ViewSonic VB-WIFI-001 · Price in Qatar

Name: ViewSonic VB-WIFI-001 Wireless Module for ViewBoard, Wi-Fi 6 (802.11ax)
Brand: ViewSonic
SKU: viewsonic-vb-wifi-001
Availability: InStock

Overview

The ViewSonic VB-WIFI-001 is a wireless module that adds Wi-Fi 6 (802.11ax) connectivity to compatible ViewBoard and Wireless Presentation Display models. It runs on dual-band 2.4GHz and 5GHz, supports Bluetooth 2.1 to 5.2 BLE, and draws under 4.5W. Its rated operating range of 0°C to 40°C means the room must stay air-conditioned in Qatar summers. It suits boardrooms, classrooms and hotel meeting rooms. Confirm model compatibility before ordering, then request a quote from SmartRooms Qatar.

What the VB-WIFI-001 adds to a ViewBoard display

The ViewSonic VB-WIFI-001 is a wireless module built for ViewBoard interactive displays and compatible Wireless Presentation Display models. It brings Wi-Fi 6 (802.11ax) connectivity to the display, so people can share content without running a network cable to the panel. The module works across the 802.11 a/b/g/n/ac/ax standards on both the 2.4GHz and 5GHz bands. Because compatibility covers selected models only, confirm your exact display before you order.

Specifications that matter for planning

The module is rated at 5V DC and 0.9A, and its consumption is below 4.5W. Physical dimensions are 99 x 11 x 77 mm, and the unit weighs 30g net, or 80g in its packaging. Bluetooth support covers versions 2.1, 3.0, 4.0 and 5.2 BLE. The rated operating range is 0°C to 40°C, with humidity of 10% to 90% non-condensing. The module carries FCC, IC, CE and RCM markings.

Where it fits in Qatar

Three situations show how the module is used in practice. In a corporate boardroom in West Bay, executives in Doha and colleagues abroad join a session over the wireless network and present from their own laptops, which avoids the cable swap that often delays a meeting. In a private school in Al Wakrah fitting out new classrooms, teachers can share lesson material from tablets to the display, and dual-band operation gives the connection a second frequency to use when the classroom network is busy. In a hotel conference room in Lusail, the events team can prepare presentations between sessions without touching the panel.

Environment and planning checklist

Room temperature: the rated range is 0°C to 40°C. Summer temperatures in Qatar can exceed 45°C, so the room must stay air-conditioned and the cooling should be checked before installation.
Humidity: the module is rated for 10% to 90% non-condensing humidity, so avoid locations where condensation can form.
Compatibility: check that your ViewBoard or presentation display model is on the compatible list before ordering, and send the model number with your request.
Network: confirm that the access point covers the display location on the band you plan to use. SmartRooms Qatar offers free site surveys to check coverage before installation.
Power: agree with the installer how the 5V DC supply will reach the module in your display setup.

Request a quote

For a single room, or for a school or government fit-out with several displays, send SmartRooms Qatar the display models, the number of rooms and the target installation areas. Quotations are usually returned within one working day, and we accept purchase orders, LPOs and government tender paperwork including Monaqasat. Request a quote for the ViewSonic VB-WIFI-001 today and we will help confirm compatibility before you commit.

Highlights

Wi-Fi 6 (802.11ax) wireless connectivity for compatible displays
Dual-band support on 2.4GHz and 5GHz
Bluetooth support from 2.1 through to 5.2 BLE
Rated at 5V DC, 0.9A; consumption under 4.5W
Rated operating range of 0°C to 40°C
Marked FCC, IC, CE and RCM

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

11 specifications · Source: manufacturer · checked Oct 2026

Wifi-Standard1

Value: Wifi Standard: 802.11 a/b/g/n/ac/ax

BT1

Value: Bluetooth: Support 2.1/3.0/4.0/5.2 BLE

Power2

Requirements: 5V DC, 0.9A
Consumption: < 4.5W

Dimension2

Physical: 3.90x0.43x3.03 in / 99x11x77mm
Packaging: 3.54x0.63x6.18 in / 90x16x157mm

WEIGHT2

Net: 0.07lb / 30g
Gross: 0.18lb / 80g

OPERATING CONDITION2

Temperature: 32°F to 104°F (0°C to 40°C)
Humidity: 10% ~ 90% non-condensing

COMPLIANCE1

Value: FCC, FCC ID, IC ID, CE, RCM

Downloads

4 files from the manufacturer

PDF Datasheets VB-WIFI-001_Datasheet.pdf 1.4 MB PDF Manuals & guides VB-WIFI-001_QSG.pdf 2.8 MB PDF Manuals & guides VB-WIFI-001_QSG_ENG.pdf 1.3 MB PDF Certificates & compliance VS18758_CE_DoC.pdf 91 KB

Questions about VB-WIFI-001

What does the ViewSonic VB-WIFI-001 do?

