SMART Interactive Flat Panels Current

SBID-6275S-V3

SMART Board 6075S-V3 75-inch Interactive Display with iQ

Screen size: 65"
Resolution: 4K UHD (3840 × 2160)
Touch: HyPr Touch with InGlass
System: Included

Priceon request

QuotationWithin 1 working day

DeliveryConfirmed with your quote, based on stock

Overview

The SMART Board 6075S-V3 is a 75-inch 4K UHD interactive display with built-in iQ running Android 11, HyPr Touch with InGlass and up to 40 touch points. It suits classrooms, meeting rooms and training areas in Doha and beyond that need one large touch screen without a separate PC. Two 20 W speakers and a four-microphone array support lessons and discussions. Request a quote from SmartRooms Qatar for supply, delivery and installation.

What the SMART Board 6075S-V3 with iQ is

The SMART Board 6075S-V3 is a 75-inch interactive display with a 4K UHD panel and iQ, the built-in Android 11 experience. It pairs a large touch surface with its own computing environment, so teams can open lesson material, web applications and shared files without connecting a separate PC. This is the standard 75-inch edition in the 6000S (V3) range with iQ, and it differs from the Pro edition mainly in the software bundled with it.

Panel and touch performance that matter in daily use

The 3840 × 2160 resolution gives fine detail on a 75-inch screen. The fully heat-tempered, anti-glare glass reduces reflections and resists smudges and fingerprints. Rated brightness is at least 350 cd/m², which helps in classrooms and boardrooms with overhead lighting. Touch uses HyPr Touch with InGlass, with ±1 mm accuracy, a 2 mm minimum object size and up to 40 touch points on supported operating systems. Pen ID, Object Awareness and Pressure Sensitive Ink add writing features that teachers and presenters use every day.

Where it fits in Qatar

Classrooms in a private school in Al Sadd or Al Rayyan: a teacher writes, annotates and plays media from the front of the room, while the built-in speakers and four-microphone array support class discussion.
A training centre in Lusail: one screen runs group exercises with up to 40 touch points and saves annotated notes through SMART Notebook.
A boardroom in West Bay or Msheireb: a 75-inch panel lets a team review documents shared with colleagues abroad, connecting a laptop through HDMI or USB-C.

Planning the connections and installation

The rear panel carries two HDMI 2.1 inputs, a VGA input, a 3.5 mm stereo input, an RS-232 port, two RJ45 network ports and a 60 W OPS slot for optional SMART PCM computing modules. The front has one HDMI 2.1 input, one USB-C input with 65 W power delivery and DisplayPort 1.2, and USB 3.0 and USB 2.0 ports for touch and peripherals. The unit measures 69 1/4 by 42 5/8 inches (175.8 by 108.2 cm), is 4 7/8 inches (12.4 cm) deep and weighs 143 lb (65 kg). It uses an M8 VESA pattern of 600 × 400 mm. Because of its weight, a wall mount needs a structural check, so booking a free site survey before installation day is wise.

Operating conditions and ordering

The operating range is 5 to 35°C with 5 to 80% non-condensing humidity. In Qatar, where summer temperatures often exceed 45°C, the display should sit in an air-conditioned room away from direct sun through glass, with the ventilation clearance its installation guide specifies. The power input of 100V to 240V AC, 50 to 60 Hz covers Qatar's supply, and a country-specific power cable is included. The box contains two pens, two erasers, a remote, three dual-band antennae and a WM-SBID-200 wall mount. SmartRooms Qatar supplies this model across all eight municipalities of Qatar with professional installation, and quotations are usually issued within one working day. Request a quote and we will confirm the accessories, mounting plan and installation details for your building.

Highlights

75-inch 4K UHD panel at 3840 × 2160 in a 16:9 aspect ratio
HyPr Touch with InGlass, up to 40 touch points, ±1 mm accuracy
Built-in iQ with Android 11, 6 GB DDR memory and 32 GB storage
Two integrated 20 W speakers and a four-microphone array
Two HDMI 2.1 inputs at the back, one at the front, and a 60 W OPS slot
Operating range 5–35°C; power input 100V to 240V AC, 50–60 Hz

Classroom fit

At 75″ the farthest student should sit within about 5.6 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

115 specifications · Source: manufacturer · checked Oct 2026

Display15

Screen sizes (diagonal): 65", 75", 86"
Backlight: LED
Aspect ratio: 16:9
Maximum display resolution: 4K UHD (3840 × 2160)
Refresh rate: 60 Hz
Lifespan: ≥ 50,000 hours
Brightness (maximum): ≥ 350 cd/m²
Response time: 65": ≤ 9 ms; 75": ≤ 8 ms; 86": ≤ 8 ms
Viewing angle: 178°
Glass: Fully heat-tempered anti-glare glass that resists smudges and fingerprints
Frame color: White or black
Convenience buttons: Power, home, volume, screen shade, freeze frame
Sensors: Proximity, ambient light, infrared, room temperature, humidity
Audio: 2 integrated 20 W speakers; Integrated linear four-microphone array
NFC: Integrated RFID NFC reader/writer

