OneScreen Touchscreen TL7 Education 75-inch Interactive Display

Screen size: 75″
Resolution: 4K UHD (3840 × 2160)
Touch: Zero Bonding IR (Gen 2)
System: Android 11

Priceon request

QuotationWithin 1 working day

DeliveryConfirmed with your quote, based on stock

PDFDownload datasheet

Overview

The OneScreen Touchscreen TL7 Education 75 is a 75-inch 4K UHD interactive flat panel for classrooms and meeting rooms. It combines a 40-point zero bonding infrared touch layer with 1.5 mm accuracy, Android 11, 8 GB RAM and 64 GB storage, plus an OPS PC slot and a 65W USB Type-C port. It suits Qatari schools and offices that need a large, dependable touch display for teaching and collaboration. Request a quote from SmartRooms Qatar.

What the TL7 Education 75 is built for

The OneScreen Touchscreen TL7 Education 75 is a 75-inch interactive flat panel for classrooms, lecture spaces and meeting rooms. Its LED-backlit 4K UHD panel shows 3840 x 2160 pixels in a 16:9 format, with a 60Hz refresh rate, 400 cd/m² brightness and a 178 degree viewing angle, so people seated at the side of the room can still read the content. The panel displays 1.07 billion colours at 10-bit depth.

The glass has an anti-glare, anti-fingerprint finish, an ambient light sensor adjusts brightness to the room, and a blue light filter is included.

Touch, processing and software

Touch uses a second-generation zero bonding infrared system with 40 touch points, 1.5 mm accuracy and a response time under 7 ms. Two stylus pens with an anti-bacterial coating are supplied, so teachers and presenters can write on the glass as soon as the panel is running.

Android 11 runs on a quad-core ARM Cortex A55 processor clocked up to 1.8 GHz, backed by 8 GB of RAM and 64 GB of storage. The OPS PC slot gives IT teams a route to add a plug-in computer module. The shared TL7 software set includes OneScreen Central, which manages several panels from one place, along with built-in whiteboard, timer, screen recorder and freeze frame tools.

Ports and connectivity for lessons and meetings

The side of the panel carries two HDMI inputs, one HDMI output, a VGA input with audio input, a 3.5 mm audio output, an RS-232 control port, two RJ-45 network ports, two USB 3.0 ports, a USB 2.0 port and the OPS slot. The front adds an HDMI input, a touch USB port, two USB 3.0 ports and a USB Type-C port rated at 65W Power Delivery. Wireless is dual-band Wi-Fi 6 with Bluetooth 5.2, and wired networking is Gigabit Ethernet.

Where it fits across Qatar

In a secondary school in Al Rayyan, the 75-inch size suits a standard classroom where rear-row students still need to read worksheets and diagrams. A teacher can annotate the same slide the class is viewing, and the 40 touch points support more than one student writing during group work.

In a training room at a centre in Education City, facilitators can project software walkthroughs from a laptop while participants mark up the screen. In a ministry or corporate meeting room in Msheireb or West Bay, the panel works as a shared display for internal reviews, with network access through Ethernet or Wi-Fi.

What to plan before you order

The panel measures about 170.9 cm wide, 102.0 cm high and 8.8 cm deep, and weighs about 47.3 kg (104.28 lb). It is designed for a flush wall mount with an 800 x 400 mm VESA pattern, so wall structure, mounting height and cable route should be checked first. SmartRooms Qatar offers a free site survey, which we recommend before fixing a panel of this weight.

The power supply accepts 100 to 240 V AC at 50 to 60 Hz, with typical consumption of 200 W and a maximum of 360 W. The product data does not give an operating temperature range for this model, so for lobbies, sunlit rooms or spaces without air conditioning, ask the SmartRooms Qatar team to confirm the environment before ordering. The panel carries a 3 year standard warranty, with options for advanced hardware or extended cover.

Schools and public bodies can order by LPO or respond to a government tender, and payment is possible by bank transfer, cheque or purchase order. Send your room dimensions, mounting wall and number of units with your request, and SmartRooms Qatar will return a quotation, usually within one working day.

