Dahua LPH65-MC470-C-S3 · Price in Qatar

Name: Dahua LPH65-MC470-C-S3 65-inch Smart Interactive Whiteboard
Brand: Dahua
SKU: dahua-lph65-mc470-c-s3
Availability: InStock

Overview

The Dahua LPH65-MC470-C-S3 is a 65-inch smart interactive whiteboard with a 3840 × 2160 display, a built-in Android 16.0 system, Wi-Fi 6 and 50-point infrared touch. It includes an 8-array microphone, a 52 MP camera and two 20 W speakers, so one unit can handle teaching, presentations and video calls. It suits classrooms and meeting rooms in Doha, Lusail and Education City. Request a quote from SmartRooms Qatar.

What the Dahua LPH65-MC470-C-S3 does

The Dahua LPH65-MC470-C-S3 is a 65-inch smart interactive whiteboard that pairs a large 4K panel with a built-in Android computing layer. The LCD runs at 3840 × 2160 with a DLED backlight, 400 cd/m² brightness and a static contrast ratio of 1500:1. Its 178-degree viewing angles keep content readable for students or colleagues seated well off-centre, and the 60 Hz refresh rate with a response time of 8 ms or less suits everyday presentation and video playback. The listed certifications are CE, CB and EDLA.

The panel runs Android 16.0 with 8 GB of RAM and 128 GB of storage, so staff can open apps and files on the screen itself rather than relying only on a connected laptop. An external module option runs Windows 11 or Android, which lets IT teams choose the environment that matches their software.

Touch, writing and room capture

Touch is infrared with a zero air gap attachment, rated for up to 50 touch points on both Android and Windows. The surface is 3 mm anti-dazzle tempered glass with a hardness of 9H or greater, which helps in rooms with strong overhead light. Writing works with a finger or the magnetic stylus, and two stylus pens are included in the box.

Camera: 52 MP with an 87-degree horizontal field of view and face detection.
Microphone: an 8-array system with echo cancellation, automatic gain control and intelligent noise filtering, picking up voices from 8 to 12 m.
Speakers: two 20 W front-end speakers covering 150 Hz to 20 kHz.

Connectivity for daily teaching and meetings

The front panel offers a Type-C port, two USB 3.0 ports, an HDMI IN and a touch port, so a presenter can connect a laptop or memory stick without reaching behind the screen. The rear adds an HDMI OUT, two HDMI IN ports, a DisplayPort IN, a Type-C IN, two RJ-45 ports and further USB 2.0 and USB 3.0 ports. Wireless options include Wi-Fi 6 (802.11a/b/g/n/ac/ax), Bluetooth 5.4 and NFC. An SD card slot accepts cards up to 512 GB, and an RS-232 port is listed for control integration.

Where it fits in Qatar

A private school in Al Wakrah fitting out a secondary classroom, where a 65-inch screen suits a room of moderate size and the microphone picks up the teacher from across the room.
A company meeting room in West Bay that connects Doha staff with colleagues abroad, using the camera, microphone and speakers for video calls.
A training centre in Education City running short courses, where trainers write on the glass with a finger or stylus and keep session files on the 128 GB internal storage.

What to plan before installation

At 38 kg net and 45.2 kg gross, the panel needs a solid wall and a clear mounting plan. The mounting holes are spaced 500 × 400 mm, and the unit can be installed on a wall mount or a mobile bracket. Overall dimensions are 1,485.4 mm × 115.7 mm × 942.2 mm, so measure the room, sightlines and door clearance before ordering. SmartRooms Qatar offers free site surveys to check wall condition and fixing points.

Power is rated at 100 to 240 VAC, 50/60 Hz, drawing 100 W in basic use and up to 300 W at maximum, with standby below 0.5 W. The operating range is 0 °C to +40 °C, which is well below Qatar summer conditions, so the panel should sit in an air-conditioned room. The IP20 rating means it is designed for indoor use. Confirm the plug type for your site before installation.

Quotations are usually issued within one working day. SmartRooms Qatar supplies and delivers to all eight municipalities of Qatar and accepts purchase orders and tender paperwork. Request a quote to confirm the mounting option and the quantity for each room.

Highlights

65-inch 3840 × 2160 DLED display with 400 cd/m² brightness
Built-in Android 16.0 with 8 GB RAM and 128 GB storage
Infrared touch with up to 50 points on Android and Windows
52 MP camera and 8-array microphone with 8–12 m pickup
Wi-Fi 6, Bluetooth 5.4, NFC and dual RJ-45 ports
Operating range 0 °C to +40 °C; wall mount or mobile bracket

Classroom fit

At 65″ the farthest student should sit within about 4.9 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

85 specifications · Source: manufacturer · checked Oct 2026

Built-in System6

Operating System: Android 16.0
CPU: Quad-core A53 + quad-core A72
CPU Frequency: Main frequency 2.2 GHz
GPU: Mali-G52 MC3
RAM: 8 GB
ROM: 128 GB

