SMART Interactive Flat Panels Current

SBID-6286S-V3-PW

SMART Board 6086S-V3 Pro 86-inch Interactive Display with iQ - White

Screen size: 65"
Resolution: 4K UHD (3840 × 2160)
Touch: HyPr Touch with InGlass
System: Included

Priceon request

QuotationWithin 1 working day

DeliveryConfirmed with your quote, based on stock

Overview

The SMART Board 6086S-V3 Pro with iQ is an 86-inch 4K UHD interactive display with a white frame and built-in Android 11. It supports up to 40 touch points at a 150 Hz frame rate, includes two 20 W speakers and a four-microphone array, and offers at least 350 cd/m² brightness. It suits boardrooms, lecture halls and training rooms in Qatar that need a large, self-contained display. Request a quote from SmartRooms Qatar.

An 86-inch white-frame Pro display with built-in iQ

The SBID-6286S-V3-PW is the 86-inch model in the SMART Board 6000S (V3) Pro series with iQ, finished in a white frame. The 4K UHD panel (3840 × 2160) uses a 16:9 aspect ratio, an LED backlight, a 60 Hz refresh rate and a maximum brightness of at least 350 cd/m². Its anti-glare front reduces reflections and resists fingerprints, which keeps shared content readable during long sessions.

Touch and pen features for teaching and planning sessions

HyPr Touch with InGlass gives this panel a 150 Hz frame rate, ±1 mm accuracy and a 2 mm minimum object size, with up to 40 touch points on supported operating systems. Two pens and two erasers are included, and intelligent magnetic tool holders sit along the frame. Pen ID, object awareness and pressure-sensitive ink let a presenter write, erase and move content quickly. A multicolor four-pen bundle (order code TS-4PEN-MC) is available as an option.

iQ and the Pro licence bundle

The built-in iQ system runs Android 11 with 6 GB DDR memory and 32 GB storage, and it receives automatic over-the-air updates. The Pro edition includes a SMART Meeting Pro room licence and ten personal licences, along with SMART Ink and the SMART product drivers. Remote management is a subscription that runs for the length of the included warranty. The manufacturer's list of iQ interface languages does not include Arabic, so confirm language needs for your staff before ordering.

Ports and computing for a Qatar meeting room

The front edge has one HDMI 2.1 input, one USB-C port (4K at 60 Hz, DisplayPort 1.2, 65 W power delivery), a USB 3.0 Type-A port and a USB 2.0 Type-B touch connection. The rear adds two more HDMI 2.1 inputs, an HDMI 2.1 output, a second 65 W USB-C port, two RJ45 ports, VGA, RS-232, stereo 3.5 mm input and output, S/PDIF output and three USB 3.0 Type-B ports. One rear OPS slot supports 60 W SMART PCM computing modules, which are optional. Wireless uses 802.11 a/b/g/n/ac with 2 × 2 MIMO on 2.4 and 5 GHz, plus Bluetooth 5.0 dual mode.

Where an 86-inch Pro panel fits in Qatar

Boardroom in West Bay: a leadership team in a tower room joins colleagues abroad over video, with the screen showing shared documents and the integrated four-microphone array picking up speakers at a long table.
Lecture hall at Education City: an 86-inch screen gives a clear view across a mid-sized lecture room, and two pens let the lecturer annotate slides during class.
Training room in the Industrial Area: a safety or operations trainer uses the 4K panel for drawings and procedures, with a SMART PCM module running the training PC if one is fitted.

Planning the installation: weight, space and power

The panel weighs 190 lb (86 kg) and measures 79 inches (200.5 cm) wide, 48 1/8 inches (122.1 cm) high and 4 7/8 inches (12.4 cm) deep. The wall must carry that load, and the mounting point should match VESA M8, 600 × 400 mm. A WM-SBID-200 wall mount is included, and the panel ships upright with two handles. Leave space around the display for ventilation, and keep it in an air-conditioned room away from direct sunlight through windows, because the operating range is 5 to 35°C (41 to 95°F) at 5 to 80% non-condensing humidity. Typical draw at this size is 161 W, with 0.4 W standby, on 100 to 240 V AC at 50 to 60 Hz. SmartRooms Qatar offers a free site survey to check the wall, access and cable routes before mounting.

Request a quote for the SBID-6286S-V3-PW and SmartRooms Qatar will confirm the mount, cables and power cable for your site within the quotation. We accept purchase orders (LPOs) as well as bank transfer and cheque payments.

