LG 98TR3DK · Price in Qatar

Overview

The LG CreateBoard 98TR3DK is a 98-inch 4K UHD interactive digital board built for classrooms, lecture halls and boardrooms that need a large, touch-first display. It supports up to 40 touch points on Windows, runs Android 13 with 8GB RAM and 64GB storage, and includes a built-in OPS slot and Wi-Fi 6. Request a quote for supply, installation and delivery across Qatar.

A 98-inch interactive board for large teaching and meeting rooms

The LG CreateBoard 98TR3DK is built around a 3840x2160 UHD IPS panel. It is the largest size in the TR3DK series, which the manufacturer data lists from 55 to 98 inches, so it suits rooms where everyone needs to read the same content from the back row. Its touch layer handles up to 40 points on Windows, which lets several people write, annotate and move content at the same time.

Display and touch figures to check against your room

Brightness is rated between 350 and 440 nits depending on whether the protective glass is fitted. Contrast is 1200:1 static and 3000:1 dynamic. The panel uses direct backlighting, a 60Hz refresh rate, an 8ms response time and a 178 degree viewing angle. The rated lifetime is 50,000 hours (L30), and operation is specified at 16 hours a day, 7 days a week. Touch response is 5ms or less with ±1.5mm accuracy, and the anti-glare protection glass, listed as 4T, transmits 88 percent of light.

Connectivity, software and an OPS slot

The board provides three HDMI inputs with HDCP 2.2, one VGA input, one USB-C port with USB power delivery and DisplayPort Alt mode, four USB 3.0 Type A ports, one USB 2.0 Type A port, an audio input, an RS232C input and a LAN port. Two touch USB outputs and an optical S/PDIF audio output are also fitted. Inside, it has 64GB storage, 8GB RAM, Android 13, Wi-Fi 6 (802.11ax) through a slot-type module, Gigabit LAN and Bluetooth 5.0. The built-in OPS slot lets you mount an OPS computer at the back of the board without a separate external desktop. The OPS player is sold separately.

Share a screen wirelessly with up to 9 shared screens through LG CreateBoard Share
Import and export files with Google Drive, OneDrive and USB storage
Manage boards remotely with LG ConnectedCare DMS in the cloud

Where a 98-inch board fits in Qatar

Three realistic setups show where this size makes sense:

A lecture hall in Education City where the lecturer runs slides from a laptop and marks up a diagram directly on the board while students follow from the back.
A boardroom in West Bay where the team shares material from several devices and joins a meeting that links Doha with colleagues abroad.
A school group in Al Wakrah or Lusail with several classrooms, where facilities and IT staff monitor each board and its alerts from one console instead of visiting every room.

Planning the installation

The head weighs 103.6 kg and measures 2244 x 1323 x 91 mm, so the wall or floor must be checked before installation. The packed weight is 133.2 kg, so plan the delivery route and room access in advance. The VESA mount interface is 800 x 600 mm. The wall mount WM-L000S and floor stand ST-000F are optional. The operating range is 0 to 40 °C and 10 to 90 percent relative humidity, so the room must stay air-conditioned, because Qatar summer temperatures can exceed 45 °C. The power supply is 100 to 240 V at 50/60 Hz, with typical draw of 395W and maximum of 610W. Include that heat load in your cooling plan. A free site survey from SmartRooms Qatar helps confirm the mounting point, power and cabling before the board arrives.

Request a quote from SmartRooms Qatar for the 98TR3DK, with installation and delivery to all 8 municipalities of Qatar. We usually reply within one working day.

Highlights

98-inch 3840x2160 UHD IPS panel with 1200:1 contrast
Up to 40 touch points on Windows, 32 on Android
Android 13 with 8GB RAM and 64GB internal storage
Built-in OPS slot with OPS power built in
Built-in Wi-Fi 6 and Bluetooth 5.0
Operating range 0 to 40 °C and 10 to 90% humidity

Classroom fit

At 98″ the farthest student should sit within about 7.3 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

64 specifications · Source: manufacturer · checked Oct 2026

Panel17

Screen Size: 98"
Panel Technology: IPS
Back Light Type: Direct
Aspect Ratio: 16:9
Native Resolution: 3840x2160 (UHD)
Refresh Rate: 60Hz
Brightness: 440nit(wo Glass, max), 390nit (wo Glass, typ) 400nit(w Glass, typ), 350nit (w Glass, typ)
Contrast Ratio: 1200:1
Dynamic CR: 3000:1
Color gamut: NTSC 72%
Viewing Angle(H x V): 178°(H/V)
Color Depth: 1.07B(10bit)
Response Time: 8ms
Surface Treatment(Haze): 25%
Life time: 50,000hrs (L30)
Operation Hours (Hours/Day): 16/7
Portrait / Landscape: No / Yes