General20

Operating System of External Module: Windows 11; Android
Power Supply: 100–240 VAC, 50/60 Hz
Power Consumption: 100 W (basic), 300 W (max)
Standby Power Consumption: ≤0.5 W
Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity: 0%–93%, 101 kPa
Storage Humidity: 0%–93%, 101 kPa
Protection: IP20
Product Material: Metal casing
Glass: 3 mm anti-dazzle tempered glass
Casing Color (Frame/Rear): Black on the left and right, dark blue on the top and bottom
Product Dimensions: 1,485.4 mm × 115.7 mm × 942.2 mm (58.48" × 4.56" × 37.09")
Frame Size: Top frame: 40.9 mm (1.61"); Left and right frame: 17.5 mm (0.69"); Bottom frame: 65.3 mm (2.57")
Packaging Dimensions: 1,623.0 mm × 227.0 mm × 1,068.0 mm (63.90" × 8.94" × 42.05") (L × W × H)
Net Weight: 38 kg (83.78 lb)
Gross Weight: 45.2 kg (99.65 lb)
Holes Distance: 500 mm × 400 mm (19.69" × 15.75")
Installation: Wall mount or mobile bracket
Packing List: 1 × Smart Display 2 × Stylus Pen 1 × Wall Mount Bracket 1 × Global Laws and Regulations Manual 1 × Wireless Plug-in Module 1 × Power Cord 1 × Quick Start Guide 1 × Expansion Tube and Expansion Screw Set 1 × Remote Control

LCD Panel11

Screen Size: 65 inch
Backlight: DLED
Aspect Ratio: 16:9
Brightness: 400 cd/m²
Static Contrast Ratio: 1500:1
Resolution: 3840 (H) × 2160 (V)
Viewing Angle: 178° (H)/178° (V)
Lifespan: ≥30,000 hrs
Display Color: 90% NTSC
Response Time: ≤8 ms
Refresh Rate: 60 Hz

Camera7

Camera: 52 MP
Auto Control: Auto White Balance
Distortion: ≤8.6%
Max. Resolution: 3840 (H) × 2160 (V)
Storage: 512 MB
Field of View: Horizontal: 87°, vertical: 49°, diagonal: 99°
Face Detection: Yes

Device Ports17

Light Sensor: 1
Front Button: 8 buttons: Custom Volume - Volume + Curtain Touch lock Signal source Home Power supply
Front Ports: 1 × TYPE-C port 2 × USB 3.0 port 1 × HDMI IN port 1 × Touch port
Rear Port: 1 × HDMI OUT port 2 × HDMI IN ports 2 × Touch ports 1 × USB 2.0 port 2 × RJ-45 ports 1 × Type-C IN port 1 × DP IN port 2 × USB 3.0 port
SD Card Slot: 1 × SD card slot, up to 512 GB
Others: 1 × SPDIF OUT port 1 × RS-232 port 1 × LINE OUT port 1 × LINE IN port 1 × VGA AUDIO IN port 1 × VGA IN port 1 × Touch port
Wi-Fi: Yes
Wi-Fi Standard: 802.11b/g/n/a/ac/ax
Wi-Fi Frequency Range: 2400-2483.5 MHz，5150-5350 MHz，5470-5725 MHz，5725-5850 MHz
MAX Power Transmission (Wi-Fi): ≤20 dBm@2400-2483.5 MHz； ≤23 dBm@5150-5250 MHz； ≤20 dBm@5250-5350 MHz； ≤27 dBm@5470-5725 MHz； ≤14 dBm@5725-5850 MHz
Bluetooth: Yes
Bluetooth Standard: BR/EDR/BLE (Bluetooth mode), BT5.4
Bluetooth Frequency Range: 2400-2483.5 MHz
MAX Power Transmission (Bluetooth): ≤20 dBm@2400-2483.5 MHz；
RFID Modulation Method: ASK
RFID Frequency Range: 13.56 MHz
MAX Power Transmission (RFID): 13.56 MHz: 42 dBuA/m @10 m

Function3

IR Receiver: 1
NFC: 1 × NFC
Wireless Access Point: Wi-Fi 6, 2.4 GHz/5 GHz; supports 802.11a/b/g/n/ac/ax

Touchscreen11

Response Time: ≤1.67 ms
Touch Technology: Infrared
Attachment Method: Zero Air Gap
Touch Points: Android: 50 points Windows: 50 points
Touch Accuracy: ±0.5 mm (covers 90% of the area)
Valid Touch: 1.5 mm (0.06")
Writing Mode: Finger and stylus pen (magnetic)
Communication Mode: USB
Anti-light Interference: Anti-dazzle tempered glass
Surface Hardness: ≥9H
Touch Resolution: 32767 × 32767

Speaker3

Built-in Speaker: 2 mid-high frequency speakers
Power: 2.0 sound channel, front-end 2 × 20 W
Frequency: 150 Hz–20 kHz

Microphone6

Microphone: 8 arrays
Pick-up Distance: 8 m-12 m (26.25 ft–39.37 ft) pickup
AGC: Yes
Echo Cancellation: Yes
Polar Pattern: Omnidirectional
Intelligent Noise Filtering: Yes