Highlights

86-inch 4K UHD panel at 3840 × 2160 resolution
HyPr Touch with InGlass supports up to 40 touch points
Built-in iQ with Android 11, 6 GB memory, 32 GB storage
Pro edition includes SMART Meeting Pro room licence
Rear OPS slot for 60 W SMART PCM computing modules
Operating range 5–35°C; 100–240 V AC, 50–60 Hz

Classroom fit

At 86″ the farthest student should sit within about 6.4 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

115 specifications · Source: manufacturer · checked Oct 2026

Display15

Screen sizes (diagonal): 65", 75", 86"
Backlight: LED
Aspect ratio: 16:9
Maximum display resolution: 4K UHD (3840 × 2160)
Refresh rate: 60 Hz
Lifespan: ≥ 50,000 hours
Brightness (maximum): ≥ 350 cd/m²
Response time: 65": ≤ 9 ms; 75": ≤ 8 ms; 86": ≤ 8 ms
Viewing angle: 178°
Glass: Fully heat-tempered anti-glare glass that resists smudges and fingerprints
Frame color: White or black
Convenience buttons: Power, home, volume, screen shade, freeze frame
Sensors: Proximity, ambient light, infrared, room temperature, humidity
Audio: 2 integrated 20 W speakers; Integrated linear four-microphone array
NFC: Integrated RFID NFC reader/writer

Interactive experience10

Touch technology: HyPr Touch with InGlass
Touch features: Tool Explorer; Simultaneous Tool Differentiation; Object Awareness; Pen ID; Silktouch; Pressure Sensitive Ink
Typical response time: 9 ms
Frame rate: 150 Hz
Accuracy: ±1 mm
Minimum object size: 2 mm
Multitouch capabilities: Up to 40 touch points (OS dependent)
Tools included: Pens (×2); Erasers (×2)
Tool holders: Intelligent, magnetic, frame‑mounted
Optional tools: Multicolor four-pen bundle; Magic pen; Highlighter pen; Stamps and cubes

Software5

iQ built-in Android experience: Included
SMART Notebook: Included
SMART Ink and SMART Product Drivers: Included
SMART Remote Management: Subscription for length of the included warranty
SMART Learning Suite: Optional

iQ built-in Android experience6

Operating system: Android version 11
Memory: 6 GB DDR
Storage: 32 GB
Other features: Personalized home screen and settings; Live input preview; Interactive widgets; Templates, graphic organizers, and manipulatives; File and app libraries; Google Drive and OneDrive access
Languages supported: Basque, Catalan/Valencian, Chinese (simplified), Chinese (traditional), Czech, Danish, Dutch, English, Estonian, Finnish, French, Galician, German, Greek, Hungarian, Italian, Japanese, Korean, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Romanian, Russian, Slovak, Slovenian, Spanish, Swedish, Ukrainian, Vietnamese, Welsh
Updates: Automatic over‑the‑air (OTA)

PC computing3

OPS support: SMART PCM modules
PC module power supported OPS: 60 W
Optional computing modules: See smarttech.com/accessories

Inputs12

OPS PC accessory slot (60 W devices): Front: –; Back: 1
HDMI 2.1 with HDCP 1.4 and HDCP 2.3 support: Front: 1; Back: 2
VGA video: Front: –; Back: 1
Stereo 3.5 mm: Front: –; Back: 1
RS-232: Front: –; Back: 1
RJ45: Front: –; Back: 2
USB Type-C 4K @ 60Hz, Display Port 1.2, USB 2.0 (UFP) for touch and digital audio, USB 2.0 (DFP) for peripherals; 65 W power delivery: Front: 1; Back: –
USB Type-C, 4K @ 60Hz, Display Port 1.2, USB 2.0 (UFP) for touch and digital audio, USB 3.2 Gen 1 (DFP) for peripherals; 65W power delivery: Front: –; Back: 1
USB 2.0 Type-A: Front: –; Back: 1
USB 3.0 Type-A: Front: 1; Back: 2
USB 3.0 Type-B: Front: –; Back: 3
USB 2.0 Type-B: Front: 1; Back: –

Outputs3

HDMI 2.1: Front: –; Back: 1
Stereo 3.5 mm: Front: –; Back: 1
S/PDIF: Front: –; Back: 1

Included cables and accessories11

Country-specific power cable: 1
USB cable: 1
Pens (red and black): 2
Erasers: 2
External dual-band 2.4 and 5 GHz antennae: 3
Remote control: 1
AAA batteries: 2
WM-SBID-200 wall mount: 1
SMART ID card (for NFC sign in): 2
Illustrated installation instructions: 1
Important information document: 1

