Philips 55BDL8107X/00 · Price in Qatar

Name: Philips 55BDL8107X/00 55-inch Full HD Video Wall Display
Brand: Philips
SKU: philips-55bdl8107x-00
Availability: InStock

Overview

The Philips 55BDL8107X/00 is a 55-inch Full HD LCD video wall panel built to be tiled into larger displays. It has a 0.44 mm + 0.44 mm bezel, 700 cd/m² brightness and control for tiled matrices up to 15 x 15. Inputs include DisplayPort 1.3, two HDMI 2.0 and an OPS slot, with network control built in. It suits control rooms, lobbies and corporate reception areas in Doha, Lusail and West Bay.

A 55-inch panel built for tiled video walls

The Philips 55BDL8107X/00 is a 55-inch LCD panel from the Videowall 8000 range, built mainly as one tile in a larger wall, though it also works as a standalone display. Its 54.5-inch diagonal carries a Full HD 1920 x 1080 panel in 16:9, and it runs in landscape or portrait orientation around the clock.

Bezels and tiling for a larger wall

The 0.44 mm + 0.44 mm bezel keeps the gap between neighbouring screens narrow, which matters more than usual once several panels sit side by side. The controls support a tiled matrix of up to 15 x 15 panels, so one model can scale from a small array to a large command wall.

Picture quality and room lighting

The panel is rated at 700 cd/m² with a typical contrast ratio of 1200:1, and its 178-degree horizontal and vertical viewing angles keep the image readable from the side of a room. Brightness is the figure to test against your space: a wall facing glazing in West Bay or Lusail should be checked under real daylight before you commit.

Connections, control and sound

Video inputs are one DisplayPort 1.3, two HDMI 2.0, one DVI-D and one VGA, with a DisplayPort 1.3 output for passing the signal on. An OPS slot takes a compatible computing module, and the supported video formats reach 2160p at 50 and 60 Hz over HDMI, OPS or DisplayPort. Because the panel itself is Full HD, 4K sources are scaled down to it.

Network control: two LAN RJ45 ports, with RJ45 and DisplayPort loop-through.
Sound: two 10 W RMS built-in speakers, plus 3.5 mm audio input and output.
Languages: on-screen menus in Arabic and English, plus ten other languages.
Power: 0.5 W standby, energy label G, rated consumption 134 W.
Environment: 0 to 40 °C operation, 20 to 80% humidity without condensation, up to 3,000 m altitude.
Reliability: MTBF of 50,000 hours and a 3-year warranty.

Where it fits in Qatar

A ministry or energy operator can use several 55-inch tiles in a control room to show operational dashboards from one network controller. A corporate lobby in The Pearl or West Bay can run a single panel for bilingual company messages, and a university media lab in Education City can combine tiles for lectures and recording sessions. Doha summers push poorly cooled spaces past 45 °C, so keep this panel in air-conditioned rooms, since its rated operating maximum is 40 °C. The SmartRooms Qatar team can confirm the environment for your site.

Planning the installation

Each panel weighs 23.8 kg before any mount, so the wall needs checking before fixing. The wall mount pattern is 400 x 400 mm with M6 fixings, and the Smart Insert pattern is 100 x 100 mm. The package includes three gap pads, edge alignment pins and kit, a remote control, an IR sensor cable, a power cord and an RJ45/RS232 converter. Optional EFK5539 (top and bottom) and EFK5569 (left and right) edge finishing kits suit tiled installations.

SmartRooms Qatar offers a free site survey before installation, delivery to all eight municipalities of Qatar and professional installation. Purchase orders and government tenders are welcome, so send your wall layout and room details and request a quote. Quotations usually arrive within one working day.

