BenQ RM6502K 65-inch 4K UHD Education Interactive Flat Panel Display

Screen size: 65''
Resolution: UHD 3840 × 2160 pixels
Touch: Infrared touch
System: Android 8.0

Priceon request

QuotationWithin 1 working day

DeliveryConfirmed with your quote, based on stock

PDFDownload datasheet

Overview

The BenQ RM6502K is a 65-inch 4K UHD interactive flat panel built for classrooms and training rooms. It pairs a 3840 × 2160 IPS screen with 20-point infrared touch, EZWrite 5.0 whiteboarding, an OPS slot for a slot-in PC and two 16 W front speakers. It suits schools and training centres in Doha and beyond that want touch teaching at a practical size.

What the RM6502K is and how it is built

The BenQ RM6502K is a 65-inch interactive flat panel with a 4K UHD IPS screen at 3840 × 2160 pixels. It offers 400 nits typical brightness, a 1200:1 typical contrast ratio and 10-bit colour depth across a 1428.5 × 803.5 mm active area. The panel weighs 70.2 kg without packaging, so the mounting plan should be settled before delivery.

The panel runs Android 8.0 on a four-core processor with 4GB of memory and 32GB of storage. A dedicated OPS slot accepts a slot-in PC, which suits schools and offices that need a Windows environment alongside the built-in system.

Touch, connectivity and classroom software

Touch is handled by a 20-point infrared layer with a response time under 8 ms. Two pens are supplied, so two people can write or draw at the same time in different colours. The rear panel offers three HDMI 2.0 inputs, one HDMI 2.0 output for a second display, a VGA input, two USB-B ports for touch, a 1000 Mbps Ethernet port, an RS-232 port and an optical S/PDIF output. A Mic-In port lets teachers add an external microphone alongside the two 16 W speakers at the front.

The software centres on EZWrite 5.0, which annotates over any app, video, website or document from a floating toolbar and saves notes and files to Google Drive and Dropbox. InstaShare 1 handles wireless sharing from phones, tablets and PCs, X-Sign Broadcast sends alerts to one room, a group of screens or the whole school, and DMS manages devices remotely.

Where it fits in Qatar

A primary classroom in Al Wakrah: the teacher projects a lesson from a laptop, annotates it on the panel and shares notes to students' devices after the lesson.
A corporate training room in West Bay: the trainer runs pair exercises with the two pens and mirrors slides to a second display through the HDMI output.
A school administration office in Education City: staff post announcements to several rooms with X-Sign Broadcast, grouping screens so each message reaches only the intended classes.

What to plan before installation

The mount is VESA 600 × 400 mm with four M8 × 25 screws, and a wall mount is included. Because the panel weighs 70.2 kg and ships at 99.6 kg, SmartRooms Qatar recommends a free site survey to check the wall, the access route and the delivery path first. Qatar summer heat regularly passes 45°C, so keep the panel in an air-conditioned room away from direct sun through windows, since the rated operating range is 0°C to 40°C. Confirm the room conditions with the SmartRooms Qatar team before fixing the unit. Power is AC 100-240V at 50/60Hz, with typical consumption of 124 W and standby below 0.5 W.

Ordering from SmartRooms Qatar

Schools and government bodies often buy through LPOs or tenders, including Monaqasat. SmartRooms Qatar supplies the RM6502K with delivery to all eight municipalities of Qatar, professional installation and quotations usually within one working day. Payment can be made by bank transfer, cheque or purchase order. Tell us how many rooms need touch, which ones need a second display and where each panel will be mounted, and we will prepare your quote. Request a quote for the RM6502K today.