Interactive experience10

Touch technology: HyPr Touch with InGlass
Touch features: Tool Explorer; Simultaneous Tool Differentiation; Object Awareness; Pen ID; Silktouch; Pressure Sensitive Ink
Typical response time: 9 ms
Frame rate: 150 Hz
Accuracy: ±1 mm
Minimum object size: 2 mm
Multitouch capabilities: Up to 40 touch points (OS dependent)
Tools included: Pens (×2); Erasers (×2)
Tool holders: Intelligent, magnetic, frame‑mounted
Optional tools: Multicolor four-pen bundle; Magic pen; Highlighter pen; Stamps and cubes

Software5

iQ built-in Android experience: Included
SMART Notebook: Included
SMART Ink and SMART Product Drivers: Included
SMART Remote Management: Subscription for length of the included warranty
SMART Learning Suite: Optional

iQ built-in Android experience6

Operating system: Android version 11
Memory: 6 GB DDR
Storage: 32 GB
Other features: Personalized home screen and settings; Live input preview; Interactive widgets; Templates, graphic organizers, and manipulatives; File and app libraries; Google Drive and OneDrive access
Languages supported: Basque, Catalan/Valencian, Chinese (simplified), Chinese (traditional), Czech, Danish, Dutch, English, Estonian, Finnish, French, Galician, German, Greek, Hungarian, Italian, Japanese, Korean, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Romanian, Russian, Slovak, Slovenian, Spanish, Swedish, Ukrainian, Vietnamese, Welsh
Updates: Automatic over‑the‑air (OTA)

PC computing3

OPS support: SMART PCM modules
PC module power supported OPS: 60 W
Optional computing modules: See smarttech.com/accessories

Inputs12

OPS PC accessory slot (60 W devices): Front: –; Back: 1
HDMI 2.1 with HDCP 1.4 and HDCP 2.3 support: Front: 1; Back: 2
VGA video: Front: –; Back: 1
Stereo 3.5 mm: Front: –; Back: 1
RS-232: Front: –; Back: 1
RJ45: Front: –; Back: 2
USB Type-C 4K @ 60Hz, Display Port 1.2, USB 2.0 (UFP) for touch and digital audio, USB 2.0 (DFP) for peripherals; 65 W power delivery: Front: 1; Back: –
USB Type-C, 4K @ 60Hz, Display Port 1.2, USB 2.0 (UFP) for touch and digital audio, USB 3.2 Gen 1 (DFP) for peripherals; 65W power delivery: Front: –; Back: 1
USB 2.0 Type-A: Front: –; Back: 1
USB 3.0 Type-A: Front: 1; Back: 2
USB 3.0 Type-B: Front: –; Back: 3
USB 2.0 Type-B: Front: 1; Back: –

Outputs3

HDMI 2.1: Front: –; Back: 1
Stereo 3.5 mm: Front: –; Back: 1
S/PDIF: Front: –; Back: 1

Included cables and accessories11

Country-specific power cable: 1
USB cable: 1
Pens (red and black): 2
Erasers: 2
External dual-band 2.4 and 5 GHz antennae: 3
Remote control: 1
AAA batteries: 2
WM-SBID-200 wall mount: 1
SMART ID card (for NFC sign in): 2
Illustrated installation instructions: 1
Important information document: 1

Connectivity3

Wired: RJ45 (×2) 1000baseT
Wi-Fi: IEEE 802.11 a/b/g/n/ac with 2 × 2 MIMO (both 2.4 and 5 GHz bands) supporting WEP, WPA, WPA2 PSK, and 802.1X EAP authentication protocols
Bluetooth: 5.0 dual mode

Storage and operating requirements4

Power requirements: 100V to 240V AC, 50 Hz to 60 Hz
Operating temperature: 41–95°F ( 5–35°C )
Storage temperature: -4–140°F ( -20–60°C )
Humidity: 5–80% relative humidity, non‑condensing

Power consumption2

Typical: 65": 105 W; 75": 134 W; 86": 161 W
Standby: 0.4 W

Certification and compliance6

Notes: Product availability may vary by region. This product has received additional certifications not listed here.
Regulatory models: IDS665-3, IDS675-3, and IDS686-3
US / Canada: UL, FCC, ISED, TSCA, CONEG Packaging, Proposition 65
EU / EEA / EFTA / UK: CE, UKCA, LVD, CB, EMCD, RED, REACH, RoHS, Battery, WEEE, Packaging, POP, Ecodesign
Australia / New Zealand: RCM
Performance standards: ENERGY STAR, HDMI

