Huawei IdeaHub Board 3 Base

Name: HUAWEI IdeaHub Board 3 Base 65-inch and 86-inch Interactive Display
Brand: Huawei
SKU: huawei-ideahub-board-3-base
Availability: InStock

Overview

The HUAWEI IdeaHub Board 3 Base is a 4K interactive display sold in 65-inch (IHB3-65AA) and 86-inch (IHB3-86AA) sizes. It has a bezel-less panel, 25 ms writing latency, and Wi-Fi Direct projection that needs no password. An OPS module, sold separately, adds Windows. It suits classrooms, training rooms and meeting rooms across Qatar. Request a quote from SmartRooms Qatar.

What the HUAWEI IdeaHub Board 3 Base is

The HUAWEI IdeaHub Board 3 Base is an interactive display for classrooms, training rooms, meeting rooms and open discussion areas. It comes in two sizes: the 65-inch IHB3-65AA and the 86-inch IHB3-86AA. Both use a 4K D-LED backlight and a bezel-less panel, which puts more of the wall to work as screen.

Display and writing performance

The panel uses zero bonding lamination and offers a 72% NTSC colour gamut. Optical anti-blue light with zero colour cast is built into the screen, and the manufacturer lists a TÜV Rheinland Low Blue Light (Hardware Solution) certification for it. Writing latency is 25 ms, and touch sensing starts at 2 mm from the glass, so handwriting and annotation keep pace with the pen. Intelligent writing recognition converts handwriting into text and shapes.

Connecting laptops, phones and room equipment

Wi-Fi Direct projection does not need a password or a network connection. Enable Wi-Fi on the display and on your PC or phone, then start a 4K projection through the IdeaShare app. Wired options include HDMI and Type-C. The front panel has two USB-A 3.0 ports, a USB-B 2.0 port, HDMI-IN and a Type-C port that supports 65 W charging. The side panel adds USB 2.0, a COM port, and 3.5mm line-in and line-out. Wi-Fi 5 and Bluetooth 5.3 are built in, and the datasheet lists Wi-Fi 6 with the OPS module.

The OPS module, sold separately, enables Windows alongside Android 15.0.
OPS ports add three USB-A 3.0 ports, one USB-A 2.0 port, HDMI IN and OUT, Type-C, and RJ45 IN and OUT.

Sizes, weights and mounting planning

65-inch: 908.0 mm x 1484.5 mm x 90 mm; net weight 36.7 kg, gross weight 45.5 kg
86-inch: 1172.3 mm x 1953.0 mm x 90 mm; net weight 59.7 kg, gross weight 73.0 kg
VESA mounting: M8 x 25 mm, with 600 mm x 400 mm for 65-inch and 800 mm x 400 mm for 86-inch
Rolling stand and wall-mounted bracket are optional accessories

The manufacturer notes that dimensions and weights may vary with configuration, so confirm the final unit specification before fixing a bracket. For the 86-inch model, a site survey should check wall load, bracket position and cable routes before installation.

Where it fits in Qatar

A private school in Al Wakrah fitting out several classrooms can standardise on the 65-inch model, with one purchase order (LPO) covering the batch. A boardroom in West Bay or Msheireb may prefer the 86-inch model for larger meetings, and an external camera and microphone must be planned into the order because meeting use requires them. A sales office in Lusail can use the display in an open discussion area, with staff projecting from their laptops over Wi-Fi Direct.

Before ordering, confirm with the SmartRooms Qatar team the operating environment for your room. The source data does not list an operating temperature range, so keep the panel away from direct sun and dusty windows until suitability is confirmed. Send us your room sizes, unit quantities and mounting wall details and request a quote. Quotations usually follow within one working day, and we deliver across all eight municipalities of Qatar with professional installation.

Highlights

4K D-LED display in 65-inch and 86-inch sizes
25 ms writing latency with 2 mm touch sensing distance
Wi-Fi Direct projection without a password or network connection
TÜV Rheinland Low Blue Light hardware certification listed
OPS module, sold separately, enables Windows and extra ports
65 W Type-C charging on the front panel

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

Source: manufacturer · checked Oct 2026

The full specification and datasheet for this model are available on request; we send them with your quotation.

Downloads

3 files from the manufacturer

PDF Datasheets HUAWEI IdeaHub Board 3 Base Datasheet-V5.pdf 2.6 MB PNG Other documents IdeaHub Board 3 Base Smart Working Poster.png 5.6 MB JPG Other documents IdeaHub Board 3 Base roll-up banner-Education.jpg 14.0 MB

Questions about IdeaHub Board 3 Base

What sizes does the IdeaHub Board 3 Base come in?