Connectivity3

Wired: RJ45 (×2) 1000baseT
Wi-Fi: IEEE 802.11 a/b/g/n/ac with 2 × 2 MIMO (both 2.4 and 5 GHz bands) supporting WEP, WPA, WPA2 PSK, and 802.1X EAP authentication protocols
Bluetooth: 5.0 dual mode

Storage and operating requirements4

Power requirements: 100V to 240V AC, 50 Hz to 60 Hz
Operating temperature: 41–95°F ( 5–35°C )
Storage temperature: -4–140°F ( -20–60°C )
Humidity: 5–80% relative humidity, non‑condensing

Power consumption2

Typical: 65": 105 W; 75": 134 W; 86": 161 W
Standby: 0.4 W

Certification and compliance6

Notes: Product availability may vary by region. This product has received additional certifications not listed here.
Regulatory models: IDS665-3, IDS675-3, and IDS686-3
US / Canada: UL, FCC, ISED, TSCA, CONEG Packaging, Proposition 65
EU / EEA / EFTA / UK: CE, UKCA, LVD, CB, EMCD, RED, REACH, RoHS, Battery, WEEE, Packaging, POP, Ecodesign
Australia / New Zealand: RCM
Performance standards: ENERGY STAR, HDMI

Purchasing information – Order numbers13

SBID-6265S-V3: SMART Board 6065S-V3 interactive display with iQ
SBID-6275S-V3: SMART Board 6075S-V3 interactive display with iQ
SBID-6286S-V3: SMART Board 6086S-V3 interactive display with iQ
SBID-6265S-V3-B: SMART Board 6065S-V3 interactive display with iQ – Black
SBID-6275S-V3-B: SMART Board 6075S-V3 interactive display with iQ – Black
SBID-6286S-V3-B: SMART Board 6086S-V3 interactive display with iQ – Black
TS-4PEN-MC: Tool Explorer multicolor 4-pen bundle (orange, purple, green, blue) with magnetic penwell
TS-4CUBE-LEARN: Tool Explorer Learn 4-Cube Bundle
TS-4CUBE-MATH: Tool Explorer Math 4-Cube Bundle
TS-4STAMP-PLAY: Tool Explorer Play 4-Stamp Bundle
TS-PEN-HLITE: Tool Explorer double-ended Highlighter (yellow & green)
TS-PEN-MAGIC: Tool Explorer Magic Pen
SBID-ID-10: Identification cards for SMART Board 6000S - Qty 10

Purchasing information – Optional accessories1

Optional accessories: See smarttech.com/accessories

Warranty1

SMART Assure warranty: Includes advanced hardware replacement and access to onsite support. Terms and conditions vary by region. Contact your local reseller or distributor for information and visit smarttech.com/warranty .

Cable requirements5

HDMI: Certified premium high speed HDMI (18 Gbps); Maximum length: 23' ( 7 m )
USB 2.0: USB 2.0 certified; Hi-Speed (480 Mbps) support; Maximum length: 16' ( 5 m )
USB 3.0: USB 3.0 certified; SuperSpeed (5 Gbps) support; Maximum length: 9' ( 3 m )
USB Type-C: USB 3.2 Gen 1 certified; SuperSpeed (5 Gbps) support; Maximum length: 6' ( 2 m )
More information: See Using recommended cables

Installation, dimensions, and weights1

Notes: All dimensions ± 1/8" ( 0.3 cm ) . All weights ± 2 lb. ( 0.9 kg ) . Product ships upright. Leave space around the display to ensure adequate ventilation. See the SMART Board 6000S and 6000S Pro installation and maintenance guide ( smarttech.com/kb/171414 ) for the specific space requirements.

Installation, dimensions, and weights – SBID-6265S-V3/SBID-6265S-V3-B4

Dimensions: Screen (diagonal): 65"; Width: 60 1/4" (153.2 cm); Height: 37 5/8" (95.5 cm); Depth: 4 7/8" (12.4 cm)
Weight: 112 lb. ( 51 kg )
VESA mount: M8, 600 × 400 mm
Handles: 2

Installation, dimensions, and weights – SBID-6275S-V3/SBID-6275S-V3-B4

Dimensions: Screen (diagonal): 75"; Width: 69 1/4" (175.8 cm); Height: 42 5/8" (108.2 cm); Depth: 4 7/8" (12.4 cm)
Weight: 143 lb. ( 65 kg )
VESA mount: M8, 600 × 400 mm
Handles: 2

Installation, dimensions, and weights – SBID-6286S-V3/SBID-6286S-V3-B4

Dimensions: Screen (diagonal): 86"; Width: 79" (200.5 cm); Height: 48 1/8" (122.1 cm); Depth: 4 7/8" (12.4 cm)
Weight: 190 lb. ( 86 kg )
VESA mount: M8, 600 × 400 mm
Handles: 2

SBID-6286S-V3-PW2

description: SMART Board 6086S-V3 Pro interactive display with iQ - White
spec_page: SMART Board 6000S (V3) Pro series with iQ specifications

Downloads

0 files from the manufacturer

No downloadable files are listed for this model yet. Ask us and we will send the datasheet.

