Barco SAS-050 Secure Appliance Server for CTRL

Name: Barco SAS-050 Secure Appliance Server for CTRL
Brand: Barco
SKU: barco-sas-050
Availability: InStock

Overview

The Barco SAS-050 is the service node for Barco CTRL, the networked visualization platform behind video walls and operator workstations. It manages system hardware, coordinates information shared between displays, and runs the platform's security features. Dual Gigabit Ethernet ports offer active failover, and it is designed for 24/7 operation from 0 to 40°C. Built for control rooms across Qatar. Request a quote from SmartRooms Qatar.

Role of the SAS-050 in a Barco CTRL system

The SAS-050 is the service node of the Barco CTRL platform. It sits at the centre of the networked visualization system, managing the hardware that makes up the installation and coordinating how information is shared between displays and operator workstations. In a control room with several screens showing different sources, this server keeps the wall and the workstations working from the same shared state.

It also runs the Barco CTRL software and manages the platform's cybersecurity features. Because the wall, the operator workstations and the security settings all depend on it, the SAS-050 belongs at the start of a project specification rather than being added later.

Connectivity, uptime and security details

Two 1 Gb/s Ethernet ports configured for active failover, so traffic can move to the second port if the first path is lost.
Four USB ports: two USB 3.0 and two USB 2.0, all Type A.
On-screen display (OSD) output is available, as listed in the output specification.
Designed for 24/7 operation, with a redundancy option listed in the product data.
Compliance listed includes CE, UL, FCC Class B, UKCA and TAA, among other marks.

Noise is rated at a maximum of 24 dBA measured at one metre and 25°C, which matters when the server sits near an operator position.

Where the SAS-050 fits in Qatar

Operations centres in the Industrial Area or Mesaieed, where teams watch plant or logistics activity across several screens, need one central server that keeps the wall and workstations in step around the clock. A government command room in Doha with restricted access and a formal procurement process is another fit, where the platform's security role and the listed TAA compliance are relevant to the approval file.

A university operations room in Education City, or a multi-screen control suite in Lusail with several operator stations, follows the same pattern: one service node, many displays and workstations, and a single point to manage.

Planning the room, power and environment

The SAS-050 measures 28 x 180 x 190 mm without its plastic cover and 33 x 180 x 190 mm with it, and weighs 1.03 kg. Typical power draw is 25 W and the maximum is 55 W, so plan cable routes and circuit capacity for the maximum. The unit is specified at 19 V DC and 3.42 A.

The operating temperature range is 0°C to 40°C (32°F to 104°F), with humidity up to 80% non-condensing. Qatar summers can exceed 45°C, so house the server in an air-conditioned control or equipment room, away from hot cabinets and direct sun. Confirm the room conditions during the free site survey.

Regional order codes differ by power cable, and one code is supplied without a power cable. Confirm the correct variant for Qatar's 240 V, 50 Hz mains before ordering.

Request a quote for the SAS-050

SmartRooms Qatar supplies the SAS-050 with delivery to all eight municipalities of Qatar, professional installation and payment by bank transfer, cheque or purchase order. The unit is covered by the manufacturer's warranty. Send your quantity, the number of displays and workstations, and any redundancy requirement, and the SmartRooms Qatar team will confirm the right variant and return a quotation, usually within one working day.

Highlights

Service node for Barco CTRL networked visualization systems
Two 1 Gb/s Ethernet ports with active failover
Designed for 24/7 operation
Operating range 0°C to 40°C (32°F to 104°F)
Compact 180 x 190 mm footprint, 1.03 kg
Power draw 25 W typical, 55 W maximum

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

13 specifications · Source: manufacturer · checked Oct 2026

General Specifications13

Network: 2 x 1Gb/s Ethernet -active failover
Output: OSD available
USB: 2x USB 3.0 (Type A) \r\n2x USB 2.0 (Type A)
Dimensions: 28 x 180 x 190 mm without plastic cover 33 x 180 x 190 mm with plastic cover
Power supply: 19 DCV, 3.42A
Weight: 1.03 kg
Power consumption: 25W typical operation, max. 55W
Heat dissipation: 85,48 BTU/h/m² (typ) / 187,67 BTU/h/m² (max)
Temperature range: 0° -40°C | 32° -104°F
Humidity: Max. 80% (noncondensing)
Noise Level: Max. 24dbA (measured at 1m/32.8ft distance at 25°C)
Compliance: CE, CB, UL, FCC Class B, BIS, KC, CU-EAC, CCC, DoC, RCM, BSMI, UKCA, TAA Regulatory Model Name: P50_X
Order Information: R985005B | Secure Appliance Server US R985005D | Secure Appliance Server IN R985005F | Secure Appliance Server EU R985005G | Secure Appliance Server UK R985005I | Secure Appliance Server CN R985005AU | Secure Appliance Server AU R985005BTW | Secure Appliance Server TW R985005 | Secure Appliance Server No Power Cable

Downloads

2 files from the manufacturer

PDF Datasheets SAS-050-en-Spec-sheet.pdf 361 KB URL Manuals & guides · Opens on manufacturer site Manuals, drivers and support

Questions about SAS-050

What is the Barco SAS-050 used for?