It comes in two sizes: the 65-inch IHB3-65AA and the 86-inch IHB3-86AA. Both are 4K interactive displays with the same feature set, so a school can standardise on one platform and choose size by room. The 65-inch suits smaller classrooms and meeting rooms, while the 86-inch suits lecture halls and larger boardrooms where people sit further from the screen.

Who is this interactive display best suited to?

It suits teachers, trainers and meeting organisers who need projection, writing and annotation on one panel. A school in Doha or Al Rayyan can use the 65-inch model in a standard classroom, while a training centre near Education City can use it for group sessions. The source data names classrooms, meeting rooms, training rooms and open discussion areas as the main settings.

Do I need a password or a cable to project from a laptop or phone?

Wi-Fi Direct projection does not need a password or a network connection. Turn on Wi-Fi on the display and on your PC or phone, then start a 4K projection through the IdeaShare app. Wired options include HDMI and Type-C. Mirroring and control from a phone also require the IdeaShare app to be installed on the source device.

Can it run Windows applications?

The system runs Android 15.0 as standard. Windows is available only when the OPS module is installed, and the OPS module is sold separately. Dual-system switching lets a presenter move between Android and Windows, which helps when lesson software or business tools run only on Windows. The OPS module also adds USB-A 3.0 ports, HDMI IN and OUT, Type-C and RJ45 network ports.

How responsive is the handwriting?

Writing latency is 25 ms, and touch sensing starts at a distance of 2 mm. Intelligent writing recognition converts handwriting into text and shapes. Whiteboard content can be saved to local storage or a USB flash drive, and the source notes that an AI handwriting prediction algorithm supports smoother strokes during annotation of lesson slides or floor plans.

Can it host video meetings with teams abroad?

Meeting use requires an external camera and microphone, so plan them into the order from the start. The source data lists third-party meeting app support for H2 2026. For a boardroom in West Bay or Msheireb that connects with teams abroad, check camera position and room audio during the site survey. The 86-inch model gives a larger shared view for bigger tables.

What ports are on the front and side of the panel?

The front has two USB-A 3.0 ports, a USB-B 2.0 port, one HDMI-IN and a Type-C port that supports 65 W charging. The side adds a USB 2.0 port, a COM port, and 3.5mm line-in and line-out. A teacher or presenter can connect a laptop at the front without reaching behind the panel. The OPS module, sold separately, adds further USB, HDMI and RJ45 ports.

How heavy are the panels and what mounting do they need?

The 65-inch model has a net weight of 36.7 kg and the 86-inch model 59.7 kg, with gross weights of 45.5 kg and 73.0 kg. Both use M8 x 25 mm VESA fixings, with a 600 x 400 mm pattern for the 65-inch and 800 x 400 mm for the 86-inch. A rolling stand and wall bracket are optional. Book a free site survey before drilling to check wall load and cable routes.

Can a school order several units on a purchase order?

Yes. SmartRooms Qatar accepts purchase orders (LPOs), and government tenders can be handled through Monaqasat. A school in Al Wakrah fitting out several classrooms can send one LPO listing the 65-inch quantity and the room names. Quotations usually follow within one working day. Payment can be made by bank transfer, cheque or purchase order.

What does the anti-blue light feature involve?

The screen includes optical anti-blue light with zero colour cast, and the manufacturer lists a TÜV Rheinland Low Blue Light (Hardware Solution) certification. This suits students and staff who spend long sessions in front of the display. The certification relates to the hardware solution described in the source data, so request the certification documents from the SmartRooms Qatar team before citing it in a tender.

Can it be placed near a sunny window in Doha's summer?

The source data does not list an operating temperature range or a dust rating, so the environment must be confirmed before installation. Summer temperatures above 45°C and dust storms are common in Doha, so keep the panel away from direct sun and open windows. Ask the SmartRooms Qatar team to confirm suitability for your room, especially for lobby or semi-outdoor areas.

Is it covered by warranty, and how do I get a quote?

Products are covered by the manufacturer's warranty. The source data does not give warranty terms, so confirm the details with your quotation. To request a quote, send the number of units, the room types, your preferred size and details of the mounting wall. Quotations usually arrive within one working day, and delivery covers all eight municipalities of Qatar with professional installation available.
