TE9218UWI-B1AG
iiyama ProLite TE9218UWI-B1AG 92-inch 5K Interactive Display
- Screen size
- 91.5" / 232.5cm
- Resolution
- 5120 x 2160 (14.75 megapixel
- Touch
- PureTouch-IR⁺
- Brightness
- 500 cd/m²
Priceon request
QuotationWithin 1 working day
DeliveryConfirmed with your quote, based on stock
Overview
The iiyama TE9218UWI-B1AG is a 92-inch interactive touchscreen with a 21:9 ultra-wide 5K panel, 50-point PureTouch-IR+ touch and iiWare 11 on Android 13. A single back USB-C port carries video and touch and charges a compatible laptop at up to 100W. A built-in 8-array microphone and speakers suit large boardrooms, lecture halls and training centres in Doha and beyond that need side-by-side content and hybrid meetings.
A 92-inch 5K canvas for rooms that run several things at once
The iiyama ProLite TE9218UWI-B1AG is a 91.5-inch interactive touchscreen built on a 21:9 ultra-wide panel with a 5120 x 2160 native resolution. Its viewable area of 2142 x 903.6 mm gives presenters room to keep a document, a live video call and an annotation layer on screen together, so no single window has to shrink to fit.
Specifications that shape the buying decision
- Panel: VA panel rated at 500 cd/m² with 4000:1 static contrast and a 0.418 mm pixel pitch.
- Touch: PureTouch-IR+ with 50 touch points, plus or minus 1 mm accuracy, palm rejection and support for stylus, finger or gloved use.
- Inputs: four HDMI, one DisplayPort and two USB-C ports, including a 100W power delivery port on the back.
- Outputs: one HDMI, one USB-C and S/PDIF optical audio for sending signal onward or to a sound system.
- Software: iiWare 11 on Android 13, 8GB RAM, 64GB storage and a WiFi 6 module in the box.
- Audio: an 8-array microphone with 8 m pickup, two 20W speakers and a 20W subwoofer.
Where it fits in Qatar
In a boardroom in West Bay, the 21:9 format suits a director reviewing a financial pack beside a live video feed of colleagues abroad, while the microphone array picks up speakers across a long table. In a university lecture hall in Education City, the width lets a lecturer show slides, a simulation and a student's shared screen side by side. In a training centre in Al Rayyan, trainees can annotate directly on the glass with the bundled pens, and the USB ports handle media playback and storage devices without connecting a separate computer for basic use.
Planning the installation
At 67.6 kg without packaging and 2203 x 1000 x 92 mm, the panel needs a wall that can carry its weight and a clear route for lifting at the site. The VESA pattern is 800 x 600 mm and a wall mounting bracket of that size is included. The power supply accepts 100 to 240 V at 50/60 Hz, which covers Qatar's 240 V mains, with typical draw of 227 W and 0.5 W in standby. The operating range is 0 to 40 °C, so the room must be air-conditioned and kept away from direct sun through glass, particularly when outside temperatures pass 45 °C. Our free site survey covers the wall, access and cable routing before anything is ordered.
Getting a quotation
Send the room dimensions, the number of units if you are buying several, and whether you need a wall bracket or a compatible mount from the list of MD-WLIFT2031-W1, MD-CAR2031-B1 and MD-ADAP001. SmartRooms Qatar usually issues quotations within one working day, accepts LPOs and government tenders including Monaqasat, and delivers to all 8 municipalities of Qatar. Request a quote for the TE9218UWI-B1AG today and the team will confirm stock and lead time with your quotation.
Highlights
- 91.5-inch 21:9 panel with 5120 x 2160 native resolution
- PureTouch-IR+ with 50 touch points and 32-point writing
- 100W power delivery on the back USB-C port
- Four HDMI, one DisplayPort and two USB-C inputs
- 8-array microphone with 8 m pickup and 2 x 20W speakers plus subwoofer
- iiWare 11 on Android 13 with 8GB RAM and 64GB storage
- Operating range 0 to 40 °C; manufacturer warranty of 5 years
Classroom fit
At 92″ the farthest student should sit within about 6.9 m (6× the screen height).
Estimated timeline
Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.
