LG 86UH5Q-E 86-inch 4K UHD Signage Display

Overview

The LG 86UH5Q-E is an 86-inch 4K UHD signage display rated for 24/7 operation. It delivers 3840 x 2160 resolution at 700 nit typical brightness and runs webOS 8.0 without an external media player. Built-in Wi-Fi, three HDMI inputs and a DisplayPort input support common sources. It suits corporate lobbies, campus corridors and government reception areas across Qatar. Request a quote.

An 86-inch 4K panel built for all-day signage

The LG 86UH5Q-E is a business-grade 86-inch display with a 3840 x 2160 UHD panel, rated for 24/7 operation with a typical panel life of 50,000 hours. Its edge-lit 16:9 panel reaches 700 nit typical brightness and 1,200:1 contrast, with 95% BT.709 colour coverage and viewing angles of 178 degrees horizontally and vertically. Content stays readable from the side of a corridor as well as from straight on, which matters for wayfinding and promotional loops.

Playback, control and connectivity

The panel runs webOS 8.0 on its own processor and stores content on 16GB of internal eMMC memory, so a separate media player is not needed for simple loops. SuperSign CMS, SuperSign Control+, SuperSign WB, SuperSign Cloud and Mobile CMS are listed as compatible. Built-in Wi-Fi and Bluetooth, a LAN port, RS232C in and out, and IR in give the IT team several ways to connect and manage the screen.

Three HDMI inputs with HDCP 2.2 and 1.4 support
One DisplayPort input with HDCP 2.2 or 1.3
Two USB 2.0 Type A ports for media and plug-and-play use
Two built-in 10W speakers and an audio output
Portrait and landscape orientation

Where it fits in Qatar

In a hotel in Msheireb or a serviced apartment building in The Pearl, the 86-inch format works well in a lobby or reception where guests read schedules, offers and directions from a few metres away. A university building in Education City could place two or three units along a corridor, looping event notices and campus maps in English and Arabic. The on-screen menus include Arabic, so staff can set them to Arabic.

For a ministry or government authority in Doha, the display can sit in a visitor hall showing service information and waiting updates. Tile mode and portrait orientation let the same model form a small video wall or a vertical totem.

Planning the installation

At 53.0 kg for the head and 66.7 kg packed, this panel needs a planned lift with at least two people and a wall that can carry its load on a 600 x 400 mm VESA interface. The optional LSW640A/B wall mount is listed as an accessory. A free site survey from SmartRooms Qatar lets the team check wall structure, cable routes and window positions before the panel arrives.

Environment is the other planning point. The operating range is 0 to 40 °C with 10 to 80 percent humidity. Qatar summers can climb above 45 °C, so the display should go into an air-conditioned interior. The power supply accepts 100 to 240 V at 50/60 Hz. Dimensions without the IR sensor and handle are 1928.8 x 1099.8 x 29.7 mm, so measure the recess or bracket before ordering.

Request a quote for your site

Tell SmartRooms Qatar how many panels you need, where they will hang and what content they will show. The team will return a quotation, usually within one working day. Orders can be placed by LPO, and government buyers can submit through tender channels including Monaqasat. Request a quote for the LG 86UH5Q-E today.

Highlights

86-inch 4K UHD panel at 3840 x 2160 resolution
webOS 8.0 playback with 16GB internal eMMC storage
700 nit typical brightness and 178-degree viewing angles
Rated for 24/7 operation with 50,000-hour typical life
IP5X dust protection and conformal-coated power board
Operating range 0 to 40 °C, 10 to 80 percent humidity

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

101 specifications · Source: manufacturer · checked Oct 2026

PANEL17

Screen Size (Inch): 86
Panel Technology: ADS
Back Light Type: Edge
Aspect Ratio: 16:9
Native Resolution: 3840 x 2160 (UHD)
Refresh Rate: 60Hz
Brightness: 700nit(Typ.)
Contrast Ratio: 1,200:1
Dynamic CR: 1,000,000:1
Color Gamut: BT709 95%
Viewing Angle (H x V): 178º x 178º
Color Depth (Number of Colors): 1.07 Billion colors
Response Time: 8ms (G to G)
Surface Treatment (Haze): 25%
Life time: 50,000Hrs (Typ.)
Operation Hours (Hours/Day): 24/7
Portait / Landscape: YES / YES