Highlights

75-inch 4K UHD (3840 x 2160) LED display at 400 cd/m²
Zero bonding infrared touch with 40 points and 1.5 mm accuracy
Android 11 with 8 GB RAM and 64 GB storage
OPS PC slot plus USB Type-C with 65W Power Delivery
Dual-band Wi-Fi 6, Gigabit Ethernet and Bluetooth 5.2
3 year standard manufacturer warranty

Classroom fit

At 75″ the farthest student should sit within about 5.6 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

37 specifications · Source: manufacturer · checked Oct 2026

Touchscreen TL7 Education 7537

size_inch: 75
datasheet: datasheets/OneScreen-Touchscreen-for-Education-TL7_75-Spec-Sheet.pdf
datasheet_url: https://partnerportal.onescreensolutions.com/resources/OneScreen-Touchscreen-for-Education-TL7_75-Spec-Sheet.pdf
specs · Touch · Touch Type: Zero Bonding IR (Gen 2)
specs · Touch · Touch Points: 40
specs · Touch · Touch Accuracy: 1.5 mm
specs · Computing · Operating System: Android 11
specs · Computing · RAM: 8 GB
specs · Computing · Storage: 64 GB
specs · Computing · Processor: 1 Quad-core ARM cortex A55 (up to 1.8 Ghz)
specs · Power · Power Requirements: 100 - 240v AC 50-60 Hz
specs · Power · Power Consumption (typical): 200 W (0.5W standby)
specs · Power · Power Consumption (Maximum): 360 W
specs · Power · Energy Star: 109.05 W
specs · Panel · Screen Size (Diagonal): 75”
specs · Panel · Panel Backlight: LED
specs · Panel · Resolution: 4K UHD (3840 × 2160)
specs · Panel · Brightness: 400 cd/m²
specs · Panel · Aspect Ratio: 16:9
specs · Panel · Refresh Rate: 60Hz
specs · Panel · Viewing Angle: 178°
specs · Panel · Blue light filter: Yes
specs · Panel · Display Colors: 1.07 Billion (10 bit)
specs · Physical · Product Weight: 104.28 lbs
specs · Physical · Product Dimensions: 67.28” x 40.16” x 3.46” (L x H x W)
specs · Physical · Shipping Weight: 133.49 lbs
specs · Physical · Shipping Dimensions: 73.34” x 44.88” x 8.86” (L x H x W)
specs · Ports and Connectivity · Sensors: 1x Ambient Light Sensor for adaptive screen brightness
specs · Ports and Connectivity · Connectivity: Wifi 6 (2.4Ghz & 5Ghz), Gigabit Ethernet (1000M), Bluetooth 5.2
specs · Ports and Connectivity · Input/Output Ports (Side): 2x HDMI-In, 1x VGA-In, 1x VGA Audio-In, 1x HDMI-Out, 1x USB Touch, 1x Audio-Out (3.5mm), 1x RS-232, 2x-RJ- 45, 2x USB 3.0, 1x USB 2.0,1x OPS PC Slot
specs · Ports and Connectivity · Input/Output Ports (Front): 1x HDMI-In, 1x USB Touch, 2x USB 3.0, 1x USB Type-C (65W PD)
specs · Audio · Speakers: 2x 16W with stereo output
specs · Accessories and Mounting · Wall Mount: VESA Standard 800 x 400 Flush Wall mount
specs · Accessories and Mounting · Cables & Accessories: 1x HDMI Cable, 1x Power cable, 1x USB Touch Cable, 1x Type C Cable, 2x Stylus pens with antibacterial coating, 1x Remote control for Display
specs · Warranty and Certifications · Warranty: 3 Years Standard warranty with options for advanced hardware warranty or extended warranty
specs · Warranty and Certifications · Certifications: Available, RoHS, FCC, Energy Star, UL, CE, RoHS, WEEE, CB
specs · Glass · Surface Protection: Level 7 MoHS Anti-Glare and Anti-Fingerprint

Downloads

20 files from the manufacturer

Questions about Touchscreen TL7 Education 75

Is the TL7 Education 75 the right size for a training room at a centre in Education City?

