Barco ClickShare Power Supply 100W, 100-Watt Video Conferencing Accessory
EasyConnect EC-PK-DK
Biamp EasyConnect EC-PK-DK Table Cable Management Box with Control Pad
- Platforms
- CE Marked (Europe)
Priceon request
QuotationWithin 1 working day
DeliveryConfirmed with your quote, based on stock
Overview
The Biamp EasyConnect EC-PK-DK mounts into a conference table and stores Ethernet, HDMI and USB cables in one low-profile box. Its 5-foot (1.5 m) cables pull out and retract, and it adds an AC power receptacle plus an 8-button programmable Impera Echo Plus control pad. Well suited to boardrooms and meeting rooms in Doha, West Bay and Lusail. Request a quote.
What the EasyConnect EC-PK-DK does at the table
The Biamp EasyConnect EC-PK-DK is a tabletop connectivity box that mounts into a conference table. It keeps Ethernet, HDMI and USB cables stored in the table and brings them up when a presenter needs them. The unit combines that cable store with an 8-button Impera Echo Plus programmable control pad (model 8EUB) and an integral 12VDC power supply, so cabling, power and room control sit in one fitting rather than in separate boxes.
Cables, power and control in one fitting
Cables included with the box are two CAT5e Ethernet cables, one HDMI 1.4 cable and one USB 2.0 Type-A cable. Each 5-foot (1.5 m) cable pulls out and retracts, and a sliding cover with a cable pass-through keeps the top of the table clear when the box is closed. Two unpopulated cable feed-throughs allow for up to six cables, which leaves room to add connections later.
- Power: one AC power receptacle, with the DK power connector integrated into the unit.
- Control: eight programmable buttons on the Impera Echo Plus pad for room control.
- Footprint: 4 inches (102 mm) high and 5.5 lbs (2.5 kg) in weight, with a top plate measuring 9.9 inches (251 mm) by 5.3 inches (135 mm).
Where it fits in Qatar
Three situations suit this box well:
- A boardroom in a West Bay office tower, where executives connect laptops carrying Arabic and English decks and visiting delegations expect a clean table.
- A seminar room in Education City, where faculty and visiting researchers share one table point for Ethernet, HDMI and USB during hybrid sessions with partners abroad.
- A classroom or training room at a private school in Al Wakrah or a training centre in the Industrial Area, where the control pad gives a teacher one interface for room functions.
What to plan before ordering
Measure the table before ordering, because the box must mount into it. The unit weighs 5.5 lbs (2.5 kg), and a site survey confirms the cut-out, the cable route to the room's equipment and the position of the power receptacle. SmartRooms Qatar offers free site surveys and professional installation across Qatar, so the survey can be booked before you commit to a quantity.
Check the environment as well. The manufacturer states an ambient operating range of 0 to 30°C (36 to 86°F), with 10 to 90% relative humidity, non-condensing, and altitude up to 6,600 ft (2,000 m). Qatar summers regularly pass 45°C outside, so the table should sit in an air-conditioned room that stays within that range. If the room runs warm, confirm the conditions with the SmartRooms Qatar team before installation. The unit carries CE and RoHS marks and a 5-year warranty from the manufacturer.
Need a box for a single meeting room or several rooms in a school or ministry? Request a quote, and the SmartRooms Qatar team will confirm quantities, availability and purchase order or tender paperwork.
Highlights
- 8-button programmable Impera Echo Plus control pad (model 8EUB)
- Cables included: two CAT5e Ethernet, HDMI 1.4, USB 2.0 Type-A
- Two unpopulated feed-throughs allow for up to six cables
- Integral 12VDC power supply with one AC power receptacle
- Operating range 0 to 30°C; humidity 10–90% non-condensing
- 5-year manufacturer warranty; CE and RoHS marked
Room fit
Tell us the room size and platform (Teams, Zoom or BYOD) and we confirm the right combination with your quotation.
Estimated timeline
Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.
Specifications
8 specifications · Source: manufacturer · checked Oct 2026
GENERAL4
- Height
- 4 inches (102 mm)
- Width
- 8.6 inches (218 mm) Top Plate Dimensions: 9.9 inches (251 mm)
- Depth
- 3.5 inches (89 mm) Top Plate Dimensions: 5.3 inches (135 mm)
- Weight
- 5.5 lbs (2.5 kg)
COMPLIANCE1
- Certifications
- CE Marked (Europe) RoHS Directive (Europe)
ENVIRONMENTAL3
- Ambient Operating Temperature Range
- 36 - 86° F (0 – 30° C)
- Humidity
- 10-90% relative humidity (non-condensing)
- Altitude
- 0-6,600 ft (0-2000m) MSL
Downloads
1 file from the manufacturerQuestions about EasyConnect EC-PK-DK
What is the Biamp EasyConnect EC-PK-DK used for?