Purchasing information – Order numbers13

SBID-6265S-V3: SMART Board 6065S-V3 interactive display with iQ
SBID-6275S-V3: SMART Board 6075S-V3 interactive display with iQ
SBID-6286S-V3: SMART Board 6086S-V3 interactive display with iQ
SBID-6265S-V3-B: SMART Board 6065S-V3 interactive display with iQ – Black
SBID-6275S-V3-B: SMART Board 6075S-V3 interactive display with iQ – Black
SBID-6286S-V3-B: SMART Board 6086S-V3 interactive display with iQ – Black
TS-4PEN-MC: Tool Explorer multicolor 4-pen bundle (orange, purple, green, blue) with magnetic penwell
TS-4CUBE-LEARN: Tool Explorer Learn 4-Cube Bundle
TS-4CUBE-MATH: Tool Explorer Math 4-Cube Bundle
TS-4STAMP-PLAY: Tool Explorer Play 4-Stamp Bundle
TS-PEN-HLITE: Tool Explorer double-ended Highlighter (yellow & green)
TS-PEN-MAGIC: Tool Explorer Magic Pen
SBID-ID-10: Identification cards for SMART Board 6000S - Qty 10

Purchasing information – Optional accessories1

Optional accessories: See smarttech.com/accessories

Warranty1

SMART Assure warranty: Includes advanced hardware replacement and access to onsite support. Terms and conditions vary by region. Contact your local reseller or distributor for information and visit smarttech.com/warranty .

Cable requirements5

HDMI: Certified premium high speed HDMI (18 Gbps); Maximum length: 23' ( 7 m )
USB 2.0: USB 2.0 certified; Hi-Speed (480 Mbps) support; Maximum length: 16' ( 5 m )
USB 3.0: USB 3.0 certified; SuperSpeed (5 Gbps) support; Maximum length: 9' ( 3 m )
USB Type-C: USB 3.2 Gen 1 certified; SuperSpeed (5 Gbps) support; Maximum length: 6' ( 2 m )
More information: See Using recommended cables

Installation, dimensions, and weights1

Notes: All dimensions ± 1/8" ( 0.3 cm ) . All weights ± 2 lb. ( 0.9 kg ) . Product ships upright. Leave space around the display to ensure adequate ventilation. See the SMART Board 6000S and 6000S Pro installation and maintenance guide ( smarttech.com/kb/171414 ) for the specific space requirements.

Installation, dimensions, and weights – SBID-6265S-V3/SBID-6265S-V3-B4

Dimensions: Screen (diagonal): 65"; Width: 60 1/4" (153.2 cm); Height: 37 5/8" (95.5 cm); Depth: 4 7/8" (12.4 cm)
Weight: 112 lb. ( 51 kg )
VESA mount: M8, 600 × 400 mm
Handles: 2

Installation, dimensions, and weights – SBID-6275S-V3/SBID-6275S-V3-B4

Dimensions: Screen (diagonal): 75"; Width: 69 1/4" (175.8 cm); Height: 42 5/8" (108.2 cm); Depth: 4 7/8" (12.4 cm)
Weight: 143 lb. ( 65 kg )
VESA mount: M8, 600 × 400 mm
Handles: 2

Installation, dimensions, and weights – SBID-6286S-V3/SBID-6286S-V3-B4

Dimensions: Screen (diagonal): 86"; Width: 79" (200.5 cm); Height: 48 1/8" (122.1 cm); Depth: 4 7/8" (12.4 cm)
Weight: 190 lb. ( 86 kg )
VESA mount: M8, 600 × 400 mm
Handles: 2

SBID-6275S-V32

description: SMART Board 6075S-V3 interactive display with iQ
spec_page: SMART Board 6000S (V3) series with iQ specifications

Downloads

0 files from the manufacturer

No downloadable files are listed for this model yet. Ask us and we will send the datasheet.

Questions about SBID-6275S-V3

Who is the SMART Board 6075S-V3 best suited for in Qatar?

It suits a medium to large classroom, training room or meeting room where people need to write and annotate directly on a 75-inch screen. A private school in Al Sadd could use it for interactive lessons, while a boardroom in West Bay could use it for presentations and shared documents. Up to 40 touch points let several people work at once. Choose it when an 86-inch panel is more than the room needs and a 65-inch panel feels too small for the group.

How does the standard 75-inch model differ from the 75-inch Pro edition?

