Specktron DSUDX86S2KPA · Price in Qatar

Name: Specktron UDX-S2 ProEdu 86-inch Interactive Display (DSUDX86S2KPA)
Brand: Specktron
SKU: specktron-dsudx86s2kpa
Availability: InStock

Overview

The Specktron DSUDX86S2KPA is an 86-inch 4K UHD interactive display from the UDX-S2 ProEdu series, built for classrooms and lecture halls. It pairs 50-point infrared touch and 400 nits of brightness with an octa-core processor, a 6 TOPS NPU and Google EDLA certification. Schools, colleges and training centres across Qatar can request a quote, with a free site survey before installation.

What the 86-inch UDX-S2 ProEdu panel is built to do

The Specktron DSUDX86S2KPA is the largest size in the UDX-S2 ProEdu series for education, with an 86-inch 4K UHD screen. It combines the display, the touch surface and an onboard computer in one unit, so teachers do not need a separate PC for everyday lessons. The Google EDLA certification means the platform has been certified against Google's education device requirements, which matters when a school plans its software for years rather than months.

The numbers that matter for a large classroom

Screen: 86-inch 4K UHD panel with 400 nits of brightness
Touch: 50-point infrared multi-touch with adaptive technology
Viewing angle: 178/178 degrees
Processing: Octa-core CPU with a 6 TOPS NPU for on-device AI tasks
Memory and storage: 8 GB RAM and 128 GB storage
Audio: Built-in 2 x 20W speakers

A brightness rating of 400 nits suits rooms with controlled lighting. If a room receives strong daylight through large windows, check the panel position during a site survey before placing it facing the glass. The 9H toughened, anti-fingerprint glass is designed for the frequent touch use a busy classroom produces.

Teaching tools: touch, NFC login and the AI whiteboard

Teachers can write and annotate directly over live video and convert handwriting into digital text. The built-in whiteboard is compatible with SparkyAI features for lesson generation, equation solving, translation and summaries. Password-less NFC login loads a user's profile, files and settings when they tap, so several teachers can share one panel without repeated setup. The platform also includes Bytello OS for classroom management.

Wireless sharing, ports and the optional Windows route

Up to nine devices can share their screens wirelessly, with two-way touch control and instant web access, so students can present from their own devices. BYOM support and a wireless dongle are listed for wireless screen sharing with touchback. The ports include three HDMI inputs, one HDMI output, a VGA port, four USB 3.0 ports, one USB 2.0 port, a 65W USB-C port, a 15W USB-C port, two USB-B touch connections, LAN in and out, and RS232 for control. The source lists optional Windows configurations with i5 or i7 processors, up to 16 GB RAM and a 512 GB SSD, and an OPS Windows Module as a compatible accessory. Confirm the exact configuration in your quotation.

Where this panel fits in Qatar

An 86-inch panel suits a lecture hall at a university in Education City, where students at the back need a readable image. It also suits a large classroom at a private school in Al Wakrah that is being fitted out for the new term, or a training centre in Msheireb that runs sessions where participants bring their own devices and share screens wirelessly to the panel. Schools running Arabic and English curricula side by side should confirm the language settings they need when requesting the quote.

Planning the installation before the panel arrives

An 86-inch display needs a wall or stand position with enough clearance, a nearby power point and a clean route for cabling. The source data does not list weight, dimensions or an operating temperature range, so request the full datasheet and confirm those figures before the site visit. Buildings without full air-conditioning should confirm the environment in advance, because heat and dust can affect any display in Qatar's summer. SmartRooms Qatar offers a free site survey, professional installation and delivery to all eight municipalities. Quotations are usually issued within one working day, and payment can be made by bank transfer, cheque or purchase order, which suits schools buying several units. The panel is covered by the manufacturer's warranty.

Request a quote for the DSUDX86S2KPA and we will confirm the accessories, such as stands, and the installation details for your room.

Highlights

86-inch 4K UHD display with 400 nits brightness
50-point infrared multi-touch with adaptive technology
Octa-core processor with a 6 TOPS NPU
8 GB RAM and 128 GB storage
Google EDLA-certified with NFC login
Wireless sharing for up to 9 devices

Classroom fit

At 86″ the farthest student should sit within about 6.4 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

14 specifications · Source: manufacturer · checked Oct 2026

Specifications14

Available Sizes: 65", 75", 86"
Resolution: 4K UHD
Brightness: 400 nits
Viewing Angle: 178/178
Touch Technology(IR): 50-Point Multi-Touch with Adaptive Technology
Processor: Octa-Core
RAM: 8 GB
Storage: 128 GB
Operating System: Android 14, Optional Windows (i5/i7 configurations with up to 16GB RAM + 512GB SSD)
Speakers: 2 x 20W
Glass: 9H Toughened Anti-Fingerprint Glass
Wireless Connectivity: BYOM Support, Wireless Screen Sharing with Touchback, Wireless Dongle
Updates: OTA (Over-the-Air)
Input/Output Ports: 3x HDMI In, 1x HDMI Out, 1x VGA, 1x Audio In, 1x Audio-Out, 4x USB 3.0, 1x USB 2.0, 1xUSB-C (65W), 1xUSB-C(15W), 2x USB-B Touch, 1x LAN in, 1xLAN out, 1x SPDIF, 1x RS232, 1x DIP-In, 1x TF-Card

Downloads

0 files from the manufacturer

No downloadable files are listed for this model yet. Ask us and we will send the datasheet.

