Dahua LPH75-MC470-P · Price in Qatar

Name: Dahua LPH75-MC470-P 75-inch Smart Interactive Whiteboard
Brand: Dahua
SKU: dahua-lph75-mc470-p
Availability: InStock

Overview

The Dahua LPH75-MC470-P is a 75-inch smart interactive whiteboard for classrooms and meeting rooms. Its 3840 × 2160 panel, infrared touch with up to 32 points on Android, and 16 GB system memory keep lessons and presentations responsive. An AI camera with auto-framing, a 16-array microphone and 2 × 20 W front speakers handle video calls. Request a quote from SmartRooms Qatar.

What the Dahua LPH75-MC470-P is

The Dahua LPH75-MC470-P is a 75-inch smart interactive whiteboard from the MC470-P Series of the Business range. It brings a large 4K display, an Android 14 system, an AI camera and a microphone array into one metal-cased unit, which reduces the number of separate devices a classroom or meeting room needs. The 16:9 panel uses DLED backlighting, with 450 cd/m² typical brightness and a typical static contrast ratio of 1,200:1.

Display, touch and writing

The 3840 × 2160 resolution, 60 Hz refresh rate and 178° horizontal and vertical viewing angles keep text and diagrams readable from the back of a room. Infrared touch supports up to 32 touch points on Android and 50 on Windows, and writing works with a finger or the magnetically attached pen. The 3.2 mm tempered glass front has an anti-dazzle finish and a surface hardness of 9H or higher. The rated lifespan is 50,000 hours or more.

Camera, microphones and speakers

The built-in camera adds face detection, auto white balance, auto flip and up to 9x digital zoom, with a horizontal field of view of 87°. Auto-framing and voice tracking keep the speaker in view during calls. A 16-array microphone picks up speech at 8 to 12 metres, with echo cancellation, automatic gain control and intelligent noise filtering. Audio comes from two 20 W front speakers and one 20 W rear speaker in a 2.1 channel layout.

Where it fits in Qatar

Classrooms in Education City or Al Wakrah: teachers annotate lessons directly on the panel and connect a laptop by HDMI or USB-C, while students work on the touch surface.
Boardrooms in West Bay or Lusail: meetings that link Doha with teams abroad use the camera, microphone array and speakers, with a Windows PC connected through the Type-C port or an HDMI input.
Government and corporate meeting rooms in Doha: a 75-inch panel gives clear sight lines to mid-sized teams, and the RJ-45 port and Wi-Fi let staff choose wired or wireless networking.

Planning the room and the installation

Plan the room climate first. The operating range is 0 °C to +40 °C, so this model suits air-conditioned meeting rooms and classrooms, not lobbies with sun-facing windows or any space that can exceed 40 °C. Qatar summers regularly pass 45 °C, so confirm the cooling capacity before the panel is installed.

The unit weighs 59 kg net and 69.5 kg gross, and measures 1,708.7 × 93.3 × 1,093.5 mm. The mounting holes are 600 × 400 mm, and the packing list includes a wall mount bracket and screw pack. Because of its weight, SmartRooms Qatar recommends a free site survey before wall mounting to check the wall, fixings and cable routes. The power supply accepts 100–240 VAC at 50/60 Hz, with typical consumption of 272 W and a maximum of 350 W. The DeepHub Meeting collaboration software is sold separately.

Send the room size, wall type and intended use to SmartRooms Qatar and request a quote for the Dahua LPH75-MC470-P. Quotations are usually issued within one working day, and we accept LPOs and government tenders.

Highlights

75-inch 3840 × 2160 display with 450 cd/m² typical brightness
Android 14 system with 16 GB memory and 128 GB storage
AI camera with auto-framing, voice tracking and 9x digital zoom
16-array microphone with 8 to 12 metre far-field pickup
Infrared touch with 32 points on Android, 50 on Windows
Operating range 0 °C to +40 °C, for air-conditioned rooms

Classroom fit

At 75″ the farthest student should sit within about 5.6 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

92 specifications · Source: manufacturer · checked Oct 2026

Built-in System7

Operating System: Android 14
CPU: Quad-core A73 + Quad-core A53
CPU Frequency: 2.2 GHz + 2.0 GHz
GPU: ARM Mali-G52 MP8 (8EE)
RAM: 20 GB (System: 16 GB, Camera: 4 GB）
ROM: 128 GB
NFC: Supports quick unlock via NFC

Function2

Operating System of External Module: Windows 7/8/10/11
Wi-Fi Hotspot: Dual-band 2.4 G/5 G; supports enabling Hotspot and Wi-Fi at the same time

LCD Panel11

Screen Size: 75 inch
Backlight: DLED
Aspect Ratio: 16:9
Brightness: 450 cd/m² (typ.)
Resolution: 3840 (H) × 2160 (V)
Viewing Angle: H (178°) / V (178°)
Lifespan: ≥50, 000 hr
Display Color: 90% NTSC (typ.)
Refresh Rate: 60 Hz
Static Contrast Ratio: 1200 (typ.)
Response Time: 8 ms (typ.)