Certification1

Certifications: CE, CB, EDLA

Downloads

6 files from the manufacturer

PDF Datasheets LPH65-MC470-C-S3_datasheet_20260708.pdf 2.9 MB PDF Manuals & guides Dahua Smart Interactive Whiteboard_Quick Start Guide_V1.0.0.pdf 3.8 MB PDF Manuals & guides LPH65-MC470-C-S3_INSTALLATION_METHOD_EN.pdf 43 KB PDF Drawings & CAD LPH65-MC470-C-S3_DIMENSIONS.pdf 535 KB PDF Drawings & CAD LPH65-MC470-C-S3_PORT.pdf 362 KB DOCX Other documents LPH65-MC470-C-S3_A&E_20260901215534.docx 39 KB

Questions about LPH65-MC470-C-S3

Who is the Dahua LPH65-MC470-C-S3 designed for?

It suits schools, training centres and offices that need one large display for teaching, presentations and video calls in the same room. The 65-inch 4K panel, built-in Android 16.0 system and 50-point infrared touch cover those tasks without a separate computer for everyday apps. A 65-inch screen suits a classroom or meeting room of moderate size rather than a large lecture hall, so measure the room before choosing.

Does it run its own operating system, and what is the Windows option?

Yes. The panel runs Android 16.0 on a quad-core A53 plus quad-core A72 processor, with 8 GB of RAM and 128 GB of storage. The external module listed in the data runs Windows 11 or Android, so IT teams can choose the environment that matches their software. Confirm the exact module configuration when you request a quote.

How many touch points does it support, and can I write with a pen?

The infrared touch screen supports 50 touch points on Android and 50 on Windows, with a zero air gap attachment and touch accuracy of ±0.5 mm across 90% of the area. Writing works with a finger or the magnetic stylus, and two stylus pens are included in the box. The surface hardness is rated 9H or greater.

Will it work with 240 V mains power in Qatar?

The power supply is rated 100 to 240 VAC at 50/60 Hz, so Qatar's 240 V, 50 Hz supply falls within its range. Basic consumption is 100 W and maximum consumption is 300 W, with standby below 0.5 W. The data does not specify the plug type, so confirm the power cord and socket arrangement with the SmartRooms Qatar team before installation.

Can I place it in a hot space, such as a lobby or a room with weak air conditioning?

The operating temperature range is 0 °C to +40 °C, with operating humidity from 0% to 93%, and the protection rating is IP20. Summer temperatures in Doha often exceed 45 °C, so place the panel in a conditioned room with reliable cooling rather than a sun-facing lobby or corridor. Check the room conditions during the site survey.

How heavy is it, and what does the wall need?

The net weight is 38 kg and the gross weight with packaging is 45.2 kg. The mounting holes are spaced 500 × 400 mm, and the package includes a wall mount bracket. The wall must be solid and able to carry that load. SmartRooms Qatar offers a free site survey to check wall condition and fixing points before installation in your building.

Is it suitable for a classroom in Al Wakrah or Lusail?

Yes, for a classroom or meeting room where the audience sits within a few metres of the screen. The 65-inch 16:9 panel at 3840 × 2160 keeps small text legible, and the 178-degree viewing angle helps students seated at the sides. A school fitting out several classrooms should check sightlines and wall space in each room before ordering.

Can it run video conferences with teams abroad?

The built-in camera is 52 MP with an 87-degree horizontal field of view and face detection. The microphone array picks up speakers from 8 to 12 m, and the two 20 W speakers cover 150 Hz to 20 kHz. Those components suit a Doha boardroom calling colleagues abroad. The data does not name specific conferencing platforms, so confirm the application you plan to use before installation.

Which ports will I need for laptops, video sources and networking?

The front has a Type-C port, two USB 3.0 ports, an HDMI IN and a touch port. The rear adds an HDMI OUT, two HDMI IN ports, a DP IN, a Type-C IN, two RJ-45 ports and further USB ports. Audio outputs include SPDIF OUT and LINE OUT, and legacy VGA IN and VGA AUDIO IN are also listed. The SD slot supports cards up to 512 GB.

Does it support wireless connections for sharing content?

Yes. The data lists Wi-Fi 6 supporting 802.11a/b/g/n/ac/ax on 2.4 GHz and 5 GHz, Bluetooth 5.4 and NFC. Wireless connections let staff share content without cables, but for stable video calls in a busy office a wired RJ-45 connection is still a sensible choice. Plan the network layout before the panel is installed.

Can it connect to room control systems?

The data lists an RS-232 port and an IR receiver, which are interfaces commonly used for control integration. It also has SPDIF OUT and LINE OUT for connecting external audio equipment. The data does not describe the command set, so confirm the control protocol and required interface with your integrator before ordering.

How do a school or government office order several units?

Quotations are usually issued within one working day. SmartRooms Qatar accepts purchase orders (LPOs) and government tenders, including Monaqasat, with payment by bank transfer, cheque or purchase order. Each unit's packing list includes a remote control, two stylus pens, a power cord and a wall mount bracket, so the quotation can list quantities per room. Send room sizes and unit counts when you request a quote.