Connectivity(Jack Interface)2

Input: HDMI (3, HDCP2.2), RGB (1, VGA), Audio In, RS232C IN, RJ45(LAN), USB3.0 Type A (4), USB2.0 Type A(1), USB Type-C(1, USB-PD, DP-Alt,)
Output: DP Out (HDMI Out), Audio Out (1, Optical 1(SPDIF)), Touch USB (2), RJ45(LAN)

Mechanical Specification8

Bezel Color: Black
Bezel Width: T/R/L/B : 30/27/27/45mm
Weight(Head): 103.6Kg
Packed Weight: 133.2Kg
Monitor Dimension(W x H x D): 2244 × 1323 × 91mm
Carton Dimensions(W x H x D) (Box outer size): 2406 × 1474 × 280mm
Handle: Yes
VESA™ Standard Mount Interface: 800×600mm

Key Feature2

HW: Internal Memory (64GB), Built-in Wi-Fi (Slot type), Auto Brightness sensor, Power Indicator
SW: Android 13, Background Image (Booting Logo Image), Multi-screen (PIP (1 external source), PBP(1 external source)), Screen Share (LG CreateBoard Share), Power (Smart Energy Saving (Energy Saving))

Environment Conditions2

Operation Temperature: 0 ~ 40 °C
Operation Humidity: 10 ~ 90 % RH

Power2

Power Supply: 100-240V~ 50/60Hz 5.5A
Power Type: Built-In Power

Power Consumption5

Typ.: 395W
Max.: 610W
BTU (British Thermal Unit): 1348 BTU/Hr(Typ.), 2081 BTU/Hr(Max)
DPM: ≤0.5W
Power off: ≤0.5W

Sound1

Speaker: Yes (15W x 2)

Certification3

Safety: CB / NRTL
EMC: FCC Class "A" / CE / KC
ErP / Energy Star: Yes / Yes

OPS Compatibility2

OPS Type Compatible: Yes (Slot)
OPS Power Built In: Yes

Software Compatibility2

LG ConnectedCare: Yes
LG ConnectedCare DMS: Yes (DMS)

Language1

OSD: English, Denmark, Finnish, German, Korean, Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Spanish, Swedish, Hungarian, Thai

Accessory2

Basic: Power Cord 3 M*1, USB Cable(Type A-Type B) 5 M*1, USB Type-C Cable(C to C) 1.8 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
Optional: Wall Mount(WM-L000S), Floor Stand(ST-000F)

Special Feature8

Touch - Available object size for touch: Ø2 mm ↑ .
Touch - Reponse Time: ≤5ms
Touch - Accuracy: ±1.5mm
Touch - Interface: USB2.0
Touch - Protection Glass Thickness: 4T (Anti-Glare)
Touch - Protection Glass Transmission: 88%
Touch - Operating System Support: Windows 7/8/10/Linux/Mac/Android (Linux/Mac Support one point touch)
Touch - Multi touch point: Max 40 points (Windows), Max 32 points (Android)

ANDROID SYSTEM7

SoC: Quad core A55
GPU: Mali G52MP2
Internal Memory - Storage: 64GB
Internal Memory - RAM: 8GB
Wi-Fi: 802.11a/b/g/n/ac/ax (WiFi 6)
LAN: Gigabit LAN
Bluetooth: Bluetooth 5.0

Downloads

8 files from the manufacturer

PDF Datasheets TR3DK-BM(Corporate)_Datasheet(low)_LG CreateBoard_240809_20240820_131342_.pdf 4.0 MB PDF Datasheets TR3DK-BM(Education)_Datasheet(low)_LG CreateBoard_240809_20240820_131355_.pdf 3.9 MB PDF Manuals & guides Android13_ENG.pdf 24.6 MB PDF Manuals & guides MFL71968601_12_260421.pdf 1.2 MB PDF Manuals & guides MFL71968603_04_260303.pdf 1.5 MB PDF Manuals & guides OM_ARA.pdf 2.2 MB PDF Manuals & guides OM_ENG.pdf 2.1 MB URL Software & firmware · Opens on manufacturer site Software & Drivers (support page)

Questions about 98TR3DK

Who should buy the 98-inch model instead of a smaller size?

