TeamConnect Ceiling Medium CTFP-W
Sennheiser TeamConnect Ceiling Medium CTFP-W Replacement Ceiling Tile
Priceon request
QuotationWithin 1 working day
DeliveryConfirmed with your quote, based on stock
Overview
The Sennheiser TeamConnect Ceiling Medium CTFP-W is a replacement tile for TeamConnect Ceiling Medium and M Plus systems. It houses 15 German-made electret capsules, automatic beamforming and TruVoicelift processing, powered over PoE or PoE+ via an RJ45 Dante connector. Suited to Qatari meeting rooms and boardrooms where an existing ceiling microphone needs replacing. Request a quote.
What this ceiling tile replaces
The Sennheiser TeamConnect Ceiling Medium CTFP-W is a replacement ceiling tile for the TeamConnect Ceiling Medium and the TeamConnect Ceiling M Plus. It takes the place of a damaged or worn tile inside an existing installation, so the rest of the setup can stay in service. Each order covers one TCCM CTFP-W unit.
Audio and connectivity facts that matter
The tile houses 15 SMD electret condenser capsules made in Germany and runs automatic dynamic beamforming, which steers pickup toward whoever is speaking. TruVoicelift processing is part of the feature set. Output can be Dante or analog, and the unit connects through an RJ45 Dante connector. It is powered over PoE or PoE+ and supports single-cable mode and daisy chaining, which keeps cabling above the ceiling simpler.
- Exclusion and priority zones let you define areas of the room where pickup is excluded or favoured.
- Camera control uses talker position data, so a compatible camera can be directed toward the active speaker.
- Network security: the encrypted Sennheiser Sound Control Protocol API (SSCv2) runs over TLS 1.2, and IEEE 802.1x is supported.
Where it fits in Qatar
A ministry meeting room in Msheireb with a failing ceiling microphone can be brought back into service by swapping in this tile, provided the existing system is a TeamConnect Ceiling Medium or M Plus. In West Bay, a bank boardroom with a long table benefits from beamforming that follows speakers seated at either end. A hotel meeting room in The Pearl or Lusail that needs a tile matching a white ceiling can use the paintable metal housing, after checking the painting guidance. Schools in Al Wakrah or Al Khor that run Arabic and English sessions in the same hall can use exclusion zones to ignore areas near doors or displays.
What to plan before ordering
Confirm the model of the existing system before ordering, because the data lists compatibility only with the TeamConnect Ceiling Medium and TeamConnect Ceiling M Plus. Measure the ceiling opening against the tile footprint of 590.8 mm by 590.8 mm and its 26 mm height, and check the 1,034 g weight against your suspension arrangement. The data lists flush, surface, suspended, VESA and ceiling tile mounting options. No operating temperature range appears in the source data, so confirm the ceiling void conditions with the SmartRooms Qatar team, particularly in roof spaces that can exceed 45°C in summer.
Every unit carries the manufacturer's 2-year warranty. SmartRooms Qatar offers free site surveys, delivery to all eight municipalities of Qatar, professional installation, and purchase orders and government tenders. To confirm the right replacement for your room, request a quote, and the team usually replies within one working day.
Highlights
- Replacement tile for TeamConnect Ceiling Medium and M Plus systems
- 15 electret condenser capsules made in Germany
- Powered over PoE or PoE+ with an RJ45 Dante connector
- Automatic dynamic beamforming and TruVoicelift processing
- Encrypted SSCv2 API over TLS 1.2 with IEEE 802.1x support
- Certified for Microsoft Teams with a 2-year manufacturer warranty
Room fit
Tell us the room size and platform (Teams, Zoom or BYOD) and we confirm the right combination with your quotation.
Estimated timeline
Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.
Specifications
10 specifications · Source: manufacturer · checked Oct 2026
Logistics1
- Warranty (years)
- 2
Product Features1
- Color HEX
- #FFFFFF
Product2
- Color
- White
- Warranty AMER (years)
- 2
Connectivity1
- Connectors
- RJ45 Dante
Battery & Power1
- Battery included
- N
Dimensions4
- Product weight (g)
- 1034
- Product height
- 26
- Product length
- 590.8
- Product width
- 590.8
Downloads
10 files from the manufacturer
PDF
Sennheiser TeamConnect Ceiling Medium CTFP-W datasheets (PDF, 46 KB)
PDF
Sennheiser TeamConnect Ceiling Medium CTFP-W manuals & guides (PDF, 1.2 MB)
PDF
Sennheiser TeamConnect Ceiling Medium CTFP-W manuals & guides (PDF, 2.2 MB)
PDF
Sennheiser TeamConnect Ceiling Medium CTFP-W manuals & guides (PDF, 1.2 MB)
PDF
Sennheiser TeamConnect Ceiling Medium CTFP-W manuals & guides (PDF, 1.4 MB)
DWG
Sennheiser TeamConnect Ceiling Medium CTFP-W manuals & guides (DWG)
DXF
Sennheiser TeamConnect Ceiling Medium CTFP-W manuals & guides (DXF)
PDF
Sennheiser TeamConnect Ceiling Medium CTFP-W certificates & compliance (PDF, 93 KB)
QPLU
Sennheiser TeamConnect Ceiling Medium CTFP-W other documents (QPLUG)
ZIP
Sennheiser TeamConnect Ceiling Medium CTFP-W other documents (ZIP)
Questions about TeamConnect Ceiling Medium CTFP-W
What is the TeamConnect Ceiling Medium CTFP-W used for?
