ViewSonic Interactive Flat Panels Current

IFP6552-2F

ViewSonic ViewBoard IFP6552-2F 65-inch 4K Interactive Display

Screen size: 65"
Resolution: UHD 3840x2160
Touch: 40 points touch
Memory: 8GB

Priceon request

QuotationWithin 1 working day

DeliveryConfirmed with your quote, based on stock

PDFDownload datasheet

Overview

The ViewSonic IFP6552-2F is a 65-inch 4K interactive display for classrooms and meeting rooms in Qatar. It runs Android 13 with Google Play access under EDLA certification, bundles myViewBoard software, and offers three USB-C ports plus vCast casting from up to four devices. An 8-microphone array and front speakers suit hybrid lessons. Ask SmartRooms Qatar for a quote.

What the ViewBoard IFP6552-2F does in a room

The ViewSonic IFP6552-2F combines a 65-inch 4K UHD display, a touch surface and a built-in Android 13 computer in one unit. It replaces the mix of projector, separate PC and whiteboard that many rooms still rely on. The octa-core processor, 8GB of RAM and 64GB of storage run everyday classroom and meeting apps directly on the panel, while touch responds to up to 40 points with Windows and 20 points with Android.

The specifications that shape daily use

Picture: 3840 x 2160 resolution, 350 nits typical brightness, 4000:1 typical contrast and 1.07 billion colours.
Glare and wear: anti-glare coating and 7H surface hardness, useful in rooms with daylight.
Inputs: three HDMI, one DisplayPort, one VGA, one PC audio, one RS232 and an OPS module slot.
USB-C: the front port supplies 65W power delivery, the main rear port 100W, and a second rear port carries USB 3.0 data only.
Audio: an 8-microphone array for voice pickup, plus two 15W front speakers and a 15W subwoofer.
Compliance: EDLA certified, EPEAT Silver and Energy Star listed.

Where it fits across Qatar

A 65-inch panel suits smaller rooms where everyone can read the screen from their seat. Three typical settings:

Classroom in Al Wakrah: a private school fitting out several classrooms can standardise on the same panel, the same myViewBoard whiteboard and the same Google Play apps, so teachers move between rooms without relearning the screen.
Meeting room in West Bay: a laptop connects by one USB-C cable for picture and charging, while remote colleagues join from abroad and hear the room through the microphone array.
Training room in Education City: vCast lets up to four participants cast from their own devices at the same time, useful for group exercises.

What to plan before installation

Weight: 59 kg net and 68 kg gross, so a site survey should confirm the wall or bracket can carry the load.
Mounting: VESA 500 x 400 wall mount pattern; the box includes screws for the mount and camera plate.
Environment: operating range 0°C to 40°C and 20% to 80% RH non-condensing. Install in an air-conditioned room away from direct sun and dust, because Qatar summers can exceed 45°C.
Power: 100-240VAC input with a 3m cord; confirm the plug type for your Qatar sockets before ordering.
Wireless internet: the Wi-Fi module is an optional upgrade, so budget for it if the room needs wireless access.

Ordering from SmartRooms Qatar

Send the room size, number of units and any accessories such as a web camera, document camera or motorised trolley to the SmartRooms Qatar team, who will prepare a quotation, usually within one working day. Free site surveys, professional installation and delivery to all eight municipalities are available, and orders can be placed by LPO. Request a quote today to confirm the configuration for your room.

Highlights

65-inch 4K UHD panel at 3840 x 2160 resolution
EDLA certified with Android 13 and Google Play access
Three USB-C ports, one rated for 100W power delivery
vCast casting from four devices at the same time
8-microphone array with noise detection and cancellation
Operating range 0°C to 40°C, 20% to 80% humidity

Classroom fit

At 65″ the farthest student should sit within about 4.9 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

54 specifications · Source: manufacturer · checked Oct 2026

Display13

Panel Size: 65"
Panel Type: TFT LCD Module with DLED Backlight, VA
Display Area (mm): 1428.48(H) x 803.52 (V) (64.5” diagonal)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07B colors
Brightness: 350 nits (typ)
Contrast Ratio: 4000:1(Typ.) 5000:1(Min. with DCR enabled)
Response Time: ≤7ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 50,000 hrs (typ).
Surface Treatment: Hardness: 7H. Anti-glare coating
Orientation: Landscape

