Overview
The Yealink USB2-EXT-5M is a USB 2.0 extender kit that carries high-speed USB data over standard Cat5e cable, reaching up to 40 meters. It includes a transmitter and a receiver with two USB Type-A ports, plus a 48V/0.7A power adapter. It suits Doha meeting rooms, classrooms and training centres where cameras or peripherals must sit far from the host computer.
What the USB2-EXT-5M does
The Yealink USB2-EXT-5M is a USB 2.0 extender kit built from two units. A transmitter connects to the USB host and a receiver connects to the peripheral, and the two are joined by a standard Cat5e network cable through RJ45 ports. The kit carries high-speed USB 2.0 data at 480Mbps, and the manufacturer states that it can extend a USB signal up to 40 meters.
Because the link runs over Cat5e, the cable length is a choice you make on site rather than a fixed accessory. The model code carries a 5M designation, so confirm with the SmartRooms Qatar team which cable length that refers to and how much Cat5e your room will need before ordering.
Specifications that shape the decision
- Transfer rate: USB 2.0 high-speed at 480Mbps.
- Reach: up to 40 meters of USB signal over Cat5e.
- Transmitter: one RJ45 port, one 48V/0.7A power port and a 0.1 m USB Type-A cable.
- Receiver: one RJ45 port and two USB Type-A ports for peripherals.
- Power adapter: AC 100 to 240V input, DC 48V/0.7A output.
- Operating range: 0 to 40°C and 10 to 95% humidity.
- Packed weight: 0.36 kg net and 0.41 kg gross per carton.
Two numbers matter most for Qatar. The power adapter accepts 100 to 240V, which covers the 240V supply used across Qatar, although the plug type should still be checked against BS 1363 sockets. The 0 to 40°C operating range sits well below summer outdoor temperatures, which can exceed 45°C, so the units belong in air-conditioned rooms.
Where it fits in Qatar
Three situations show where the extender earns its place:
- A government boardroom in Msheireb: the host PC sits in a credenza at one end, while the conferencing camera and speakerphone need to sit near the far wall. A single Cat5e run keeps the cabling tidy and avoids long USB cables.
- A classroom in Al Wakrah: the teacher's document camera or interactive tools are far from the front-of-room computer. The receiver's two USB ports allow two peripherals at the desk.
- A training room in Education City: a keyboard, mouse or capture device must reach a lectern across a long room, and the cable route runs through trunking rather than across the floor.
Planning the installation
Plan the route before walls are closed. Measure the distance from the host PC to each peripheral, then decide the Cat5e length and where each unit will sit. The transmitter needs a power point, so check socket positions in advance. SmartRooms Qatar offers a free site survey, a practical way to confirm routes, socket positions and room conditions before anything is fixed.
The box contents include a transmitter, a receiver, an interface protective cover, the power adapter and a quick start guide. The manufacturer describes the kit as suitable for nearly all USB peripherals, but confirm that your specific device works over USB 2.0 before ordering several units.
Ordering for your organisation
Schools, ministries and companies buying more than one kit can issue a purchase order (LPO) or bid for a government tender, including Monaqasat. Payment is by bank transfer, cheque or purchase order, and the product is covered by the manufacturer's warranty. Send us the room list, the distance for each run and the peripherals involved, and the SmartRooms Qatar team will return a quotation, usually within one working day. Request a quote today.
Highlights
- USB 2.0 high-speed transmission at 480Mbps
- Up to 40 meters over standard Cat5e cable
- Receiver with two USB Type-A ports
- 48V/0.7A power adapter, 100 to 240V input
- Operating range 0 to 40°C, 10 to 95% humidity
- Package includes transmitter, receiver and protective cover
Room fit
Tell us the room size and platform (Teams, Zoom or BYOD) and we confirm the right combination with your quotation.
Estimated timeline
Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.
Specifications
10 specifications · Source: manufacturer · checked Oct 2026
Package includes1
- Details
- Extender Transmitter Extender Receiver Interface Protective Cover Power Adapter (48V/0.7A) Quick Start Guide
Extender Transmitter2
- Transmision Rate
- USB2.0 highspeed 480Mbps
- Details
- 1x 0.1m USB Type-A cable 1x RJ45 port 48V/0.7A Power port
Extender Receiver1
- Details
- 1x RJ45 port 2x USB Type-A port Interface Protective Cover
Package Features3
- N.W/CTN
- 0.36 kg
- G.W/CTN
- 0.41kg
- Giftbox Size
- 180 mm x 119 mm x 56 mm
Other Physical Features3
- External Yealink Power Adapter
- AC 100~240V input and DC 48V/0.7A Output
- Operating humidity
- 10~95%
- Operating temperature
- 0~40℃
Downloads
3 files from the manufacturerQuestions about USB2-EXT-5M
What is the Yealink USB2-EXT-5M used for?
