SMART Interactive Flat Panels Current

SBID-6086S-V3-PW

SMART Board 6086S-V3 Pro 86-inch Interactive Display, White

Screen size: 65"
Resolution: 4K UHD (3840 × 2160)
Touch: HyPr Touch with InGlass
System: Included

Priceon request

QuotationWithin 1 working day

DeliveryConfirmed with your quote, based on stock

Overview

The SMART Board 6086S-V3 Pro is an 86-inch white interactive display with a 4K UHD panel and HyPr Touch with InGlass. It offers two RJ45 ports, a 60 W OPS slot for a PC module, and HDMI 2.1 inputs front and back. Suited to boardrooms, lecture halls and training rooms, its 86 kg weight makes a site survey worthwhile before wall mounting. Request a quote from SmartRooms Qatar.

What this 86-inch Pro white model is

The SMART Board 6086S-V3 Pro is a 16:9 interactive flat panel with an 86-inch LED display, 4K UHD resolution (3840 × 2160) and a 60 Hz refresh rate. Its fully heat-tempered anti-glare glass resists smudges and fingerprints, and the white frame suits offices and schools that keep a light colour scheme. This is the Pro variant without the built-in iQ Android experience, so you connect a laptop, a PC module or another source to run lessons and meetings.

Touch, pens and the specifications behind daily use

Touch is powered by HyPr Touch with InGlass, rated at ±1 mm accuracy, a 2 mm minimum object size and up to 40 touch points depending on the operating system. The typical response time is 9 ms and the frame rate is 150 Hz. Two pens and two erasers are included, held in intelligent, magnetic tool holders on the frame. A multicolour four-pen bundle is available as an option.

Brightness: at least 350 cd/m² maximum
Lifespan: at least 50,000 hours
Sensors: proximity, ambient light, infrared, room temperature and humidity
Audio: two integrated 20 W speakers and a four-microphone array

Connections for meetings and teaching

The front panel carries one HDMI 2.1 input, one USB Type-C port that delivers 4K at 60 Hz with DisplayPort 1.2 and up to 65 W power delivery, one USB 3.0 Type-A port and one USB 2.0 Type-B port. The back adds a 60 W OPS slot, two more HDMI 2.1 inputs, VGA, 3.5 mm stereo audio, RS-232, two RJ45 ports, another USB Type-C port and several USB Type-A and Type-B ports. Outputs include HDMI 2.1, 3.5 mm audio and S/PDIF. Wired networking runs through the RJ45 ports, and no built-in Wi-Fi is listed for this model.

Environment, weight and installation planning

The operating range is 5 to 35°C (41 to 95°F) with 5 to 80% relative humidity, non-condensing. Summer temperatures in Qatar can exceed 45°C, so install the panel indoors in an air-conditioned room, away from direct sun through glass and from dusty entrances. Leave space around the display for ventilation as the installation guide describes. The panel weighs 86 kg (190 lb) and measures 79 inches wide, 48 1/8 inches high and 4 7/8 inches deep, so the wall or stand must be rated for that load. It has a VESA M8 mount of 600 × 400 mm, two handles and a WM-SBID-200 wall mount in the box. Typical power draw is 161 W with 0.4 W standby, and the supply accepts 100 to 240 V AC at 50 to 60 Hz.

Where it fits in Qatar and how to order

Three situations suit this size and connection set. A boardroom in Lusail or West Bay can share one panel between a laptop, a room PC and a camera for calls with teams abroad. A lecture hall at Education City can use the 86-inch screen and touch tools for annotated lessons. A hotel conference room in Doha can keep the panel wall-mounted between events, with front-panel ports for quick connections. SmartRooms Qatar offers free site surveys, which we recommend before wall mounting an 86-inch panel. Send the room size, mounting plan and quantity to receive a quotation, usually within one working day. Orders can be placed by LPO or through government tenders, including Monaqasat, with payment by bank transfer, cheque or purchase order. Delivery reaches all eight municipalities of Qatar. Request a quote for the SMART Board 6086S-V3 Pro today.