The 98-inch model suits large rooms where many people must read the board from a distance, such as a lecture hall in Education City or a boardroom in West Bay seating a large group. Its 2244 x 1323 mm footprint and 103.6 kg head weight mean you should confirm the room can take it before ordering. The series runs from 55 to 98 inches, so ask us to compare sizes for smaller rooms.

How heavy is the board and what mounting options are there?

The head weighs 103.6 kg and ships at 133.2 kg packed. It has a VESA 800 x 600 mm mount interface and a handle. The wall mount WM-L000S and floor stand ST-000F are optional extras. Because of the weight, the wall or floor must be structurally checked. SmartRooms Qatar offers free site surveys to confirm the mounting point and the access route before installation.

Can I install it in a room without air conditioning, such as a hot lobby in Msheireb?

No. The operating temperature is 0 to 40 °C with 10 to 90 percent relative humidity, while summer temperatures in Qatar can exceed 45 °C. The room should be air-conditioned and kept within that range throughout the year. If the space is a lobby or a semi-open area, confirm the environment with the SmartRooms Qatar team before the quotation is finalised.

What power does it need, and does it work on Qatar's 240V supply?

The power supply is listed as 100-240V at 50/60Hz, which covers Qatar's 240V, 50Hz mains. Typical draw is 395W and maximum draw is 610W, equal to 1,348 and 2,081 BTU/hr of heat. Standby and power-off draw are 0.5W or less. Check that the room circuit and cooling capacity can handle the maximum figure during long teaching or meeting days.

How many touch points does it support, and how accurate is the touch?

It supports up to 40 touch points on Windows and 32 on Android. Touch response is 5ms or less, with ±1.5mm accuracy and a minimum object size of 2mm. Touch is supported on Windows 7, 8 and 10, Linux, Mac and Android, with Linux and Mac supporting one-point touch. The anti-glare protection glass, listed as 4T, transmits 88 percent of light.

Which ports are available for laptops and other devices?

The inputs include three HDMI ports with HDCP 2.2, one VGA port, and one USB-C port that supports USB power delivery and DisplayPort Alt mode. There are four USB 3.0 Type A ports, one USB 2.0 Type A port, an audio input, an RS232C input and a LAN port. The box includes a 3 m HDMI cable and a 1.8 m USB-C to USB-C cable for connecting your devices.

How does the OPS slot work, and is the OPS player included?

The board has a built-in OPS slot with OPS power built in, so you can mount an OPS desktop at the back of the board instead of using a separate external PC. The OPS player for LG CreateBoard is sold separately, so include it in your quotation if you need it. OPS stands for Open Pluggable Specification. Confirm the OPS model suits your software before ordering.

Can teachers or staff share screens wirelessly during a meeting?

Yes. LG CreateBoard Share lets the host show up to 9 shared screens or a file on the board in real time, once the Share app is installed on the connecting device. Built-in Wi-Fi 6 and Bluetooth 5.0 also support wireless accessories such as a speaker, mouse or keyboard. A team in Doha meeting colleagues abroad can view material together with fewer cables.

How can IT staff manage several boards across different sites?

LG ConnectedCare DMS is a cloud tool for monitoring, controlling and managing the status of CreateBoard units in educational environments. It can send messages and urgent alerts to classroom devices, and it can warn about thresholds across eight categories, including display temperature, memory usage and signal. For a school group in Lusail or Al Khor with several rooms, this reduces the need for site visits.

Can a government office or school order this under an LPO?

Yes. SmartRooms Qatar accepts purchase orders (LPOs) and government tenders, including Monaqasat, and payment can be made by bank transfer, cheque or purchase order. A school ordering several units can include the board, the OPS player and any optional wall mount or floor stand in one quotation and one LPO. Quotations are usually issued within one working day, and the product is covered by the manufacturer's warranty.

What comes in the box, and what do I need to order separately?

The box includes two writing pens, a remote controller with two batteries, the Wi-Fi module, a 3 m power cord, a 3 m HDMI cable, a 5 m USB Type A to Type B cable, a 1.8 m USB-C cable, a user manual and a quick start guide. The wall mount WM-L000S and floor stand ST-000F are optional, and the OPS player is sold separately. Ask us to confirm mounting and OPS requirements in your quotation.