The 75-inch panel suits a training room where the back row still needs to read slides, spreadsheets and small text, without the weight and wall space of an 86-inch screen. The 4K UHD resolution keeps detail sharp, and the 40-point touch lets trainers annotate directly on the slide. Confirm the room size and sightlines with SmartRooms Qatar before ordering.

Will a 75-inch screen work in a secondary school classroom in Al Rayyan?

For a standard classroom, yes, it is a practical size. Teachers can write on the glass with the two included stylus pens, while students at the back read 4K text and diagrams across a 178 degree viewing angle. Measure the wall first, since the panel is 170.9 cm wide, and plan the mount around the board position your classroom already uses.

We want to mount it in a boardroom in West Bay. What should we plan for?

The panel weighs about 47.3 kg and is 170.9 cm wide, so the wall structure and mounting height need checking before installation. It is designed for a flush wall mount with an 800 x 400 mm VESA pattern. SmartRooms Qatar offers a free site survey to check the wall, socket position and cable route before anything is fixed. Mention the survey when you request your quote.

Can it go in a sunlit hotel lobby in Doha during the summer?

The product data does not give an operating temperature range for this model, so the SmartRooms Qatar team should confirm the environment before you order. Direct sun, glare from large windows and heat near the panel are all points to check. The anti-glare, anti-fingerprint glass and ambient light sensor help with lighting, but they do not replace a suitable indoor location with air conditioning.

Can a ministry office in Msheireb connect laptops and a second screen for internal meetings?

Yes. The front has an HDMI input and a USB Type-C port rated at 65W Power Delivery, which can supply power to a compatible laptop. The side has two HDMI inputs and one HDMI output, which can feed a second display. Network access is available through two RJ-45 ports with Gigabit Ethernet, or through dual-band Wi-Fi 6.

How accurate is the touch, and what comes in the box for writing?

The second-generation zero bonding infrared touch system offers 40 touch points, 1.5 mm touch accuracy and a response time under 7 ms. In a lesson, that means precise annotation and more than one person writing at a time. The box includes two stylus pens with an anti-bacterial coating, a remote control and a USB touch cable, so the panel is ready to use once it is connected.

What operating system and memory does it run, and can IT manage it centrally?

The panel runs Android 11 on a quad-core ARM Cortex A55 processor clocked up to 1.8 GHz, with 8 GB of RAM and 64 GB of storage. The shared TL7 software set includes OneScreen Central for managing several panels from one place, and the built-in whiteboard, cloud drive and classroom tools run on the same platform. Ask SmartRooms Qatar to confirm the software details when you request a quote.

How many ports does it have, and can it take a plug-in computer?

The side panel has one OPS PC slot, two HDMI inputs, one HDMI output, a VGA input, an RS-232 port, two RJ-45 ports, two USB 3.0 ports and a USB 2.0 port. The front adds an HDMI input, a touch USB port, two USB 3.0 ports and a 65W USB Type-C port. The OPS slot is the usual route for a plug-in PC module, so confirm the module you need with SmartRooms Qatar before ordering.

Does the power supply suit Qatar's 240 V mains?

The rated input is 100 to 240 V AC at 50 to 60 Hz, which covers Qatar's 240 V, 50 Hz supply. Typical consumption is 200 W, the maximum is 360 W, and standby power is 0.5 W. Confirm the plug type and socket position for your room before installation, and check the supplied power cable against your planned socket.

What warranty applies, and can a public school or government body buy it through an LPO or tender?

The panel carries a 3 year standard manufacturer warranty, with options for advanced hardware or extended warranty. Public schools and government bodies can request a quote and order by LPO, or respond to a government tender such as Monaqasat. Payment is possible by bank transfer, cheque or purchase order, and SmartRooms Qatar aims to return quotations usually within one working day.

How does it compare with the 65-inch and 86-inch TL7 Education models?

All three share the 4K UHD panel, 40-point touch, Android 11, 8 GB RAM and 64 GB storage. The 75-inch and 65-inch models both have a typical consumption of 200 W, while the 86-inch draws 350 W typical. The 75-inch uses an 800 x 400 mm VESA pattern, against 600 x 400 mm for the 65-inch and 800 x 600 mm for the 86-inch. Choose the 75-inch for mid-sized rooms.