Highlights

65-inch 4K UHD IPS panel at 3840 × 2160 resolution
20-point infrared touch with response time under 8 ms
EZWrite 5.0 whiteboard with Google Drive and Dropbox access
OPS slot for a slot-in PC, with Android 8.0 built in
Three HDMI 2.0 inputs, one HDMI 2.0 output, VGA and RS-232
Operating range 0°C to 40°C; AC 100-240V, 50/60Hz

Classroom fit

At 65″ the farthest student should sit within about 4.9 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

58 specifications · Source: manufacturer · checked Oct 2026

Panel14

Screen size: 65''
Panel type: IPS
Active area: 1428.5 × 803.5 mm
Aspect ratio: 16:9
Resolution: UHD 3840 × 2160 pixels
Response time: 8 ms
Color depth: 10-bit
Orientation: Landscape
Operation hours: 18 hours / 7 days
Panel brightness (typical): 400 nits
Contrast ratio (typical): 1200:1
Dynamic contrast ratio: 30,000:1
Color gamut: 68% NTSC
Backlight life (typical): 50,000 hrs

Glass3

Germ-resistant technology: Nano-ionic silver
Anti-glare: Yes | NA
Hardness: 9H tempered

Touch screen3

Touch technology: Infrared touch
Touch points: 20
Touch response time: < 8 ms

System4

GPU: Mali-G51MP4
CPU: A73 × 2 + A53 × 2
Memory | Storage: 4GB I 32GB
OS: Android 8.0

Connectivity10

HDMI (in | out): 3 × HDMI 2.0 | 1 × HDMI 2.0
USB-A: 2 × 2.0 + 3 × 3.0
USB-B (for touch): 2 × 2.0
3.5 mm Line in (1): Mic / PC Audio × 1_test
VGA: 1 | 0
3.5 mm Line out: Earphone × 1
OPS slot (for slot-in PC): 1
S/PDIF out: 0 | 1 (optical)
Ethernet: 10 / 100 / 1000 Mbps (Android) × 1
RS-232: 1 | 0

Built-in peripherals1

Speaker: 2 × 16 W

Power2

Power: AC 100-240V 50/60Hz
Typical power consumption: 124 W

Physical5

Dimensions (W x H x D): 1488.7 × 938.9 × 115.6 mm (58.6 × 37.0 × 4.6 inch)
Shipping dimensions (W x H x D): 1675 × 1056 × 220 mm (65.9 × 41.6 × 8.7 inch)
Weight (product I shipping): 70.2 kg | 99.6 kg (154.8 lbs | 219.6 lbs)
Mount (screws): VESA 600 × 400 mm (4 × M8 × 25L)
Pen Tray: 1

Environment4

Operating temperature: 0°C ~ 40°C | 32°F ~ 104°F
Storage temperature: -20°C ~ 60°C | -4°F ~ 140°F
Storage humidity: 10% ~ 90% RH non-condensing
Operating humidity: 10% ~ 90% RH non-condensing

Software8

Whiteboarding: EZWrite 5.0
Wireless screen sharing: InstaShare 1 (BenQ App Store)
Device management: DMS
Account management: AMS
Flicker Free: Yes
Quick access tool: Floating Tool
Broadcast system: X-Sign Broadcast
Low Blue Light: Yes

Accessories4

Cables: 1 × VGA(5 m | 16.4 ft), 1 × HDMI (1.5 m | 4.9 ft), 1 × USB (3 m | 9.8 ft)
Wall mount: 1
Pen: 2
Remote control: 1

Downloads

16 files from the manufacturer

PDF Datasheets rm6502k-tuv-ff-20220908.pdf 895 KB PDF Datasheets rm6502k-tuv-lbl-20220907.pdf 925 KB PDF Manuals & guides IH_EN_260519104241.pdf 14.5 MB PDF Manuals & guides RCUM_EN_250616104132.pdf 968 KB PDF Manuals & guides RS232 & LAN Command List_1_Others.pdf 620 KB PDF Manuals & guides UM_AR_210319164902.pdf 9.5 MB PDF Manuals & guides UM_EN_210319164902.pdf 9.6 MB PDF Manuals & guides · Opens on manufacturer site AMS_EN_250819160158.pdf PDF Manuals & guides · Opens on manufacturer site DMS Cloud_EN_260929100553.pdf PDF Manuals & guides · Opens on manufacturer site DMS Local_EN_251223091035.pdf PDF Manuals & guides · Opens on manufacturer site Saffi_EN_230704164442.pdf PDF Manuals & guides · Opens on manufacturer site X-Sign-Broadcast_EN_221206164346.pdf ZIP Drawings & CAD · Opens on manufacturer site RM6502K_Display CAD_1_Others.zip ZIP Drawings & CAD · Opens on manufacturer site Wallmount Drawing_1.00_Others_260922163728.zip PDF Certificates & compliance siaa-tuv-certificates-antibacteria-simplified-2021.pdf 1.0 MB ZIP Software & firmware · Opens on manufacturer site Additional Driver to Support Gesture_Mac_v06.00.717_Mac.zip

Questions about RM6502K

Who is the BenQ RM6502K designed for?