It is a USB 2.0 extender kit that moves a USB signal from a host computer to a peripheral several meters away over ordinary Cat5e network cable. It suits meeting rooms, classrooms and training spaces where a camera or microphone cannot sit beside the computer. The kit runs at 480Mbps, and the manufacturer quotes a reach of up to 40 meters.
How far can the extender carry a USB signal?
The manufacturer states that the kit extends a USB 2.0 signal up to 40 meters over Cat5e cable. The reach you need depends on the actual route through the room and any wall or ceiling trunking, so measure that path before choosing the Cat5e length. Ask the SmartRooms Qatar team to confirm which cable length the 5M model code refers to before ordering.
Does the kit need a special cable?
The link runs on standard Cat5e network cable with RJ45 connectors at both ends, so you choose the length to suit each room. The transmitter includes a 0.1 m USB Type-A cable for connecting to the host computer. Plan the Cat5e run and its route before ordering, so the quantity matches each location.
What is included in the box?
The package contains an extender transmitter, an extender receiver, an interface protective cover, a power adapter with 48V/0.7A output and a quick start guide. The gross carton weight is 0.41 kg and the giftbox measures 180 mm x 119 mm x 56 mm, which helps when planning storage and delivery for several rooms at once.
What ports are on the transmitter and receiver?
The transmitter has one RJ45 port for the Cat5e link, a 48V/0.7A power port and a 0.1 m USB Type-A cable. The receiver has one RJ45 port and two USB Type-A ports, so two peripherals can connect at the far end of the link. An interface protective cover is also included in the package.
Will the power adapter work on Qatar's 240V supply?
The external adapter accepts AC 100 to 240V input and outputs DC 48V/0.7A, so its input range covers the 240V supply used in Qatar. The source data does not state the plug type, so confirm it suits BS 1363 (Type G) sockets with the SmartRooms Qatar team before ordering. Power feeds the transmitter, so plan a socket near that unit.
Can I install the units in a hot or unconditioned space in Doha?
No. The operating range is 0 to 40°C with 10 to 95% humidity, while outdoor summer temperatures in Doha can exceed 45°C. Keep both units in air-conditioned rooms such as a boardroom or classroom, and avoid rooftops, unventilated cabinets and hot ceiling voids.
How does it suit a boardroom in West Bay?
In a West Bay boardroom, the host PC may sit in a credenza at one end while the camera and speakerphone sit near the far wall. One Cat5e link from the host to the peripheral keeps long USB cables off the floor. The receiver's two USB Type-A ports leave room for two peripherals at that end of the table, so measure the route before the site visit.
Is it useful for a classroom in Al Wakrah?
Yes, when a document camera, microphone or other peripheral sits far from the front-of-room computer. The receiver's two USB Type-A ports let two devices connect at the teacher's desk. Because the operating range is 0 to 40°C, keep the units inside the air-conditioned classroom and confirm the trunking and socket positions with the team before fitting.
Will it work with my USB device?
The manufacturer describes the kit as suitable for nearly all USB peripherals, but the source data does not list tested devices. Before ordering several units, check the requirements of your camera, microphone, keyboard or storage device and confirm it works over USB 2.0 high-speed at 480Mbps. SmartRooms Qatar can review your device list as part of the quotation.
Can a school or ministry order several units under an LPO or tender?
Yes. Schools, ministries and companies can issue a purchase order (LPO) or take part in a government tender, including Monaqasat. Payment is by bank transfer, cheque or purchase order, and the product is covered by the manufacturer's warranty. Send the room list and cable distances, and SmartRooms Qatar will return a quotation, usually within one working day.
What should we check before a site visit?
Measure the path from the host computer to each peripheral, note socket positions for the power adapter, and compare the room temperature against the 0 to 40°C range. SmartRooms Qatar offers a free site survey to confirm the Cat5e route and mounting positions. Confirm the cable length that the 5M model code refers to before the Cat5e run is cut and fixed.
