ViewSonic Interactive Flat Panels Current

IFP8652

ViewSonic IFP8652 86-inch 4K Interactive Display

Screen size: 86"
Resolution: UHD 3840x2160
Touch: 33 points touch
Memory: 4GB / 8GB

Priceon request

QuotationWithin 1 working day

DeliveryConfirmed with your quote, based on stock

PDFDownload datasheet

Overview

The ViewSonic IFP8652 is an 86-inch 4K UHD interactive display for lecture halls, boardrooms and training rooms. One USB-C cable carries video, data, network and up to 60W of power to a connected laptop. It adds 33-point touch on Windows, an 8-microphone array and a 20W soundbar with subwoofer. Suited to spaces needing one screen for annotation and presenting.

What the ViewSonic IFP8652 is

The IFP8652 is an 86-inch interactive display with a 4K UHD (3840 x 2160) TFT LCD panel and DLED backlight. It is built for teaching and meeting spaces where one large screen has to present, annotate and take input from several sources. The panel is rated at 400 nits typical brightness and 1200:1 typical contrast, with a 178-degree viewing angle both horizontally and vertically. The surface is 9H hardness with anti-fingerprint and anti-glare coatings, and the backlight is rated at 50,000 hours typical life.

One cable for laptop, power and network

The USB-C port carries video, USB 3.0 data, Ethernet and up to 60W of power to a connected laptop, so a presenter can connect a single cable and start. The display also offers three HDMI inputs, a DisplayPort input, a VGA input, an audio input and an RS232 port for control. An HDMI output is available on demand, alongside an optical SPDIF output and an earphone output. The RJ45 LAN port supports 10/100/1000M networking. The box includes a 3-metre HDMI cable and a 1.5-metre USB-C cable.

Touch, writing and on-screen collaboration

Touch runs on Ultra Fine Touch technology, with 33 touch points on Windows and 20 on Android. Two touch pens are supplied and the display supports dual-pen use, so two people can write at the board. Palm awareness helps the screen ignore a writer's hand resting on the glass. Shortcut keys let a teacher disable touch quickly or freeze the image while a personal device is used. The system runs Android 11 on a quad-core ARM Cortex A73 processor, with two configurations: 4GB RAM and 32GB storage (IFP8652-1A), or 8GB RAM and 64GB storage (IFP8652-1B). The myViewBoard WhiteBoard app for Android is included, and the Windows annotation software runs on the compatible slot-in PCs listed in the specification (VPC12, VPC25/27-O and VPC25/27-O-B).

Sound, camera and central management

Two 20W speakers and a 20W subwoofer sit in the front soundbar. An 8-microphone array is built in, with a top camera plate for mounting a camera and a light sensor for the display. For IT teams, the browser-based myViewBoard Manager lets administrators update, schedule and broadcast to several displays from any location.

Where it fits in Qatar

Lecture hall in Education City: a lecturer annotates slides directly on the screen while the 8-microphone array picks up questions from students in the room.
Boardroom in West Bay: a company holding meetings in Arabic and English side by side connects a laptop with one cable and marks up shared documents during video calls.
Primary school in Al Wakrah fitting out new classrooms: several units are installed and managed from one console, so updates reach every room without visiting each one.

What to plan before installation

The panel weighs 71.0 kg net and 89.1 kg in packaging, and its physical size is 1966.4 x 1204.4 x 118.4 mm, so the wall structure and bracket need checking before fixing. SmartRooms Qatar offers a free site survey for this purpose. The operating range is 0 to 40 degrees C at 20% to 80% relative humidity, non-condensing, so install the display in an air-conditioned room, because Qatar summer temperatures can exceed 45 degrees C. It accepts 100-240VAC with a typical consumption of 187.9W. For government ministries and schools, a purchase order (LPO) or tender reference can be used with the quotation.

Request a quote from SmartRooms Qatar with your room size, wall type and number of units. Our team usually replies with a quotation within one working day.

