Name: Newline IP+ Series TT-8621IP 86-inch Interactive Display
Brand: Newline
SKU: newline-ip-plus-tt-8621ip
Availability: InStock

Overview

The Newline TT-8621IP is an 86-inch interactive flat panel from the IP+ Series. It pairs a 4K optically bonded display and a 178° viewing angle with 20-point capacitive touch. Its Linux-based operating system replaces Android, and an OPS-PC slot lets you add an on-board PC. It suits boardrooms, lecture halls and training rooms in Qatar. Request a quote for supply and installation.

What the TT-8621IP is built for

The Newline TT-8621IP is the largest model in the IP+ Series, with an 86-inch 4K panel and a display area of 1895 × 1066 mm. It is designed for rooms where one shared screen serves a whole group: a presenter at the front, a team around the table, and remote participants joining by video call. Its operating system is Linux-based rather than Android, a design the manufacturer built for enterprise security and for organisations that need tighter control over their network.

Display and touch performance

The panel is an LED backlit, optically bonded display with 3840 × 2160 resolution, brightness of at least 370 cd/m², a dynamic contrast ratio of 4000:1 and an 8 ms response time. The 178° viewing angle keeps slides readable from side seats in a lecture hall. Projected capacitive (P-cap) touch supports 20 touch points and works with a passive pen, so presenters can annotate with a finger or stylus. The surface is anti-glare, rated 8H in hardness, with 88% ± 3 transparency.

Connectivity and expansion

Inputs: three HDMI inputs at 4K and 60Hz, with ARC on HDMI 1, a USB-C 3.0 port with 60W power delivery and a microphone input.
Outputs and control: one HDMI output at 4K and 60Hz, a line audio output, S/PDIF, RS-232 and an RJ-45 network port.
Expansion: an OPS-PC slot for an on-board PC and an SDM-S slot.
Touch and USB: three USB Type-B touch ports, a public-facing USB 3.0 port and a USB 2.0 port.

Where it fits in Qatar

Consider a university lecture hall in Education City, where an 86-inch panel shows slides and live video to rows of students. A boardroom in West Bay can use it for meetings that connect Doha with colleagues abroad, with the Linux system keeping network access under control. A hotel conference room in Lusail can host training sessions with a laptop connected through a single USB-C cable. Each setup depends on room layout, lighting and power, so these scenarios should be checked during planning.

What to plan before ordering

Weight: the specification table lists 59 kg, while the datasheet gives 60 kg net and 76 kg gross, so walls and mounts must be rated for this load.
Dimensions: outline size is 1977 × 1150 × 86 mm and packed size is 2119 × 1281 × 275 mm, which affects doorways and lift access.
Power: input 100 to 240 V AC, maximum 4.5 A, maximum consumption 500 W, eco consumption 400 W and standby below 0.5 W.
Environment: operating range is 0°C to 40°C at 20 to 80% humidity, non-condensing. Qatar summer temperatures can exceed 45°C, so install in air-conditioned rooms away from unshaded windows. Storage range is -10°C to 45°C.

Wall mounting and a mobile stand are both listed as optional. SmartRooms Qatar offers free site surveys before wall-mounting a panel this size, and installation can be included in your quotation. Request a quote for the TT-8621IP and our team will confirm the configuration, delivery and installation for your site.

Highlights

86-inch 4K display (3840 × 2160) with 1895 × 1066 mm display area
Optically bonded panel with 178° viewing angle
20-point P-cap touch with passive pen support
Linux-based operating system in place of Android
OPS-PC slot for adding an on-board PC
Single USB-C port with 60W power delivery

Classroom fit

At 86″ the farthest student should sit within about 6.4 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

7 specifications · Source: manufacturer · checked Oct 2026

TT-8621IP7

General · Screen Size: 86″
General · Display area (mm): 1895 × 1066
General · Weight (kg): 59
General · Touch Technology: P-Cap
General · Resolution: 3840 × 2160 (4K)
General · Viewing Angle: 178°
General · Backlight: LED

Downloads

0 files from the manufacturer

No downloadable files are listed for this model yet. Ask us and we will send the datasheet.

