Dahua LPH86-MC470-C-S3 · Price in Qatar

Name: Dahua LPH86-MC470-C-S3 86-inch Smart Interactive Whiteboard
Brand: Dahua
SKU: dahua-lph86-mc470-c-s3
Availability: InStock

Overview

The Dahua LPH86-MC470-C-S3 is an 86-inch interactive whiteboard with a 3840 × 2160 panel, 50-point infrared touch and Android 16.0 built in. It carries a 52 MP camera, eight microphone arrays and two 20 W speakers, and an external module runs Windows 11 or Android. Suited to lecture halls, training rooms and boardrooms across Doha, Lusail and Education City, it is supplied by quotation from SmartRooms Qatar.

What the LPH86-MC470-C-S3 is built to do

The LPH86-MC470-C-S3 is an 86-inch interactive display from Dahua's MC470-C Series, built for lessons, presentations and meetings where people write, annotate and share content on one large surface. Its 3840 × 2160 panel gives sharp detail for spreadsheets, floor plans and multi-page documents, and the screen responds to fingers or the supplied magnetic stylus, so a presenter can work directly on the content.

The figures that shape day-to-day use

Image: 400 cd/m² brightness, a 1500:1 static contrast ratio, a DLED backlight, 90% NTSC colour and 178° viewing angles, so slides stay readable from the far side of a room.
Touch: infrared technology with a zero air gap attachment, 50 touch points on Android and on Windows, and a response time of ≤1.67 ms.
Glass and build: 3 mm anti-dazzle tempered glass with a surface hardness of ≥9H, set in a metal casing.
Processing: Android 16.0 on a quad-core A53 and quad-core A72 processor at 2.2 GHz, with 8 GB RAM and 128 GB ROM. An external module runs Windows 11 or Android.
Camera and audio: a 52 MP camera with face detection, eight microphone arrays with an 8 m to 12 m pickup distance, echo cancellation and noise filtering, and two 20 W front speakers.

Where it fits across Qatar

In a university lecture hall in Education City, a large screen that students can read and a lecturer can annotate directly reduces the need for a separate board. The built-in microphones and speakers also cut down the number of separate devices a room needs.

In a training room in Doha, the Windows 11 external module can run the course material the trainer already uses, while Android apps run on the panel itself.

In a boardroom in West Bay or Lusail, the camera and eight-array microphone system help remote colleagues follow discussions held around a long table, with pickup from 8 m to 12 m. For a government office in Msheireb or a team working in Arabic and English, confirm the language and software requirements when you request a quote.

Planning the installation

At 62.3 kg net and 74.6 kg gross, with overall dimensions of 1,953.8 mm × 115.7 mm × 1,205.9 mm, this is a heavy wall-mounted panel. The wall mount bracket and expansion tube and screw set are in the box, and the mounting holes are spaced 800 mm × 400 mm. The source also lists a mobile bracket option. A free site survey lets the SmartRooms Qatar team check the wall, the power point and the viewing distance before anything is drilled.

Keep the unit indoors in air-conditioned rooms. Its operating range is 0 °C to +40 °C and it is rated IP20, so the room should be kept clear of dust storms and direct sunlight through windows. Power input is 100–240 VAC at 50/60 Hz, drawing 135 W typically and 400 W at maximum. Listed certifications are CE, CB and EDLA.

Ready to plan a room? Request a quote from SmartRooms Qatar, and our team will confirm the bracket, power and delivery details with your quotation, usually within one working day.

Highlights

86-inch 3840 × 2160 DLED panel with 16:9 aspect ratio
Infrared touchscreen with 50 touch points on Android and Windows
Android 16.0 with 8 GB RAM and 128 GB ROM
52 MP camera and eight-array microphone system
Wi-Fi 6, Bluetooth 5.4 and NFC built in
100–240 VAC supply; 135 W typical and 400 W maximum

Classroom fit

At 86″ the farthest student should sit within about 6.4 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

85 specifications · Source: manufacturer · checked Oct 2026

Built-in System6

Operating System: Android 16.0
CPU: Quad-core A53 + quad-core A72
CPU Frequency: Main frequency 2.2 GHz
GPU: Mali-G52 MC3
RAM: 8 GB
ROM: 128 GB