Camera8

Camera: Android: Photo: 52 MP; Video: 8 MP Windows: Photo: 8 MP; Video: 8 MP
Auto Control: Auto flip; Auto white balance
Distortion: –8.6%
Max. Resolution: Photo: 9632 (H) × 5418 (V); Video: 3840 (H) × 2160 (V)
Storage: 8GB eMMC
Field of View: H: 87°; V: 49°; D: 99°
Face Detection: Yes
Digital Zoom: Yes, supports up to 9x digital zoom.

Device Ports24

Light Sensor: 1
Front Button: 1 × power button (right side)
Front Ports: 1 × USB 3.2 Gen1 (left side)
Network Port: 1 × RJ-45
Wi-Fi: Yes, 1 × Station, 1 × AP
Wi-Fi Standard: Station: 802.11b/g/n/a/ac AP: 802.11b/g/n/a/ac/ax
Wi-Fi Frequency Range: 2400–2483.5 MHz, 5150–5350 MHz, 5470–5725 MHz, 5725–5850 MHz
MAX Power Transmission (Wi-Fi): ≤20 dBm@2400–2483.5 MHz; ≤23 dBm@5150–5250 MHz; ≤20 dBm@5250–5350 MHz; ≤27 dBm@5470–5725 MHz; ≤14 dBm@5725–5850 MHz
Bluetooth: Yes
Bluetooth Standard: BR/EDR/BLE, BT5.3
Bluetooth Frequency Range: 2400–2483.5 MHz
MAX Power Transmission (Bluetooth): ≤20 dBm@2400–2483.5 MHz
RFID Modulation Method: ASK
RFID Frequency Range: 13.56 MHz
MAX Power Transmission (RFID): 42dBuA/m @10 m
USB: 3 × USB 3.2 Gen1 Type-A; 1 × Micro USB 2.0
RS-232: 1 × DB9 port, male connector
Video Input: 2 × HDMI 2.0 (4K@60 Hz）
Video Output: 1× HDMI 2.0 (4K@60 Hz）
Audio Output: 1 × 3.5 mm Line Out port; 1 × SPDIF port
Others: 1 × Touch port
IrDA: 1
Microphone: 16 arrays
Type-C Port: 1 × Type-C IN (DP IN (4K60 fps) + USB 3.2 Gen1 HOST+ USB 2.0 Device (touch) + PD 65 W)

Touchscreen9

Response Time: ≤3.3 ms
Touch Technology: Infrared
Touch Points: 32@Android, 50@windows
Valid Touch: 1.5 mm (0.06") (over 90% touch area）
Writing Mode: Finger + Pen (attaches magnetically)
Anti-light Interference: Anti-dazzle tempered glass
Surface Hardness: ≥9H
Touch Resolution: 32767 × 32767
Number of Multi-user Writing Points: 10 points (over 90% touch area）

Speaker4

Number of Cavities: 3
Frequency: 150 Hz–20 kHz
Power: 2.1 channel, front-end 2 × 20 W + rear-end 20 W
Built-in Speaker: 3

Fingerprint2

Fingerprint Capacity: 100
Fingerprint Resolution: 160 × 160

Microphone6

Pick-up Distance: Far-field sound pickup: 8 m–12 m (26.25 ft–39.37 ft)
Number of Microphones: 16 arrays
AGC: Yes
Echo Cancellation: Yes
Polar Pattern: Omnidirectional
Intelligent Noise Filtering: YES

General19

Power Supply: 100–240 VAC, 50/60 Hz
Power Consumption: 272 W (basic), 350 W (max)
Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity: 10%–90% (RH), non-condensing
Storage Humidity: 10%–90% (RH), non-condensing
Product Material: Metal casing
Protective Glass: 3.2 mm Anti-dazzle tempered glass
Casing Color (Frame/Rear): Black on the left and right, Starry Gray on the top and bottom.
Product Dimensions: 1,708.7 mm × 93.3 mm × 1,093.5 mm (67.26" × 3.67" × 43.03") (L × W × H)
Frame Size: Top border: 28.6 mm (1.13"), left and right borders: 17.9 mm (0.70"), bottom border: 69.6 mm (2.74")
Packaging Dimensions: 1,875 mm × 227 mm × 1,177 mm (73.82" × 8.94" × 46.38") (L × W × H)
Net Weight: 59 kg (130.08 lb)
Gross Weight: 69.5 kg (153.22 lb)
Holes Distance: 600 mm × 400 mm (23.62" × 15.75")
Installation: Wall mount; mobile bracket
Standby Power Consumption: ≤0.5 W
Packing List: 1 × Smart interactive whiteboard 1 × Power cord 2 × Stylus pen 1 × Quick start guide 1 × Wall mount bracket 1 × Remote control 1 × Legal and Regulatory Information 1 × Wall-mount screw pack
Glass Thickness: 3.2 mm (0.13")