Platform3

Processor: Octa-Core CPU (A73*4 + A53*4)
RAM: 8GB
Storage: 64GB

Touch3

Type/ Tech: UFT (Ultra Fine Touch) Technology
Touch Resolution: 32767 x 32767
Touch Point: Windows: 40 points touch, Android: 20 points touch

INPUT6

HDMI: x3 ( Frontx1:HDMI2.0 with CEC ; Rearx2:HDMI2.1 with CEC/ARC & HDMI 2.0 with CEC)
RGB / VGA: x1
DisplayPort: x1
Audio: x1 (PC audio in)
RS232: x1
OPS: module slot x 1

OUTPUT3

HDMI: x1
Audio: x1 (Earphone out)
SPDIF: x1

LAN1

RJ45: x2

USB3

Type A: USB3.0 x 4 (Front x 2; Rear x 2 ) USB 2.0x1 (Rear)
Type B: USB 3.0 x3(Front x1; Rear x 2)
Type C: x3 (Front x1 with USB3.0, DP1.2, Ethernet 100M, PD 65W; Rear x1 with USB3.0, DP1.2, Ethernet 100M, PD 100W; Rear x1 with USB3.0 data only)

SPEAKERS1

Value: 15W x 2 front soundbar + 15W x 1 subwoofer

MICROPHONE1

Value: built-in 8-array microphone

Top Camera Plate1

Value: Yes

Embedded OS1

Value: Android 13

Bundle Software3

Basic Annotation Software: myViewBoard WhiteBoard for Android
Pro Annotation Software: myViewBoard WhiteBoard for Windows (embedded in VPC)
Wireless Presentation: myViewBoard Display, vCast, AirSync* *myViewBoard Display will be replaced by AirSync in Q1 2025.

Special Features3

All-in-one USB port: USB 3.0 “SmartPort USB” to all channels.
Simple LAN sharing between IFP and slot-in device: 10/100/1000M (USB Type-C 10/100, Android & PC 10/100/1000)
Light Sensor: Yes

Power2

Voltage: 100-240VAC +/- 10% Wide Range
Consumption: 91.41W (Energy Star) / Off:

ERGONOMICS1

Wall Mount (VESA® ): 500 x 400

OPERATING CONDITIONS2

Temperature (º C): 0°C to 40°C
Humidity: 20% ~ 80% RH non-condensing

DIMENSIONS (W x H x D)2

Physical (inch / mm): 1502.7 x 948.66 x 122.18 mm / 59.161 x 37.349 x 4.81 in
Packaging (inch / mm): 1618 x 1060 x 225 mm / 63.7 x 41.7 x 8.9 in

WEIGHT2

Net (lb / kg): 130.1 lb/59kg
Gross (lb / kg): 149.9lb/68kg

REGULATIONS1

Value: NRTL w/ CA,FCC-B w, DOE Energy Star,DOE EPEAT, CE EMC, LVD or CB, RoHS Green BOM & RoHS DoC, ErP, REACH SVHC List & DoC, EEL, WEEE

PACKAGE CONTENTS1

Value: 1. 3m power cord by ship area 2. Remote control with AAA battery (new VS remote control) 3. 3m touch USB cable 4. Touch pen x 2 (a set) 5. Quick Start Guide + Compliance statement 6. RS232 adapter 7. Clamp x 5 8. Camera Plate 9. Screw x 8 (camera 2+2, wall mount 4) 10. HDMI cable 3m 11. AAA Battery x 2 12. Compliance statement

Compatible Slot-in PC1

Value: VPC2-O series/VPC2-O-1B series/VPC12-WPO-15/16

Downloads

12 files from the manufacturer

PDF Datasheets IFP6552-2F_Datasheet.pdf 538 KB PDF Manuals & guides IFP52-2_QSG.pdf 1.3 MB PDF Manuals & guides IFP52-2_UG_ENG.pdf 24.3 MB URL Manuals & guides · Opens on manufacturer site IFP6552-2F User Guide (Online View) URL Manuals & guides · Opens on manufacturer site IFP6552-2F User Guide (ﺍﻟﻌﺭﺑﻳﺔ) URL Drawings & CAD · Opens on manufacturer site IFP6552-2F 3D drawing(stp) PDF Software & firmware ViewBoard_Network_Requirements_ENG.pdf 2.9 MB URL Software & firmware · Opens on manufacturer site IFP6552-2F_IFP6552-2ED_Firmware_Pack_20251022 URL Software & firmware · Opens on manufacturer site vCastSender for Linux URL Software & firmware · Opens on manufacturer site vCastSender for Windows PDF Other documents IFP6552-2F_CFR.pdf 946 KB PDF Other documents Silkscreen_IFP6552-2_20231004.pdf 1.2 MB

Questions about IFP6552-2F

Which kind of Qatar room suits a 65-inch panel like this one?