It is a replacement ceiling tile for the TeamConnect Ceiling Medium and TeamConnect Ceiling M Plus, so an existing ceiling microphone can be restored without replacing the whole system. A ministry meeting room in Msheireb with a damaged tile is a typical case. The unit contains the microphone array, processing and Dante connection, and it arrives as a single tile.
Is it compatible with other Sennheiser ceiling microphones?
The source data lists compatibility only with the TeamConnect Ceiling Medium and TeamConnect Ceiling M Plus, so do not assume it will work with other Sennheiser models. Before ordering, confirm the exact model of your installed ceiling unit with the SmartRooms Qatar team, who can check it against your system as part of your quote request.
How is the tile powered and connected to the network?
The CTFP-W is powered over PoE or PoE+ and supports single-cable mode and daisy chaining. Its connector is RJ45 Dante, and the output can be Dante or analog. The specification lists no battery. Ask your IT team to confirm switch capacity and the PoE class required before installation.
How many microphone capsules does it use, and where are they made?
The tile uses 15 SMD electret condenser capsules made in Germany. These capsules feed the automatic dynamic beamforming, which directs pickup toward active speakers, along with TruVoicelift processing. In a West Bay boardroom with speakers at both ends of a long table, beamforming is the feature to compare against your room layout.
Can I set zones so the microphone ignores parts of a room?
Yes. The feature set includes exclusion and priority zones, which let you define areas where pickup is excluded or prioritised, along with Intelligent Noise Control. In an Al Wakrah school hall used for both Arabic and English sessions, zones can be mapped to keep focus on the front of the room. Plan zones against the room layout before installation so they match where people actually speak.
Does it work with cameras?
The data lists camera control via talker position data, so a compatible camera can be steered toward the person speaking. The source does not name specific camera brands, so confirm your camera model and video conferencing platform with the SmartRooms Qatar team. The tile is also certified for Microsoft Teams, which matters for Doha teams that meet colleagues abroad.
How secure is the control interface?
Control runs on the encrypted Sennheiser Sound Control Protocol API, SSCv2, using TLS 1.2. The tile also supports IEEE 802.1x for port-based network access control. For a government ministry in Doha where IT security teams review every networked device, present these two points to the network team before approval.
What are the dimensions and weight, and how can it be mounted?
The unit measures 590.8 mm by 590.8 mm, has a height of 26 mm and weighs 1,034 g. The data lists flush, surface, suspended, VESA and ceiling tile mounting options. Measure the ceiling grid opening before ordering and have the installer confirm the suspension. SmartRooms Qatar offers free site surveys if you want the mounting checked on site first.
Can the housing be painted to match a hotel ceiling?
The metal housing is listed as easily paintable, and the unit is supplied in white. A hotel meeting room in The Pearl or Lusail with a different ceiling tone may want a painted tile, but check the manufacturer's painting guidance first and keep paint away from the microphone openings.
Do I need a battery or a separate power adaptor?
The specification lists no battery, and the unit is powered over PoE or PoE+. A separate power adaptor is not mentioned in the source data, so the power route is the PoE switch and its cabling. Your installer should confirm switch capacity and PoE class for the number of tiles on the network before you request a quote.
Is it covered by a warranty?
Yes. The manufacturer gives this model a 2-year warranty. SmartRooms Qatar can explain how it applies when the tile is supplied in Qatar. For a hospital meeting room in Doha where each replacement must be logged, ask for the warranty details to be stated in your written quotation.
Can we buy it through an LPO or a government tender?
Yes. SmartRooms Qatar accepts purchase orders (LPOs) and government tenders, including Monaqasat, with payment by bank transfer, cheque or purchase order. Delivery covers all eight municipalities of Qatar, and quotations are usually issued within one working day. For a ministry replacing several tiles across meeting rooms, send the item list with your request to quote.
