55VM5J-H
LG 55VM5J-H 55-inch Slim Bezel LCD Video Wall Display
- Screen size
- 55″
- Bezel
- Black
- Resolution
- 1920 x 1080 (FHD)
- Brightness
- 500nit (Typ.)
Priceon request
QuotationWithin 1 working day
DeliveryConfirmed with your quote, based on stock
Overview
The LG 55VM5J-H is a 55-inch full HD LCD panel built for tiled video walls, with a 1.74mm panel-to-panel bezel, 500 nits typical brightness and an IPS panel that holds colour from wide viewing positions. It is rated for 24/7 operation and includes IP5X-tested dust protection. It suits control rooms, lobbies and boardrooms in Doha, Lusail and Education City. Request a quote from SmartRooms Qatar.
The LG 55VM5J-H is a 55-inch LCD panel built to be tiled into one larger display. Its narrow bezel and full HD resolution suit control rooms, lobby walls, retail corridors and meeting spaces where several screens must read as a single image.
How the bezel and image tools affect a tiled wall
The panel-to-panel gap is 1.74mm, measured from bezel to bezel, so the joins between neighbouring screens stay slim. An image gap reduction algorithm softens the break where content crosses two panels, and tile mode settings help align the wall. The IPS panel is rated at 178º horizontal and vertical viewing angles, so colours hold up for people at the side of a room or looking up at a wall mounted high.
Specifications that shape the installation
- Display: 1920 x 1080 native FHD, 16:9, 500 nits typical, 60Hz refresh and 8ms grey-to-grey response.
- Operating envelope: 0 °C to 40 °C and 10% to 80% humidity, rated for 24/7 operation.
- Power: AC 100-240V, 50/60Hz with built-in power, 160W typical and 190W maximum, 546 BTU/hr typical for cooling planning.
- Mechanical: 1212.2 x 683.0 x 86.9mm, 18.8kg head weight, black bezel and a 600 x 400mm VESA mount interface.
- Connections: two HDMI inputs, DisplayPort in and out, DVI-D in, LAN, RS232C and IR control, and a USB 2.0 Type A port.
Where it fits in Qatar
A government authority in West Bay building a briefing room could tile these panels for live dashboards, and the conformal-coated power board and IP5X-tested dust protection suit offices where dust settles quickly. A private school in Al Wakrah fitting out a reception atrium could use a wall to show announcements and student work, with the 24/7 rating covering long opening hours. A hotel in The Pearl could run a lobby wall for wayfinding and event listings, provided the space is air-conditioned, since the operating range tops out at 40 °C.
Planning a 55-inch video wall in Qatar
Survey the wall before ordering. Each panel head weighs 18.8kg, so the wall structure, the 600 x 400mm mounting pattern and the bracket layout need checking by a qualified installer. SmartRooms Qatar offers a free site survey to measure the wall, confirm cable routes and review the room environment. Plan room cooling for the heat load, because every panel adds 160W typical to the room. The guide bracket, screws and cabling in the box give you a starting point for the mounting plan.
Send your room dimensions, the number of panels and the wall you plan to use to SmartRooms Qatar, and request a quote. Quotations are usually issued within one working day.
Highlights
- 1.74mm panel-to-panel bezel for tiled video walls
- Native 1920 x 1080 FHD, 16:9, 500 nits typical
- IPS panel with 178º horizontal and vertical viewing angles
- Rated for 24/7 operation, 0 °C to 40 °C operating range
- IP5X-tested dust protection and conformal-coated power board
- Built-in webOS 4.1 with LAN, HDMI and DisplayPort daisy chaining
Plan your video wall
Rows
Columns
Wall size about 3.65 × 2.05 m · 9 panels
Estimated timeline
Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.
Specifications
135 specifications · Source: manufacturer · checked Oct 2026
SOUND1
- Speaker (Built-in)
- NO
LANGUAGE1
- OSD
- English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portuguese(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portuguese(Europe), Dutch, Czech, Greek, Turkish, Arabic
ACCESSORY2
- Basic
- Remote Controller(include battery 2ea), Power Cord, RS232C cable, Lan cable, DP cable, IR Receiver, Guide Bracket, Screws, Manual
- Optional
- OPS Kit(KT-OPSF)
POWER2
- Power Supply
- AC 100-240V~, 50/60Hz
- Power Type
- Built-in Power
CERTIFICATION4
- EMC
- FCC Class "B" / CE / KC
- ePEAT(US only)
- NO
- ERP / Energy Star
- YES / Energy Star 8.0
- Safety
- CB / NRTL
ENVIRONMENT CONDITIONS2
- Operation Humidity
- 10 % to 80 %
- Operation Temperature
- 0 °C to 40 °C
OPS COMPATIBILITY2
- OPS Power Built-in
- NO
- OPS Type compatible
- YES (Piggyback)
POWER CONSUMPTION6
- BTU (British Thermal Unit)
- 546 BTU/Hr(Typ.), 648 BTU/Hr(Max.)
- DPM
- 0.5W
- Max.
- 190W
- Power off
- 0.5W
- Smart Energy Saving (70%)
- 90W
- Typ.