Specifications
75 specifications · Source: manufacturer · checked Oct 2026
DISPLAY CHARACTERISTICS17
- Design
- Thin bezel
- Diagonal
- 91.5", 232.5cm
- Panel
- VA
- Touch Glass
- AG coated glass, zero bonding
- Native resolution
- 5120 x 2160 (14.75 megapixel, 5K UHD)
- Aspect ratio
- 21:9
- Panel brightness
- 500 cd/m²
- Light transmittance
- 92%
- Static contrast
- 4000:1
- Dynamic contrast
- 5000:1
- Response time (GTG)
- 6.5ms
- Viewing zone
- horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
- Colour support
- 1.07B 10bit (NTSC 90%)
- Horizontal Sync
- 30 - 135kHz
- Viewable area W x H
- 2142 x 903.6mm, 84.3 x 35.6"
- Pixel pitch
- 0.418mm
- Bezel colour and finish
- black, matte
TOUCH7
- Touch technology
- PureTouch-IR⁺
- Touch points
- 50, 32pt writing (HID, only with supported OS)
- Touch accuracy
- +- 1mm
- Touch method
- stylus, finger, glove
- Touch interface
- USB
- Supported operating systems
- All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
- Palm rejection
- yes
INTERFACES / CONNECTORS / CONTROLS9
- Digital signal input
- HDMI x4 (1x 2.1, max. 5120x2160 @60Hz; 3x 2.0, max. 3840x2160 @60Hz, YUV444) DisplayPort x1 (5120) USB-C x2 (3.2 Gen 1, 3840x2160 @60Hz, DP Alt mode 1.2, Touch, front: 15W PD, back: 100W PD)
- Audio input
- Mini jack x1
- Monitor control input
- RS-232c x1 (DSUB 9pin)
- Digital signal output
- HDMI x1 (3840x2160 @60Hz, YUV/RGB444) USB-C x1 (3.2 Gen 1, 3840x2160 @60Hz (DP 1.2 Alt mode, Touch, 15W PD, MSD (Multi-Screen Display))
- Audio output
- S/PDIF (Optical) x1 Mini jack x1 Speakers 2 x 20W (Front + 20W Subwoofer)
- HDCP
- HDMI, DP & USB-C: 2.3
- USB ports
- x8 (media playback / peripherals / storage – front: 2x 3.2 (Gen 1, 5Gbit), 1x USB-C 3.2 (Gen 1, 15W PD, DP Alt 1.2), back side: 2x 3.2 (Gen 1, 5Gbit), 1x USB-C 3.2 (Gen 1, 100W PD, DP Alt 1.2), top side: 2x 3.2 (Gen 1, 5Gbit))
- RJ45 (LAN)
- x2 (IN/OUT, Auto switch for PC & Android, 1000MB)
- Microphone
- 8-Array (8m voice pick-up, Front facing)
FEATURES12
- Integrated software
- iiWare 11 (Android 13 OS) featuring iiyama DMS, iiyama OS, iiyama Class, Note, web browser, file manager, cloud drives, WPS office, iiyama Share and EShare for wireless connection with Windows/iOS/Android devices
- WiFi
- yes (WiFi 6 Module OWM002 - Dual WiFi Bandwidth: 2.4GHz/5GHz, WiFi Standard: IIEEE 802.11 a/b/g/n/ac/ax, Bluetooth Support: 2.1+EDR/ 3.0/ 4.x/ 5.0)
- Hardware
- CPU: A311D2, A76*4+A55*4(2.4GHz), GPU: Mali G610, RAM: 8GB, ROM: 64GB
- Extra
- WiFi 6 Module (OWM002), Slot for optional OPS Slot PC, 4x Touch pen
- Kiosk mode
- yes
- Max. non-stop operating time
- 16/7
- Anti image retention
- yes
- Media playback
- yes
- Glass thickness
- 3mm
- Glass hardness
- 7H
- Housing (bezel)
- metal
- OSD key lock
- yes
GENERAL6
- OSD languages
- EN, DE, FR, ES, IT, RU, CZ, NL, PL, CAT, SV, FI, DA, NB
- Control buttons
- Power, Power Indicator, Remote Sensor, Ambient Light Sensor, USB-C Connector (3.2), USB Connector (3.2), Microphone Indicator
- User controls
- general settings (input, volume, backlight), audio settings (volume, bass, treble, balance, sound mode, mute), screen settings (pixel shift, eye care, auto light, ECO, ECR, auto colour temp.), display settings (brightness, contrast, hue, sharpness, display mode, colour temp.), settings (wireless & networks, personal, input & output, application, system)