It suits primary and secondary classrooms, training rooms and small meeting rooms where a teacher or trainer writes and shares content from one screen. At 65 inches it works well in rooms where people sit close enough to read handwriting and text on the panel, such as a classroom in Education City or a training room in Doha.

What is the screen resolution and panel type?

The RM6502K uses a 65-inch IPS panel at 4K UHD resolution, 3840 × 2160 pixels. It has 400 nits typical panel brightness, a 1200:1 typical contrast ratio, 10-bit colour depth and an active area of 1428.5 × 803.5 mm, which gives sharp text for lessons and detailed diagrams in meeting presentations.

How does the touch function work and how many touch points does it support?

The panel uses infrared touch with 20 touch points and a touch response time below 8 ms. Two pens are included, so two users can write or draw at the same time in different colours, which is useful for group problem solving at the board or pair exercises in a training session.

Which inputs can I connect to the panel?

There are three HDMI 2.0 inputs, a VGA input, and one HDMI 2.0 output for sharing content on a second display. Two USB-B ports handle touch, and an RS-232 port supports control. Teachers can connect a laptop on HDMI and use the same screen for annotation at the same time.

Does the panel run its own operating system, and can I add a PC?

Yes. The panel runs Android 8.0 with 4GB of memory and 32GB of storage. It also has an OPS slot for a slot-in PC, so an office or school that uses Windows applications can add that computer and switch between the built-in system and the PC.

Will the panel work in a hot room in Doha during summer?

The rated operating temperature is 0°C to 40°C, and Qatar summer temperatures often exceed 45°C. Install the panel in an air-conditioned room, away from direct sunlight through windows. Confirm the room conditions with the SmartRooms Qatar team before the installation is fixed in place.

What power supply does the RM6502K need?

The power input is AC 100-240V at 50/60Hz. Typical power consumption is 124 W, and standby consumption is below 0.5 W. The stated input range includes 240 V at 50 Hz, the mains supply used in Qatar, so the panel can be connected to a standard supply in your building.

How heavy is the panel and how should it be mounted?

The panel weighs 70.2 kg and ships at 99.6 kg. It uses a VESA 600 × 400 mm pattern with four M8 × 25 screws, and a wall mount is included. Book a free site survey so the wall structure and delivery route can be checked before the unit is delivered and fixed.

Can teachers share files from Google Drive or Dropbox?

Yes. EZWrite 5.0 lets teachers download files from Google Drive and Dropbox, open them directly in EZWrite, annotate them and save them back to cloud storage. Teachers can prepare materials at home and open them on the panel at school, without copying files to a USB drive.

How can an IT team manage several panels across a school?

DMS Cloud allows remote control and app management over the internet, and OTA updates keep firmware current. For a local network, DMS Local manages panels over LAN, and MDA controls them through RS-232. A school ordering several units under an LPO can standardise settings across all rooms.

What eye-care and germ-resistance features does the screen include?

The glass uses nano-ionic silver compounds for germ resistance and 9H tempered glass for protection. The Smart Eye-Care feature uses a motion sensor to activate Flicker-Free and Low Blue Light when people move close to the screen. Source certificates from TÜV and SIAA are cited by the manufacturer for germ resistance.

Can a school or ministry buy the RM6502K through a tender or LPO?

Yes. SmartRooms Qatar supplies by quotation, accepts purchase orders (LPOs) and government tenders, including Monaqasat, and offers payment by bank transfer, cheque or purchase order. Quotations are usually issued within one working day, and the panel is covered by the manufacturer's warranty.
