Barco NAN-110 Audio Node for TransForm N Video Walls

Name: Barco NAN-110 Audio Node for TransForm N Video Walls
Brand: Barco
SKU: barco-nan-110
Availability: InStock

Overview

The Barco NAN-110 is an audio node from the TransForm N series, built to support Barco video wall installations. It combines an Intel Core i5 processor, 8 GB RAM and a 128 GB industrial SSD running Linux, with two 1 Gb/s LAN ports and a 150W external power supply. Rated for 0 to 40°C, it suits control rooms, command centres and AV rooms in Doha and Education City that need dedicated audio processing in a cooled equipment space.

What the NAN-110 is within a Barco video wall

The Barco NAN-110 is an audio node from the TransForm N series. It is a dedicated computer appliance rather than a display, and it belongs in the equipment space that supports a Barco video wall. It runs Barco Audio Node Appliance Software on Linux, so audio handling sits in its own unit beside the wall.

Hardware and specifications that matter for planning

Inside the chassis are an Intel Core i5 processor, 8 GB of RAM and a 128 GB industrial SSD. Two 1 Gb/s LAN ports provide the network connections. Typical power draw is 83 W, with a maximum of 109 W, and heat output is 283 BTU/h. The unit weighs 2.2 kg and measures 60 x 190 x 190 mm, so it occupies little space in an equipment cabinet.

Typical 83 W power consumption, maximum 109 W
Heat dissipation of 283 BTU/h, which cooling calculations should include
MTBF rated at 47,500 hours
Maximum noise of 32 dBA measured at 1 m

Power, temperature and environment in Qatar

The external power supply accepts 90 to 264 VAC at 47 to 63 Hz, a range that covers Qatar's 240 V, 50 Hz mains. The rated operating range is 0 to 40°C, with humidity up to 80% non-condensing. Qatar summers can exceed 45°C, so the NAN-110 should not sit in a hot cupboard or an unconditioned room. A ventilated rack inside an air-conditioned comms room is the sensible choice.

Where it fits in Qatar

A control room at a government authority in Doha that runs a monitoring video wall can keep the NAN-110 in the adjacent comms room, with the wall networked over the site LAN. A university AV team in Education City fitting out a shared teaching hall can keep the node in its rack, away from students. In an executive suite in West Bay, the 32 dBA noise figure matters if the equipment room opens onto the meeting space.

What to plan before ordering

Choose the mains cable by article number. The EU, US, UK, China, C13/C14 and no-cable options each carry a separate part number, and the plug must suit BS 1363 sockets in Qatar. Barco lists a P110 VESA mount for one OPS-110 plus one PSU and a P110 rack mount for two OPS-110 units plus two PSUs, so check these against your layout. The packed unit weighs 4.5 kg, and SmartRooms Qatar delivers to all eight municipalities. Ask for a quotation that lists the exact article number, mounting kit and cable, and book a free site survey before the rack is built. Quotations usually follow within one working day.

Highlights

Intel Core i5 processor, 8 GB RAM, 128 GB industrial SSD
Linux with Barco Audio Node Appliance Software
Two 1 Gb/s LAN ports
External 150W PSU, 90 to 264 VAC, 47 to 63 Hz
Operating range 0 to 40°C, humidity up to 80% non-condensing
Maximum noise 32 dBA at 1 m, typical 83 W consumption

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

21 specifications · Source: manufacturer · checked Oct 2026

General specifications21

Processor: Intel(R) Core(TM) i5
Software: Barco Audio Node Appliance Software
Operating system: Linux
Memory: 8 GB RAM
Hard disk: 128 GB Industrial SSD
Network: 2 x 1 Gb/s LAN
Power supply: External PSU 150W / 90 – 264 VAC / 47 – 63 Hz
Power consumption: Typ. 83W | max. 109 W
Inrush current limiting: 174A @230V / 72.5A @115V
Heat dissipation: 283 BTU/h
Temperature range: 0° -40°C | 32° -104°F
Humidity: Max 80% (non-condensing)
MTBF: 47,500 h
Noise Level: Max. 32dbA (measured at 1m/32.8ft distance at 22°/72°F )
Regulation Compliance: CE, CB, UL, RCM, BIS, CU-EAC, CCC, KC, FCC Class A, CCC
Model: P110
Form factor: 60 x 190 x 190 mm | 2.36 x 7.48 x 7.48 in Packed: 230 x 260 x 308 mm | 9.06 x 10.24 x 12.13 in
Weight: 2.2 kg (4.5 kg packed)
Package content: 1x NAN-110 Audio Node 1x Power Supply 1x Mounting bracket set 1x Vertical stand 1x Region specific mains cable (option)
Article number: R9811001F NAN-110 Audio Node (EU Power Cable) R9811001B NAN-110 Audio Node (US Power Cable) R9811001G NAN-110 Audio Node (UK Power Cable) R9811001I NAN-110 Audio Node (CN Power Cable) R9811001X NAN-110 Audio Node (C13C14 Power Cable) R9811001 NAN-110 Audio Node (No Power Cable included)
Mounting: R9811098 P110 VESA Mount (for 1x OPS-110 + 1x PSU) R9811099 P110 Rack Mount (for 2x OPS-110 + 2x PSU)

Downloads

2 files from the manufacturer

PDF Datasheets NAN-110-en-Spec-sheet.pdf 89 KB URL Manuals & guides · Opens on manufacturer site Manuals, drivers and support

Questions about NAN-110

What is the Barco NAN-110 used for?

