Name: Dahua LPH75-ST470-C-S3 75-inch Smart Interactive Whiteboard
Brand: Dahua
SKU: dahua-lph75-st470-c-s3
Availability: InStock

Overview

The Dahua LPH75-ST470-C-S3 is a 75-inch interactive display with a 4K (3840 × 2160) DLED panel, infrared touch supporting 50 points on Android and on Windows, and an Android 16.0 system with 8 GB RAM and 128 GB storage. Its built-in microphone array and two 20 W speakers suit classrooms and training rooms across Doha and Al Wakrah. Request a quote from SmartRooms Qatar.

What the LPH75-ST470-C-S3 is built around

The Dahua LPH75-ST470-C-S3 is a 75-inch display from the ST470-C Series, aimed at teaching and collaborative meetings. Its 16:9 DLED panel runs at 3840 × 2160 resolution with 400 cd/m² brightness, a 1500:1 static contrast ratio, 90% NTSC colour and a 60 Hz refresh rate. Viewing angles reach 178° both horizontally and vertically, and the panel is rated for at least 30,000 hours.

An Android 16.0 system powers the display, with a quad-core A53 and quad-core A72 processor at a 2.2 GHz main frequency, 8 GB of RAM and 128 GB of ROM. An external module supports Windows 11 or Android, so teachers and staff can run Windows software on the same screen when their lessons require it.

Touch, glass and sound for lessons and meetings

Infrared touch uses a zero air gap attachment behind 3 mm anti-dazzle tempered glass with surface hardness of 9H or more. The touchscreen registers 50 points on Android and 50 on Windows, with a valid touch of 1.5 mm and ±0.5 mm accuracy across 90% of the area. Writing works with a finger or the magnetic stylus, and two stylus pens are included.

Built-in audio combines two mid-high frequency speakers rated 2 × 20 W across 150 Hz to 20 kHz with an eight-array microphone that picks up voices from 0.5 m to 8 m. Automatic gain control, echo cancellation and intelligent noise filtering help in a standard classroom or meeting room, where it may remove the need for a separate sound set. Test larger halls before deciding.

Ports and wireless options to plan

Front: one TYPE-C port, two USB 3.0 ports, one HDMI IN, one touch port
Rear: HDMI OUT, two HDMI IN, DP IN, Type-C IN, two RJ-45 ports, two USB 3.0 and one USB 2.0
Other: SPDIF OUT, RS-232, line in and line out, VGA with VGA audio input, and an SD card slot up to 512 GB
Wireless: Wi-Fi 6 with access point mode, Bluetooth 5.4, NFC and 13.56 MHz RFID

Where it fits in Qatar

A private school in Al Wakrah fitting out new classrooms would use the 75-inch size on the front wall of a standard room. The 4K resolution keeps small text in both Arabic and English materials readable from the back row, and the front ports let a teacher connect a laptop without moving around the board.

A meeting room in West Bay used for project reviews and calls with teams abroad can use the rear HDMI and DP inputs for a laptop or conferencing system, with a wired RJ-45 connection for the network as an alternative to Wi-Fi 6.

A government office in Doha setting up a training room would order through a purchase order or tender and plan the wall position around daytime light, since brightness and glass finish matter in bright rooms.

What to plan before ordering

The panel weighs 48.6 kg net and 57.3 kg gross, measures 1,707.6 × 115.7 × 1,067.2 mm and uses a 600 × 400 mm mounting hole pattern. Two people should lift it, and a free site survey will confirm that the wall and the lift route can take it. The box includes a wall mount bracket; the data also lists a mobile bracket, so state your preferred mounting in your request.

The operating range is 0 °C to +40 °C with 0–93% humidity, and the IP20 rating means indoor use only. In Doha summer conditions, keep the panel out of direct sunlight and confirm that the room's air conditioning holds it within range. Power is 100–240 VAC, 50/60 Hz, with 120 W typical and 350 W maximum consumption, and standby no higher than 0.5 W. The manufacturer's warranty applies to the product.

Send your room dimensions, wall type and intended use, and request a quote. SmartRooms Qatar offers free site surveys, delivery to all eight municipalities of Qatar, professional installation and quotations usually within one working day.

Highlights

75-inch 4K (3840 × 2160) DLED panel, 16:9 aspect ratio
Infrared touch with 50 points on Android and Windows
Android 16.0 with 8 GB RAM and 128 GB ROM
8-array microphone with echo cancellation and noise filtering
Two 20 W front speakers, 150 Hz to 20 kHz
Wi-Fi 6, Bluetooth 5.4, NFC and RJ-45 network port

Classroom fit

At 75″ the farthest student should sit within about 5.6 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

78 specifications · Source: manufacturer · checked Oct 2026

Built-in System6

Operating System: Android 16.0
CPU: Quad-core A53 + quad-core A72
CPU Frequency: Main frequency 2.2 GHz
GPU: Mali-G52 MC3
RAM: 8 GB
ROM: 128 GB