The VB-WIFI-001 is a wireless module that gives compatible ViewBoard and Wireless Presentation Display models Wi-Fi 6 (802.11ax) connectivity on the 2.4GHz and 5GHz bands. It suits schools, government offices and corporate meeting rooms that want to share content to a screen without running network cabling to the panel. Its rated operating range is 0°C to 40°C, so it belongs in air-conditioned rooms.

Which displays is the VB-WIFI-001 compatible with?

ViewSonic lists compatibility with selected ViewBoard and Wireless Presentation Display models only, so the module is not a universal fit. Before buying, match your exact display model against the manufacturer's compatibility information. Include the model number in your quote request and the SmartRooms Qatar team will help check it before the quotation is finalised. Avoid ordering several units until each model is confirmed.

Does the module support Wi-Fi 6 and the 5GHz band?

Yes. The VB-WIFI-001 supports dual-frequency 2.4GHz and 5GHz operation and Wi-Fi 6 (802.11ax). Its listed Wi-Fi standards run from 802.11a through to 802.11ax. In a lecture hall in Education City with a busy campus network, having both bands lets the IT team test which band gives the steadiest connection before the room is handed over to staff.

What Bluetooth support does it have?

The module lists Bluetooth support from version 2.1 through 3.0 and 4.0 to 5.2 BLE. That range covers Bluetooth Low Energy as well as older Bluetooth devices. Confirm which devices in the room you plan to pair with the display, then test them on site before the installation day so that no time is lost at handover.

How much power does the module need?

The module is rated at 5V DC and 0.9A, and its consumption is less than 4.5W. For a school fitting out a row of classrooms, that figure is simple to add to the electrical schedule. The installer should still confirm how the 5V DC supply reaches the module in each display setup, so every classroom is planned the same way.

Can it run in a hot room in Qatar?

Its rated operating temperature is 0°C to 40°C, with humidity of 10% to 90% non-condensing. Outdoor temperatures in Qatar can exceed 45°C in summer, so the display room must stay air-conditioned through the working week, Sunday to Thursday. If the display sits in a lobby or in a room that gets direct sun through glass, ask SmartRooms Qatar to review the location before installation.

Is the module suitable for a ministry boardroom in Msheireb?

In a ministry boardroom in Msheireb, the module lets attendees connect to the display from their own devices without swapping cables, which helps meetings start on time. Its listed dimensions are 99 x 11 x 77 mm and it weighs 30g net. Because the display model decides compatibility, send the model and a room plan with your request so the team can check both before quoting.

Could a private school in Al Wakrah use it for new classrooms?

Yes, if the classroom display is a compatible ViewBoard or Wireless Presentation Display model. Teachers can share lesson material from their own devices, and dual-band support helps when many devices use the same network during a lesson. A school fitting out several classrooms should confirm each room's temperature control and network coverage, and can raise a purchase order (LPO) with the quotation request.

Is it suitable for a hotel conference room in Lusail?

It suits a hotel conference room where the events team changes presentations between sessions without touching the panel. Wireless sharing reduces cable runs in rooms that are reconfigured often. The hotel should confirm that the room stays within 0°C to 40°C and that the wireless network covers the room on the band in use. SmartRooms Qatar offers free site surveys to check coverage before the display is installed.

What are the physical dimensions and weight?

The module measures 99 x 11 x 77 mm and weighs 30g net. The packaging measures 90 x 16 x 157 mm and weighs 80g gross. If you are receiving several units, the packaging size matters more than the module itself, so set aside dry, secure storage for stock held before installation.

Which certifications does it carry?

The module is marked FCC, IC, CE and RCM, which are the regulatory markings listed for this model. The source data does not list a Qatar-specific approval. If your government tender requires a particular certificate, raise it with the SmartRooms Qatar team before you submit the bid, and include the tender reference with your quote request so the paperwork can be checked early.

Can we order through an LPO for several rooms?

Yes. SmartRooms Qatar accepts purchase orders (LPOs), and payment can be made by bank transfer, cheque or purchase order. We also supply government tenders, including those on Monaqasat. Send the number of rooms, the display models and the delivery location with your request. Quotations are usually issued within one working day, and lead times are estimates confirmed in the quotation.