General20

Operating System of External Module: Windows 11; Android
Power Supply: 100–240 VAC, 50/60 Hz
Power Consumption: 135 W (basic), 400 W (max)
Standby Power Consumption: ≤0.5 W
Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity: 0%–93%, 101 kPa
Storage Humidity: 0%–93%, 101 kPa
Protection: IP20
Product Material: Metal casing
Glass: 3 mm anti-dazzle tempered glass
Casing Color (Frame/Rear): Black on the left and right, dark blue on the top and bottom
Product Dimensions: 1,953.8 mm × 115.7 mm × 1,205.9 mm (76.92" × 4.56" × 47.48")
Frame Size: Top frame: 40.9 mm (1.61"); Left and right frame: 17.5 mm (0.69"); Bottom frame: 65.3 mm (2.57")
Packaging Dimensions: 2,090.0 mm × 227.0 mm × 1,315.0 mm (82.28" × 8.94" × 51.77") (L × W × H)
Net Weight: 62.3 kg (137.35 lb)
Gross Weight: 74.6 kg (164.46 lb)
Holes Distance: 800 mm × 400 mm (31.50" × 15.75")
Installation: Wall mount or mobile bracket
Packing List: 1 × Smart Display 2 × Stylus Pen 1 × Wall Mount Bracket 1 × Global Laws and Regulations Manual 1 × Wireless Plug-in Module 1 × Power Cord 1 × Quick Start Guide 1 × Expansion Tube and Expansion Screw Set 1 × Remote Control

LCD Panel11

Screen Size: 86 inch
Backlight: DLED
Aspect Ratio: 16:9
Brightness: 400 cd/m²
Static Contrast Ratio: 1500:1
Resolution: 3840 (H) × 2160 (V)
Viewing Angle: 178° (H)/178° (V)
Lifespan: ≥30,000 hrs
Display Color: 90% NTSC
Response Time: ≤8 ms
Refresh Rate: 60 Hz

Camera7

Camera: 52 MP
Auto Control: Auto White Balance
Distortion: ≤8.6%
Max. Resolution: 3840 (H) × 2160 (V)
Storage: 512 MB
Field of View: Horizontal: 87°, vertical: 49°, diagonal: 99°
Face Detection: Yes

Device Ports17

Light Sensor: 1
Front Button: 8 buttons: Custom Volume - Volume + Curtain Touch lock Signal source Home Power supply
Front Ports: 1 × TYPE-C port 2 × USB 3.0 port 1 × HDMI IN port 1 × Touch port
Rear Port: 1 × HDMI OUT port 2 × HDMI IN ports 2 × Touch ports 1 × USB 2.0 port 2 × RJ-45 ports 1 × Type-C IN port 1 × DP IN port 2 × USB 3.0 port
SD Card Slot: 1 × SD card slot, up to 512 GB
Others: 1 × SPDIF OUT port 1 × RS-232 port 1 × LINE OUT port 1 × LINE IN port 1 × VGA AUDIO IN port 1 × VGA IN port 1 × Touch port
Wi-Fi: Yes
Wi-Fi Standard: 802.11b/g/n/a/ac/ax
Wi-Fi Frequency Range: 2400-2483.5 MHz，5150-5350 MHz，5470-5725 MHz，5725-5850 MHz
MAX Power Transmission (Wi-Fi): ≤20 dBm@2400-2483.5 MHz； ≤23 dBm@5150-5250 MHz； ≤20 dBm@5250-5350 MHz； ≤27 dBm@5470-5725 MHz； ≤14 dBm@5725-5850 MHz
Bluetooth: Yes
Bluetooth Standard: BR/EDR/BLE (Bluetooth mode), BT5.4
Bluetooth Frequency Range: 2400-2483.5 MHz
MAX Power Transmission (Bluetooth): ≤20 dBm@2400-2483.5 MHz；
RFID Modulation Method: ASK
RFID Frequency Range: 13.56 MHz
MAX Power Transmission (RFID): 13.56 MHz: 42 dBuA/m @10 m

Function3

IR Receiver: 1
NFC: 1 × NFC
Wireless Access Point: Wi-Fi 6, 2.4 GHz/5 GHz; supports 802.11a/b/g/n/ac/ax

Touchscreen11

Response Time: ≤1.67 ms
Touch Technology: Infrared
Attachment Method: Zero Air Gap
Touch Points: Android: 50 points Windows: 50 points
Touch Accuracy: ±0.5 mm (covers 90% of the area)
Valid Touch: 1.5 mm (0.06")
Writing Mode: Finger and stylus pen (magnetic)
Communication Mode: USB
Anti-light Interference: Anti-dazzle tempered glass
Surface Hardness: ≥9H
Touch Resolution: 32767 × 32767

Speaker3

Built-in Speaker: 2 mid-high frequency speakers
Power: 2.0 sound channel, front-end 2 × 20 W
Frequency: 150 Hz–20 kHz

Microphone6

Microphone: 8 arrays
Pick-up Distance: 8 m-12 m (26.25 ft–39.37 ft) pickup
AGC: Yes
Echo Cancellation: Yes
Polar Pattern: Omnidirectional
Intelligent Noise Filtering: Yes