CONNECTIVITY9

HDMI In: YES (3ea)
HDMI In (HDCP Ver.): 2.2/1.4
DP In: YES (HDCP 2.2/1.3)
RS232C In: YES
RJ45(LAN) In: YES (1ea)
IR In: YES
USB In: USB2.0 Type A (2ea)
Audio Out: YES
RS232C Out: YES

MECHANICAL SPECIFICATION8

Bezel Color: Black
Bezel Width: 13.4mm(Even)
Weight (Head): 53.0Kg
Packed Weight: 66.7Kg
Monitor Dimensions (W x H x D): 1928.8 x 1099.8 x 29.7mm (without IR, Handle)
Carton Dimensions (W x H x D): 2100 x 1250 x 253mm
Handle: YES
VESA Standard Mount Interface: 600 x 400 mm

FEATURE - HARDWARE6

Internal Memory (eMMC): 16GB
Wi-Fi/BT (Built-in): YES
Temperature Sensor: YES
Auto Brightness Sensor: YES (EU in-box / Others Acc.)
Acceleration(Gyro) Sensor: YES
Local Key Operation: YES

FEATURE - SOFTWARE35

OS Ver. (webOS): webOS 8.0
Local Contents Scheduling: YES
Group Manager: YES
USB Plug & Play: YES
Fail over: YES
Booting Logo Image: YES
No Signal Image: YES
RS232C Sync: YES
Local Network Sync: YES
PIP: YES
PBP: YES (4PBP)
Screen Share: YES
Video Tag: YES (4 Video Tag)
Play via URL: YES
Screen Rotation: YES
External Input Rotation: YES
Gapless Playback: YES
Tile Mode Setting: YES
Setting Data Cloning: YES
SNMP: YES
ISM Method: YES
Auto Set ID: YES
Status Mailing: YES
Control Manager: YES
Cisco Certification: YES
Crestron Connected: YES
Smart Energy Saving: YES
PM mode: YES
Wake on LAN: YES
Network Ready: YES
Beacon: YES
HDMI-CEC: YES
SI Server Setting: YES
webRTC: YES
Pro:Idiom: YES

ENVIRONMENT CONDITIONS2

Operation Temperature: 0 °C to 40 °C
Operation Humidity: 10 % to 80 %

POWER2

Power Supply: AC 100-240V~, 50/60Hz
Power Type: Built-in Power

POWER CONSUMPTION6

Typ.: 205W (TBD)
Max.: 297W (TBD)
BTU (British Thermal Unit): 699 BTU/Hr(Typ.), 1013 BTU/Hr(Max) (TBD)
Smart Energy Saving (70%): 144W (TBD)
DPM: 0.5W
Power off: 0.5W

SOUND1

Speaker (Built-in): YES (10W x 2)

CERTIFICATION4

Safety: CB / NRTL
EMC: FCC Class "B" / CE / KC
ERP / Energy Star: NA / O
ePEAT(US only): YES

SOFTWARE COMPATIBILITY6

SuperSign CMS: YES
SuperSign Control+: YES
SuperSign WB: YES
SuperSign Cloud: YES
Mobile CMS: YES
Connected Care: YES

LANGUAGE1

OSD: English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portuguese(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese(Europe), Dutch, Czech, Greek, Turkish, Arabic

ACCESSORY2

Basic: Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(6EA), Cable Holder(7Pin/1EA)
Optional: Wall Mount (LSW640A/B)

SPECIAL FEATURE2

Conformal Coating (Power Board): YES
IP Rating: IP5X

Downloads

5 files from the manufacturer

PDF Datasheets standard-86-75uh5q-2025-documents-86-75uh5q-datasheet-low-lg-uhd-signage-260109_20260317_221555_.pdf 1.4 MB PDF Manuals & guides 7586UH5Q_UH7Q_ARA.pdf 1.5 MB PDF Manuals & guides 7586UH5Q_UH7Q_EN.pdf 461 KB PDF Manuals & guides MFL05824501_02_QSG.pdf 2.5 MB PDF Manuals & guides webOS 8.0_ENG.pdf 2.6 MB

Questions about 86UH5Q-E

What is the LG 86UH5Q-E best suited for?