Highlights

86-inch 4K UHD LED display at 3840 × 2160 resolution
HyPr Touch with InGlass, ±1 mm accuracy, up to 40 touch points
60 W OPS slot for an optional PC computing module
Two RJ45 ports plus HDMI 2.1 inputs front and back
Operating range 5–35°C, 86 kg, VESA M8 600 × 400 mm
Includes two pens, two erasers and a WM-SBID-200 wall mount

Classroom fit

At 86″ the farthest student should sit within about 6.4 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

115 specifications · Source: manufacturer · checked Oct 2026

Display15

Screen sizes (diagonal): 65", 75", 86"
Backlight: LED
Aspect ratio: 16:9
Maximum display resolution: 4K UHD (3840 × 2160)
Refresh rate: 60 Hz
Lifespan: ≥ 50,000 hours
Brightness (maximum): ≥ 350 cd/m²
Response time: 65": ≤ 9 ms; 75": ≤ 8 ms; 86": ≤ 8 ms
Viewing angle: 178°
Glass: Fully heat-tempered anti-glare glass that resists smudges and fingerprints
Frame color: White or black
Convenience buttons: Power, home, volume, screen shade, freeze frame
Sensors: Proximity, ambient light, infrared, room temperature, humidity
Audio: 2 integrated 20 W speakers; Integrated linear four-microphone array
NFC: Integrated RFID NFC reader/writer

Interactive experience10

Touch technology: HyPr Touch with InGlass
Touch features: Tool Explorer; Simultaneous Tool Differentiation; Object Awareness; Pen ID; Silktouch; Pressure Sensitive Ink
Typical response time: 9 ms
Frame rate: 150 Hz
Accuracy: ±1 mm
Minimum object size: 2 mm
Multitouch capabilities: Up to 40 touch points (OS dependent)
Tools included: Pens (×2); Erasers (×2)
Tool holders: Intelligent, magnetic, frame‑mounted
Optional tools: Multicolor four-pen bundle; Magic pen; Highlighter pen; Stamps and cubes

Software5

iQ built-in Android experience: Included
SMART Notebook: Included
SMART Ink and SMART Product Drivers: Included
SMART Remote Management: Subscription for length of the included warranty
SMART Learning Suite: Optional

iQ built-in Android experience6

Operating system: Android version 11
Memory: 6 GB DDR
Storage: 32 GB
Other features: Personalized home screen and settings; Live input preview; Interactive widgets; Templates, graphic organizers, and manipulatives; File and app libraries; Google Drive and OneDrive access
Languages supported: Basque, Catalan/Valencian, Chinese (simplified), Chinese (traditional), Czech, Danish, Dutch, English, Estonian, Finnish, French, Galician, German, Greek, Hungarian, Italian, Japanese, Korean, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Romanian, Russian, Slovak, Slovenian, Spanish, Swedish, Ukrainian, Vietnamese, Welsh
Updates: Automatic over‑the‑air (OTA)

PC computing3

OPS support: SMART PCM modules
PC module power supported OPS: 60 W
Optional computing modules: See smarttech.com/accessories

Inputs12

OPS PC accessory slot (60 W devices): Front: –; Back: 1
HDMI 2.1 with HDCP 1.4 and HDCP 2.3 support: Front: 1; Back: 2
VGA video: Front: –; Back: 1
Stereo 3.5 mm: Front: –; Back: 1
RS-232: Front: –; Back: 1
RJ45: Front: –; Back: 2
USB Type-C 4K @ 60Hz, Display Port 1.2, USB 2.0 (UFP) for touch and digital audio, USB 2.0 (DFP) for peripherals; 65 W power delivery: Front: 1; Back: –
USB Type-C, 4K @ 60Hz, Display Port 1.2, USB 2.0 (UFP) for touch and digital audio, USB 3.2 Gen 1 (DFP) for peripherals; 65W power delivery: Front: –; Back: 1
USB 2.0 Type-A: Front: –; Back: 1
USB 3.0 Type-A: Front: 1; Back: 2
USB 3.0 Type-B: Front: –; Back: 3
USB 2.0 Type-B: Front: 1; Back: –

Outputs3

HDMI 2.1: Front: –; Back: 1
Stereo 3.5 mm: Front: –; Back: 1
S/PDIF: Front: –; Back: 1

Included cables and accessories11

Country-specific power cable: 1
USB cable: 1
Pens (red and black): 2
Erasers: 2
External dual-band 2.4 and 5 GHz antennae: 3
Remote control: 1
AAA batteries: 2
WM-SBID-200 wall mount: 1
SMART ID card (for NFC sign in): 2
Illustrated installation instructions: 1
Important information document: 1