Questions about TT-8621IP

Is the TT-8621IP suited to a lecture hall in Education City?

Yes, it suits rooms where one large screen serves a whole class or audience. At 86 inches with a 1895 × 1066 mm display area, it is the largest panel in the IP+ Series, so students in back rows can follow slides and video. Final placement depends on room layout and lighting, which our team reviews with you during the free site survey before installation.

Why does the IP+ Series run Linux instead of Android, and who benefits?

The IP+ Series replaces the traditional Android operating system with Linux, a design the manufacturer built for enterprise security. It gives IT teams more control over network access while still letting staff and visitors walk up and use the touch screen. Government offices, banks and other organisations that put network security first in purchasing decisions are typical buyers of this model.

Will people seated at the side of a large room see the screen clearly?

The panel has a 178° viewing angle, brightness of at least 370 cd/m², and a dynamic contrast ratio of 4000:1. These figures help content stay readable from wide seating positions. Room lighting and window placement still affect glare on the glass, so review seating and light sources with the SmartRooms Qatar team before the panel is fixed in position.

How many touch points does it support, and does it work with a pen?

The screen uses projected capacitive (P-cap) touch with 20 touch points and accepts a passive pen. The anti-glare surface has 8H hardness, which helps it cope with daily use in classrooms and meeting rooms. Teachers and presenters can annotate slides and write directly on the glass, making whiteboarding quick and natural for longer sessions.

Can a presenter in a West Bay boardroom connect a laptop with one cable?

Yes. The USB-C 3.0 port provides power delivery of up to 60W, so one compatible laptop cable can carry data, audio, video and power. Three HDMI inputs at 4K and 60Hz remain available for other sources, such as a second computer. This suits meetings where presenters change often and a quick switch between sources matters.

What ports are on the TT-8621IP?

The panel has three HDMI inputs at 4K and 60Hz (with ARC on HDMI 1), one HDMI output at 4K and 60Hz, one USB-C 3.0 port with 60W power delivery, three USB Type-B touch ports, a public-facing USB 3.0 port, a USB 2.0 port, a microphone input, a line audio output, S/PDIF, RS-232 and an RJ-45 network port. The OPS-PC slot and SDM-S slot add expansion options.

Can I add a PC to run Windows applications?

Yes, the panel includes an OPS-PC slot for an on-board PC, and the manufacturer describes using the familiar Windows system with it. The specification sheet does not say whether a PC module is included, so confirm compatibility and whether it is part of your quotation before ordering. Ask for the module details when you request a quote.

Will it run on Qatar's 240 V mains supply?

The input range is 100 to 240 V AC, so it covers the 240 V supply used in Qatar. The 86-inch model draws a maximum of 4.5 A and up to 500 W, with eco mode at 400 W and standby below 0.5 W. Ask the SmartRooms Qatar team to confirm that the supplied power cord's plug matches your BS 1363 wall sockets before installation.

Can it go in a Msheireb lobby near windows without air conditioning?

Not without suitable conditions. The operating range is 0°C to 40°C at 20 to 80% humidity, non-condensing, while Qatar summer temperatures can exceed 45°C. Choose an air-conditioned lobby away from direct sunlight, and note the storage range of -10°C to 45°C for panels waiting on site before installation.

Can a school in Al Rayyan wall-mount an 86-inch panel?

Wall mounting is one of two optional mounting methods, the other being a mobile stand. The 59 kg weight in the specification table (the datasheet lists 60 kg net) and the 1977 × 1150 × 86 mm outline mean the wall and bracket must be checked first. SmartRooms Qatar offers a free site survey to check wall structure, clearances and the access route.

Can a school in Al Wakrah order several units under one LPO?

Yes. SmartRooms Qatar accepts purchase orders (LPOs), supplies government tenders including Monaqasat, and accepts payment by bank transfer, cheque or purchase order. A school can list several TT-8621IP panels on one quotation, with installation planned room by room. Quotations are usually issued within one working day.