- 160W
MECHANICAL SPECIFICATION10
- Weight (Head)
- 18.8Kg
- Bezel Color
- Black
- Bezel Width
- B2B : 1.74mm (Panel Bezel to Panel Bezel), 1.3mm(T/L), 0.44mm(B/R) A2A : 2.49mm (Active area to Active area), 1.75mm(T/L), 0.74mm(B/R)
- Carton Dimensions (W x H x D)
- 1393 x 955 x 303mm
- Handle
- YES
- Monitor Dimensions (W x H x D)
- 1212.2 x 683.0 x 86.9mm
- Monitor Dimension with Stand (W x H x D)
- N/A
- Packed Weight
- 28.0Kg
- VESA Standard Mount Interface
- 600 x 400 mm
- Weight (Head+Stand)
- N/A
PANEL19
- Aspect Ratio
- 16:9
- Back Light Type
- Direct
- Brightness
- 500nit (Typ.)
- Color Depth (Number of Colors)
- 1.07 Billion colors
- Color Gamut
- NTSC 72%
- Contrast Ratio
- 1,000:1
- Dynamic CR
- 500,000:1
- Life time
- 60,000Hrs (Typ.)
- Native Resolution
- 1920 x 1080 (FHD)
- Operation Hours (Hours/Day)
- 24/7
- Panel Technology
- IPS
- Portait / Landscape
- YES / YES
- QWP (Quarter Wave Plate)
- N/A
- Refresh Rate
- 60Hz
- Response Time
- 8ms (G to G)
- Screen Size (Inch)
- 55
- Surface Treatment (Haze)
- Haze 28%
- Transparency
- N/A
- Viewing Angle (H x V)
- 178º x 178º
CONNECTIVITY19
- Audio In
- YES
- Audio Out
- YES
- Daisy Chain
- Input : HDMI, DP, DVI-D / Output : DP
- DP In
- YES (HDCP 2.2)
- DP Out
- YES
- DVI-D In
- YES (HDCP 1.4)
- External Speaker Out
- NO
- HDMI In
- YES (2ea)
- HDMI In (HDCP Ver.)
- 2.2
- HDMI Out
- NO
- IR In
- YES
- IR Out
- NO
- RGB In
- NO
- RJ45(LAN) In
- YES (1ea)
- RJ45(LAN) Out
- YES
- RS232C In
- YES
- RS232C Out
- YES
- Touch USB
- NO
- USB In
- USB2.0 Type A (1ea)
SPECIAL FEATURE8
- Conformal Coating (Power Board)
- YES
- Direct Sunlight
- N/A
- IP Rating
- IP5X tested
- Overlay Touch Compatibility
- N/A
- Power Protection
- N/A
- Smart Calibration
- N/A
- Tilt (Face down)
- N/A
- Tilt (Face up)
- N/A
SOFTWARE COMPATIBILITY7
- Connected Care
- YES
- Mobile CMS
- NO
- Promota
- NO
- SuperSign Cloud
- NO
- SuperSign CMS
- YES
- SuperSign Control+
- YES
- SuperSign WB
- YES
FEATURE - HARDWARE13
- Acceleration(Gyro) Sensor
- YES
- Auto Brightness Sensor
- NO
- BLU Sensor
- YES
- Current Sensor
- NO
- FAN (Built-in)
- NO
- Humidity Sensor
- NO
- Internal Memory (eMMC)
- 8GB
- Local Key Operation
- YES
- Pixel Sensor
- NO
- Power Indicator
- NO
- Proximity Sensor
- NO
- Temperature Sensor
- YES
- Wi-Fi/BT (Built-in)
- NO
FEATURE - SOFTWARE39
- Auto Set ID
- YES
- Backlight Sync
- NO
- Beacon
- NO
- Booting Logo Image
- NO
- Brightness Compensation
- NO
- Cisco Certification
- NO
- Control Manager
- YES
- Crestron Connected
- YES
- External Input Rotation
- YES
- Fail over
- YES
- Gapless Playback
- YES
- Group Manager
- YES
- HDMI-CEC
- YES
- ISM Method
- YES
- Local Contents Scheduling
- YES
- Local Network Sync
- YES
- Network Ready
- YES
- No Signal Image
- YES
- OS Ver. (webOS)
- webOS 4.1
- PBP
- NO
- PIP
- NO
- Play via URL
- YES
- PM mode
- YES
- Pro:Idiom
- YES
- RS232C Sync
- YES
- Scan Inversion
- YES
- Screen Rotation
- YES
- Screen Share
- NO
- Setting Data Cloning
- YES
- SI Server Setting
- YES
- Smart Energy Saving
- YES
- SNMP
- YES
- Status Mailing
- YES
- Tile Mode Setting
- YES
- USB Plug & Play
- YES
- Video Tag
- YES (4 Video Tag)
- Wake on LAN
- YES
- webRTC
- YES
- W/B Setting by Grey scale
- YES
Downloads
9 files from the manufacturer
PDF
LG 55VM5J-H datasheets (PDF, 2.5 MB)
PDF
LG 55VM5J-H manuals & guides (PDF, 1.6 MB)
PDF
LG 55VM5J-H manuals & guides (PDF, 1.3 MB)
PDF
LG 55VM5J-H manuals & guides (PDF, 3.0 MB)
URL
LG 55VM5J-H manuals & guides (URL)
PDF
LG 55VM5J-H drawings & cad (PDF, 3.0 MB)
DWG
LG 55VM5J-H drawings & cad (DWG)
URL
LG 55VM5J-H software & firmware (URL)
URL
LG 55VM5J-H software & firmware (URL)
Questions about 55VM5J-H
What is the LG 55VM5J-H built for?