Highlights

86-inch 4K UHD panel at 3840 x 2160 resolution
Single USB-C cable for video, data, network and 60W power
33-point touch on Windows with dual-pen support
Two 20W speakers and a 20W subwoofer
8-microphone array and top camera plate
Android 11 with browser-based myViewBoard remote management

Classroom fit

At 86″ the farthest student should sit within about 6.4 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

54 specifications · Source: manufacturer · checked Oct 2026

Display12

Panel Size: 86"
Panel Type: TFT LCD Module with DLED Backlight
Display Area (mm): 1895.04(H) x 1065.96(V)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07B colors (10bit)
Brightness: 400 nits (typ.)
Contrast Ratio: 1200:1 Typ. , 5000:1 Max.(DCR enable)
Response Time: 8ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 50,000 Hours (Typ.)
Surface Treatment: Hardness: 9H with Anti-Fingerprint coating & Anti-Glare coating

Platform3

Processor: ARM Cortex A73*4
RAM: 4GB (IFP8652-1A), 8GB (IFP8652-1B)
Storage: 32GB (IFP8652-1A), 64GB (IFP8652-1B)

Touch3

Type/ Tech: UFT (Ultra Fine Touch) Technology
Touch Resolution: 32767 x 32767
Touch Point: Windows: 33 points touch, Android: 20 points touch

INPUT7

HDMI: x2 (3840x2160@60Hz, HDCP2.2, CEC, Front x1, Side x 1), x1 (3840x2160@60Hz, HDCP2.2, CEC, ARC, Side x 1)
RGB / VGA: x1 (1920x1080 @60Hz)
DisplayPort: x1 (3840x2160 @60Hz)
Audio: x1 (PC audio in)
RS232: x1
OPS: module slot x 1
WiFi: module slot x 1

OUTPUT3

HDMI: x1 (on demand)
Audio: x1 (Earphone out)
SPDIF: x1 (optical)

LAN1

RJ45: x1

USB3

Type A: USB 2.0 x1(Side x1), USB 3.0 x4 (Front x2, Side x2, SmartPort™ USB)
Type B: x2, for touch
Type C: x1 (USB3.0, DP1.2 Alt Mode, Ethernet, PD 60W)

SPEAKERS1

Value: 20W x 2 + 20W x 1 subwoofer

MICROPHONE1

Value: built-in 8-array microphone

Top Camera Plate1

Value: Yes

Embedded OS1

Value: Android 11

Bundle Software3

Basic Annotation Software: myViewBoard WhiteBoard for Android
Pro Annotation Software: myViewBoard WhiteBoard for Windows (embedded in VPC)
Wireless Presentation: ViewBoard Cast & myViewBoard Display

Special Features3

All-in-one USB port: USB 3.0 x 4
Simple LAN sharing between IFP and slot-in device: 10/100/1000M for Android and PC
Light Sensor: Yes

Power2

Voltage: 100-240VAC +/- 10% Wide Range
Consumption: 187.9W (Typ.) < 0.5 W (""Off"")

ERGONOMICS1

Wall Mount (VESA® ): 800 x 600

OPERATING CONDITIONS2

Temperature (º C): 0°C to 40°C
Humidity: 20% ~ 80% RH Non-Condensing

DIMENSIONS (W x H x D)2

Physical (inch / mm): 1966.4 (W) x 1204.4 (H) x 118.4 (D) mm, 77.42 (W) x 47.42 (H) x 4.66 (D) inch
Packaging (inch / mm): 2140 (W) x 1340 (H) x 280 (D) mm, 84.25 (W) x 52.76 (H) x 11.02 (D) inch

WEIGHT2

Net (lb / kg): 156.53 lb / 71.0 kg
Gross (lb / kg): 196.43 lb / 89.1 kg

REGULATIONS1

Value: cTUVus, FCC, EPEAT, Mexico coc, Mexico Energy, RoHS, Energy Star 8, CEC, EMC/CE, CB, RoHS & DOC, REACH, WEEE, ErP. EEI, RCM, BIS, PSE, VCCI, CCC, CECP, BSMI

PACKAGE CONTENTS1

Value: 1. Power cable (3 meters) 2. Remote control 3. USB Type-C cable (1.5 meters) 4. USB Touch cable (3 meters, USB2.0) 5. Touch pen x 2 6. Quick Start Guide + Compliance statement 7. RS232 adapter 8. Clamp x 5 9. Camera Plate 10. Screw x 8 (camera 2+2, wall mount 4) 11. HDMI cable (3 meters) 12. Eraser 13. AAA Battery x 2

Compatible Slot-in PC1

Value: VPC12 & VPC25/27-O & VPC25/27-O-B series

Downloads

15 files from the manufacturer

Questions about IFP8652

What is the ViewSonic IFP8652 and who is it for?