- Blue light reducer
- yes
- Plug&Play
- DDC2B
- Warranty
- 5 years (for details and eligible countries please check the Warranty section of our website)
MECHANICAL6
- Orientation
- landscape
- Fanless design
- yes
- VESA mounting
- 800 x 600mm
- Operation temperature range
- 0°C - 40°C
- Storage temperature range
- - 20°C - 60°C
- MTBF
- 50.000 hours (excluding backlight)
ACCESSORIES INCLUDED5
- Cables
- power, USB, HDMI
- Touch pen
- x4 (Dual function tips, Anti-Bacterial)
- Guides
- quick start guide, safety guide
- Other
- WiFi Module (OWM002), Wall Mounting Bracket (VESA 800x600mm), Mounting bracket for NUC, Mounting bracket for webcam
- Remote control
- yes (batteries included)
POWER MANAGEMENT3
- Power supply unit
- internal
- Power supply
- AC 100 - 240V, 50/60Hz
- Power usage
- 227W typical, 0.5W stand by, 0.3W off mode
SUSTAINABILITY2
- Regulations
- CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH (RoHS)
- REACH SVHC
- above 0.1%: Lead, Lead monoxide
DIMENSIONS / WEIGHT5
- Product dimensions W x H x D
- 2203 x 1000 x 92mm
- Box dimensions W x H x D
- 2360 x 225 x 1140mm
- Weight (without box)
- 67.6kg
- Weight (with box)
- 88.5kg
- EAN code
- 4948570124305
COMPATIBLE ACCESSORIES2
- Mounts / Stands / Brackets
- MD-WLIFT2031-W1 , MD-CAR2031-B1 , MD-ADAP001
- Other
- OPS PC Slot
RELATED INFORMATION1
- Related products
- ProLite TE10518UWI-B1AG
Downloads
12 files from the manufacturer
XLSX
iiyama TE9218UWI-B1AG datasheets (XLSX, 10 KB)
PDF
iiyama TE9218UWI-B1AG datasheets (PDF, 2.2 MB)
PDF
iiyama TE9218UWI-B1AG manuals & guides (PDF, 2.5 MB)
PDF
iiyama TE9218UWI-B1AG manuals & guides (PDF, 8.4 MB)
PDF
iiyama TE9218UWI-B1AG brochures (PDF, 5.4 MB)
PDF
iiyama TE9218UWI-B1AG drawings & cad (PDF, 2.9 MB)
PDF
iiyama TE9218UWI-B1AG certificates & compliance (PDF, 72 KB)
PDF
iiyama TE9218UWI-B1AG certificates & compliance (PDF, 29 KB)
ZIP
iiyama TE9218UWI-B1AG software & firmware (ZIP)
PDF
iiyama TE9218UWI-B1AG other documents (PDF, 318 KB)
ZIP
iiyama TE9218UWI-B1AG other documents (ZIP)
ZIP
iiyama TE9218UWI-B1AG other documents (ZIP)
Questions about TE9218UWI-B1AG
What is the iiyama TE9218UWI-B1AG best suited for?
It suits large rooms where several people share content and join remote participants at the same time. In Qatar that usually means a boardroom in West Bay, a ministry meeting room or a large conference room in Lusail. The 92-inch 21:9 canvas lets a presenter show a document, a video call and a spreadsheet side by side, and the 8-array microphone picks up voices up to 8 metres away.
Would this display work in a lecture hall in Education City?
Yes, the 92-inch size and 21:9 format suit a lecture hall where students sit at a distance and need to read slides and annotations. The panel has a 5120 x 2160 native resolution and a viewable area of 2142 x 903.6 mm. Its two 20W speakers and 20W subwoofer cover the room for multimedia playback, but ask the team to confirm sightlines and mounting height for your tiered seating before quoting.