The LG 86UH5Q-E is an 86-inch 4K UHD display for indoor digital signage such as wayfinding, announcements and promotional loops in lobbies and corridors. Its 24/7 operating rating and built-in webOS player suit a screen that runs all day. It fits well where viewers stand or walk at a reasonable distance, such as a hotel lobby in Msheireb or a university corridor in Education City. Request a quote to confirm the layout.

Does it need a separate media player?

No. The panel runs webOS 8.0 on a high-performance SoC and has 16GB of internal eMMC storage for content and apps. Content can be scheduled locally and played via URL. SuperSign CMS, SuperSign Control+, SuperSign WB, SuperSign Cloud and Mobile CMS are listed as compatible software. Request a quote that includes the software set-up your team needs.

How do brightness and viewing angle work in a lobby with windows?

The panel has 700 nit typical brightness, a 25% surface haze treatment and viewing angles of 178 degrees horizontally and vertically. In a lobby with daylight, a wall away from direct sun is a better position than one facing the windows. SmartRooms Qatar can review the room during a free site survey. Request a quote to start that review.

Can it cope with Qatar's summer heat?

The manufacturer lists an operating temperature of 0 °C to 40 °C and a humidity range of 10% to 80%. Qatar summers can go above 45 °C, so the display must be installed in an air-conditioned interior, not in an unconditioned atrium, outdoor kiosk or enclosed shop front. Confirm the room climate before ordering, and request a quote so the team can review the location.

Is it protected against dust for Qatar's dust storms?

The unit carries an IP5X rating, and its power board has a conformal coating that the manufacturer describes as protection against salt, dust, iron powder and humidity. This supports stable operation in dusty industrial and coastal areas. The ratings apply to indoor installation within the operating range, so keep the display inside a building. Request a quote for a location review.

Which inputs are available for laptops and media players?

The panel has three HDMI inputs with HDCP 2.2 and 1.4 support, one DisplayPort input with HDCP 2.2 or 1.3, a LAN port, two USB 2.0 Type A ports and an audio output. A laptop, a media player and a control system can be connected at the same time. Request a quote so the cable routes can be confirmed.

Can the display be controlled from a building management or AV system?

Yes. The data lists RS232C in and out, SNMP, Wake on LAN, Crestron Connected, HDMI-CEC and Control Manager. An IT manager can monitor status and power the screen over the network, while an existing control system can switch inputs. Confirm the exact protocol with your integrator before purchase. Request a quote for the integration you need.

Can these panels be combined into a video wall?

The panel supports tile mode setting and can be used in portrait or landscape orientation. Its bezel is 13.4 mm wide. The data does not state a maximum number of tiled units, so confirm the wall layout with SmartRooms Qatar before ordering. Request a quote that includes your wall plan, and the team will check the configuration against your room.

How heavy is it, and which wall mount does it need?

The head weighs 53.0 kg and the packed weight is 66.7 kg. The VESA interface is 600 x 400 mm, and the optional LSW640A/B wall mount is listed as an accessory. Plan a lift with at least two people and book a site survey to check the wall before mounting. Request a quote that includes the wall mount.

Does the display have built-in speakers?

Yes, it has two built-in 10W speakers and an audio output. They suit short announcements and ambient content in small to medium lobbies. Large halls may still need a separate audio system. Request a quote and describe the room size so the team can advise whether the built-in speakers are enough.

What certifications does it carry?

The data lists CB/NRTL safety approval, FCC Class B, CE and KC EMC approvals, and ePEAT for the US market only. Before submitting a government tender, check certificate requirements with your procurement team. Request a quote and state the documents your tender needs.

Can we buy it by LPO or through a government tender?

Yes. SmartRooms Qatar accepts purchase orders (LPOs), government tenders including Monaqasat, and payment by bank transfer, cheque or purchase order. Delivery is available to all eight municipalities. A school or ministry ordering several 86-inch panels can request one quotation covering every unit. Request a quote for your order.