Certification1

Certifications: CE, CB, EDLA

Downloads

7 files from the manufacturer

PDF Datasheets LPH86-MC470-C-S3_datasheet_20260708.pdf 3.0 MB PDF Manuals & guides Dahua Smart Interactive Whiteboard_Quick Start Guide_V1.0.0.pdf 3.8 MB PDF Manuals & guides LPH86-MC470-C-S3_INSTALLATION_METHOD_EN.pdf 43 KB PDF Drawings & CAD LPH86-MC470-C-S3_DIMENSIONS.pdf 570 KB PDF Drawings & CAD LPH86-MC470-C-S3_PORT.pdf 362 KB 2607 Software & firmware · Opens on manufacturer site DHI_DeepHubClassicSeriesS3_MultiLang_V3.012.0000000.1.R.260722 DOCX Other documents LPH86-MC470-C-S3_A&E_20260901215536.docx 39 KB

Questions about LPH86-MC470-C-S3

Who is this 86-inch model best suited for?

It suits lecture halls, training rooms and boardrooms where many people need to read the same screen. In a training room in Doha or a lecture hall in Education City, the 86-inch 4K panel lets people at the back read slides and spreadsheets, while the touchscreen lets presenters annotate directly on the content.

Can it run Windows 11 as well as Android?

Yes. The source lists Windows 11 and Android as operating systems for the external module, while the built-in system runs Android 16.0 with 8 GB RAM and 128 GB ROM. Teams can run their usual Windows software through the external module, and Android apps run on the panel itself. Touch supports 50 points on both systems.

How many touch points does it support, and can it be written on with a stylus?

The touchscreen uses infrared technology and supports 50 touch points on Android and 50 on Windows, with touch accuracy of ±0.5 mm across 90% of the area. Writing works with a finger or the magnetic stylus, and two stylus pens are included in the box. The surface hardness is at least 9H on 3 mm anti-dazzle tempered glass, which helps it resist scratches from daily use.

What wall space and bracket do I need?

The unit measures 1,953.8 mm × 115.7 mm × 1,205.9 mm and weighs 62.3 kg net, with mounting holes spaced 800 mm × 400 mm. The package includes a wall mount bracket and an expansion tube and screw set, and the source also lists a mobile bracket option. Because of the weight, a free site survey before drilling and a lift by at least two people are advisable.

Can it be installed in a hot outdoor area or a room without air conditioning?

No. Its operating temperature range is 0 °C to +40 °C and it is rated IP20, so it is intended for indoor, air-conditioned rooms. Qatar summer temperatures often exceed 45 °C, so keep it away from sunlit windows and open covered entrances. Ask the SmartRooms Qatar team to confirm your room conditions before ordering.

What does it draw from the mains?

It is rated for 100–240 VAC at 50/60 Hz, a range that covers Qatar's 240 V supply. Power use is 135 W basic and 400 W maximum, with standby consumption of 0.5 W or less. A power cord is included in the box. When planning the circuit, size for the 400 W maximum rather than the typical draw.

Can I connect a laptop, a PC and conferencing equipment?

Yes, through several inputs. The front has a TYPE-C port, two USB 3.0 ports, an HDMI IN and a touch port. The rear adds an HDMI OUT, two HDMI IN ports, a DP IN, a Type-C IN, two USB 3.0 ports, a USB 2.0 port, two RJ-45 ports and two touch ports. RS-232, SPDIF OUT and VGA inputs are also provided for older equipment.

Does it have built-in Wi-Fi and Bluetooth?

Yes. It supports Wi-Fi standards 802.11 a/b/g/n/ac/ax and can act as a Wi-Fi 6 access point on 2.4 GHz and 5 GHz. It also includes Bluetooth 5.4, NFC and an IR receiver, and the source lists a 13.56 MHz RFID function. The access point capability may suit rooms with limited network coverage.

How do the camera and microphones help in a remote meeting?

The 52 MP camera delivers a maximum resolution of 3840 × 2160, with an 87° horizontal and 49° vertical field of view, plus face detection and auto white balance. The eight microphone arrays pick up sound from 8 m to 12 m, with echo cancellation and noise filtering. In a boardroom in Lusail or West Bay, remote colleagues can hear participants at the far end of the table. Confirm that your conferencing software is compatible when you request a quote.

Which certifications does it carry?

The source lists CE, CB and EDLA certifications. Buyers preparing government tender files or internal purchase paperwork should state their certificate requirements when they request a quote, so the details can be included in the documents they need. Check the full specification sheet before approving the order.

Can a school order several units through a purchase order?

Yes. SmartRooms Qatar accepts purchase orders (LPOs) and government tenders, including those on Monaqasat, and payment by bank transfer, cheque or purchase order. Schools fitting out several classrooms should quote the model LPH86-MC470-C-S3 on the order so each unit is identified clearly. Quotations are usually issued within one working day, and lead times are estimates confirmed in the quotation.