General20

Operating System of External Module: Windows 11; Android
Power Supply: 100–240 VAC, 50/60 Hz
Power Consumption: 120 W (basic), 350 W (max)
Standby Power Consumption: ≤0.5 W
Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity: 0%–93%, 101 kPa
Storage Humidity: 0%–93%, 101 kPa
Protection: IP20
Product Material: Metal casing
Glass: 3 mm anti-dazzle tempered glass
Casing Color (Frame/Rear): Black on the left and right, dark blue on the top and bottom
Product Dimensions: 1,707.6 mm × 115.7 mm × 1,067.2 mm (67.23" × 4.56" × 42.02")
Frame Size: Top frame: 40.9 mm (1.61"); Left and right frame: 17.5 mm (0.69"); Bottom frame: 65.3 mm (2.57")
Packaging Dimensions: 1,875.0 mm × 227.0 mm × 1,177.0 mm (73.82" × 8.94" × 46.34") (L × W × H)
Net Weight: 48.6 kg (107.14 lb)
Gross Weight: 57.3 kg (126.32 lb)
Holes Distance: 600 mm × 400 mm (23.62" × 15.75")
Installation: Wall mount or mobile bracket
Packing List: 1 × Smart Display 2 × Stylus Pen 1 × Wall Mount Bracket 1 × Global Laws and Regulations Manual 1 × Wireless Plug-in Module 1 × Power Cord 1 × Quick Start Guide 1 × Expansion Tube and Expansion Screw Set 1 × Remote Control

LCD Panel11

Screen Size: 75 inch
Backlight: DLED
Aspect Ratio: 16:9
Brightness: 400 cd/m²
Static Contrast Ratio: 1500:1
Resolution: 3840 (H) × 2160 (V)
Viewing Angle: 178° (H)/178° (V)
Lifespan: ≥30,000 hrs
Display Color: 90% NTSC
Response Time: ≤8 ms
Refresh Rate: 60 Hz

Device Ports17

Light Sensor: 1
Front Button: 8 buttons: Custom Volume - Volume + Curtain Touch lock Signal source Home Power supply
Front Ports: 1 × TYPE-C port 2 × USB 3.0 port 1 × HDMI IN port 1 × Touch port
Rear Port: 1 × HDMI OUT port 2 × HDMI IN ports 2 × Touch ports 1 × USB 2.0 port 2 × RJ-45 ports 1 × Type-C IN port 1 × DP IN port 2 × USB 3.0 port
SD Card Slot: 1 × SD card slot, up to 512 GB
Others: 1 × SPDIF OUT port 1 × RS-232 port 1 × LINE OUT port 1 × LINE IN port 1 × VGA AUDIO IN port 1 × VGA IN port 1 × Touch port
Wi-Fi: Yes
Wi-Fi Standard: 802.11b/g/n/a/ac/ax
Wi-Fi Frequency Range: 2400-2483.5 MHz，5150-5350 MHz，5470-5725 MHz，5725-5850 MHz
MAX Power Transmission (Wi-Fi): ≤20 dBm@2400-2483.5 MHz； ≤23 dBm@5150-5250 MHz； ≤20 dBm@5250-5350 MHz； ≤27 dBm@5470-5725 MHz； ≤14 dBm@5725-5850 MHz
Bluetooth: Yes
Bluetooth Standard: BR/EDR/BLE (Bluetooth mode), BT5.4
Bluetooth Frequency Range: 2400-2483.5 MHz
MAX Power Transmission (Bluetooth): ≤20 dBm@2400-2483.5 MHz；
RFID Modulation Method: ASK
RFID Frequency Range: 13.56 MHz
MAX Power Transmission (RFID): 13.56 MHz: 42 dBuA/m @10 m

Function3

IR Receiver: 1
NFC: 1 × NFC
Wireless Access Point: Wi-Fi 6, 2.4 GHz/5 GHz; supports 802.11a/b/g/n/ac/ax

Touchscreen11

Response Time: ≤1.67 ms
Touch Technology: Infrared
Attachment Method: Zero Air Gap
Touch Points: Android: 50 points Windows: 50 points
Touch Accuracy: ±0.5 mm (covers 90% of the area)
Valid Touch: 1.5 mm (0.06")
Writing Mode: Finger and stylus pen (magnetic)
Communication Mode: USB
Anti-light Interference: Anti-dazzle tempered glass
Surface Hardness: ≥9H
Touch Resolution: 32767 × 32767

Speaker3

Built-in Speaker: 2 mid-high frequency speakers
Power: 2.0 sound channel, front-end 2 × 20 W
Frequency: 150 Hz–20 kHz

Microphone6

Microphone: 8 arrays
Pick-up Distance: 0.5 m-8 m (1.64 ft–26.25 ft) pickup
AGC: Yes
Echo Cancellation: Yes
Polar Pattern: Omnidirectional
Intelligent Noise Filtering: Yes

Certification1

Certifications: CE, CB, EDLA

Downloads

7 files from the manufacturer

PDF Datasheets LPH75-ST470-C-S3_datasheet_20260708.pdf 2.9 MB PDF Manuals & guides Dahua Smart Interactive Whiteboard_Quick Start Guide_V1.0.0.pdf 3.8 MB PDF Manuals & guides LPH75-ST470-C-S3_INSTALLATION_METHOD_EN.pdf 43 KB PDF Drawings & CAD LPH75-ST470-C-S3_DIMENSIONS.pdf 549 KB PDF Drawings & CAD LPH75-ST470-C-S3_PORT.pdf 344 KB 2607 Software & firmware · Opens on manufacturer site DHI_DeepHubClassicSeriesS3_MultiLang_V3.012.0000000.1.R.260722 DOCX Other documents LPH75-ST470-C-S3_A&E_20260901215535.docx 39 KB

Questions about LPH75-ST470-C-S3

Who is the LPH75-ST470-C-S3 best suited for?