The NAN-110 is an audio node in Barco's TransForm N series, intended as part of a Barco video wall installation rather than a standalone display. It runs Barco Audio Node Appliance Software on Linux and sits in the equipment space that supports the wall. It suits control rooms and command centres in Doha that need dedicated audio processing next to the wall, away from the viewing area.

What processor, memory and storage does the NAN-110 have?

The NAN-110 uses an Intel Core i5 processor with 8 GB of RAM and a 128 GB industrial SSD. Its operating system is Linux. Barco lists these specifications for this model, so your IT team can check them against internal standards before approving a purchase order.

Does the NAN-110 include a power supply and mains cable?

The package includes an external 150W power supply. Mains cable depends on the article number you choose: Barco lists EU, US, UK, China, C13/C14 and no-cable versions, each with its own part number. Qatar uses BS 1363 sockets, so ask SmartRooms Qatar to confirm the correct cable before you place a purchase order.

Is the NAN-110 compatible with Qatar's 240 V, 50 Hz mains?

The power supply accepts 90 to 264 VAC at 47 to 63 Hz, a range that includes Qatar's 240 V, 50 Hz supply. Typical consumption is 83 W, rising to a maximum of 109 W, with inrush current of 174 A at 230 V. Choose the cable variant that matches the BS 1363 plug, and have a qualified electrician check the socket that will feed the rack.

Can it be installed in a comms room without cooling during Qatar summers?

No. Barco rates the NAN-110 for 0 to 40°C (32 to 104°F) with humidity up to 80% non-condensing. Qatar summers can exceed 45°C, so a hot cupboard or a room without air conditioning is unsuitable. Use a ventilated rack inside an air-conditioned room and include the 283 BTU/h heat output in your cooling calculation.

How many network ports does it have, and how should they be connected?

The NAN-110 has two 1 Gb/s LAN ports. Agree the port allocation, IP addressing and any network segment separation with your network team before the site survey. Bring the planned switch port and cable route to the free site survey so the rack location is confirmed early in the project.

Is it quiet enough for a boardroom in West Bay?

Barco lists a maximum noise level of 32 dBA, measured at 1 m, which is a low figure for equipment. Even so, the best location is a separate equipment room rather than the boardroom itself. If the room adjoins an executive meeting space, confirm the rack position during the free site survey before the wall and cabling are fixed.

Can the NAN-110 be wall-mounted or rack-mounted?

Barco lists two mounting kits for the P110 model: a VESA mount (R9811098) for one OPS-110 plus one PSU, and a rack mount (R9811099) for two OPS-110 units plus two PSUs. The unit measures 60 x 190 x 190 mm and weighs 2.2 kg. Send the room dimensions and mounting surface with your quote request so the bracket choice can be checked.

What comes in the box, and how heavy is it to move?

Each NAN-110 ships with the audio node, a power supply, a mounting bracket set and a vertical stand, with mains cable depending on the article number. The packed unit weighs 4.5 kg and measures 230 x 260 x 308 mm. Those dimensions matter when moving equipment through a school or office building in Al Sadd or the Industrial Area, where lift access and storage space may be limited.

Is this suited to a university in Education City building a shared teaching hall?

Yes, where the hall uses a Barco video wall. The NAN-110 can sit in a comms room next to the hall, keeping its audio hardware out of student areas. Plan the cable route and rack location with your IT team during a free site survey, and request a quotation that lists the exact article number, mounting kit and mains cable.

How do government bodies buy the NAN-110 through a tender?

SmartRooms Qatar supplies by quotation and accepts purchase orders (LPOs) and government tenders, including Monaqasat. Because the mains cable option changes the part number, the purchase order should cite the exact article number from the quotation. Quotations are usually issued within one working day, so you can align the request with your tender timeline.

Is the NAN-110 covered by warranty, and what is its reliability rating?

Products supplied by SmartRooms Qatar are covered by the manufacturer's warranty. The source data does not give a warranty period for this model, so request the warranty terms in writing with your quotation. Barco lists an MTBF of 47,500 hours for the NAN-110, a manufacturer reliability figure rather than a guarantee of service life.
