Touchscreen TL7 Business 105

A 105-inch interactive display for rooms that share one screen

The OneScreen Touchscreen TL7 Business 105 is the largest model in the TL7 Business series. It pairs a 105-inch VA panel with its own Android 13 computer, so presentations, shared documents, video calls and handwritten annotation can run from the panel itself without a separate PC brought into each meeting. For organisations in Qatar that host large groups, it turns one wall into a working surface.

Display and touch facts that matter at this size

The panel has a 5120 × 2160 resolution and a brightness rating of 400 cd/m², with a 4000:1 contrast ratio, 10-bit colour (1.07 billion colours) and 90% NTSC coverage. The 178° viewing angle keeps the picture readable from the far end of a long table or the back row of a hall. The DLED backlight is rated for at least 30,000 hours.

Touch is infrared with 50 touch points, ±1 mm accuracy, a 2 mm minimum object size and a writing height of 2 mm or less. Both passive and active infrared pens are listed, giving presenters a choice of input tools. Touch response is 5 ms or less, and the panel response time is 6.5 ms.

Computing, ports and sound

The built-in system runs Android 13 with 8 GB RAM and 64 GB storage on an octa-core processor (four A76 and four A55 cores) with a Mali-G610 MP4 graphics unit. Connections include:

• Three HDMI inputs up to 4K at 60Hz, one HDMI output and one DisplayPort input at 4K 30Hz
• Two USB Type-C inputs carrying video, audio, touch and network sharing
• Six USB 3.0 ports across the rear, top and front, plus one USB 2.0 port for software updates
• RJ45 input and output at up to 1000 Mbps, an RS-232 port and a 3.5mm audio output

Sound comes from a 2.1 system with 2 × 16W and 15W speakers rated at 80dB sound pressure level. An eight-microphone array picks up voices up to 8 metres away, which suits a boardroom table or a lecture stage. The stated typical draw is 410 W and the maximum is 558 W, quoted with an OPS module fitted.

Where the 105-inch model fits in Qatar

A boardroom in West Bay or Lusail where a government authority or energy company meets teams abroad benefits from the large, readable panel and microphone array, with a camera and conferencing codec connected through the USB and HDMI ports. A lecture hall or seminar room in Education City, where the back row must read the same slide as the front, is another natural fit. A conference room at a Doha hotel or events venue can use the screen for pre-recorded content and interactive briefings.

What to plan before ordering

At 91.4 kg net and 119.5 kg gross, the panel needs a wall structure that can carry its load and a mount matched to its 1000 × 400 mm VESA pattern, fixed with M8 × 25 mm wall-hanging screws. The stated thickness of 135.1 mm applies with the WIB1060A wall mount. The shipping box measures 2668 × 280 × 1305 mm, so check the route from the delivery door to the room, including lifts and corridors, before delivery day. The 100 to 240 V input range covers Qatar's 240 V, 50 Hz supply, but have your electrician confirm the circuit and socket location.

The data gives a storage range of -20 to 60 °C and 10% to 90% humidity, but no operating temperature range for this model. Confirm room conditions with SmartRooms Qatar before placing the panel in a glazed, sunlit or unconditioned space, especially where summer temperatures exceed 45 °C.

A free site survey from SmartRooms Qatar can confirm the wall, the delivery route and the power before you commit. Request a quote and we will usually respond within one working day. We deliver to all eight municipalities of Qatar and accept LPOs and government tenders.