Questions about SBID-6286S-V3-PW

What is the SBID-6286S-V3-PW and who is it for?

The SBID-6286S-V3-PW is an 86-inch SMART Board 6086S-V3 Pro interactive display with iQ in a white frame. It suits boardrooms, lecture halls and large training rooms where presenters write, annotate and share content with a group. Because it is a self-contained unit, it can replace a separate projector and whiteboard setup in rooms short of space.

What resolution and brightness does the panel offer?

The panel is 4K UHD at 3840 × 2160 with a 16:9 aspect ratio, an LED backlight and a 60 Hz refresh rate. Maximum brightness is at least 350 cd/m², and the viewing angle is 178 degrees. The anti-glare glass reduces reflections, but seat positions and blinds still matter in rooms with windows.

How many people can write on the screen at once?

Touch uses HyPr Touch with InGlass, which supports up to 40 touch points on supported operating systems, with a 2 mm minimum object size and ±1 mm accuracy. Two pens and two erasers are included, and the frame has magnetic tool holders. A multicolor four-pen bundle (TS-4PEN-MC) is available as an option for teams that want more colours.

Which licences are included with the Pro edition?

The Pro edition includes a SMART Meeting Pro room licence and ten SMART Meeting Pro personal licences, plus SMART Ink and the SMART product drivers. Remote management is a subscription for the length of the included warranty. A school or ministry buying several units should ask SmartRooms Qatar to confirm the licence details for each panel in the quotation.

Does the iQ system support Arabic?

The manufacturer's list of iQ interface languages includes English, French, German, Spanish and many others, but it does not list Arabic. Before ordering for a school or office that works in Arabic, confirm that the language your staff need is available. The iQ system runs Android 11 with 6 GB DDR memory and 32 GB storage.

Can a training centre in the Industrial Area run its own PC on this panel?

Yes, if an optional SMART PCM computing module is fitted in the rear OPS slot, which supports devices drawing up to 60 W. The front USB-C port also delivers 65 W power and carries 4K video, so a laptop can connect with one cable. Modules are sold as optional accessories, so confirm the module you need with SmartRooms Qatar.

Is 86 inches the right size for a lecture hall in Education City?

An 86-inch screen suits a mid-sized lecture or seminar room, where students at the back can still read slides and handwritten notes. Very large auditoriums may need a larger or multi-screen setup. Before quoting, share the room length, the distance to the farthest seat and the available wall space so the team can check the layout.

How do I connect a laptop and a video conferencing setup in a West Bay boardroom?

The front USB-C port supports 4K at 60 Hz through DisplayPort 1.2 and delivers 65 W, so a laptop can connect with one cable. The rear HDMI 2.1 inputs and two RJ45 ports add more connection options. Confirm your camera and microphone connectors with SmartRooms Qatar, as the manufacturer data does not list specific camera models.

Is the panel suitable for a hot room in Msheireb or a hotel meeting room with glass walls?

The operating range is 5 to 35°C at 5 to 80% humidity, non-condensing, and storage ranges from -20 to 60°C. Install the panel in an air-conditioned room away from direct sunlight through glass walls. Outdoor temperatures in Doha can exceed 45°C in summer, so keep the display inside a cooled space and ask the team to confirm room conditions before quoting.

How heavy is it and what wall preparation is needed?

The panel weighs 190 lb (86 kg) and needs a VESA M8 mount at 600 × 400 mm. A WM-SBID-200 wall mount is included. SmartRooms Qatar offers a free site survey across Qatar that checks wall structure, access and cable routes before installation. Leave clear space around the panel for ventilation, as the manufacturer advises.

What power does it need and how much does it draw?

The unit runs on 100 to 240 V AC at 50 to 60 Hz. Typical consumption at 86 inches is 161 W, and standby draw is 0.4 W. A country-specific power cable is included. Qatar's 240 V, 50 Hz supply falls within this range, but confirm the supplied plug matches the BS 1363 sockets in your building before installation.

What warranty covers the SBID-6286S-V3-PW?

The panel is covered by SMART Assure, which includes advanced hardware replacement and access to onsite support. Terms vary by region, so SmartRooms Qatar will confirm the exact terms and duration in your quotation. Remote management, where ordered, runs for the length of the included warranty.