Highlights

55-inch panel with 54.5-inch diagonal and Full HD 1920 x 1080 resolution
0.44 mm + 0.44 mm bezel for tiled video walls up to 15 x 15
700 cd/m² brightness and 1200:1 typical contrast ratio
DisplayPort 1.3 input and output, two HDMI 2.0 inputs
OPS slot, two LAN RJ45 ports and IR control
0 to 40 °C operating range with 3-year warranty

Plan your video wall

Rows3

Columns3

Wall size about 3.65 × 2.05 m · 9 panels

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

54 specifications · Source: manufacturer · checked Oct 2026

Connectivity6

Video output: Display Port 1.3 (x 1)
External control: IR (in) 3.5 mm jack; LAN RJ45 (x2); Signal loopthrough RJ45 (x 2)
Audio input: 3.5 mm mini jack (x 1)
Other connections: OPS; USB 2.0 (x 1); Thermal sensor
Video input: DVI-D (x 1); VGA (Analogue D-Sub) (x 1); Display Port1.3 (x 1); HDMI 2.0 (x 2)
Audio output: 3.5 mm Mini Jack (x 1)

Convenience7

Signal loop through: DisplayPort; RJ45
Energy-saving functions: Smart Power
Tiled Matrix: Up to 15 x 15
Network controllable: LAN (RJ45)
Ease of installation: Carrying Handles; Smart Insert
Placement: Landscape (24/7); Portrait (24/7)
Screen-saving functions: Pixel Shift, Low Bright

Accessories2

Included Accessories: Gap pad x 3; IR sensor cable (1.8 m) (x 1); Quick start guide (x 1); Remote control and AAA batteries; RJ45/RS232 converter; Power cord; DP cable (x1); RJ45 cable (x1); Edge alignment pin (x2); Edge alignment kit (x 1)
Optional accessories: Edge finishing kit top/bottom: EFK5539; Edge finishing kit left/right: EFK5569

Dimensions10

Smart Insert mount: 100 mm x 100 mm, 6 x M4 x L6
Set Height (inch): 26.85 inch
Set Width: 1211.1 mm
Set Depth: 95.3 mm(D@WallMount)/94.3 mm(D@Handle) mm
Product weight: 23.8 kg
Set Depth (inch): 3.75 (D@WallMount) / 3.71 (D@Handle) inch
Bezel width: 0.44 mm + 0.44 mm
Set Height: 681.9 mm
Wall Mount: 400 mm x 400 mm, M6
Set Width (inch): 47.68 inch

Sound1

Built-in speakers: 2 x 10 W (RMS)

Power3

Standby power consumption: 0.5 W
Energy Label Class: G
Consumption: EEI lot5 134 W

Operating conditions6

Temperature range (operation): 0 ~ 40 °C
Humidity range (operation)[RH]: 20 - 80% (without condensation)
Humidity range (storage) [RH]: 5 - 95% (without condensation)
Temperature range (storage): -20 ~ 60 °C
MTBF: 50,000 hour(s)
Altitude: 0 ~ 3000 m

Miscellaneous3

Warranty: 3 year warranty
Regulatory approvals: CE; FCC, Class A; RoHS; CB
On-Screen Display Languages: Arabic; English; French; German; Italian; Japanese; Polish; Russian; Spanish; Simplified Chinese; Turkish; Traditional Chinese

Picture/Display14

Contrast ratio (typical): 1200:1
Viewing angle (vertical): 178 degree
Display colours: 16.7 M
Viewing angle (horizontal): 178 degree
Panel resolution: 1920 x 1080p
Pixel pitch: 0.63 x 0.63 mm
Response time (typical): 8 ms
Aspect ratio: 16:9
Dynamic contrast ratio: 500,000:1
Brightness: 700 cd/m²
Diagonal screen size (inch): 54.5 inch
Haze: 25%
Optimum resolution: 1920 x 1080 @ 60 Hz
Diagonal screen size (metric): 138.7 cm

Supported Display Resolution2

Computer formats: 640 x 480, 60, 72, 75 Hz; 720 x 400, 70 Hz; 800 x 600, 60, 75 Hz; 1024 x 768, 60, 75 Hz; 1280 x 768, 60 Hz; 1280 x 800, 60 Hz; 1280 x 960, 60 Hz; 1280 x 1024, 60 Hz; 1360 x 768, 60 Hz; 1366 x 768, 60 Hz; 1600 x 1200, 60 Hz; 1920 x 1080, 60 Hz
Video formats: 720p, 50, 60 Hz; 1080i, 25, 30 Hz; 1080p, 50, 60 Hz; 2160 P 50, 60 Hz ((HDMI/OPS/DP)

Downloads

4 files from the manufacturer

PDF Datasheets 55BDL8107X_00_a_Videowall_55BDL8107X_00.pdf 517 KB PDF Manuals & guides Philips_55BDL8107X_EDFU_dfu_V1_00_eng.pdf 13.6 MB PDF Manuals & guides · Opens on manufacturer site 1781222566-philips_55bdl8107x_edfu_dfu_v1_00_ara.pdf PDF Drawings & CAD Outline_Drawing_Philips_55BDL8107X_V0_2_20260116.pdf 352 KB

Questions about 55BDL8107X/00

Is this panel suited to a ministry control room in Doha?