Questions about DSUDX86S2KPA

Who is the Specktron DSUDX86S2KPA designed for?

It is designed for education spaces that need a large display at the front of the room, such as classrooms, lecture halls and seminar rooms. The 86-inch 4K UHD screen gives students at the back a readable image, while the touch surface lets teachers annotate lessons without a separate computer. Schools, colleges and training centres across Qatar can request a quote for this 86-inch model.

How is the 86-inch model different from the 65-inch and 75-inch versions?

The DSUDX86S2KPA is the largest size in the UDX-S2 ProEdu series, which is offered in 65-inch, 75-inch and 86-inch sizes. The data sheet covers the touch, processing and connectivity features for the whole series, so the main difference is screen size. Choose the 86-inch model for large rooms with greater viewing distances, and confirm the right size for your room with a site survey before ordering.

What touch technology does the panel use?

The panel uses infrared touch with 50-point multi-touch and adaptive technology, so several people can write or tap at the same time. Live annotation lets a teacher mark up video while it plays. The 9H toughened, anti-fingerprint glass protects the surface from daily classroom use. Touch performance depends on lighting, so the SmartRooms Qatar team can check glare in the room during the free site survey.

What does the 6 TOPS NPU do on this panel?

The octa-core processor includes a 6 TOPS neural processing unit for real-time AI processing on the panel itself. In a classroom it supports the AI-powered whiteboard features, including lesson generation, equation solving, translation and summaries. The unit also has 8 GB RAM and 128 GB storage for everyday applications. Confirm with your quotation which AI features your school needs and how they will be set up.

How many devices can connect wirelessly to the panel?

Up to nine devices can share their screens wirelessly, with screen mirroring, two-way touch control and instant web access. Wireless screen sharing with touchback is supported, and BYOM support is listed for connecting personal devices. A teacher can present from a laptop or tablet without cables, while students send their work from their own devices. The wireless dongle is listed as a compatible accessory.

Which ports are included on the DSUDX86S2KPA?

The ports include three HDMI inputs, one HDMI output, one VGA port, audio in and audio out, four USB 3.0 ports, one USB 2.0 port, a 65W USB-C port and a 15W USB-C port. There are also two USB-B touch connections, LAN in and LAN out, SPDIF, RS232, a DIP input and a TF-card slot. These ports allow older and newer classroom sources to connect to the same panel.

What does Google EDLA certification mean for a school?

Google EDLA certification means the platform has been certified against Google's education device requirements. The panel provides Play Store access and Google Workspace integration, so schools that use Google accounts can sign in and open their files directly. The source also describes enterprise-grade security. List the apps your school needs in your quotation request so the account setup can be planned in advance.

Can I add a Windows PC to the panel?

The source data lists optional Windows configurations, including i5 and i7 options with up to 16 GB RAM and a 512 GB SSD, and it lists an OPS Windows Module among compatible accessories. This allows a school to run Windows software alongside the Android-based platform. Confirm the right configuration in your quotation, because the base unit and the Windows option are specified separately.

Is this panel suitable for a lecture hall in Education City?

Yes for many lecture halls, provided the room is sized for an 86-inch screen. The 178/178 viewing angle helps students seated to the side see the content, and the built-in 2 x 20W speakers are part of the unit. If the hall receives strong daylight, check the 400 nits brightness during a site survey, because the position of the panel affects glare. A quotation can cover the wall or stand layout.

A private school in Al Wakrah is fitting out several classrooms. How should it order?

Send the list of rooms and their sizes to SmartRooms Qatar, and a quotation is usually issued within one working day. The school can pay by bank transfer, cheque or purchase order, and one LPO can cover several units. A free site survey checks wall strength, power points and viewing distance in each classroom before installation. The panel is covered by the manufacturer's warranty.

Can this panel be purchased through a government tender in Qatar?

SmartRooms Qatar can quote for government tenders, including those published on Monaqasat. Include the model code DSUDX86S2KPA and the quantity in the tender request so the quotation matches the specification. Payment can be arranged by purchase order. The core product specifications from the manufacturer can be supplied for the technical evaluation committee.

Can it be used in a hot, dusty or non-air-conditioned room?

The source data does not list an operating temperature range, so this cannot be confirmed from the specification alone. Summer temperatures in Qatar often exceed 45°C, and dust can enter rooms, so any hall or corridor without full air-conditioning should be checked before installation. Ask the SmartRooms Qatar team to confirm the environment during the site survey, and place the panel in an air-conditioned room where possible.
