55VL5F-A

A 55-inch narrow-bezel panel built for tiled video walls

The LG 55VL5F-A is a 55-inch LCD display designed to be tiled into a video wall. Its 3.5 mm bezel-to-bezel gap keeps frame lines small when several panels sit side by side, so the wall reads as one picture rather than a grid. The panel uses IPS technology with a 1920 x 1080 Full HD resolution, a 16:9 aspect ratio and a 60 Hz refresh rate.

Picture and panel facts that matter on a wall

On a wall, uniform brightness and colour across every screen matter more than peak figures on a single panel. The key specifications are:

• Brightness: 500 nit typical, with a 1,200:1 contrast ratio and 500,000:1 dynamic contrast.
• Viewing angle: 178 degrees horizontally and 178 degrees vertically, so people standing well to the side still see accurate colour.
• Colour: NTSC 72% colour gamut and 1.07 billion displayable colours.
• Surface and response: 3% haze surface treatment and 8 ms G-to-G response time.
• Calibration: colour temperature adjustable in 100K steps from the remote, and grey-scale white balance that can be set for each value.

The image gap reduction feature adjusts content at bezel boundaries during video playback, which reduces visible breaks when a moving image runs across adjacent screens.

Where it fits in Qatar

Three realistic scenarios show where this panel earns its place:

• A corporate lobby in West Bay or Lusail, where a video wall greets visitors and shows company news to people approaching from several directions.
• A hospital or clinic reception in Doha, where wayfinding and health information on a wall must be readable from the waiting area.
• A control room at an industrial site in Mesaieed or Ras Laffan, where operators need a wall showing process data around the clock.

What to plan before installation

Environment comes first. The panel operates between 0 °C and 40 °C and between 10% and 80% humidity, so it belongs in an air-conditioned indoor room. Summer temperatures in Qatar often exceed 45 °C, so keep the wall away from sunlit windows and outdoor positions. Typical power draw is 130 W and maximum is 150 W, with heat output of 444 BTU/hr typical and 512 BTU/hr maximum. Include these figures in your cooling load when several panels run together.

Mechanical planning matters just as much. Each head weighs 20.3 kg and the packed unit weighs 33 kg, so plan for at least two people to lift it. The VESA interface is 600 x 400 mm, and the panel supports both portrait and landscape orientation. The manufacturer lists optional wall mounts WM-L640V for landscape and WM-P640V for portrait. A free site survey from SmartRooms Qatar lets the wall structure and bracket layout be checked before any panel is fixed.

Connecting and controlling the wall

Inputs include two HDMI ports (HDCP 1.4), one DisplayPort input (HDCP 1.3) and one DVI-D input (HDCP 1.4). Outputs include DisplayPort for daisy-chaining, plus RS232C in and out, an RJ45 LAN port, IR input, audio in and out, and a USB 2.0 Type A port. The panel has built-in power, but it has no OPS slot, no built-in Wi-Fi and no speaker, so content comes from an external player. Management software includes SuperSign CMS, SuperSign Control+ and SuperSign WB, with SNMP, Wake on LAN, HDMI-CEC and Crestron connectivity for network control. The manufacturer states security updates for 5 years from the product launch date.

Request a quote for your video wall

Send us the wall size, the number of panels and the room conditions, then request a quote from SmartRooms Qatar. Quotations usually arrive within one working day. We supply and deliver to all eight municipalities of Qatar, with professional installation, and we accept LPOs, government tenders including Monaqasat, and payment by bank transfer, cheque or purchase order. The product is covered by the manufacturer's warranty.
