227mm (W)
Warranty: 1 year
Color: 16.7M/1.07B, 95% [CIE1931]

Technical12

Media Player: Integrated Android RK3288 2+8G Android 5.1/7.1 OS Optional RAM: 4GB/8GB/16GB Optional SSD: 32GB/64GB/128GB/256GB Optional Media Players: No Media Player with HDMI Input Integrated Windows Media Player with i3 Processor 4GB RAM 128GB SSD Integrated Windows Media Player with i5 Processor 4GB RAM 128GB SSD Integrated Windows Media Player with i7 Processor 4GB RAM 128GB SSD
Operations: 24/7
Type: TFT
Viewing Angle: 89/89/89/89
Storage: 8GB
CPU: RK3188, quad-core, frequency 1.6GHz
Response Time: 6 (Typ.) (G to G) MS,
Input Voltage: 10V~240V
Touch screen: Optional with IR / Capacitive
Memory: 2GB
Size: 55 Inch
MTBF: 50000

Downloads

1 file from the manufacturer

PDF Datasheets TD-55DKF_Datasheet.pdf 372 KB

Questions about TD-55DKF

What is the Trend TD-55DKF designed for?

It is a freestanding 55-inch kiosk that shows content on both sides and is built for continuous indoor use. The source data lists retail, hospitality, corporate and public-space use, so it suits promotions, wayfinding and information displays where people approach from more than one direction. A single double-sided unit can replace two separate screens on a walkway, which keeps the footprint small in busy Doha malls and lobbies.

Does the kiosk show the same image on both sides?

Both faces carry Full HD visuals, but the source data does not specify whether the two sides can run different content. Whether they show identical or separate playlists depends on the media player configuration you choose, so ask the SmartRooms Qatar team to confirm the setup against your content plan before you request a quote. Planning this early avoids a configuration change after delivery.

What resolution and brightness does it offer?

Each side uses a 55-inch TFT panel at 1920x1080 Full HD with 400 cd/m2 brightness and a pixel pitch of 0.227mm. Colour is listed at 16.7M colours with 95% CIE1931 coverage, and the response time is 6 ms typical grey to grey. The brightness suits indoor lobbies and corridors, but it is not a rating for outdoor or direct-sun installation.

We run a hospital reception in Doha around the clock. Is this kiosk suitable?

The data sheet rates the TD-55DKF for 24/7 operation and gives an MTBF of 50,000 hours, which is a useful planning figure for a reception that never closes. Keep the area around the unit free of obstructions so air can circulate, and confirm the indoor environment with the SmartRooms Qatar team. Ask for a quotation that states the touch and media player options your reception staff will need.

Can I place it outdoors or near a window in Qatar's summer?

The source data lists this model for indoor application only and does not state an operating temperature range. Summer temperatures in Qatar regularly pass 45°C, and dust storms are common, so do not place it outdoors or where direct sun falls on the panel. For a glass-fronted entrance, position the unit deeper inside the space and ask SmartRooms Qatar to confirm the environment before you request a quote.

What touch options are available?

Touch is optional. The data lists an infrared (IR) touch screen and a capacitive touch screen for the 55-inch model. The two technologies differ in how they respond to input and in the surface they use, so describe your interaction needs when you request a quote and the team will recommend the better fit for your kiosk.

Which media player options are there?

Three configurations are listed. The base unit has an integrated Android media player with 8GB storage and 2GB memory. You can also choose a version with no media player that takes an HDMI input from your own PC or player, or an integrated Windows media player with an i3, i5 or i7 processor, 4GB RAM and a 128GB SSD. Choose the Windows option when your content needs Windows software, and the HDMI input when content is already produced elsewhere.

Does it work with Qatar's 240 V mains supply?

The source data gives an input voltage range of 10V to 240V, which covers Qatar's 240 V, 50 Hz mains. Before ordering, confirm the power cable and plug supplied for BS 1363 (Type G) sockets, because the data sheet does not describe the plug. Ask the SmartRooms Qatar team to confirm the power arrangement at your location, including socket planning for the freestanding base.

What warranty comes with it?

The source data lists a 1-year warranty, and SmartRooms Qatar supplies the TD-55DKF under the manufacturer's warranty. For a purchase order from a government body or school, make sure the warranty period and terms are stated in the quotation you approve. Warranty details beyond the one-year period in the data sheet are not covered on this page, so ask the team to confirm the terms that apply to your order.

We are fitting out a shopping mall walkway in West Bay. Why choose double-sided?

A walkway with shops on both sides gets foot traffic from two directions, and a single-sided screen only reaches one of them. A double-sided 55-inch kiosk placed in the centre of the walkway shows promotions to shoppers approaching from either end. Plan a clear route around the base, confirm the footprint through a site survey, and request one quotation covering the number of units your mall management needs.

Is it suitable for a hotel lobby in The Pearl or Msheireb?

Yes, for indoor lobbies. Guests arriving from the lift and from the entrance can read the same information on either face, which suits arrival messages, local guidance and event listings. Keep the unit out of direct sun through glass. SmartRooms Qatar offers a free site survey, which helps you place the kiosk where it is visible without blocking the lobby's circulation routes.

Can a university or school in Education City or Al Wakrah use it for wayfinding?

A double-sided kiosk works well at a junction where students and visitors arrive from two corridors. It can show directions, timetables or event listings on both faces. Because the unit is freestanding, it does not need wall fixings, but confirm the floor and clearance requirements during the site survey. A school ordering several units can request a single quotation and issue one purchase order (LPO).