Connectivity3

Wired: RJ45 (×2) 1000baseT
Wi-Fi: IEEE 802.11 a/b/g/n/ac with 2 × 2 MIMO (both 2.4 and 5 GHz bands) supporting WEP, WPA, WPA2 PSK, and 802.1X EAP authentication protocols
Bluetooth: 5.0 dual mode

Storage and operating requirements4

Power requirements: 100V to 240V AC, 50 Hz to 60 Hz
Operating temperature: 41–95°F ( 5–35°C )
Storage temperature: -4–140°F ( -20–60°C )
Humidity: 5–80% relative humidity, non‑condensing

Power consumption2

Typical: 65": 105 W; 75": 134 W; 86": 161 W
Standby: 0.4 W

Certification and compliance6

Notes: Product availability may vary by region. This product has received additional certifications not listed here.
Regulatory models: IDS665-3, IDS675-3, and IDS686-3
US / Canada: UL, FCC, ISED, TSCA, CONEG Packaging, Proposition 65
EU / EEA / EFTA / UK: CE, UKCA, LVD, CB, EMCD, RED, REACH, RoHS, Battery, WEEE, Packaging, POP, Ecodesign
Australia / New Zealand: RCM
Performance standards: ENERGY STAR, HDMI

Purchasing information – Order numbers13

SBID-6265S-V3: SMART Board 6065S-V3 interactive display with iQ
SBID-6275S-V3: SMART Board 6075S-V3 interactive display with iQ
SBID-6286S-V3: SMART Board 6086S-V3 interactive display with iQ
SBID-6265S-V3-B: SMART Board 6065S-V3 interactive display with iQ – Black
SBID-6275S-V3-B: SMART Board 6075S-V3 interactive display with iQ – Black
SBID-6286S-V3-B: SMART Board 6086S-V3 interactive display with iQ – Black
TS-4PEN-MC: Tool Explorer multicolor 4-pen bundle (orange, purple, green, blue) with magnetic penwell
TS-4CUBE-LEARN: Tool Explorer Learn 4-Cube Bundle
TS-4CUBE-MATH: Tool Explorer Math 4-Cube Bundle
TS-4STAMP-PLAY: Tool Explorer Play 4-Stamp Bundle
TS-PEN-HLITE: Tool Explorer double-ended Highlighter (yellow & green)
TS-PEN-MAGIC: Tool Explorer Magic Pen
SBID-ID-10: Identification cards for SMART Board 6000S - Qty 10

Purchasing information – Optional accessories1

Optional accessories: See smarttech.com/accessories

Warranty1

SMART Assure warranty: Includes advanced hardware replacement and access to onsite support. Terms and conditions vary by region. Contact your local reseller or distributor for information and visit smarttech.com/warranty .

Cable requirements5

HDMI: Certified premium high speed HDMI (18 Gbps); Maximum length: 23' ( 7 m )
USB 2.0: USB 2.0 certified; Hi-Speed (480 Mbps) support; Maximum length: 16' ( 5 m )
USB 3.0: USB 3.0 certified; SuperSpeed (5 Gbps) support; Maximum length: 9' ( 3 m )
USB Type-C: USB 3.2 Gen 1 certified; SuperSpeed (5 Gbps) support; Maximum length: 6' ( 2 m )
More information: See Using recommended cables

Installation, dimensions, and weights1

Notes: All dimensions ± 1/8" ( 0.3 cm ) . All weights ± 2 lb. ( 0.9 kg ) . Product ships upright. Leave space around the display to ensure adequate ventilation. See the SMART Board 6000S and 6000S Pro installation and maintenance guide ( smarttech.com/kb/171414 ) for the specific space requirements.

Installation, dimensions, and weights – SBID-6265S-V3/SBID-6265S-V3-B4

Dimensions: Screen (diagonal): 65"; Width: 60 1/4" (153.2 cm); Height: 37 5/8" (95.5 cm); Depth: 4 7/8" (12.4 cm)
Weight: 112 lb. ( 51 kg )
VESA mount: M8, 600 × 400 mm
Handles: 2

Installation, dimensions, and weights – SBID-6275S-V3/SBID-6275S-V3-B4

Dimensions: Screen (diagonal): 75"; Width: 69 1/4" (175.8 cm); Height: 42 5/8" (108.2 cm); Depth: 4 7/8" (12.4 cm)
Weight: 143 lb. ( 65 kg )
VESA mount: M8, 600 × 400 mm
Handles: 2

Installation, dimensions, and weights – SBID-6286S-V3/SBID-6286S-V3-B4

Dimensions: Screen (diagonal): 86"; Width: 79" (200.5 cm); Height: 48 1/8" (122.1 cm); Depth: 4 7/8" (12.4 cm)
Weight: 190 lb. ( 86 kg )
VESA mount: M8, 600 × 400 mm
Handles: 2

SBID-6086S-V3-PW2

description: SMART Board 6086S-V3 Pro interactive display - White
spec_page: SMART Board 6000S (V3) Pro series specifications

Downloads

0 files from the manufacturer

No downloadable files are listed for this model yet. Ask us and we will send the datasheet.