It is a tabletop cable management box with a built-in control pad, made for conferencing. It mounts into a conference table, stores Ethernet, HDMI and USB cables, adds one AC power receptacle and includes an 8-button programmable Impera Echo Plus pad. It suits boardrooms, meeting rooms and learning spaces where presenters need connections at the table without loose leads on the surface.
Which cables come with the EC-PK-DK?
The box comes with two CAT5e Ethernet cables, one HDMI 1.4 cable and one USB 2.0 Type-A cable. The cables are 5 feet (1.5 m) long, pull out and retract for storage, and sit behind a sliding cover with a cable pass-through. Two unpopulated cable feed-throughs allow for up to six cables, so you can add connections later if a room changes its setup.
What does the 8-button control pad do?
The EC-PK series includes the 8-button Impera Echo Plus programmable control pad, model 8EUB, which gives users a simple interface for room control. Because the buttons are programmable, the functions assigned can match the equipment in your room. Confirm the programming requirements for your room when you request a quote, so the pad is set up for the way your meetings run.
Does the box include a power outlet and power supply?
Yes. The EC-PK-DK adds one AC power receptacle and has an integral 12VDC power supply, with the DK power connector integrated into the unit. This lets presenters power a device at the table without running a cable from a floor outlet. Before ordering, ask SmartRooms Qatar to confirm that the receptacle configuration suits the power supply in your room.
How big is the box and how much does it weigh?
The unit measures 4 inches (102 mm) high, 8.6 inches (218 mm) wide and 3.5 inches (89 mm) deep, with a top plate of 9.9 inches (251 mm) by 5.3 inches (135 mm). It weighs 5.5 lbs (2.5 kg). Compare these dimensions with the table's cut-out and the space below the surface before ordering. A free site survey from SmartRooms Qatar checks this on the actual table.
Can the EC-PK-DK run in a hot meeting room in Doha?
Only in an air-conditioned room. The manufacturer gives an ambient operating range of 0 to 30°C (36 to 86°F) and 10 to 90% relative humidity, non-condensing. Outdoor summer temperatures in Doha regularly exceed 45°C, so the box should sit in a climate-controlled meeting room. If a room has weak cooling or direct sun through glass, confirm the conditions with the SmartRooms Qatar team before installation.
Is it suitable for a West Bay boardroom that hosts international guests?
Yes, for connecting laptops at the table. The box provides Ethernet, HDMI and USB connections in one fitting, and the cables stay stored until needed, which keeps the table clear for visitors. Confirm during a site survey that the 5-foot (1.5 m) cables reach the seats you plan to use, since cable reach depends on where the box is mounted in the table.
Can teachers use it in a school classroom in Al Wakrah?
A classroom with a teacher's table can use the box to keep Ethernet, HDMI and USB cables tidy. The sliding cover closes the top when the table is not in use, and the 8-button control pad offers one interface for room control. Because the pad is programmable, the school can set its functions around lessons. Plan the table cut-out and power position with the school's facilities team before ordering.
Can it support hybrid meetings between a Doha office and partner teams abroad?
The box gives you Ethernet, HDMI 1.4 and USB 2.0 Type-A connections at the table, which can serve laptops and room equipment. The conferencing itself depends on the room system, so check that its inputs match these cable types. Share the codec or room system model when you request a quote, and the SmartRooms Qatar team can confirm whether the connections match your setup.
Does the EC-PK-DK come with a warranty?
Yes. The manufacturer gives the EasyConnect EC-PK-DK a 5-year warranty, and SmartRooms Qatar supplies it under that manufacturer warranty. Keep the purchase order and delivery paperwork with the room records so that any warranty claim can be traced to the right unit and room. For an institution, the purchase order or tender reference can be filed with the same records.
Can we buy this for several rooms at a university or government office?
Yes. SmartRooms Qatar accepts purchase orders (LPOs) and government tenders, including Monaqasat, and accepts payment by bank transfer, cheque or purchase order. Tell the team how many rooms need a box, the table types and whether each room already has Ethernet, HDMI or USB points, so the quotation covers every room. Quotations usually come within one working day.
What should we plan for before installing the EC-PK-DK?
Plan the table cut-out, the cable route to the room's equipment, the power position and the room's environment. The box measures 4 inches (102 mm) high and weighs 5.5 lbs (2.5 kg), and it needs an ambient range of 0 to 30°C with 10 to 90% non-condensing humidity. A free site survey from SmartRooms Qatar covers these points before the table is cut, and professional installation is available across Qatar.