It is a 55-inch FHD LCD panel made to be joined with other panels into one video wall. With a 1.74mm bezel-to-bezel gap, 500 nits typical brightness and 24/7 operation, it suits control rooms, boardrooms, lobbies and retail spaces in Qatar where one image must span several screens. A single panel works as a large display, but its narrow bezel is what makes it valuable in a grid.
How narrow is the bezel, and what do the figures mean?
The bezel-to-bezel gap between two panels is 1.74mm, while the active-area-to-active-area gap is 2.49mm. Within the bezel, the top and left edges measure 1.3mm and the bottom and right edges measure 0.44mm, so the top and left edges are noticeably thicker. For a multi-panel wall, the bezel-to-bezel figure is the one that matters most when judging how visible the joins will be in a control room.
Can the panel be used in portrait orientation for digital signage?
Yes. The panel supports both portrait and landscape use, and its on-screen menu is designed for portrait screens, with bigger font sizes and a 9:16 layout. That makes it a fit for a vertical totem in a Msheireb office lobby or a shopping mall corridor in Doha, where directories read more naturally in tall format. Confirm the bracket orientation before installation, since the included guide bracket and VESA pattern are the starting point for that plan.
Can it be installed near a window or in a non-air-conditioned area?
The operating range is 0 °C to 40 °C with 10% to 80% humidity, so the panel is not rated for open-air or unconditioned spaces. Summer temperatures in Qatar regularly pass 45 °C, which means a panel near a sun-facing window or in a hot storeroom could exceed its rating. Keep the wall in an air-conditioned room and ask the SmartRooms Qatar team to review the exact location during the site survey.
Does the panel need a separate media player?
Not necessarily. The panel has a built-in SoC and the webOS 4.1 signage platform, which can run several tasks and play content without an external media player. Web apps can play four videos simultaneously, and the panel works with SuperSign CMS and SuperSign Control+ for managing content. Ask the SmartRooms Qatar team to confirm your content workflow when you request a quote.
Can I add a PC or OPS module to this panel?
The panel is compatible with OPS in a piggyback configuration, and LG lists an optional OPS kit, the KT-OPSF. The panel does not provide built-in OPS power, so the power arrangement for any OPS module must be planned separately. An OPS module lets you run a computer inside the panel itself, which suits boardrooms and control rooms that need one neat installation.
How do I connect and control a wall of these panels?
A LAN daisy chain lets you control and monitor the whole wall and update firmware on all panels at once. For video, HDMI and DisplayPort can be daisy-chained to build a UHD wall without DisplayPort MST, with DisplayPort providing the output. Each panel also has RS232C in and out, IR control and LAN in and out, so a control system can manage the wall from one point.
Does the panel work with Qatar's 240 V power supply?
The power specification is AC 100-240V at 50/60Hz, which covers the 240V, 50Hz mains used in Qatar. A power cord is included in the box. Typical draw is 160W and maximum is 190W, and smart energy saving at 70% brings the draw to 90W. Your electrical contractor should confirm circuit capacity and socket outlets for the number of panels planned before installation.
How well does it handle dust and humidity?
The panel is IP5X tested, and its power board has conformal coating that protects against salt, dust, iron powder and humidity. That matters for industrial sites in Mesaieed, Ras Laffan or the Industrial Area, where airborne dust is common. The panel is still rated for 10% to 80% humidity and 0 °C to 40 °C, so keep it within those limits in a sheltered, air-conditioned space.
Is it suitable for a boardroom or executive meeting room?
Yes. It is certified as EMC Class B, a rating for equipment used close to people in offices as well as residential settings. Colour temperature can be adjusted in 100K steps with the remote, and each grey-scale value can be set for white balance, which helps a boardroom in Msheireb or West Bay match brand colours. The 55-inch size suits a small group seated in front of one wall.
Does the panel include speakers?
No. The panel has no built-in speaker and no external speaker output, so sound must come from a separate source. It does provide audio input and audio output ports, so you can route audio from a media source or conferencing system into the wall setup. Plan the audio arrangement at the design stage, especially for a lobby or atrium where background sound carries.
Can an LPO or government tender be used to buy this panel?
Yes. SmartRooms Qatar supplies against purchase orders (LPOs) and government tenders, including Monaqasat, and accepts payment by bank transfer, cheque or purchase order. For a school or ministry ordering several 55VM5J-H panels, the quotation should list each panel, the bracket plan and the included accessories. Send the room layout and quantity with your request, and the team will confirm lead times with the quotation.