Questions about SBID-6086S-V3-PW

Is the SBID-6086S-V3-PW suited to a boardroom or a classroom?

It suits a boardroom, executive meeting room or large training room where an 86-inch panel is the focal point. A room this size needs a wall or stand rated for 86 kg (190 lb), so plan the layout first. For a smaller classroom, a 65-inch or 75-inch model in the same range may fit better. SmartRooms Qatar can confirm the right size from your room plan.

Does this model include the built-in iQ Android system?

No. This Pro white model does not include the built-in iQ Android experience, which is listed only on the iQ variants of the 6000S (V3) range. Content comes from the inputs on the front and back, so a laptop, a PC module or another source provides it. If you want Android on the panel itself, ask SmartRooms Qatar to confirm the iQ version before ordering.

Can I run a PC on this display without a separate computer?

Not on its own. The back has a 60 W OPS slot that accepts SMART PCM computing modules, which are optional accessories and not included in the box. Once a module is installed, the display can run as a computer for lessons or meetings. Check the module's specifications against your software before ordering, and ask the SmartRooms Qatar team to confirm compatibility.

Does this model have built-in Wi-Fi?

The source data lists wired connectivity only: two RJ45 ports supporting 1000baseT networking. No Wi-Fi or Bluetooth is listed for this Pro white model. For a meeting room in Doha, run a network cable to one of the RJ45 ports so the display reaches the office network. Plan that cable route during the site survey so the port sits near the wall mount.

How hot can the room be for this display to run safely?

The listed operating range is 5 to 35°C (41 to 95°F), with 5 to 80% relative humidity that does not condense. Summer temperatures in Qatar can pass 45°C, so the display belongs in an air-conditioned room, not an open lobby or a space with afternoon sun through glass. A training centre in the Industrial Area or Mesaieed should check room cooling capacity before installation. The storage range is -20 to 60°C.

How do we mount an 86-inch panel that weighs 86 kg?

The panel ships with a WM-SBID-200 wall mount and has a VESA M8 pattern of 600 × 400 mm. Have the wall or stand checked for the 86 kg (190 lb) load before the day of installation. The panel has two handles, but it should be lifted by more than one person. SmartRooms Qatar offers free site surveys to check wall structure, cable routes and clearance.

What connections do we need for a hybrid meeting in West Bay?

A laptop can connect through the front HDMI 2.1 input or the front USB Type-C port, which carries 4K at 60 Hz with DisplayPort 1.2 and up to 65 W power delivery. A camera or PC on the back can use USB Type-A or Type-B ports, and wired network access runs through the RJ45 ports. Certified HDMI cables are rated up to 7 m and USB Type-C cables up to 2 m, so plan cable routes to the table position.

How many pens come with it, and how many people can write at once?

Two pens and two erasers are included, with the pens in red and black. The panel supports up to 40 touch points, depending on the operating system, so several people can annotate at the same time. For a hotel conference room in Doha that runs colour-coded sessions, the multicolour four-pen bundle (TS-4PEN-MC) is available as an option. Accuracy is ±1 mm and the minimum object size is 2 mm.

Can a school in Al Rayyan order several units through an LPO?

Yes. SmartRooms Qatar supplies against purchase orders (LPOs), and government tenders, including Monaqasat, are also accepted. Payment can be made by bank transfer, cheque or purchase order. Each panel weighs 86 kg, so request a site survey and an installation plan for every classroom before the order is confirmed. Quotations are usually issued within one working day.

What warranty covers this display?

The display is covered by the manufacturer's SMART Assure warranty, which includes advanced hardware replacement and access to onsite support. The source notes that terms and conditions vary by region, so confirm the coverage period and details for a Qatar purchase in writing with your quotation. SMART Remote Management is not listed for this Pro model.