Downloads

8 files from the manufacturer

PDF Datasheets LPH75-MC470-P-S2_S2A_datasheet_20250804.pdf 9.4 MB PDF Manuals & guides Dahua Smart Interactive Whiteboard_Quick Start Guide_V1.0.0.pdf 986 KB PDF Manuals & guides Dahua Smart Interactive Whiteboard_User Manual_V1.0.1.pdf 6.8 MB PDF Manuals & guides LPH75-MC470-P-S2_INSTALLATION_METHOD_EN.pdf 50 KB PDF Drawings & CAD LPH75-MC470-P-S2_DIMENSIONS.pdf 1.9 MB PDF Drawings & CAD LPH75-MC470-P-S2_PORT.pdf 304 KB 2601 Software & firmware · Opens on manufacturer site DHI_DeepHubProS2_MultiLang_V3.012.0000000.1.R.260121 DOCX Other documents LPH75-MC470-P-S2_A&E_20250721091627.docx 40 KB

Questions about LPH75-MC470-P

Who is the Dahua LPH75-MC470-P built for?

It suits classrooms, training rooms and meeting rooms that need a 75-inch panel for group viewing. Its 3840 × 2160 display, 32-point touch on Android, built-in camera and microphones cover lessons, presentations and video calls in one unit. For a large lecture hall, compare the size with larger models before requesting a quote from SmartRooms Qatar.

Does it support Windows computers?

The source data lists Windows 7, 8, 10 and 11 as the operating systems for its external module. The Type-C input carries DisplayPort 4K at 60 fps along with USB and touch signals. Because module setup depends on the configuration you need, confirm the Windows setup for your room with the SmartRooms Qatar team before ordering.

How many video inputs and outputs does it have?

It has two HDMI 2.0 inputs supporting 4K at 60 Hz, one HDMI 2.0 output for an extra display, and one Type-C input that carries DisplayPort 4K60 with USB and touch signals. A 3.5 mm line out and an SPDIF port handle audio, and an RS-232 DB9 port allows control from a room system.

Can it charge a laptop through the Type-C port?

The Type-C input is rated for PD 65 W power delivery, so a compatible laptop can be powered while it sends its display and USB signals to the panel. Check your laptop's charging requirements against 65 W before relying on this. The front USB 3.2 Gen1 port and three USB-A ports serve other peripherals.

What wireless and network connections are included?

The unit has dual-band 2.4 GHz and 5 GHz Wi-Fi, with one station and one access point. The station supports 802.11 b/g/n/a/ac and the access point adds 802.11 ax. It also has Bluetooth 5.3, NFC for quick unlock and an RJ-45 network port, and the Wi-Fi hotspot and Wi-Fi can run at the same time.

Can it be used in an outdoor area or a hot lobby in Doha?

No. The operating temperature range is 0 °C to +40 °C, with 10% to 90% non-condensing humidity. Doha summer heat can exceed 45 °C, so outdoor areas, unconditioned lobbies and sun-facing rooms are unsuitable. Install it in an air-conditioned classroom or boardroom and keep it out of direct sunlight. The storage range is –20 °C to +60 °C.

Will it work with the electricity supply in Qatar?

The power supply is rated for 100–240 VAC at 50/60 Hz, which covers the 240 V, 50 Hz mains used in Qatar. Typical consumption is 272 W and the maximum is 350 W, with standby below 0.5 W. A power cord is included, but confirm the plug type with the SmartRooms Qatar team before installation so it matches the local socket.

How much space and wall support does a wall mount need?

The product measures 1,708.7 × 93.3 × 1,093.5 mm and weighs 59 kg net, 69.5 kg gross. The mounting holes are 600 × 400 mm, and the packing list includes a wall mount bracket and screw pack. A free site survey helps confirm wall strength, fixings and clearance, particularly in a new fit-out in Lusail or Msheireb.

Is a mobile stand included?

The source data lists installation as wall mount or mobile bracket, but the packing list includes only the wall mount bracket and screw pack. If the room needs to move the panel between spaces, ask for a quote that includes the mobile bracket option and confirm its availability with SmartRooms Qatar.

How well does the microphone pick up voices?

The 16-array microphone picks up speech from 8 to 12 metres with an omnidirectional pattern, and it includes echo cancellation, automatic gain control and intelligent noise filtering. It suits a teacher speaking from the front of a classroom or a participant seated at a boardroom table. Test the room acoustics during installation to get the best results.

Can a government department in Qatar buy this through an LPO or tender?

Yes. SmartRooms Qatar accepts purchase orders (LPOs) and government tenders, including Monaqasat, and offers payment by bank transfer, cheque or purchase order. The Dahua LPH75-MC470-P is covered by the manufacturer's warranty. Send the quantity and room list, and quotations are usually provided within one working day.

Is DeepHub Meeting included with the whiteboard?

No. DeepHub Meeting with Collaboration is listed as a separate purchase, so it is not part of the standard package. If your team needs it, ask SmartRooms Qatar to include it in the quotation and confirm that it fits your meeting workflow before buying.