Does the TE9218UWI-B1AG support Microsoft Teams Front Row?
The manufacturer describes integration with Microsoft Teams Front Row, which allows users to host or join virtual meetings from the touchscreen itself. Teams configuration, licences and the room camera setup depend on your tenant and equipment rather than on the display alone. Ask the SmartRooms Qatar team to confirm the setup your organisation needs before you request a quote, so the room is specified correctly the first time.
How accurate is the touch, and how many people can write at once?
The panel uses PureTouch-IR+ infrared touch with 50 touch points, a 32-point writing mode when the operating system supports it, and touch accuracy of plus or minus 1 mm. It responds to a stylus, finger or gloved hand and includes palm rejection. Four dual-function touch pens with anti-bacterial tips are included, which suits a training centre in Al Rayyan where several trainees annotate during a session.
Which ports are on the TE9218UWI-B1AG?
Video inputs are four HDMI (one HDMI 2.1 at 5120 x 2160 at 60Hz, three HDMI 2.0 at 3840 x 2160 at 60Hz), one DisplayPort and two USB-C 3.2 Gen 1 ports. The front USB-C offers 15W power delivery and the back USB-C offers 100W. Outputs include one HDMI, one USB-C, an optical S/PDIF audio output and a mini jack. Eight USB ports, two RJ45 LAN ports and an RS-232c control port complete the rear and side connections.
Can it charge a laptop through a single cable?
The back USB-C port carries video and touch signal and provides up to 100W power delivery, so a compatible laptop can connect and charge through one cable. The front USB-C port provides 15W power delivery, which suits a smaller device. Check your laptop's USB-C power requirement against these ratings before ordering, and confirm the charging setup with the SmartRooms Qatar team during quotation.
Can this panel be installed in a sunny lobby in Msheireb?
The operating range is 0 to 40 °C and storage range is -20 to 60 °C, so the panel should sit in an air-conditioned space. A glass-fronted lobby in Msheireb, where summer temperatures exceed 45 °C and direct sun falls on the screen, needs a different location or shading. The free site survey assesses window orientation and cooling before the panel is specified, which avoids an unsuitable install.
Does it support Arabic menus and how is the software managed?
The integrated software is iiWare 11 on Android 13, with Note, a web browser, a file manager, cloud drives, WPS Office, iiyama Share and EShare for wireless connection from Windows, iOS and Android devices. The on-screen menu lists languages including English, German, French, Spanish and Italian, but the source data does not list Arabic. Confirm Arabic menu and keyboard support before ordering if your staff work in Arabic.
How heavy is it and what wall preparation is needed?
The panel weighs 67.6 kg without packaging and 88.5 kg in its box, and measures 2203 x 1000 x 92 mm. The VESA pattern is 800 x 600 mm and a wall mounting bracket of that size is included. Because the display is wide and heavy, the wall structure, fixings and lifting access should be checked by a site survey before delivery, particularly in older buildings in Al Sadd.
Which mounts and stands are compatible with this model?
The manufacturer lists MD-WLIFT2031-W1, MD-CAR2031-B1 and MD-ADAP001 as compatible mounts, stands or brackets, along with an OPS PC slot. The package includes a wall bracket, a bracket for a NUC mini PC and a bracket for a webcam. Tell the team whether the panel will be wall-mounted or set on a support, so the correct bracket is quoted with the display.
Can I add an OPS PC to this display?
Yes, the source data lists a slot for an optional OPS slot PC, and a mounting bracket for a NUC is included. OPS is a standard slot for a plug-in computer module that sits inside the display, which keeps the room tidy by removing a separate computer from the desk. Ask the SmartRooms Qatar team to confirm module compatibility and quantities before you request a quote.
Can a school in Al Wakrah buy this display on an LPO?
Yes, SmartRooms Qatar supplies on purchase orders (LPOs) and government tenders, including Monaqasat, and accepts payment by bank transfer, cheque or purchase order. A school fitting out several rooms can send the room list and accessory requirements together, so each board is quoted with the correct wall brackets and cable plan. Quotations are usually issued within one working day, and delivery covers all 8 municipalities.
