Parlé DCM-XA

What the Parlé DCM-XA White does in a meeting room

The Parlé DCM-XA White is a ceiling microphone with beamtracking and an integrated two-channel amplifier. Biamp designed it for Devio UCX meeting room systems, so the microphone, its network box and the room loudspeakers can be planned as one audio package instead of separate parts. This white edition is item 920-00028-20000. Its electrical, acoustic and amplifier specifications match the black edition, item 920-00028-10000.

Rather than passing a table microphone around, the unit sits in the ceiling and picks up speech from anywhere in the room. A 16-element digital array forms an active beamformed pickup pattern, and four 90° zones cover the full room. Participants seated on any side of the table are captured without lobe aiming or room mapping during installation.

Specifications that matter for planning

The unit measures 6.8 inches (172 mm) wide, 5.2 inches (132 mm) deep and 1.2 inches (30 mm) high, with a 5.9-inch (150 mm) diameter and a weight of 1.5 lbs (680 g). It is powered over PoE under IEEE 802.3at Class 3 at 15.4 W, and the amplifier uses Class D topology. The key figures are:

• Microphone: 150 Hz to 16 kHz response (±3 dB), SNR above 76 dB and a maximum SPL of 109 dB at below 1% THD.
• Amplifier: 40 W burst per channel at 4 Ω and 30 W at 8 Ω, with continuous output of 8 W single channel driven or 4 W dual channel driven, and a minimum load of 4 Ω.
• Audio quality: THD+N below 0.3% at continuous power, and channel-to-channel crosstalk below -90 dB at 1 kHz.
• Indicators: a green/red mute LED and a power LED that shows green, yellow or red.

Cabling, expansion and network box layout

The microphone connects to its network box with a 6.6 ft (2 m) RJ-45 cable. The network box then uses three RJ-45 connections: one to the network switch, one to the microphone and one to an optional DCM-XEX expansion microphone. The switch-to-box run can reach 330 feet (100 m), and the box-to-DCM-XEX run can reach 33 feet (10 m). Each network box supports up to two microphones, so a larger room can add a second pickup point without adding a separate DSP.

Where it fits in Qatar

A ministry boardroom in Msheireb or West Bay with a long table and regular video calls to colleagues abroad benefits from ceiling pickup, because participants do not need to move microphones to speak. A university seminar room in Education City can add a DCM-XEX to cover a second group of tables. A hotel meeting room in The Pearl or Lusail that hosts conferences can use the amplifier to drive existing ceiling loudspeakers, provided their impedance is 4 Ω or higher.

Installation planning and operating environment

The unit is rated for ambient operation from 0 to 40°C (32 to 104°F) and 0 to 95% relative humidity, non-condensing, up to 10,000 ft (3,000 m) altitude. Qatar summer temperatures outdoors often exceed 45°C, so the microphone belongs in an air-conditioned room, and the ceiling void conditions should be confirmed during the free site survey. Its UL 2043 plenum rating and suitability for air handling spaces matter where the ceiling void is used for return air. To plan the install, request a quote for item 920-00028-20000 and include your room dimensions, loudspeaker impedance and Devio UCX configuration. SmartRooms Qatar provides professional installation and delivery to all eight municipalities of Qatar, and quotations are usually issued within one working day.