The SAS-050 is the service node for Barco CTRL, the networked visualization platform. It manages the system hardware, coordinates the information shared between displays and operator workstations, runs the CTRL software and handles the platform's cybersecurity features. It suits control rooms, operations centres and command rooms in Qatar where one central server must keep a multi-screen wall and its workstations working together.

Does the SAS-050 work with video walls from other manufacturers?

The SAS-050 is described as the service node for the Barco CTRL environment, so it is intended for Barco CTRL systems. Other video wall platforms are outside its source data, so we do not assume compatibility. If your project mixes platforms or upgrades an existing installation, send the system details with your quote request so the SmartRooms Qatar team can confirm what is supported before you order.

How does active failover work on the two Ethernet ports?

The SAS-050 has two 1 Gb/s Ethernet ports configured for active failover. If the first network path fails, traffic can move to the second port, which matters in a control room where screens and workstations depend on the server continuously. Your network team decides how the ports are cabled and segmented, and the site survey is the place to confirm the layout before installation.

Can the SAS-050 sit in a control room without air conditioning in summer?

No. The SAS-050 is rated for an operating temperature range of 0°C to 40°C (32°F to 104°F), with humidity up to 80% non-condensing. Qatar summers can exceed 45°C, so install it in an air-conditioned control or equipment room, away from hot cabinets and direct sun. The SmartRooms Qatar team can confirm the room conditions during the free site survey.

How noisy is the server at an operator desk?

The manufacturer data rates the SAS-050 at a maximum of 24 dBA, measured at one metre and 25°C. That figure is useful for operators seated near the server in a quiet control room. Actual noise depends on the room layout, the cabinet and how close the unit sits to people, so check placement during planning.

What power does the SAS-050 draw, and what should I plan for?

The SAS-050 draws 25 W typically and up to 55 W at maximum, and it is specified with a 19 V DC, 3.42 A power supply. Plan circuit capacity and any backup power around the 55 W maximum, and include the rest of the control room equipment on the same circuit. Confirm the power arrangement for Qatar's 240 V, 50 Hz mains before ordering.

Which SAS-050 order code should I choose for Qatar?

The SAS-050 is listed under several regional order codes, each tied to a power cable type, plus a version supplied without a power cable under code R985005. The manufacturer data does not list a Qatar-specific code, so SmartRooms Qatar will confirm the right variant against your mains supply and the cable standard your installer uses. State the quantity and any redundancy needs in your quote request.

What size is the SAS-050 and how much does it weigh?

The SAS-050 measures 28 x 180 x 190 mm without its plastic cover and 33 x 180 x 190 mm with it, and weighs 1.03 kg. Its compact footprint makes it easier to fit into a crowded equipment area. The manufacturer data does not describe a mounting method, so confirm fixing and space requirements with the SmartRooms Qatar team during your site survey.

We are setting up a command room at a hospital in Al Sadd. Is the SAS-050 suitable?

The SAS-050 suits a hospital command room where the video wall is part of a Barco CTRL system, since it is the service node for that platform. Its 24/7 design, dual Ethernet ports with active failover and its security role match round-the-clock monitoring. Send your network, power and room temperature requirements to your facilities and IT teams, and include them with your quote request.

Can a government ministry in Doha buy the SAS-050 through a tender or LPO?

Yes. SmartRooms Qatar supplies government ministries and public bodies through purchase orders (LPOs) and government tenders, including Monaqasat. Send the tender reference or LPO requirements with your quote request so the quotation matches your procurement process. Payment is accepted by bank transfer, cheque or purchase order.

Is the redundancy option included with the SAS-050?

The manufacturer data lists a redundancy option for the SAS-050, but it does not describe what that option contains or whether it is included with the base unit. Name the redundancy option in your quote request, along with the number of units required, so the quotation shows exactly what is supplied.

Is the SAS-050 covered by a warranty?

Yes, the SAS-050 is covered by the manufacturer's warranty. The manufacturer data used for this page does not state the warranty length or terms, so request a quote and the SmartRooms Qatar team will confirm the warranty that applies to your order. Installation and a site survey can be arranged at the same time.