A 65-inch screen suits smaller rooms, such as a corporate meeting room in Msheireb or a classroom in Al Sadd, where everyone can read the display from their seat. The 4K resolution keeps small text and spreadsheets sharp at that distance, and the built-in microphones and speakers are designed for the same kind of room. For a large hall with many rows, compare a bigger screen size before ordering.

Does it run Android, and can we install apps and Google services?

Yes. The panel runs Android 13 on an octa-core processor with 8GB RAM and 64GB storage, and it is certified under the Android Enterprise Device License Agreement (EDLA). That gives access to the Google Play Store, so approved apps can be installed and arranged with widgets on the home screen. When a Windows PC is needed, it can be connected through the HDMI, DisplayPort or USB-C inputs.

How responsive is the touch surface, and what comes in the box?

Touch uses UFT (Ultra Fine Touch) technology with a 32767 x 32767 touch resolution, supporting 40 touch points on Windows and 20 on Android. Two touch pens are included, so two people can annotate at once. The box also contains a remote control with AAA batteries, a 3m touch USB cable, a 3m HDMI cable, a 3m power cord and a camera plate.

What is the easiest way to connect a laptop?

Use the rear USB-C port. It carries video through DisplayPort 1.2 along with USB 3.0 data, 100M Ethernet and up to 100W power delivery, so one cable can handle picture and charging for a compatible laptop. Other inputs include three HDMI ports, a DisplayPort, a VGA port and a PC audio input. The front USB-C port offers 65W power delivery for a quick connection.

Can several people in a Lusail meeting room share screens at the same time?

Yes. vCast is pre-installed and allows four devices to cast to the panel simultaneously from desktop and mobile devices. Split, extended and grouped screen modes let presenters arrange the content. Browser-based casting from compatible web browsers works without extra cables or app installs. Built-in Wi-Fi is not included; the Wi-Fi module is an optional upgrade, so confirm whether the room needs it.

How does the audio work when a teacher in Doha teaches students who join from home?

The built-in 8-microphone array uses noise detection and cancellation to pick up the teacher's voice and students speaking in the room. Two 15W front speakers and a 15W subwoofer carry sound for recorded videos and remote participants. Test the room acoustics before installation, since hard walls and glass make echo more likely. The array is designed for hybrid, remote and pre-recorded lessons.

We are a private school in Al Wakrah fitting out several classrooms. How do we order?

Send the number of classrooms and room sizes to SmartRooms Qatar and request a quote; the team usually responds within one working day. Because each 65-inch panel needs a mounting plan, a free site survey checks wall strength and sightlines before installation. For several units, the school can issue one LPO covering the full order, and payment by bank transfer, cheque or purchase order is accepted.

Will it work in a room without air conditioning or near a window in summer?

No. The operating temperature range is 0°C to 40°C with 20% to 80% relative humidity, non-condensing. Qatar summers can exceed 45°C, so the panel should sit in an air-conditioned room, away from direct sunlight and dust blowing in through open windows. Confirm the room's cooling and the panel position with the SmartRooms Qatar team before the site survey.

How heavy is it and what does wall mounting involve?

The panel weighs 59 kg net and 68 kg gross, and its physical size is 1502.7 x 948.66 x 122.18 mm. It uses a VESA 500 x 400 wall mount pattern, and the package includes screws for the wall mount and camera plate. Because of its weight, a site survey should confirm the wall or bracket can take the load before installation. SmartRooms Qatar offers free site surveys and professional installation.

Is the power supply suitable for Qatar, and how much energy does it use?

The power input accepts 100-240VAC with a wide range of plus or minus 10%, which covers the 240V supply used in Qatar. Typical consumption is 91.41W under Energy Star measurement, and standby draw is below 0.5W. A 3m power cord is supplied, but cords are provided per shipping region, so confirm the plug type for Qatar sockets with SmartRooms Qatar before ordering.

Can a government ministry buy this through a tender or purchase order?

Yes. SmartRooms Qatar supplies government entities against purchase orders and government tenders, including Monaqasat, and accepts payment by bank transfer, cheque or purchase order. A ministry meeting room in West Bay might need a single panel with a camera plate and a mounting plan, so send the room details, required accessories and tender reference with your request. The quotation usually arrives within one working day.