It suits classrooms, training rooms and small meeting rooms where a 75-inch screen gives the right viewing size. A teacher in a Doha classroom can show 4K lesson material, write with the stylus and use the built-in microphone for class discussion. For a lecture hall with large audiences, a bigger display or a dedicated sound system is usually the better choice, and SmartRooms Qatar can advise on that.

Can it run Windows software as well as Android apps?

Yes. The built-in system runs Android 16.0 on a quad-core A53 and quad-core A72 processor at 2.2 GHz, with 8 GB RAM and 128 GB ROM. The external module supports Windows 11 or Android, and touch works with 50 points on each platform. Confirm the software your school or office needs before ordering so the correct operating system is configured for your use.

What are the display specifications?

The panel is a 75-inch 16:9 DLED display at 3840 × 2160 resolution, with 400 cd/m² brightness, a 1500:1 static contrast ratio and 90% NTSC colour. Refresh rate is 60 Hz, response time is 8 ms or less, and viewing angles are 178 degrees horizontally and vertically. The lifespan is rated at 30,000 hours or more, which suits daily teaching use.

Can it go in a Doha room with sun-facing windows?

Place it away from direct sunlight, because the operating range is 0 °C to +40 °C and outdoor temperatures in Doha can exceed 45 °C in summer. The IP20 rating means it is designed for indoor use only, with no water protection. Ask our team to review the room during a free site survey, and check that the air conditioning can hold the room within the rated range.

How heavy is it and can it be wall-mounted or moved?

The net weight is 48.6 kg and gross weight 57.3 kg, with dimensions of 1,707.6 × 115.7 × 1,067.2 mm. It mounts on a 600 × 400 mm hole pattern using the included wall mount bracket. The data also lists a mobile bracket as an installation option. Two people should handle the lift, and a site survey before mounting confirms the wall and access route suit the panel.

Is it suitable for a West Bay meeting room that calls teams abroad?

Yes. The rear panel includes DP IN, Type-C IN and two HDMI IN ports, so a laptop or conferencing system can connect in several ways. Two RJ-45 ports allow a wired network connection, and Wi-Fi 6 provides wireless access with access point mode. The 8-array microphone with echo cancellation and noise filtering supports calls with speakers at the table, though room acoustics still matter.

Which ports will we need for cameras, PCs and USB drives?

The front has one TYPE-C port, two USB 3.0 ports, one HDMI IN and one touch port for quick connections. The rear adds HDMI OUT, two HDMI IN, DP IN, Type-C IN, two USB 3.0, one USB 2.0 and two RJ-45 ports. An SD card slot supports up to 512 GB. Match your camera and laptop cable types against these ports before ordering.

Does it include Wi-Fi and Bluetooth?

Yes. It has Wi-Fi 6 supporting 802.11a/b/g/n/ac/ax on 2.4 GHz and 5 GHz, Bluetooth 5.4, NFC and 13.56 MHz RFID. The Wi-Fi function can also act as a wireless access point. If your network policy requires a cable connection, use the RJ-45 ports instead of wireless.

Is it a good fit for a school in Al Wakrah fitting out several classrooms?

Yes. The ST470-C Series belongs to the Education Series, and the product lists EDLA among its certifications. A school fitting out several classrooms can send one purchase order covering all units, and SmartRooms Qatar can quote each room with matching mounting and cabling. Delivery covers all eight municipalities, and lead times are confirmed in the quotation based on stock.

Can a government ministry in Doha buy it through a tender?

Yes. SmartRooms Qatar supplies government ministries and authorities through purchase orders and tenders, including Monaqasat. Payment can be made by bank transfer, cheque or purchase order. Send the tender specifications with your request, and the quotation will reflect the product details listed here. The manufacturer's warranty applies to the unit.

What comes in the box?

The box includes one smart display, two stylus pens, a wall mount bracket, a wireless plug-in module, a power cord, a remote control, a quick start guide, an expansion tube and screw set, and a manual on global laws and regulations. Check the contents against your purchase order on delivery so any missing item is caught early.

What power supply and certifications does it need?

It runs on 100–240 VAC, 50/60 Hz, which covers Qatar's 240 V, 50 Hz mains. Consumption is 120 W typical and 350 W maximum, with standby at 0.5 W or less. Listed certifications are CE, CB and EDLA. Check the supplied power cord's plug against the BS 1363 Type G sockets in your room before installation, and include any certificate requirements in your tender request.
