SP-PI7B82IS-ZW(without system)

What this OPS computer module does

The Dahua SP-PI7B82IS-ZW is an OPS computer module sold without an operating system installed. It plugs into a compatible interactive panel and provides the computing power that runs presentations, collaboration apps and room software directly on the display, so a meeting room does not need a separate PC on the table. It suits integrators and facilities teams who manage several panels and want one standard computing unit for each screen.

Processing, memory and storage for daily use

The module uses an Intel Tiger Lake-H i7-11390H processor running at 3.4 GHz, with 4 cores, 8 threads and 12 MB of Level 3 cache. Intel Iris Xe graphics handle the display output. Memory is 8 GB of DDR4 at 2400 MHz in one SO-DIMM slot, and storage is a 256 GB M.2 2280 drive that supports NVMe or SATA. Because memory is a single module, buyers who expect heavy multi-application workloads should discuss the configuration with the team before ordering.

Ports, wireless connectivity and power requirements

The module provides one HDMI 1.4 output with a maximum of 4K at 30 Hz, two USB 3.1 Type-A ports, one USB 2.0 Type-A port, one USB 3.1 Type-C port, and one RJ-45 network port rated 10/100/1000 Mbps. A combined line-out and microphone connector completes the audio options. An 80-pin JAE extension interface links the module to the panel. A M.2 2230 wireless module provides Wi-Fi and Bluetooth, and two antennas are included. The module draws 44.7 W in basic operation and up to 57.7 W at maximum, with 0.8 W in standby, from a DC input of 12 to 19 VDC.

Where it fits in Qatar

In a university lecture hall in Education City, the module can run recording, annotation and presentation software on the panel itself, keeping the lectern free of extra equipment. In a government boardroom in West Bay or Msheireb, meetings can start from the screen without staff carrying laptops and tangling cables. A private school in Al Wakrah fitting out several new classrooms can specify one module per panel across every room and issue a single LPO for the full order.

What to plan before you order

Confirm that the panel has a matching OPS slot and a power supply within the 12 to 19 VDC range. The manufacturer's data lists Windows 11 Pro under its operating system field, but the model is designated without system, so the software arrangement and licence should be set out in the quotation. The module measures 119 x 180 x 30 mm and weighs 0.75 kg net. Its operating range is -5 °C to +45 °C, so install it in a ventilated, air-conditioned space. SmartRooms Qatar offers a free site survey before installation. Request a quote to confirm configuration, quantity and delivery to any of Qatar's eight municipalities.