The IFP8652 is an 86-inch interactive display with a 4K UHD panel, designed for classrooms, lecture halls and meeting rooms. It combines a large touch surface, built-in speakers and an 8-microphone array in one unit. Schools, universities and corporate boardrooms in Doha are typical buyers who want one screen for presenting, annotating and hosting remote participants.

How does the single USB-C connection work?

The USB-C port carries video, USB 3.0 data, Ethernet and up to 60W of power to a connected laptop, so one cable handles display, data, network and charging. Presenters keep using the software already on their own laptop. The power delivery also keeps the laptop battery charged during a long lesson or meeting.

Which touch and software options does it offer?

Touch uses Ultra Fine Touch technology with 33 touch points on Windows and 20 on Android. Two touch pens are supplied and dual-pen use is supported. Android 11 includes the myViewBoard WhiteBoard app. The Windows annotation software is listed as embedded in compatible slot-in PCs such as the VPC12 and VPC25/27-O series, so confirm the slot-in PC you need before ordering.

What is the difference between IFP8652-1A and IFP8652-1B?

The source data lists two configurations. The IFP8652-1A has 4GB RAM and 32GB storage, while the IFP8652-1B has 8GB RAM and 64GB storage. Both use the same quad-core ARM Cortex A73 processor and Android 11. Confirm the suffix you need before ordering, so the quotation matches the configuration chosen for your school or office.

Is an 86-inch panel right for a lecture hall in Education City?

An 86-inch panel suits a lecture hall or large seminar room where students sit several rows back. The 3840 x 2160 resolution keeps small text and diagrams sharp at a distance. Measure the wall width and the sightline from the back row before choosing, because the physical width of the unit is 1966.4 mm.

Can it be installed in a majlis, outdoor area or unconditioned space?

No. The IFP8652 operates between 0 degrees C and 40 degrees C at 20% to 80% relative humidity, non-condensing. Qatar summer temperatures can exceed 45 degrees C, so install it indoors in an air-conditioned room and keep it out of direct sunlight through windows. For any other space, confirm the environment with the SmartRooms Qatar team before ordering.

Does it need a site survey before wall mounting?

Yes, we recommend one. The unit weighs 71.0 kg net and 89.1 kg in packaging, so the wall and bracket must be checked before fixing. SmartRooms Qatar offers a free site survey that covers wall structure, cable routes and room conditions. The VESA wall-mount pattern in the data differs between sections, so we confirm the bracket fit during the survey.

Will it run on Qatar mains power?

The power specification is 100-240VAC with a wide-range input, so it accepts the 240 V supply used in Qatar. Typical consumption is 187.9W, and draw in the off state is under 0.5W. The supplied power cable is 3 metres long, but its plug type is not stated in the data, so confirm that it suits BS 1363 Type G sockets before installation.

Does it include Wi-Fi?

The IFP8652 has a Wi-Fi module slot, but the Wi-Fi module is an optional add-on and is not listed in the package contents. Once fitted, it gives the display internet access for videos and online resources, and it can act as a hotspot for the room. For wired networking, the RJ45 LAN port supports 10/100/1000M connections.

How do IT teams manage several units in a school?

The browser-based myViewBoard Manager lets IT staff and verified admin users update, schedule, broadcast and manage multiple displays simultaneously from any location. For a school fitting out several classrooms in Al Wakrah, this means one console instead of visiting each room. Guests can also cast to a display through myViewBoard Display without installing software.

Can a government body or school order through an LPO or tender?

Yes. SmartRooms Qatar supplies government ministries, public schools and other organisations against purchase orders (LPOs) and handles government tenders, including those through Monaqasat. Payment can be made by bank transfer, cheque or purchase order. Send the model name IFP8652, the configuration suffix and the quantity, and we will issue a quotation, usually within one working day.