The standard SBID-6275S-V3 includes iQ, SMART Notebook, SMART Ink and product drivers, and a SMART Remote Management subscription that runs for the length of the included warranty. The Pro edition, order number SBID-6275S-V3-P, instead lists SMART Meeting Pro room and personal licences. Both use the same 75-inch 4K panel and the same physical dimensions, so the decision depends on which software your teams plan to use.

What resolution and brightness does the panel offer?

The panel is 4K UHD at 3840 × 2160 with a 16:9 aspect ratio. The LED backlight has a maximum brightness of at least 350 cd/m², and the viewing angle is 178°. The 75-inch model has a response time of 8 ms or less, a refresh rate of 60 Hz and a rated lifespan of at least 50,000 hours. The anti-glare glass helps in rooms with overhead lights or windows.

Can the display be installed in a hot room or lobby in summer?

The operating temperature range is 5 to 35°C, with humidity of 5 to 80% non-condensing. Summer temperatures in Qatar often exceed 45°C, so the display should be installed in an air-conditioned room and kept out of direct sun through glass. Unconditioned lobbies, outdoor canopies and sun-facing rooms are not suitable. Confirm the environment with the SmartRooms Qatar team before installation, and leave the ventilation clearance described in the installation guide.

Will the 75-inch display work with Qatar's electrical supply?

The source data lists a power input of 100V to 240V AC at 50 to 60 Hz, which covers Qatar's 240 V, 50 Hz supply. Typical power consumption is 134 W, and standby draw is 0.4 W. A country-specific power cable is included with the unit. Before ordering, we will confirm the cable and plug arrangement suits the sockets in your building as part of the quotation.

Which computers and laptops can connect to it?

Any laptop or PC with HDMI or USB-C video output can connect. The rear has two HDMI 2.1 inputs and a VGA input, and the front has one HDMI 2.1 input and one USB-C input with 65 W power delivery and DisplayPort 1.2 that supports 4K at 60 Hz. A 60 W OPS slot at the back accepts optional SMART PCM computing modules, which are sold separately. A teacher can plug in a laptop at the front without reaching the back of the unit.

What network and wireless options does it offer?

Wi-Fi supports IEEE 802.11 a/b/g/n/ac with 2 × 2 MIMO on both 2.4 and 5 GHz bands, and it supports WEP, WPA, WPA2 PSK and 802.1X EAP authentication. Two RJ45 ports handle wired 1000baseT connections, and Bluetooth 5.0 dual mode is included. Three external dual-band antennae are supplied. IT teams configuring 802.1X on a school or government network should share their authentication settings before the unit arrives.

What does the built-in iQ Android system provide?

iQ runs Android version 11 with 6 GB DDR memory and 32 GB of storage. Users get a personalised home screen, live input preview, interactive widgets, templates, file and app libraries, and access to Google Drive and OneDrive. Updates arrive automatically over the air. The manufacturer's language list is long, but it does not include Arabic, so confirm the interface languages your staff need before ordering.

Is this model suitable for a school ordering several classroom units?

Yes. A school in Al Rayyan fitting out six classrooms could raise a single purchase order (LPO) covering all the displays, and SmartRooms Qatar accepts LPOs, government tenders and payment by bank transfer, cheque or purchase order. Each unit includes two pens, two erasers, a remote, three antennae and a WM-SBID-200 wall mount. The multicolour four-pen bundle, magic pen and ID cards for NFC sign-in are optional extras.

How heavy is the unit, and what does wall mounting require?

The unit weighs 143 lb (65 kg) and measures 69 1/4 inches (175.8 cm) wide, 42 5/8 inches (108.2 cm) high and 4 7/8 inches (12.4 cm) deep. It uses an M8 VESA pattern of 600 × 400 mm and has two handles for lifting. A WM-SBID-200 wall mount is included. Because the weight is substantial, a free site survey should check the wall structure before fixing the bracket in a classroom or boardroom.

What warranty applies to this display?

The manufacturer's SMART Assure warranty includes advanced hardware replacement and access to onsite support. Its terms vary by region, so SmartRooms Qatar will confirm the warranty details that apply to a unit supplied in Qatar within the quotation. The included SMART Remote Management subscription runs for the length of the included warranty. Ask us to set out the warranty terms in writing when you request the quote.

Should a boardroom choose the 75-inch or the 86-inch model?

The 75-inch unit measures 69 1/4 inches (175.8 cm) wide, while the 86-inch unit measures 79 inches (200.5 cm) wide and weighs 190 lb (86 kg). A 75-inch screen suits a boardroom for about ten to twelve people in a Msheireb or West Bay office with moderate wall space. Check the wall and the viewing distance during the site survey, then request a quote for the model that fits the room.