Yes. It is a 55-inch Full HD LCD panel designed to be tiled into a video wall, so it suits control rooms and operations centres where several screens must show one connected picture. Each unit also runs alone in landscape or portrait and includes two 10 W speakers. If you only need one screen for a meeting room, compare standalone display options before deciding.

Can a university media lab in Education City tile several of these into one wall?

Yes. The model supports a tiled matrix of up to 15 x 15 panels, and its 0.44 mm + 0.44 mm bezel keeps the gap between screens small. Each unit comes with three gap pads, edge alignment pins and an edge alignment kit. For a finished edge on a tiled installation, the optional EFK5539 covers top and bottom edges and the EFK5569 covers left and right edges. A site survey helps set the matrix before you order.

Can this panel run in a non-air-conditioned area in Doha?

No. The rated operating range is 0 to 40 °C with 20 to 80% humidity, without condensation, while Doha summers regularly exceed 45 °C. Install it only in air-conditioned rooms such as lobbies and control rooms, and confirm cabinet ventilation with the SmartRooms Qatar team before installation. Storage is rated from -20 to 60 °C.

Which video inputs and outputs does it have?

It has one DisplayPort 1.3 input, two HDMI 2.0 inputs, one DVI-D input and one VGA input, plus a 3.5 mm audio input and one USB 2.0 port. The DisplayPort 1.3 output passes the signal to the next panel in a chain. The OPS slot lets you add a compatible computing module. Check your source device outputs against these ports before ordering cables.

Does it support 4K video?

The supported video formats include 2160p at 50 and 60 Hz over HDMI, OPS or DisplayPort. The panel itself is 1920 x 1080, so 4K content is shown at Full HD resolution. The optimum resolution is 1920 x 1080 at 60 Hz. If sharp text matters on a wall, plan your content at Full HD.

Can a control room in Msheireb link several panels to one network controller?

Yes, through the two LAN RJ45 ports, and the RJ45 loop-through lets you connect panels on the same network. A remote control and an IR sensor cable with a 1.8 m length are included, and an RJ45/RS232 converter is in the box for serial control. Before ordering, confirm with SmartRooms Qatar which control software or building system will manage the wall.

Will the screens be readable in a bright lobby facing windows in West Bay?

The panel is rated at 700 cd/m² with a typical contrast ratio of 1200:1, a sound starting point for indoor lobbies. Direct sunlight through glass needs assessing on site, so a wall opposite a window should be checked for light levels. SmartRooms Qatar offers a free site survey to measure conditions and position the wall before you buy.

How much does each panel weigh and what does the wall need to carry?

Each panel weighs 23.8 kg before any mount. With the wall mount fitted, the set measures 1211.1 mm wide, 681.9 mm high and 95.3 mm deep. The wall mount pattern is 400 x 400 mm with M6 fixings. Ask for a site survey so the wall structure, fixings and carrying route are checked before installation. Carrying handles help installers move each panel safely.

Can it be mounted in portrait for a vertical information display?

Yes. The specification lists both landscape and portrait placement for 24/7 operation. Portrait suits a vertical wayfinding column in a mall atrium in Lusail or a tall information board at a hospital reception, where content runs top to bottom. State the orientation in your quotation request so the mounting and content plan match.

What are the power and energy figures?

Standby consumption is 0.5 W, the energy label class is G, and the rated consumption figure is 134 W. A power cord is included in the box. Energy-saving functions include Smart Power, and screen-saving functions include pixel shift and a low-brightness mode. Confirm the power outlet and cord arrangement for your site with the SmartRooms Qatar team before installation.

Can a school or government office in Al Rayyan order several units on one LPO?

Yes. The panel carries a 3-year warranty from the manufacturer and a rated MTBF of 50,000 hours. Send your quantity list and room details with the request, and SmartRooms Qatar will quote for the full set. Payment can be made by bank transfer, cheque or purchase order, and government tenders, including Monaqasat, are supported.
